2008 MERCEDES-BENZ C300 Owner's Manual

64 Safety and Security
Driving safety systems
When you switch off the ESP®

the ESP® does not stabilize the vehicle

the engine output is not limited, which
allows the drive wheels to spin and
thus cut into surfaces for better grip

the electronic traction system will still
apply the brakes to a spinning wheel

the ESP® continues to operate when
you are braking

you cannot activate the cruise control

the cruise control switches off if
currently activated1ESP
® off/on
With the engine running, press ESP®
switch1 until the ESP® warning
lampv in the instrument cluster
comes on.
The ESP
® is switched off.Switching on the ESP
®
Press ESP® switch1.
The ESP
® warning lampv in the in-
strument cluster goes out.
You are now again in normal driving
mode with the ESP
® switched on.
Warning!G
Switch on the ESP® immediately if the afore-
mentioned circumstances do not apply any-
more. Otherwise the ESP
® will not stabilize
the vehicle when it is starting to skid or a
wheel is spinning.
iWhen the ESP® is switched off and one or
more drive wheels are spinning, the ESP® warn-
ing lampv in the instrument cluster flashes.
However, the ESP
® will then not stabilize the ve-
hicle.
Warning!G
When the ESP® warning lampv is illumi-
nated continuously, the ESP® is switched off
or is not operational due to a malfunction.
Vehicle stability in standard driving maneu-
vers reduces.
Adapt your speed and driving to the prevail-
ing road conditions and to the non-operating
status of the ESP
®.
!Avoid spinning of a drive wheel for an ex-
tended period with the ESP® switched off. This
may cause serious damage to the drivetrain
which is not covered by the Mercedes-Benz Lim-
ited Warranty.

65 Safety and Security
Driving safety systems
Four wheel electronic traction system
(4MATIC) with the ESP®
Models with all-wheel-drive only.
The 4MATIC improves vehicle’s ability to
use available traction, e.g. during winter
operation in mountains under snowy
conditions, by applying power to all four
wheels.
Warning!G
If you see the ESP® warning lampv
flashing in the instrument cluster, proceed
as follows:

While driving off, apply as little throttle
as possible

While driving, ease up on the accelera-
tor

Adapt your speed and driving style to
the prevailing road conditions
Failure to observe these guidelines could
cause the vehicle to skid.
The ESP
® cannot prevent accidents result-
ing from excessive speed.
!Do not tow with one axle raised.
Otherwise the transfer case can be damaged,
which is not covered by the Mercedes-Benz
Limited Warranty.
!Performance testing must only be conduct-
ed on a two-axle dynamometer.
Otherwise the transfer case can be damaged,
which is not covered by the Mercedes-Benz
Limited Warranty.
!Because the ESP® operates automatically,
the engine must be shut off (SmartKey in starter
switch position0 or1 or KEYLESS-GO (Canada
only) start/stop button* in position0 or1) when
the parking brake is being tested on a brake test
dynamometer.
Active braking action through the ESP
® may
otherwise seriously damage the front or rear axle
brake system.
Operational tests with the engine running can
only be conducted on a two-axle dynamometer.
iAt highly demanding operating conditions,
the electronic traction system may temporarily
switch off to prevent overheating of the drive
wheel brakes. The message
Currently Un-
available See Operator’s Manual
will
then appear in the multifunction display while
the ESP
® warning lampv is flashing. The
ESP® is still functioning normally.

66 Safety and Security
Anti-theft systems
Immobilizer
The immobilizer prevents unauthorized
persons from starting your vehicle.
When leaving the vehicle, always take the
SmartKey or SmartKey with KEYLESS-GO*
(Canada only) with you and lock the
vehicle. The engine can be started by
anyone with a valid SmartKey or SmartKey
with KEYLESS-GO* (Canada only) that is
left inside the vehicle.
Activating
With the SmartKey: Remove the
SmartKey from the starter switch.
With the KEYLESS-GO* (Canada
only): Turn off the engine and open the
driver’s door.
Deactivating
Switch on the ignition.
Anti-theft alarm system
Once the alarm system has been armed, a
visual and audible alarm is triggered when
someone opens:

a door

the trunk

the hood
The alarm will stay on even if the activating
element (a door, for example) is immedi-
ately closed.
The alarm system will also be triggered
when

the vehicle is opened with the
mechanical key.

a door is opened from the inside.

the trunk is opened with the
emergency release button.
To cancel the alarm after it has been trig-
gered, see “Canceling the alarm”
(
page 67).
1Indicator lamp
iStarting the engine will also deactivate the
immobilizer.
In case the engine cannot be started (yet the
vehicle’s battery is charged), the system is not
operational. Contact an authorized
Mercedes-Benz Center or call
1-800-FOR-MERCedes (in the USA), or
1-800-387-0100 (in Canada).
iIf the alarm stays on for more than
30 seconds, a call to the Response Center is
initiated automatically by the Tele Aid* system
(
page 295) provided Tele Aid* service was
subscribed to and properly activated, and that
necessary mobile phone, power supply and GPS
coverage are available.

67 Safety and Security
Anti-theft systems
Arming: Lock the vehicle with the
SmartKey or KEYLESS-GO* (Canada
only).
The turn signal lamps flash three times,
and an acoustic signal sounds three
times, to indicate that the alarm sys-
tem is armed.
Indicator lamp1 begins to flash after
approximately 15 seconds after arming
the alarm system.
Disarming: Unlock your vehicle with
the SmartKey or KEYLESS-GO*
(Canada only).
The turn signal lamps flash once, and
an acoustic signal sounds once, to
indicate that the alarm system is
disarmed.
Canceling the alarm
To cancel the alarm, do one of the
following:
Insert the SmartKey or SmartKey with
KEYLESS-GO* (Canada only) in the
starter switch.
or
Press the Œ or ‹ button on the
SmartKey or SmartKey with
KEYLESS-GO* (Canada only).
In vehicles with KEYLESS-GO* (Canada
only):
Grasp an outside door handle.
The SmartKey with KEYLESS-GO
(Canada only) must be within 3 ft (1 m)
of the vehicle.
or
Press the KEYLESS-GO (Canada only)
start/stop button (
page 84).
The SmartKey with KEYLESS-GO
(Canada only) must be inside the vehi-
cle.
iIf the turn signal lamps do not flash three
times, and the acoustic signal does not sound
three times, one of the following elements may
not be properly closed:

a door

the trunk
the alarm system is armed.
With a door open, close the door and lock the ve-
hicle again. The turn signal lamps flash three
times, and an acoustic signal sounds three
times, to indicate that the alarm system is armed
and the vehicle is locked. If you open the un-
locked door again the alarm system will be trig-
gered.With the trunk open, close the trunk lid. The ve-
hicle will lock and the turn signal lamps flash
three times, and an acoustic signal sounds three
times, to indicate that the alarm system is armed
and the vehicle is locked.
iThe vehicle will lock and the alarm system
will rearm automatically after approximately 40
seconds if neither a door nor the trunk lid was
opened.

68

69 Controls in detail
Locking and unlocking
Starter switch positions
Seats
Steering wheel
Mirrors
Memory function* (Canada only)
Fastening the seat belts
Lighting
Windshield wipers
Power windows
Driving and parking
Manual transmission
Automatic transmission*Instrument cluster
Control system
Audio system
Driving systems
Air vents
Dual-zone automatic climate con-
trol
3-zone automatic climate control*
(Canada only)
Trunk
Power tilt/sliding sunroof
Panorama roof with power
tilt/sliding panel*
Loading and storing
Useful features

70 Controls in detail
Locking and unlocking
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks,
when set to factory settings (
page 71):

the doors

the trunk

the fuel filler flap
SmartKey with remote control
1‹ Lock button
2ŠOpening button for trunk
(
page 269)
3Mechanical key locking tab
4ŒUnlock button
5Battery check lamp
6ÂPanic button (
page 58)
!To prevent possible malfunction, avoid ex-
posing the SmartKey to high levels of electro-
magnetic radiation.
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious person-
al injury.
Warning!G
To prevent possible personal injury, always
keep hands and fingers away from the door
or trunk lid opening when closing a door or
the trunk. Be especially careful when small
children are around.
Before closing doors, make sure there is no
possibility of someone getting caught in a
door during closing.

71 Controls in detail
Locking and unlocking
Factory setting
Global unlocking: Press buttonŒ.

All turn signal lamps flash once.

An acoustic signal sounds once.

The locking knobs in the doors
move up.

The anti-theft alarm system is dis-
armed.

The locator lighting will also come
on if it is dark and the feature is ac-
tivated in the control system
(
page 172).
iUSA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iCanada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iYou can also open and close the door win-
dows and tilt/sliding sunroof, or the panorama
roof with power tilt/ sliding panel* using the
SmartKey (
page 123).
!If you cannot lock or unlock the vehicle with
the SmartKey, then either the batteries in the
SmartKey are discharged, the SmartKey is mal-
functioning or the vehicle batteries are drained.

Check the batteries in the SmartKey and re-
place them if necessary (
page 428).

Use the mechanical key to unlock the driv-
er’s door (
page 424) and trunk
(
page 425).

Use the mechanical key to lock and trunk
(
page 272).

Have the vehicle batteries and their connec-
tions checked (
page 446).
If the SmartKey is malfunctioning, contact
Roadside Assistance or an authorized
Mercedes-Benz Center.
iYour vehicle is equipped with an acoustic
lock and unlock confirmation signal feature. An
acoustic signal will sound when the vehicle is
locked or unlocked using the SmartKey.
If you wish to activate or deactivate the feature,
or adjust its signal volume, contact an authorized
Mercedes-Benz Center.
