Contents
Preparation
nBefore Use
Accessories ........................................................................\
................ 2
Laser products: ........................................................................\
.......... 2
Contents ........................................................................\
..................... 4
Safety Information ........................................................................\
...... 6
Introduction ........................................................................\
................ 8
(Product Use Safety), (Navigation System), (Beep sound and voice guidance restrictions while using Bluetooth Hands-Free
(Mazda CX-9 only)), (Screens), (LCD (Liquid crystal display))
Names and Functions ........................................................................\
9
Immediate use
nGetting startedlActivation........................................................................\
............... 12(Removing the Map Disc), (On-screen Buttons)
l
Menu ........................................................................\
..................... 14lSet Clock ........................................................................\
............... 15lNavigation Set Up ........................................................................\
. 16(User Setting), (Quick POI Selection), (Language), (Map Configuration),
(Calibration), (Restore System Defaults)
l
Screen Names and Functions....................................................... 25(Screens Before Setting Route), (Screens During Route Guidance),
(Screen adjustments, beep alert and other settings)
l
Screen change ........................................................................\
...... 29(Changing the Map Orientation/Scale)
n
RoutinglDestination Entry and Route Search............................................. 30(Change (Change Search Area)), (Address), (Point of interest),
(Emergency), (Memory Point), (Home), (Preset Destination),
(Previous Destination), (Intersection), (Freeway On/Off Ramp),
(Coordinates), (Select from map)
l
Quick POI ........................................................................\
.............. 38(Displaying POI(s) on a Map), (Local Search), (Deleting POI Markers),
(Showing POI Data)
l
Character Entry ........................................................................\
..... 39(Street name, city name, and other input),
(House phone number, and other input)
l
Direct Destination Input................................................................. 40(Direct Destination Input), (Selecting Route)
l
POI Icons on Maps / Delete Destination ....................................... 41(POI (Point of Interest) Icons), (Delete destination)
l
Route Options ........................................................................\
....... 42(Route Preferences), (Modification of Destination or Way Point Positions),
(Deletion of Destination or Way Points), (Detour), (Turn List),
(Display Preview), (Route Preview)
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

5
Before Use
Ifnecessary
Rear View
Monitor
Advanced use
nAddress BooklAddress Book ........................................................................\
........ 46(Memory Point Storage), (Memory Point Confirmation and Modification),
(Preset Destinations or Home Storage), (Memory Point Deletion),
(All Memory Point Deletion), (Displays Icons at Memory Points),
(Avoid Area Storage), (Avoid Area Confirmation and Modification),
(Avoid Area Deletion), (All Avoid Area Deletion),
(Category Name Modification),(Previous Destination Deletion),
(All Preset Destination Deletion)
n
Voice RecognitionlVoice Recognition ........................................................................\
.. 50(Voice Recognition Structure), (Language Select), (Basic Usage Pattern),
(Cancel Voice Recognition), (Voice Recognition Command)
n
Volume AdjustmentlVolume Adjustment........................................................................\
52
If necessary
nIf necessarylPrecautions/System Performance ................................................. 53(Voice Guidance), (GPS), (Map Matching), (Positioning Accuracy),
(Route Guide), (Route Search)
l
Troubleshooting ........................................................................\
..... 57(Verification First), (Error Messages)
l
Maintenance ........................................................................\
.......... 60(Care of the Product), (Handling and Care of Map Discs)
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

8
Before Use
Navigation
Set Up
RDM-TMCIf
necessary
Rear View
Monitor
Introduction
nExtremely low or high temperatures may interfere with normal operationThe inside of the vehicle can become very hot or cold when it is parked for extended
periods in direct sunlight or in cold places with the engine turned off. The navigation system
may not operate normally under such circumstances. Turn off the navigation system until
the inside of the vehicle has cooled down or warmed up. If the system does not operate
thereafter, consult an authorized dealer, we recommend an Authorized Mazda Dealer.
This navigation system utilizes GPS* satellite signals, a speed sensor and gyrosensor to track
and display your vehicle’s current position, and to guide you from your starting point to your
destination along a calculated route.
* : GPS (Global Positioning System) is a position detecting system utilizing the signals from GPS satellites
deployed by the U.S. Defense Department.
The beep sound and voice guidance related to the navigation system operation are not heard
while a Bluetooth Hands-Free is being used.
Screens displayed in this manual may differ from those on the actual display.
Direct sunlight or other outside light sources makes it difficult to view the images on the
display. For moonroof-equipped vehicles, close the sunshade to better view the display.
Product Use Safety
Navigation System
Beep sound and voice guidance restrictions while using Bluetooth Hands-Free (Mazda CX-9 only)
Screens
LCD (Liquid crystal display)
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

9
Before Use
Ifnecessary
Rear View
Monitor
Names and Functions
The navigation system can be operated by pressing a button on the panel (panel button) or
selecting a button displayed on the screen (on-screen button).
1
2
3
4
10
11
6
5
7
8
9
13
12
Panel button
Mazda CX-9
On-screen buttonPanel button
1234
6
5
7
8
9
10
11
12
13
Panel button
Mazda CX-7
On-screen button Panel button
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

10
Before Use
Navigation
Set Up
RDM-TMCIf
necessary
Rear View
Monitor
1. FM/AM button:
FM/AM broadcast reception. Each time the button is pressed,
the reception mode switches through three reception modes:
FM 1 FM 2 AM.
2. SAT button: SIRIUS digital satellite radio reception.
3. CD button: CD playback.
4. MEDIA button: Image and Sound playback is possible using a portable video
player connected to an external input terminal.
*1
Sound playback is possible using an audio player connected to
an external input terminal.*1
AUX1: External sound
AUX2: External image
5. LOAD/EJECT button: CD loading and ejection. If the display is left in the lowered position for a certain period
of time, a beep sound is heard and the display closes
automatically.
6. NAVI button
*2 : Display of the navigation screen and the vehicle's present
location.
7. MENU button
*2 : Menu screen display (various settings).
8. RTN button
*2 : Button used to return to the previous screen.
9. DISP button: Screen brightness/contrast mode selection and adjustment
display.
10.POWER/VOLUME button: The volume can be adjusted by turning the dial. Turn the audio unit off by pressing the dial.
11.TUNE/SEEK button: Performs tuning (short press) and searching (long press) in FM/AM mode. Performs track skip (short press) and fast-
forward/reverse (long press) in CD mode.
12.SCAN button: Performs scanning operation in FM/AM and CD modes.
13.AUDIO button: Audio unit-related operation screen display (preset display of
FM and AM).
The on-screen touch button "SOUND" is constantly displayed
at the bottom of the audio unit-related screen for displaying the
sound quality adjustment screen when selected.
*1 : The external input terminal is not equipped on your vehicle because it is not standard equipment.
*2 : For navigation unit operation
Note
lIf there is no response after selecting the on-screen button, remove your finger from the
screen and select it again.
l On-screen buttons that cannot be operated are not illuminated.
Select the on-screen button lightly with your finger.
Selecting the on-screen buttons using objects that have a hard or sharp end such
as a ball point pen or mechanical pencil could cause a malfunction.
Caution
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

12
RoutingAddress
Book
Getting started
Activation
Insert the map disc into the unit to start the Mobile Navigation System.
Note
l
The map disc cannot be inserted or ejected while the ignition switch is in the OFF position.
l Remember that the battery can run down if the ignition switch is kept in the ACC or ON
position for a long time while the engine not running.
nMap Disc
l Refer to “Handling and Care of Map Discs” to know how to handle a map
disc ( page 60).
1
Remove the cover.
(Mazda CX-9 only)Note
lThe main unit is located on the right side of the
cargo sub-compartment under the trunk board.
(Mazda CX-9)
The main unit is located under the front passenger
seat. (Mazda CX-7)
l Condensation may form on the optical lens or the
map disc inside the unit when the temperature in
the vehicle increases in a short time such as when
heating the car on a cold day. This condensation
may cause malfunctions. If so, unload the map disc
and do not operate the unit for approximately 1
hour. Wipe the condensation off the map disc with a
soft cloth.
If the unit does not operate correctly after 1 hour,
consult an Authorized Mazda Dealer.
Note
lWhen the ignition switch is in the ACC or ON
position, the screen changes as follows to activate
the navigation system.
l The screen (audio or navigation) that was displayed
prior to the engine being turned off is displayed.
Before the navigation screen is displayed, the
CAUTION screen will be displayed.
2
Insert the map disc
with the printed side
facing up.
Cautions
Cover
(CAUTION) screen
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

13
Getting started
Ifnecessary
Rear View
Monitor
lThe Current Position screen appears.
Note
lYou can select the language by selecting the on-screen button. You can also
change the selected language using Language Selection. ( page 20)
l The CAUTION screen remains on the display unless you select the on-screen
button.
(Mazda CX-9)
If the mobile telephone is programmed to the hands-free unit for use with the Bluetooth
hands-free telephone, the Bluetooth hands-free information is displayed on the screen
momentarily. While this information is displayed, the on-screen button cannot be
selected. Select the on-screen button after the display is cleared.
Select the on-screen button lightly with your finger.
Colors for unavailable buttons will be pale.
3
Read the CAUTION
carefully, and select
the on-screen
button.
Removing the Map Disc
1
With the ignition switch in the ACC position, remove the cover.
2
Press (EJECT).
On-screen Buttons
Most functions are inhibited while the
vehicle is in motion.
Please read the handbook for operation
instructions.
Always obey traffic regulations.
Caution
Mazda CX-9
Cover
Do not get your hand or fingers caught in
moving parts or in the disc slot. This can
cause injuries. Children are inquisitive, try
to install or remove the map disc without
infants looking on.
Caution
Scre Scre
Br
Mazda CX-7
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

15
Getting started
Ifnecessary
Rear View
Monitor
Set Clock
The current time is set using this function. Since time notification is provided by a GPS
satellite.
Before Steps select MENU
Open the [SET CLOCK] screen
Select if you prefer 24-hour display;
for 12-hour display.
Select to move the setting ahead by one hour,
and similarly, select to move it back by one
hour.
How to exit .
Note
Minutes and seconds are adjusted by the GPS, however, it is necessary to
adjust hours under the following conditions:
lDriving across different time zones
l Daylight saving time start and end
'<C)%FSSO4EKI1SRHE]2SZIQFIV41
