2008 MAZDA MODEL CX-7 display

89
Rear View Monitor
Variance Between Actual Road
Conditions and Displayed Image
Some variance occurs between the actual road and the displayed road. Such variance in
distance perspective could lead to an accident. Note the following conditions that may cause
a variance in distance perspective.
1When the vehicle is tilted due to the weight of passengers and
load
When the vehicle rear is lowered, the object displayed on the screen appears farther than the
actual distance.
The figure is an example showing Mazda CX-9.
2When there is a steep grade behind the vehicle
When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the
screen appears farther (downgrade: closer) than the actual distance.
The figure is an example showing Mazda CX-9.
Object
Variance
Appears
farther than
actual
distance Appears
closer than
actual
distance
Object at actual position
Object at actual
position
Object on screen
Object on screen
A: Distance between the vehicle and object displayed on the screen.
B: Actual distance between the vehicle and object.
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

91
Bluetooth Hands-Free (Mazda CX-9 only)
Contents
Bluetooth Hands-Free
nBluetooth Hands-Free (Mazda CX-9 only)lScreen display of Bluetooth Hands-Free information .................... 92
'<C)%FSSO4EKI1SRHE]2SZIQFIV41

92
Before
UseGetting
started
RoutingAddress
Book
Vo i c e Recognition
Navigation
Set Up
RDM-TMC
Bluetooth Hands-Free (Mazda CX-9 only)
Bluetooth Hands-Free
If the Bluetooth Hands-Free is operated, information such as radio wave reception conditions
of the Bluetooth Hands-Free are displayed on the screen. For details, refer to the "Bluetooth
Hands-Free" in the owner’s manual.
Screen display of Bluetooth Hands-Free information
Bluetooth Hands-Free information
