2008 Lexus GS350 washer fluid

148
2-3. Operating the lights and windshield wipers
GS_G_U
June 5, 2008 10:37 am
■If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the wind-
shield washer fluid reservoir.
■In extremely hot or cold weather
The system will turn off if the windshield gets extremely hot (at more than 176F
[80 C]) or cold (at less than 14 F [-10C]).
■Customization that can be configured at Lexus dealer
Settings (e.g. drip prevention function) can be changed. 
(Customizable features P. 5 7 3 )
CAUTION
■Caution regarding the use of windshield wipers in “AUTO” mode
The windshield wipers may operate unexpect edly if the sensor is touched or the
windshield is subject to vibration in “AUTO” mode. Take care that your fingers or
anything else do not become caught in the windshield wipers.
NOTICE
■When the windshield is dry
Do not use the wipers, as they may damage the windshield.
■When there is no washer fluid spray from the nozzle
Damage to the washer fluid pump may be caused if the lever is pulled toward you
and held continually.

149
2-3. Operating the lights and windshield wipers
2
When driving
GS_G_U
June 5, 2008 10:37 am
Headlight cleaner switch (if equipped)
■The headlight cleaner can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode and the headlight
switch is turned ON.
NOTICE
■When the washer fluid tank is empty
Do not use this function, as the washer fluid pump may overheat.
Washer fluid can be sprayed on the headlights.
Press the switch to clean the
headlights.

199
2-5. Driving information
2
When driving
GS_G_U
May 13, 2008 5:14 pm
Winter driving tips
Carry out the necessary preparations and inspections before driving the
vehicle in winter. Always drive the vehicle in a manner appropriate to the
prevailing weather conditions.
■ Pre-winter preparations
●Use fluids that are appropria te to the prevailing outside tempera-
tures.
• Engine oil
• Engine coolant
• Washer fluid
● Have a service technician inspect th e level and specific gravity of
battery electrolyte.
● Have the vehicle fitted with four snow tires or purchase a set of
tire chains for the rear tires.
Ensure that all tires are the same si ze and brand, and that chains match
the size of the tires.
■ Before driving the vehicle
Perform the following according to the driving conditions.
● Do not try to forcibly open a w indow or move a wiper that is fro-
zen. Pour warm water over the frozen area to melt the ice. Wipe
away the water immediately to prevent it from freezing.
● To ensure proper operation of the climate control system fan,
remove any snow that has accumulated on the air inlet vents in
front of the windshield.
● Remove any ice that has accumul ated on the vehicle chassis.
● Periodically check for and remove any excess ice or snow that
may have accumulated in the wheel well or on the brakes.

401
4-3. Do-it-yourself maintenance
4
Maintenance and care
GS_G_U
May 13, 2008 5:14 pm
ItemsPa r t s a n d t o o l s
Engine oil level (P. 4 0 9 )
• “Toyota Genuine Motor Oil” or
equivalent
• Rag or paper towel, funnel (used
only for adding engine oil)
Fuses ( P. 4 4 2 )• Fuse with same amperage rating as
original
Headlight aim ( P. 4 6 7 )• Phillips-head screwdriver
Radiator and condenser (P. 4 1 5 )
Tire inflation pressure (P. 4 3 1 )• Tire pressure gauge
• Compressed air source
Wa s h e r f l u i d ( P. 4 2 0 )
• Water washer fluid containing anti-
freeze (for winter use)
•Funnel

406
4-3. Do-it-yourself maintenance
GS_G_U
May 13, 2008 5:14 pm
Engine compartment
GS460
Engine oil level dipstick
( P. 4 0 9 )
Engine oil filler cap 
( P. 410)
Brake fluid reservoir 
( P. 4 1 6 )
Fuse box ( P. 4 4 2 )
Washer fluid tank 
( P. 420)Engine coolant reservoir 
( P. 4 1 4 )
Electric cooling fans
Condenser ( P. 415)
Radiator ( P. 415)
Fuse box ( P. 4 4 2 )
12 volt battery ( P. 417)

407
4-3. Do-it-yourself maintenance
4
Maintenance and care
GS_G_U
May 13, 2008 5:14 pm
GS350
Engine oil level dipstick
( P. 4 0 9 )
Engine oil filler cap 
( P. 410)
Brake fluid reservoir (P. 4 1 6 )
Fuse box ( P. 4 4 2 )
Washer fluid tank 
( P. 420)Engine coolant reservoir 
( P. 4 1 4 )
Electric cooling fans
Condenser ( P. 415)
Radiator ( P. 415)
Fuse box ( P. 4 4 2 )
12 volt battery ( P. 417)

420
4-3. Do-it-yourself maintenance
GS_G_U
May 13, 2008 5:14 pm
Washer fluidIf any washer does not work or the
warning message appears on the
multi-information display, the
washer tank may be empty. Add
washer fluid.
NOTICE
■When recharging the battery
Never recharge the battery while the engine is on. Also, be sure all accessories are
turned off.
CAUTION
■When refilling the washer fluid
Do not refill the washer fluid when the engine is hot or running, as the washer fluid
contains alcohol and may catch the fire if spilled on the engine etc.
NOTICE
■Do not use any fluid other than washer fluid
Do not use soapy water or engine antifreeze instead of washer fluid. 
Doing so may cause streaking on the vehicle’s painted surfaces.
■Diluting washer fluid
Dilute washer fluid with water as necessary. 
Refer to the freezing temperatures listed on the washer fluid tank.

5
When trouble arises
503
5-2. Steps to take in an emergency
GS_G_U
May 13, 2008 5:14 pm
Wa r n i n g m e s s a g eDetailsCorrection procedure
The trunk is not fully
closed. flashes and a
buzzer sounds to indi-
cate that trunk is not fully
closed (with the vehicle
having reached a speed
of 3 mph [5 km/h]).
Close the trunk.
(Flashing)
(If equipped)
The moon roof is not fully
closed (with the
“ENGINE START STOP”
switch is OFF and the
driver’s door opened).
Close the moon roof.
(Flashing)
The parking brake is still
engaged (with the vehicle
having reached a speed
of more than 3 mph [5
km/h]).
Release the parking
brake.
The washer fluid level is
low.Add washer fluid.
