2008 INFINITI QX56 sensor

DLK-166
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY UNIT
13 B/WInside key antenna 3
(front of center con-
sole) (+) signal
LOCK Any door open → all doors closed
14 W/G Inside key antenna 3
(front of center con-
sole) (-) signal
15 G Inside key antenna 1
(rear of center con-
sole) (+) signal
LOCK Any door open → all doors closed
16 L Inside key antenna 1
(rear of center con-
sole) (-) signal
17 P Rear bumper anten-
na (+) signal
LOCK Lift back door handle (close switch).
18 W/R Rear bumper anten-
na (-) signal
19 P Front outside anten-
na LH (+) signal
LOCK Press front door request switch LH.
20 V Front outside anten-
na LH (-) signal
21 B/W Remote keyless en-
try receiver RSSI sig-
nal ——
23 L/W Power back door out-
put —Power liftgate switch ON.
0
Power liftgate switch OFF. Battery voltage
25 P/L Front door request
switch RH —Press front door request switch RH.
0
Other than above Battery voltage
27 R/B Ignition knob switch — Press ignition switch.
Battery voltage
Return ignition switch to LOCK position. 0
28 R Unlock sensor
(driver side) —Door (driver si
de) is locked. 5
Door (driver side ) is unlocked. 0
29 LG/W Back door open
switch input —Back door handle switch ON.
0
Back door handle switch OFF. Battery voltage
Te r m i n a l
Wire
Color Item Condition
Voltage (V)Approx.
Ignition
Switch Po-
sition Operation or Conditions
PIIB7441E
PIIB7441E
SIIA1910J
SIIA1910J
PIIA2344E
Revision: March 2010
2008 QX56

DLK-202
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR LOCK FUNCTION SYMPTOMS
INTELLIGENT KEY
INTELLIGENT KEY : Symptom TableINFOID:0000000001539067
REMOTE KEYLESS ENTRY FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to
DLK-
6, "Work Flow".
• Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
• If the following “symptoms” are detected, check syst ems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
• Ignition switch is not depressed.
• All doors are closed.
Auto lock function does not operate properly. 1.
Check “AUTO RELOCK TIMER” setting in “WORK SUP-
PORT”. DLK-48
2. Key switch check (BCM).
D L K - 111
3. Ignition knob switch check.DLK-112
4. Door switch check. DLK-67
5. Replace Intelligent Key unit.SEC-116
Key reminder function does not operate properly.1.
Check “ANTI KEY LOCK IN FUNCTION” setting in
“WORK SUPPORT”.
DLK-48
2. Door switch check.
DLK-67
3a. Inside key antenna 1 (rear of center console) check. DLK-56
3b. Inside key antenna 2 (luggage compartment) check.DLK-58
3c. Inside key antenna 3 (front of center console) check.DLK-60
3d. Inside key antenna 4 (overhead console area) check. DLK-62
4. Front door lock actuator LH (door unlock sensor) check.DLK-77
5. Intelligent Key battery and function inspection.DLK-102
6. Replace Intelligent Key unit.SEC-116
SymptomDiagnosis/service procedureReference page
Symptom Diagnosis/service procedureReference
page
All of the remote keyless entry functions do not
operate. 1. Intelligent Key battery and function inspection.
DLK-102
2. Remote Keyless Entry function check. DLK-99
3. Replace Intelligent Key unit.SEC-116
Selective unlock function does not operate by In-
telligent Key remote control button.1.
Check “SELECT UNLOCK FUNCTION” setting in “WORK SUP-
PORT”. DLK-48
2. Intelligent Key battery inspection.
DLK-102
3. Replace Intelligent Key unit.SEC-116
Auto lock function does not operate properly.1. Check “AUTO RELOCK TIMER” setting in “WORK SUPPORT”.
DLK-48
2. Key switch check (BCM).D L K - 111
3. Ignition knob switch check.DLK-112
4. Door switch check. DLK-67
5. Replace Intelligent Key unit.SEC-116
Revision: March 2010 2008 QX56

DOOR LOCK FUNCTION SYMPTOMSDLK-203
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Key reminder function does not operate properly. 1.
Check “ANTI KEY LOCK IN FUNCTION” setting in “WORK
SUPPORT”.
DLK-48
2. Door switch check.
DLK-67
3a. Inside key antenna 1 (rear of center console) check.DLK-56
3b. Inside key antenna 2 (luggage compartment) check.DLK-58
3c. Inside key antenna 3 (front of center console) check.DLK-60
3d. Inside key antenna 4 (overhead console area) check.DLK-62
4. Front door lock actuator LH (door unlock sensor) check.DLK-77
5. Intelligent Key battery inspection.DLK-102
6. Replace Intelligent Key unit.SEC-116
Panic alarm function does not operate properly.1. Check “PANIC ALARM DELAY” setting in “WORK SUPPORT”.
DLK-49
2. Theft warning operation check.DLK-206
3. Intelligent Key battery inspection.DLK-102
4. Key switch check (BCM). D L K - 111
5. Ignition knob switch check.DLK-112
6. Replace Intelligent Key unit.SEC-116
Back door open function does not operate prop-
erly.1. Back door diagnosis.
DLK-1192. Intelligent Key battery inspection.DLK-102
3. Replace Intelligent Key unit.SEC-116
Power window down function does not operate.1. Check “PW DOWN SET” setti
ng in “WORK SUPPORT”. DLK-492. Intelligent Key battery inspection. DLK-102
SymptomDiagnosis/service procedureReference
page
Revision: March 2010 2008 QX56

KEY REMINDER FUNCTION SYMPTOMSDLK-209
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY REMINDER FUNCTION SYMPTOMS
Symptom TableINFOID:0000000001539072
KEY REMINDER FUNCTION MALFUNCTION
NOTE:
• Before performing the diagnosis in the following table, check “Work flow”. Refer to DLK-6, "
Work Flow".
• If the following symptoms” are detected, check systems shown in the “Diagnosis/service procedure” column in this order.
Conditions of Vehicle (Operating Conditions)
• “LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT-III.
• “ANSWER BACK FUNCTION” is ON when setting on CONSULT-III.
• Ignition switch is in OFF position.
• All doors are closed.
• Ignition switch is not depressed.
Symptom Diagnosis/service procedureReference page
Key reminder function does not operate. 1.
Check “ANTI KEY LOCK IN FUNCTI”setting in “WORK SUP-
PORT”. DLK-51
2. Check door switch.
DLK-67
3. Check inside key antennas (1, 2, 3, 4)Rear of center console
DLK-56Luggage compartmentDLK-58
Front of center consoleDLK-60
Overhead console areaDLK-62
4. Check unlock sensor. DLK-77
5. Check Intelligent Key battery inspection.DLK-102
6. Check Intermittent Incident. GI-38
Revision: March 2010 2008 QX56

PRECAUTIONSDLK-219
< PRECAUTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000004884149
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.
Precaution Necessary for Steering Wheel Rotation After Battery Disconnect
INFOID:0000000004884151
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecti ng both battery cables with the ignition knob in the
″ LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS , an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
Revision: March 2010 2008 QX56

DLN-1
TRANSMISSION & DRIVELINE
CEF
G H
I
J
K L
M
SECTION DLN
A
B
DLN
N
O P
CONTENTS
DRIVELINE
ATX14B
BASIC INSPECTION ....... .............................
6
DIAGNOSIS AND REPAIR WORKFLOW ..... .....6
Work Flow ........................................................... ......6
Preliminary Check .....................................................7
FUNCTION DIAGNOSIS ..............................10
4WD SYSTEM ................................................ ....10
System Diagram .................................................. ....10
System Description .................................................11
Component Parts Location ......................................16
CAN Communication ...............................................17
DIAGNOSIS SYSTEM (TRANSFER CON-
TROL UNIT) ........................................................
18
CONSULT-III Function (ALL MODE AWD/4WD) ....18
COMPONENT DIAGNOSIS .........................22
P1811 POWER SUPPLY CIRCUIT FOR
TRANSFER CONTROL UNIT ........................ ....
22
Description .......................................................... ....22
DTC Logic ...............................................................22
Diagnosis Procedure ...............................................22
Component Inspection ............................................23
P1802 – P1804, P1809 TRANSFER CON-
TROL UNIT .........................................................
24
Description ..............................................................24
DTC Logic ...............................................................24
Diagnosis Procedure ...............................................24
P1807 VEHICLE SPEED SENSOR (A/T) ..........26
Description .......................................................... ....26
DTC Logic ...............................................................26
Diagnosis Procedure ...............................................26
P1808 VEHICLE SPEED SENSOR (ABS) .........27
Description .......................................................... ....27
DTC Logic ............................................................ ....27
Diagnosis Procedure ...............................................27
P1810 NEUTRAL-4LO SWITCH .......................28
Description ...............................................................28
DTC Logic ................................................................28
Diagnosis Procedure ...............................................28
Component Inspection .............................................30
P1813 4WD SHIFT SWITCH .............................31
Description ...............................................................31
DTC Logic ................................................................31
Diagnosis Procedure ...............................................31
Component Inspection .............................................33
P1814 WAIT DETECTION SWITCH .................35
Description ...............................................................35
DTC Logic ................................................................35
Diagnosis Procedure ...............................................35
Component Inspection .............................................37
P1816 PNP SWITCH .........................................38
Description ...............................................................38
DTC Logic ................................................................38
Diagnosis Procedure ...............................................38
P1817 ACTUATOR MOTOR .............................39
Description ...............................................................39
DTC Logic ................................................................39
Diagnosis Procedure ...............................................39
Component Inspection .............................................43
P1818 ACTUATOR POSITION SWITCH ..........45
Description ...............................................................45
DTC Logic ................................................................45
Diagnosis Procedure ...............................................45
Component Inspection .............................................47
P1819 TRANSFER CONTROL DEVICE ...........48
Description ...............................................................48
DTC Logic ................................................................48
Diagnosis Procedure ...........................................
....48
Revision: March 2010 2008 QX56

DLN-10
< FUNCTION DIAGNOSIS >[ATX14B]
4WD SYSTEM
FUNCTION DIAGNOSIS
4WD SYSTEM
System DiagramINFOID:0000000001737096
COMPONENT DESCRIPTION
WDIA0164E
Components
Function
Transfer control unit Controls transfer control device, control valves and shifts between 2WD/4WD and 4H/4LO.
Transfer control device Integrates actuator motor and actuator position switch.
2-4WD shift solenoid valve Controls oil pressure and allows shifting between 2WD and 4WD.
Clutch pressure solenoid valve Controls oil pressure and distributes torque between front and rear tires.
Line pressure switch Detects line pressure.
Clutch pressure switch Detects clutch pressure.
Transfer fluid temperature sensor Detects transfer fluid temperature.
Actuator motor Moves shift rods when signaled by transfer control unit.
Actuator position switch Detects actuator motor position.
Wait detection switch Detects whether or not 4WD lock gear is locked.
4LO switch Detects if transfer case is in 4LO.
ATP switch Detects if transfer case is in neutral.
4WD shift switch Allows driver to select from 2WD/4WD, 4H/4LO and AUTO.
4WD warning lamp • Illuminates if malfunction is detected in 4WD system.
• Flashes (1 flash / 2 seconds) if large difference in diameter of front and rear tires.
• Flashes (2 flashes / 1 second) if high transfer fluid temperature is detected.
AT P w a r n i n g l a m p Indicates that A/T parking mechanism does not operate when A/T selector lever is in P position
because transfer case is in neutral.
4WD shift indicator lamp Displays driving range selected by 4WD shift switch.
4LO indicator lamp Displays 4LO range.
Revision: March 2010 2008 QX56

4WD SYSTEMDLN-11
< FUNCTION DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O PSystem DescriptionINFOID:0000000001737097
CONTROL SYSTEM
ABS actuator and electric unit
(control unit) Transmits vehicle speed signal via CAN communication to transfer control unit.
TCM Transmits the following signal via CAN communication to transfer control unit.
• Output speed sensor signal
• A/T position indicator signal (transmission range switch signal)
ECM Transmits the following signals via CAN communication to transfer control unit.
• Engine speed signal
• Accelerator pedal position signal
Components
Function
Revision: March 2010 2008 QX56
