2008 INFINITI QX56 sensor

BRC-68
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1160 DECEL G SEN SET
C1160 DECEL G SEN SET
DescriptionINFOID:0000000001686329
The yaw rate/side/decel G sensor detects the yaw rate
/side/decel G affecting the vehicle, and transmits the
data to the ABS actuator and electric uni t (control unit) as an analog voltage signal.
DTC LogicINFOID:0000000001686330
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-68, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000001686331
INSPECTION PROCEDURE
1.PERFORM SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis.
Do self-diagnosis results indicate anything other than shown above?
YES >> Perform repair or replacement for the item indicated.
NO >> Perform calibration of decel G sensor. Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR :
Description". GO TO 2
2.PERFORM SELF-DIAGNOSIS AGAIN
1. Turn the ignition switch to OFF and then to ON and erase self-diagnosis results.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis again.
Are any self-diagnosis results displayed?
YES >> Replace yaw rate/side/decel G sensor. Refer to BRC-119, "Removal and Installation".
NO >> Inspection End
DTC Display item Malfunction detected condition Possible cause
C1160 DECEL G SEN SET ABS decel G sensor adjustment is incomplete. • Decel G sensor calibration
• Yaw rate/side/decel G sensor
• ABS actuator and electric unit
(control unit)
Self-diagnosis results
DECEL G SEN SET
Self-diagnosis resultsDECEL G SEN SET
Revision: March 2010 2008 QX56

C1163 ST ANGLE SEN SAFEBRC-69
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1163 ST ANGLE SEN SAFE
DescriptionINFOID:0000000001686332
The steering angle sensor detects the rotation amount, angular velocity and direction of the steering wheel,
and transmits the data to the ABS actuator and el ectric unit (control unit) via CAN communication.
DTC LogicINFOID:0000000001686333
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-69, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000001686334
INSPECTION PROCEDURE
1.ADJUSTMENT OF STEERING AN GLE SENSOR NEUTRAL POSITION
Adjust steering angle sensor neutral position. Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SEN-
SOR NEUTRAL POSITION : Description".
>> GO TO 2
2.INDICATOR LAMP CHECK
Check that VDC OFF indicator lamp is off.
Is VDC OFF indicator lamp off?
YES >> Inspection End
NO >> Perform ABS actuator and electric uni t (control unit) self-diagnosis. Refer to BRC-24, "
CONSULT-
III Function (ABS)".
DTCDisplay item Malfunction detected condition Possible cause
C1163 ST ANGL SEN SAFE When steering angle sensor is in safe mode. • Adjust steering angle sensor
neutral position
Self-diagnosis results
ST ANGL SEN SAFE
Revision: March 2010 2008 QX56

BRC-72
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1164, C1165, C1166
, C1167 CV/SV SYSTEM
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to BRC-70, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000001691161
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
Revision: March 2010 2008 QX56

C1178, C1181, C1184, C1189 ABS ACTIVE BOOSTER
BRC-73
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1178, C1181, C1184, C1189 ABS ACTIVE BOOSTER
DescriptionINFOID:0000000001686340
The active brake booster consists of a vacuum boos ter, an active booster control group and a delta stroke
sensor. If a brake booster system malfunction occurs due to loss of vacuum, the delta stroke sensor will signal
the ABS actuator and electric unit (control unit) that a booster malfunction has occurred. The active booster
then applies supplemental force to the master cylinder re lative to the amount of force exerted on the brake
pedal.
DTC LogicINFOID:0000000001686341
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-73, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000001686342
INSPECTION PROCEDURE
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the active booster connector E49 and ABS ac tuator and electric unit (control unit) connector
E125 and inspect the terminals for deforma tion, disconnection, looseness, or damage.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair connector.
2.ACTIVE BOOSTER CIRCUIT INSPECTION
DTC Display item Malfunction detected condition Possible cause
C1178 ABS ACTIVE BOOSTER SV
NG Active booster solenoid is malfunctioning, or signal line of
active booster servo is open or shorted.
• Harness or connector
• Active booster
• ABS actuator and electric unit (control unit)
C1181
ABS ACTIVE BOOSTER RE-
SPONSE NG Active booster response is malfunctioning, or signal line
of active booster response is open or shorted.
C1184 ABS BRAKE RELEASE SW
NG Brake release switch is malfunctioning, or signal line of
brake release switch is open or shorted.
C1189 ABS BRAKE BOOSTER DE-
FECT Brake booster is defective or malfunctioning.
Self-diagnosis results
ABS ACTIVE BOOSTER SV NG
ABS ACTIVE BOOSTER RESPONSE NG ABS BRAKE RELEASE SW NG
ABS BRAKE BOOSTER DEFECT
Revision: March 2010 2008 QX56

C1178, C1181, C1184, C1189 ABS ACTIVE BOOSTER
BRC-75
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to BRC-73, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000001691162
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
Revision: March 2010 2008 QX56

BRC-76
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1179 ABS DELTA S SEN NG
C1179 ABS DELTA S SEN NG
DescriptionINFOID:0000000001686345
The active brake booster consists of a vacuum booster, an active booster control group and a delta stroke
sensor. If a brake booster system malfunction occurs due
to loss of vacuum, the delta stroke sensor will signal
the ABS actuator and electric unit (c ontrol unit) that a booster malfunction has occurred. The active booster
then applies supplemental force to the master cylinder re lative to the amount of force exerted on the brake
pedal.
DTC LogicINFOID:0000000001686346
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-76, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000001686347
INSPECTION PROCEDURE
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the delta stroke sensor connector E114 and ABS actuator and electric unit (control unit) con- nector E125 and inspect the terminals for def ormation, disconnection, looseness, or damage.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair connector.
2.DELTA STROKE SENSOR CIRCUIT INSPECTION
1. Measure the continuity between ABS actuator and electric unit (control unit) harness connector E125 (A) and delta stroke sen-
sor harness connector E114 (B).
2. Measure the continuity between ABS actuator and el ectric unit (control unit) harness connector E125 (A)
and body ground.
DTC Display item Malfunction detected condition Possible cause
C1179 ABS DELTA S SEN NG Delta stroke sensor is malfunctioning, or signal line of
delta stroke sensor is open or shorted. • Harness or connector
• Delta stroke sensor
• ABS actuator and electric unit
(control unit)
Self-diagnosis results
ABS DELTA S SEN NG
ABS actuator and electric unit (control unit) Delta stroke sensor
Continuity
Connector Terminal Connector Terminal
A: E125 26
B: E114 1
Ye s
39 3
40 5
AWFIA0029ZZ
Revision: March 2010 2008 QX56

C1179 ABS DELTA S SEN NGBRC-77
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness or connector.
3.DELTA STROKE SENSOR INSPECTION
1. Reconnect the delta stroke sensor and ABS act uator and electric unit (control unit) connectors.
2. Use “DATA MONITOR” to check if the status of “DELTA S SEN” is normal.
Is the inspection result normal?
YES >> Replace the ABS actuator and elec tric unit (control unit). Refer to BRC-116, "Removal and Instal-
lation".
NO >> Replace the delta stroke sensor.
Component InspectionINFOID:0000000001686348
1.CHECK DATA MONITOR
Use “DATA MONITOR” to check if the status of “DELTA S SEN” is normal.
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to BRC-76, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000001691163
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
A: E125 26
Ground No
39
40
Condition DELTA S SEN
(DATA MONITOR)
When brake pedal is depressed. 1.05–1.80 mm
When brake pedal is released. 0.00 mm (+0.6/-0.4)
ConditionDELTA S SEN
(DATA MONITOR)
When brake pedal is depressed. 1.05–1.80 mm
When brake pedal is released. 0.00 mm (+0.6/-0.4)
Revision: March 2010 2008 QX56

C1185 ICC UNITBRC-79
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
1. Measure the continuity between ABS actuator and electric unit
(control unit) connector E125 and ICC unit connector B13.
2. Measure the continuity between ABS actuator and electric unit
(control unit) connector E125 and body ground.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-116, "Removal and Installa-
tion".
NO >> Repair or replace harness or connector.
Special Repair RequirementINFOID:0000000001691167
1.ADJUSTMENT OF STEERING AN GLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
ABS actuator and electric unit (control unit) ICC unit
Continuity
Connector Terminal Connector Terminal
A: E125 7B: B13 10Yes
ABS actuator and electric unit (control unit) —Con tin uit y
Connector Terminal
A: E125 7Ground No
AWFIA0067ZZ
Revision: March 2010 2008 QX56
