INSPECTION AND ADJUSTMENT
INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL
ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Spe-
cial Repair Requirement
INFOID:0000000006095112
Required Procedure After Battery Disconnection
System ItemReference
Engine Control Idle Air Volume Learning Refer to EC-18
.
Brake Control Steering Angle Sensor Neutral Position Refer to BRC-8
.
Power Window Control Power Window System Initialization Refer to TSB.
Body, Lock & Security Automatic Back Door Initialization Refer to DLK-9
.
Roof Sunroof Memory Reset/Initialization Refer to RF-5
.
Seats Automatic Drive Positioner System Initialization Refer to Owner's Manual.
Audio-Visual System Audio (Radio Preset)
Refer to Owner's Manual.
Navigation System Refer to Owner's Manual.
Rear View Monitor Guiding Line Adjustment Refer to AV- 7
.
Revision: March 2010 2008 QX56

PG
HARNESSPG-41
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
MAIN HARNESS
AWMIA0111GB
G4 M1 W/16 : To R1
G4 M84 W/16 : To B101
F4 M2 W/12 : To R2 B3 M87 B/5 : Rear power vent window relay (open)
G2 M3 W/8 : Fuse block (J/B) B3 M89 B/5 : Rear power vent window relay (close)
G2 M4 W/16 : Fuse block (J/B) B3 M91 W/16 : To E26
Revision: March 2010 2008 QX56

PG-42
< COMPONENT DIAGNOSIS >
HARNESS
A3 M6 W/10 : To E10A2 M92 B/6 : Power liftgate switch
A2 M7 B/5 : Passenger select unlock relay D1 M93 W/24 : Display unit
A3 M8 W/16 : To D2 A2 M95 W/6 : Rear power vent window switch
A2 M9 BR/24 : To D1 A2 M96 BR/6 : Pedal adjusting switch
A3 M10 Y/4 : To E29 C2 M98 W/16 : A/C and AV switch assembly
A3 M11 B/1 : Parking brake switch C3 M99 BR/2 : Foot lamp LH
C3 M12 GR/6 : Key switch and ignition knob switch F4 M100 BR/2 : Foot lamp RH
D3 M13 BR/2 : Front passenger air bag OFF indicator F4 M101 Y/2 : Driver air bag module
B3 M15 W/4 : Steering lock solenoid F4 M102 GR/8 : Combination switch (spiral cable)
A2 M16 GR/6 : ADP steering switch F4 M103 Y/2 : Driver air bag module
B2 M17 W/8 : Steering angle sensor E3 M104 W/4 : Aux jack
C2 M18 W/40 : BCM (body control module) F2 M105 Y/2 : Front passenger air bag module
C2 M19 W/15 : BCM (body control module) F2 M106 O/2 : Front passenger air bag module
C2 M20 B/15 : BCM (body control module) F3 M107 B/5 : Front blower relay
C3 M22 W/16 : Data link connector D5 M108 B/6 : Yaw rate/ side/ decel G sensor
B1 M23 W/12 : Combination meter A1 M109 BR/2 : Front tweeter LH
C1 M24 W/40 : Combination meter D2 M110 BR/2 : Center speaker
F2 M25 B/4 : Remote keyless entry receiver F2 M111 BR/2 : Front tweeter LH
B2 M26 W/6 : Ignition switch C2M112 BR/14 : BO SE speaker amp.
A2 M27 B/2 : Diode-3 C2 M113 BR/23 : BOSE speaker amp.
B2 M28 W/16 : Combination switch B3 M114 W/2 : Heated steering wheel
B2 M29 Y/6 : Combination switch (spiral cable) A2 M116 GR/8 : Sonar system OFF switch
B3 M30 GR/8 : Combination switch (spiral cable) B1 M118 BR/2 : Front sonar buzzer
G4 M31 SMJ : To E152 F2 M120 W/4 : Remote keyless entry receiver
C3 M32 W/4 : In-vehicle sensor F4 M122 W/4 : Variable blower control (front)
B3 M33 W/32 : Automatic drive position control unit C3 M123 W/2 : Tire pressure warning check connector
B3 M34 W/16 : Automatic drive position control unit D2 M124 GR/3 : AV control unit
C5 M35 Y/28 : Air bag diagnosis sensor unit D2 M125 B/1 : Satellite radio antenna
G4 M36 SMJ : To B149 C3 M129 V/1 : Satellite radio tuner
G3 M37 B/1 : Fuse block (J/B) D2 M139 B/2 : Diode-1
G3 M38 B/2 : Fuse block (J/B) D1 M140 B/2 : Diode-2
D3 M39 W/8 : Fuse block (J/B) C2 M141 GR/8 : 4WD shift switch
A3 M40 SMJ : To B69 E1 M142 B/6 : Mode door motor (front)
D2 M42 W/20 : AV control unit E3 M143 B/6 : Air mix door motor (passenger)
D2 M43 W/12 : AV control unit C1 M144 B/6 : Defroster door motor
D2 M44 W/32 : AV control unit E3 M146 GR/2 : Intake sensor
D3 M45 W/40 : AV control unit D3 M147B/6 : Air mix doo r motor (driver)
D2 M46 W/32 : AV control unit D2 M148 W/4 : Headlamp aiming switch
D2 M49 L/26 : A/C auto AMP D3 M149 W/4 : Clock
D2 M50 B/26 : A/C auto AMP B1 M150 W/2 : Ignition keyhole illumination
B3 M51 L/4 : Trailer tow relay 1 G4 M157 W/20 : To B161
B2 M52 W/2 : Combination switch (spiral cable) A3 M158 W/10 : To D3
D3 M53 B/3 : Front power socket LH Console sub-harness
E3 M54 B/3 : Front power socket RH (for cigarette
lighter) D4 M201 W/16 : To M56
D2 M55 W/4 : Hazard switch D4 M202 BR/24 : To M64
Revision: March 2010 2008 QX56

PG
HARNESSPG-53
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
BODY NO. 2 HARNESS
C5 B10 Y/2 : Front LH side air bag module
C5 B13 W/24 : ICC unit
C4 B14 Y/2 : Front LH seat belt pre-tensioner
C5 B15 Y/2 : LH side air bag (satellite) sensor
C5 B17 GR/24 : ICC unit
D4 B18 W/3 : Rear door switch LH
G3 B19 — : Body ground
B4 B32 W/6 : To B124
G5 B35 B/3 : Rear combination lamp LH
B4 B37 W/16 : To B200
A3 B38 Y/2 : LH side front curtain air bag module
A4 B40 W/24 : To E34
A4 B41 W/12 : To E35
A4 B42 W/2 : To E36
B4 B43 W/16 : To B111
G3 B48 W/18 : To D401
F3 B49 W/2 : To D402
F4 B52 W/2 : Rear power vent window motor LH
E4 B54 Y/2 : LH side rear curtain air bag module
F5 B55 W/26 : Back door control unit
F4 B56 GR/16 : Sonar control unit
G4 B63 W/6 : Back door close switch
A4 B69 SMJ : To M40
G4 B70 B/3 : Rear combination lamp LH
B4 B72 BR/6 : Subwoofer
E5 B73 W/16 : Rear view camera control unit
C4 B74 Y/4
: Seat belt buckle pretensioner assembly
LH (seatbelt buckle switch)
F5 B75 W/10 : To B400
F5 B76 GR/2 : Inside key antenna 2 (luggage
compartment)
Revision: March 2010
2008 QX56

PG-54
< COMPONENT DIAGNOSIS >
HARNESS
G4 B101 W/16 : To M84
A4 B105 B/3 : Rear combination lamp RH
E4 B106 W/18 : To D301
G4 B107 W/8 : To E139
E4 B108 W/3 : Front door switch RH
G 3 B 111 W / 1 6 : To B 4 3
E4 B113 Y/12 : Air bag diagnosis sensor unit
E5 B114 Y/2 : RH side air bag (satellite) sensor
D4 B116 W/3 : Rear door switch RH
F4 B117 — : Body ground
F4 B118 W/3 : Front seat heater RH
A4 B119 W/2 : Condenser-3
A3 B120 W/2 : Condenser-4
F4 B124 W/6 : To B32
F4 B126 Y/2 : Front RH side air bag module
E5 B127 Y/2 : Front RH seat belt pre-tensioner
C3 B128 Y/2 : RH side rear curtain air bag module
G3 B129 Y/2 : RH side front curtain air bag module
A4 B130 B/3 : Rear combination lamp RH
A5 B132 — : Body ground
A5 B133 W/4 : Variable blower control (rear)
B5 B134 W/2 : Rear blower motor
E4 B136 W/8 : To B350
E4 B137 W/3 : Belt tension sensor
B3 B138 B/3 : Rear cargo power socket
A3 B139 W/16 : To D602
A2 B140 W/6 : To D601
D2 B145 W/16 : To R200
E2 B146 BR/24 : To R201
G3 B149 SMJ : To M36
B3 B150 W/2 : Rear power vent window motor RH
B2 B153 W/2 : Cargo lamp
F5 B154 W/2 : To B303
B4 B155 B/6 : Air mix door motor (rear)
B4 B156 B/6 : Mode door motor (rear)
F4 B157 Y/4 : Seat belt buckle pre-tensioner assembly
RH (seat belt buckle switch)
G4 B161 W/20 : To M157
C4 B162 W/6 : Third row power folding seat switch
RH side (front)
B4 B163 BR/6 : Third row power folding seat switch
RH side (rear)
C4 B164 BR/6 : Third row power folding seat switch
LH side (front)
Revision: March 2010
2008 QX56

PG-56
< COMPONENT DIAGNOSIS >
HARNESS
FRONT DOOR LH HARNESS
D3 R3 W/2 : Vanity lamp LHD2 R109 W/4 : Microphone
C3 R4 GR/10 : Sunroof motor assembly Room lamp sub-harness B
C2 R6 W/16 : To R101 D1 R200 W/16 : To B145
C3 R7 GR/10 : Auto anti-dazzling inside mirror D1 R201 BR/24 : To B146
B3 R8 W/2 : Vanity lamp RH C2 R202 W/12 : Video monitor
D3 R9 W/8 : To R107 D1 R203 W/3 : Personal lamp 2ND row
Room lamp sub-harness A D2 R204 W/16 : Rear audio remote control unit
C2 R101 W/16 : To R6 E1 R205 W/3 : Personal lamp 3RD row
C3 R102 GR/8 : Front room/map lamp assembly D2 R209 B/6 : Rear air control (rear)
D3 R104 GR/6 : Sunroof switch E1 R210 W/2 : Inside key antenna 4 (over head console area)
ALMIA0215GB
D1 W/24 : To M9 D9 GR/6 : Front power window motor LH
D2 W/16 : To M8 D10 W/16 : Door mirror remote control switch
D3 W10 : To M158 D11 W/2 : Front step lamp LH
D4 W/16 : Door mirror LH D12 W/2 : Front door speaker LH
D5 W/8 : Seat memory switch D14 B/6 : Front door lock assembly LH
D7 W/16 : Main power window and door lock/unlock
switch D15 B/6 : Front outside antenna
D8 W/3 : Main power window and door lock/unlock
switch
D16 GR/2 : Front door request switch LH
Revision: March 2010
2008 QX56

PG
HARNESSPG-57
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
B A
O P
N
FRONT DOOR RH HARNESS
ALMIA0218GB
D101 W/10 : To M75
D109 W/2 : Front step lamp RH
D102 BR/20 : To M74 D112 W/2 : Front door speaker RH
D104 GR/6 : Front power window motor RH D114 B/6 : Front door lock actuator RH
D105 W/16 : Power window and door lock/unlock
switch RH
D115 GR/2 : Front outside antenna RH
D107 W/16 : Door mirror RH D116 GR/2 : Front door request switch RH
Revision: March 2010 2008 QX56

PG-58
< COMPONENT DIAGNOSIS >
HARNESS
REAR DOOR LH HARNESS
AWMIA0109GB
D201 W/18 : To B6 D206 W/2 : Rear step lamp LH
D203 W/8 : Rear power window switch LH D207 W/2 : Rear door speaker LH
D204 GR/6 : Rear power window motor LH D208 BR/2 : Rear door tweeter LH
D205 B/6 : Rear door lock actuator LH D209 W/18 : Rear power window control unit LH
Revision: March 2010 2008 QX56
