Page 3601 of 4083

TM-54
< COMPONENT DIAGNOSIS >
P0731 1GR INCORRECT RATIO
Diagnosis Procedure
INFOID:0000000001604054
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-32, "
CONSULT-III Functi on (TRANSMISSION)".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-38, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-92, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTION ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.REPLACE CONTROL VALVE WITH TCM
1. Replace control valve with TCM. Refer to TM-201, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2".
2. Perform TM-53, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Confirm malfunction phenomena by “ROAD TEST” to repair malfunctioning part. Refer to TM-189,
"Description".
Revision: March 2010 2008 QX56
Page 3603 of 4083

TM-56
< COMPONENT DIAGNOSIS >
P0732 2GR INCORRECT RATIO
Diagnosis Procedure
INFOID:0000000001604059
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-32, "
CONSULT-III Functi on (TRANSMISSION)".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-38, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-92, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTION ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.REPLACE CONTROL VALVE WITH TCM
1. Replace control valve with TCM. Refer to TM-201, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2".
2. Perform TM-55, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Confirm malfunction phenomena by “ROAD TEST” to repair malfunctioning part. Refer to TM-189,
"Description".
Revision: March 2010 2008 QX56
Page 3605 of 4083

TM-58
< COMPONENT DIAGNOSIS >
P0733 3GR INCORRECT RATIO
Diagnosis Procedure
INFOID:0000000001604064
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-32, "
CONSULT-III Functi on (TRANSMISSION)".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-38, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-92, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTION ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.REPLACE CONTROL VALVE WITH TCM
1. Replace control valve with TCM. Refer to TM-201, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2".
2. Perform TM-57, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Confirm malfunction phenomena by “ROAD TEST” to repair malfunctioning part. Refer to TM-189,
"Description".
Revision: March 2010 2008 QX56
Page 3607 of 4083

TM-60
< COMPONENT DIAGNOSIS >
P0734 4GR INCORRECT RATIO
Diagnosis Procedure
INFOID:0000000001604069
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-32, "
CONSULT-III Functi on (TRANSMISSION)".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-38, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-92, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTION ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.REPLACE CONTROL VALVE WITH TCM
1. Replace control valve with TCM. Refer to TM-201, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2".
2. Perform TM-59, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Confirm malfunction phenomena by “ROAD TEST” to repair malfunctioning part. Refer to TM-189,
"Description".
Revision: March 2010 2008 QX56
Page 3609 of 4083

TM-62
< COMPONENT DIAGNOSIS >
P0735 5GR INCORRECT RATIO
Diagnosis Procedure
INFOID:0000000001604074
1.CHECK CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TM-32, "
CONSULT-III Functi on (TRANSMISSION)".
Is a malfunction in the CAN communication indicated in the results?
YES >> Check CAN communication line. Refer to TM-38, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-92, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTION ITEM
Check A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.REPLACE CONTROL VALVE WITH TCM
1. Replace control valve with TCM. Refer to TM-201, "
Control Valve with TCM and A/T Fluid Temperature
Sensor 2".
2. Perform TM-61, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Confirm malfunction phenomena by “ROAD TEST” to repair malfunctioning part. Refer to TM-189,
"Description".
Revision: March 2010 2008 QX56
Page 3610 of 4083

P0740 TORQUE CONVERTERTM-63
< COMPONENT DIAGNOSIS >
CEF
G H
I
J
K L
M A
B
TM
N
O P
P0740 TORQUE CONVERTER
DescriptionINFOID:0000000001604075
• The torque converter clutch solenoid valve is activated, with the gear in D4, D5 by the TCM in response to
signals sent from the input speed s ensor and accelerator pedal position s ensor (throttle position sensor).
Torque converter clutch piston operation will then be controlled.
• Lock-up operation, however, is prohibited when A/T fluid temperature is too low.
• When the accelerator pedal is depressed (less than 1/8) in lock-up condition, the engine speed should not change abruptly. If there is a big jump in engine speed, there is no lock-up.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000001604076
On Board Diagnosis LogicINFOID:0000000001604077
• This is an OBD-II self-diagnostic item.
• Diagnostic trouble code “P0740” with CONSULT-III is detected under the following conditions.
- When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
- When TCM detects as irregular by comparing target value with monitor value.
Possible CauseINFOID:0000000001604078
• Torque converter clutch solenoid valve
• Harness or connectors
(The solenoid circuit is open or shorted.)
DTC Confirmation ProcedureINFOID:0000000001604079
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “ENGINE” with CONSULT-III.
3. Start engine and maintain the following conditions for at least 5 consecutive seconds. VHCL SPEED SE: 80 km/h (50 MPH) or more
ACCELE POS: 0.5/8 - 1.0/8
SELECTOR LEVER: “D” position
Driving location: Driving the vehic le uphill (increased engine load) will help maintain the driving
conditions required for this test.
4. If DTC is detected go to TM-63, "
Diagnosis Procedure".
WITH GST
Follow the procedure “With CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001604080
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch “ON”.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Start engine.
Item name Condition Display value (Approx.)
TCC SOLENOID When performing slip lock-up
0.2 - 0.4 A
When performing lock-up 0.4 - 0.6 A
Revision: March 2010 2008 QX56
Page 3611 of 4083
TM-64
< COMPONENT DIAGNOSIS >
P0740 TORQUE CONVERTER
4. Read out the value of “TCC SOLENOID” while driving.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-92, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check the following items:
• The A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to TM-201, "Control Valve with TCM and A/T Fluid
Temperature Sensor 2".
NG >> Repair or replace damaged parts.
4.CHECK DTC
Perform “DTC Confirmation Procedure”.
• Refer to TM-63, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Item name Condition Display value (Approx.)
TCC SOLENOID When performing slip lock-up
0.2 - 0.4 A
When performing lock-up 0.4 - 0.6 A
Revision: March 2010 2008 QX56
Page 3613 of 4083

TM-66
< COMPONENT DIAGNOSIS >
P0744 TORQUE CONVERTER
Diagnosis Procedure
INFOID:0000000001604086
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch “ON”.
2. Select “MAIN SIGNALS” in “DATA MONITO R” mode for “TRANSMISSION” with CONSULT-III.
3. Start the engine.
4. Read out the value of “TCC SOLENOID” while driving.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2.CHECK TCM POWER SUPPLY AND GROUND CIRCUIT
Check TCM power supply and ground circuit. Refer to TM-92, "
Diagnosis Procedure".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.DETECT MALFUNCTIONING ITEM
Check the following items:
• The A/T assembly harness connector pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to TM-201, "Control Valve with TCM and A/T Fluid
Temperature Sensor 2".
NG >> Repair or replace damaged parts.
4.CHECK DTC
Perform “DTC Confirmation Procedure”.
• Refer to TM-65, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> GO TO 2.
Item name Condition Display value (Approx.)
TCC SOLENOID When performing slip lock-up
0.2 - 0.4 A
When performing lock-up 0.4 - 0.6 A
Revision: March 2010 2008 QX56
