INDEX FOR DTCEC-597
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OP0453 0453 EVAP SYS PRES SEN
EC-966
P0455 0455 EVAP GROSS LEAKEC-973
P0456 0456 EVAP VERY SML LEAKEC-979
P0460 0460 FUEL LEV SEN SLOSHEC-986
P0461 0461 FUEL LEVEL SENSOREC-988
P0462 0462 FUEL LEVL SEN/CIRCEC-990
P0463 0463 FUEL LEVL SEN/CIRCEC-990
P0500 0500
VEH SPEED SEN/CIRC*5EC-992
P0506 0506 ISC SYSTEM EC-994
P0507 0507 ISC SYSTEMEC-996
P0550 0550 PW ST P SEN/CIRCEC-998
P0603 0603 ECM BACK UP/CIRCUITEC-1003
P0605 0605 ECMEC-1007
P0643 0643 SENSOR POWER/CIRCEC-1009
P0700 0700 TCM AT- 1 0 1
P0705 0705 PNP SW/CIRCAT- 1 0 2
P0710 0710 ATF TEMP SEN/CIRCAT- 1 3 2
P0717 0717 TURBINE SENSORAT- 1 0 6
P0720 0720
VEH SPD SEN/CIR AT*5AT- 1 0 8
P0731 0731 A/T 1ST GR FNCTN AT- 11 4
P0732 0732 A/T 2ND GR FNCTNAT- 11 6
P0733 0733 A/T 3RD GR FNCTNAT- 11 8
P0734 0734 A/T 4TH GR FNCTNAT- 1 2 0
P0735 0735 A/T 5TH GR FNCTNAT- 1 2 2
P0740 0740 TCC SOLENOID/CIRCAT- 1 2 4
P0744 0744 A/T TCC S/V FNCTNAT- 1 2 6
P0745 0745 L/PRESS SOL/CIRCAT- 1 2 8
P0850 0850 P-N POS SW/CIRCUITEC-1014
P1140 1140 INTK TIM S/CIRC-B1EC-1019
P1145 1145 INTK TIM S/CIRC-B2EC-1019
P1148 1148 CLOSED LOOP-B1EC-1027
P1168 1168 CLOSED LOOP-B2EC-1027
P1211 1211 TCS C/U FUNCTNEC-1028
P1212 1212 TCS/CIRC EC-1029
P1217 1217 ENG OVER TEMPEC-1030
P1225 1225 CTP LEARNING-B1EC-1041
P1226 1226 CTP LEARNING-B1EC-1043
P1421 1421 COLD START CONTROLEC-1045
P1564 1564 ASCD SWEC-1047 (Models with ICC)
EC-1053
(Models with ASCD)
P1568 1568 ICC COMMAND VALUE*
6EC-1059
P1572 1572 ASCD BRAKE SW EC-1060 (Models with ICC)
EC-1068
(Models with ASCD)
DTC*
1
Items
(CONSULT-III screen terms) Reference page
CONSULT-III
GST*
2ECM*3
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-598
< SERVICE INFORMATION >[VK45DE]
INDEX FOR DTC
*1: 1st trip DTC No. is
the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-III.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*6: Models with ICC.
Alphabetical IndexINFOID:0000000001326484
P1574 1574 ASCD VHL SPD SEN EC-1075 (Models with ICC)
EC-1077
(Models with ASCD)
P1610 1610 LOCK MODE BL-4
P1611 1611 ID DISCARD, IMM-ECMBL-4
P1612 1612 CHAIN OF ECM-IMMU BL-4
P1614 1614 CHAIN OF IMMU-KEYBL-4
P1615 1615 DIFFERENCE OF KEYBL-4
P1715 1715 IN PULY SPEEDEC-1079
P1730 1730 A/T INTERLOCK AT- 1 3 9
P1752 1752 I/C SOLENOID/CIRCAT- 1 4 3
P1757 1757 FR/B SOLENOID/CIRCAT- 1 4 5
P1762 1762 D/C SOLENOID/CIRCAT- 1 4 7
P1767 1767 HLR/C SOL/CIRCAT- 1 4 9
P1772 1772 LC/B SOLENOID/CIRCAT- 1 5 1
P1774 1774 LC/B SOLENOID FNCTAT- 1 5 3
P1800 1800 VIAS S/V-1EC-1080
P1805 1805 BRAKE SW/CIRCUITEC-1084
P2100 2100 ETC MOT PWR-B1EC-1088
P2101 2101 ETC FNCTN/CIRC-B1EC-1092
P2103 2103 ETC MOT PWREC-1088
P2118 2118 ETC MOT-B1EC-1098
P2119 2119 ETC ACTR-B1 EC-1102
P2122 2122 APP SEN 1/CIRC EC-1104
P2123 2123 APP SEN 1/CIRCEC-1104
P2127 2127 APP SEN 2/CIRC E C - 111 0
P2128 2128 APP SEN 2/CIRCE C - 111 0
P2135 2135 TP SENSOR-B1E C - 111 6
P2138 2138 APP SENSOREC-1122
P2A00 2A00 A/F SENSOR1 (B1) EC-1129
P2A03 2A03 A/F SENSOR1 (B2)EC-1129
DTC*1
Items
(CONSULT-III screen terms) Reference page
CONSULT-III
GST*
2ECM*3
Items
(CONSULT-III screen terms) DTC*
1
Reference page
CONSULT-III
GST*
2ECM*3
A/F SEN1 HTR (B1) P0031 0031 EC-739
A/F SEN1 HTR (B1) P0032 0032EC-739
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

INDEX FOR DTCEC-599
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OA/F SEN1 HTR (B2) P0051 0051
EC-739
A/F SEN1 HTR (B2) P0052 0052EC-739
A/F SENSOR1 (B1) P0130 0130EC-798
A/F SENSOR1 (B1) P0131 0131EC-806
A/F SENSOR1 (B1) P0132 0132EC-814
A/F SENSOR1 (B1) P0133 0133EC-822
A/F SENSOR1 (B1) P2A00 2A00EC-1129
A/F SENSOR1 (B2) P0150 0150 EC-798
A/F SENSOR1 (B2) P0151 0151EC-806
A/F SENSOR1 (B2) P0152 0152EC-814
A/F SENSOR1 (B2) P0153 0153EC-822
A/F SENSOR1 (B2) P2A03 2A03EC-1129
A/T 1ST GR FNCTN P0731 0731 AT- 11 4
A/T 2ND GR FNCTN P0732 0732AT- 11 6
A/T 3RD GR FNCTN P0733 0733AT- 11 8
A/T 4THT GR FNCTN P0734 0734AT- 1 2 0
A/T 5TH GR FNCTN P0735 0735AT- 1 2 2
A/T INTERLOCK P1730 1730AT- 1 3 9
A/T TCC S/V FNCTN P0744 0744AT- 1 2 6
APP SEN 1/CIRC P2122 2122EC-1104
APP SEN 1/CIRC P2123 2123EC-1104
APP SEN 2/CIRC P2127 2127 E C - 111 0
APP SEN 2/CIRC P2128 2128E C - 111 0
APP SENSOR P2138 2138EC-1122
ASCD BRAKE SW P1572 1572EC-1060 (Models with ICC)
EC-1068
(Models with ASCD)
ASCD SW P1564 1564 EC-1047
(Models with ICC)
EC-1053
(Models with ASCD)
ASCD VHL SPD SEN P1574 1574 EC-1075
(Models with ICC)
EC-1077
(Models with ASCD)
ATF TEMP SEN/CIRC P0710 0710 AT- 1 3 2
BRAKE SW/CIRCUIT P1805 1805EC-1084
CAN COMM CIRCUIT U1000
1000*4EC-724
CAN COMM CIRCUIT U10011001*4EC-724
CHAIN OF ECM-IMMU P1612 1612 BL-4
CHAIN OF IMMU-KEY P1614 1614BL-4
CKP SEN/CIRCUIT P0335 0335EC-906
CLOSED LOOP-B1 P1148 1148EC-1027
CLOSED LOOP-B2 P1168 1168EC-1027
CMP SEN/CIRC-B1 P0340 0340 EC-911
COLD START CONTROL P1421 1421EC-1045
CONTROL UNIT(CAN) U1010 1010 EC-726
CTP LEARNING-B1 P1225 1225EC-1041
Items
(CONSULT-III screen terms) DTC*
1
Reference page
CONSULT-III
GST*
2ECM*3
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-600
< SERVICE INFORMATION >[VK45DE]
INDEX FOR DTC
CTP LEARNING-B1 P1226 1226
EC-1043
CYL 1 MISFIRE P0301 0301 EC-895
CYL 2 MISFIRE P0302 0302EC-895
CYL 3 MISFIRE P0303 0303EC-895
CYL 4 MISFIRE P0304 0304EC-895
CYL 5 MISFIRE P0305 0305EC-895
CYL 6 MISFIRE P0306 0306EC-895
CYL 7 MISFIRE P0307 0307EC-895
CYL 8 MISFIRE P0308 0308EC-895
D/C SOLENOID/CIRC P1762 1762 AT- 1 4 7
DIFFERENCE OF KEY P1615 1615 BL-4
ECM P0605 0605EC-1007
ECM BACK UP/CIRCUIT P0603 0603EC-1003
ECT SEN/CIRC P0117 0117 EC-779
ECT SEN/CIRC P0118 0118EC-779
ECT SENSOR P0125 0125EC-790
ENG OVER TEMP P1217 1217EC-1030
ETC ACTR-B1 P2119 2119 EC-1102
ETC FNCTN/CIRC-B1 P2101 2101EC-1092
ETC MOT-B1 P2118 2118EC-1098
ETC MOT PWR-B1 P2100 2100EC-1088
ETC MOT PWR P2103 2103EC-1088
EVAP GROSS LEAK P0455 0455 EC-973
EVAP PURG FLOW/MON P0441 0441EC-921
EVAP SMALL LEAK P0442 0442EC-926
EVAP SYS PRES SEN P0451 0451EC-957
EVAP SYS PRES SEN P0452 0452EC-960
EVAP SYS PRES SEN P0453 0453EC-966
EVAP VERY SML LEAK P0456 0456EC-979
FR/B SOLENOID/CIRC P1757 1757 AT- 1 4 5
FTT SEN/CIRCUIT P0182 0182EC-885
FTT SEN/CIRCUIT P0183 0183EC-885
FTT SENSOR P0181 0181EC-881
FUEL LEV SEN SLOSH P0460 0460EC-986
FUEL LEVEL SENSOR P0461 0461EC-988
FUEL LEVL SEN/CIRC P0462 0462EC-990
FUEL LEVL SEN/CIRC P0463 0463EC-990
FUEL SYS-LEAN-B1 P0171 0171EC-861
FUEL SYS-LEAN-B2 P0174 0174EC-861
FUEL SYS-RICH-B1 P0172 0172EC-871
FUEL SYS-RICH-B2 P0175 0175EC-871
HLR/C SOL/CIRC P1767 1767 AT- 1 4 9
Items
(CONSULT-III screen terms) DTC*
1
Reference page
CONSULT-III
GST*
2ECM*3
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

INDEX FOR DTCEC-601
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OHO2S2 (B1) P0137 0137
EC-831
HO2S2 (B1) P0138 0138EC-840
HO2S2 (B1) P0139 0139EC-852
HO2S2 (B2) P0157 0157EC-831
HO2S2 (B2) P0158 0158EC-840
HO2S2 (B2) P0159 0159EC-852
HO2S2 HTR (B1) P0037 0037EC-746
HO2S2 HTR (B1) P0038 0038EC-746
HO2S2 HTR (B2) P0057 0057EC-746
HO2S2 HTR (B2) P0058 0058EC-746
I/C SOLENOID/CIRC P1752 1752 AT- 1 4 3
IAT SEN/CIRCUIT-B1 P0112 0112EC-775
IAT SEN/CIRCUIT-B1 P0113 0113EC-775
IAT SENSOR-B1 P0127 0127EC-793
ICC COMMAND VALUE*6P1568 1568EC-1059
ID DISCORD, IMM-ECM P1611 1611 BL-4
IN PULY SPEED P1715 1715EC-1079
INT/V TIM CONT-B1 P0011 0011 EC-727
INT/V TIM CONT-B2 P0021 0021EC-727
INT/V TIM V/CIR-B1 P0075 0075EC-754
INT/V TIM V/CIR-B2 P0081 0081EC-754
INTK TIM S/CIRC-B1 P1140 1140EC-1019
INTK TIM S/CIRC-B2 P1145 1145EC-1019
ISC SYSTEM P0506 0506 EC-994
ISC SYSTEM P0507 0507EC-996
KNOCK SEN/CIRC-B1 P0327 0327EC-902
KNOCK SEN/CIRC-B1 P0328 0328EC-902
KNOCK SEN/CIRC-B2 P0332 0332EC-902
KNOCK SEN/CIRC-B2 P0333 0333EC-902
L/PRESS SOL/CIRC P0745 0745 AT- 1 2 8
LC/B SOLENOID FNCT P1774 1774AT- 1 5 3
LC/B SOLENOID/CIRC P1610 1610 BL-4
LOCK MODE P1772 1772AT- 1 5 1
MAF SEN/CIRCUIT-B1 P0101 0101EC-761
MAF SEN/CIRCUIT-B1 P0102 0102EC-768
MAF SEN/CIRCUIT-B1 P0103 0103EC-768
MULTI CYL MISFIRE P0300 0300EC-895
NATS MALFUNCTION P1610 - P1615 1610 - 1615EC-631
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000 —
P-N POS SW/CIRCUIT P0850 0850 EC-1014
PNP SW/CIRC P0705 0705 AT- 1 0 2
Items
(CONSULT-III screen terms) DTC*
1
Reference page
CONSULT-III
GST*
2ECM*3
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-602
< SERVICE INFORMATION >[VK45DE]
INDEX FOR DTC
*1: 1st trip DTC No. is
the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-III.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*6: Models with ICC. PURG VOLUME CONT/V P0443 0443
EC-933
PURG VOLUME CONT/V P0444 0444EC-940
PURG VOLUME CONT/V P0445 0445EC-940
PW ST P SEN/CIRC P0550 0550EC-998
SENSOR POWER/CIRC P0643 0643EC-1009
TCC SOLENOID/CIRC P0740 0740 AT- 1 2 4
TCM P0700 0700AT- 1 0 1
TCS C/U FUNCTN P1211 1211EC-1028
TCS/CIRC P1212 1212EC-1029
THERMSTAT FNCTN P0128 0128 EC-796
TP SEN 1/CIRC-B1 P0222 0222EC-889
TP SEN 1/CIRC-B1 P0223 0223EC-889
TP SEN 2/CIRC-B1 P0122 0122EC-784
TP SEN 2/CIRC-B1 P0123 0123EC-784
TP SENSOR-B1 P2135 2135E C - 111 6
TURBINE SENSOR P0717 0717 AT- 1 0 6
TW CATALYST SYS-B1 P0420 0420EC-917
TW CATALYST SYS-B2 P0430 0430EC-917
VEH SPD SEN/CIR AT*5P0720 0720AT- 1 0 8
VEH SPEED SEN/CIRC*5P0500 0500EC-992
VENT CONTROL VALVE P0447 0447 EC-946
VENT CONTROL VALVE P0448 0448EC-951
VIAS S/V-1 P1800 1800EC-1080
Items
(CONSULT-III screen terms) DTC*
1
Reference page
CONSULT-III
GST*
2ECM*3
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

PRECAUTIONSEC-603
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001612919
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SUPPLEMENTAL RESTRAINT SYS-
TEM” and “SEAT BELTS” of this Service Manual.
WARNING:
 To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SUPPLEMEN TAL RESTRAINT SYSTEM”.
 Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
Precaution for Procedur e without Cowl Top CoverINFOID:0000000001612941
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
On Board Diagnosis (OBD) System of Engine and A/TINFOID:0000000001326487
The ECM has an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:
 Be sure to turn the ignition switch OFF and di sconnect the negative battery cable before any repair
or inspection work. The op en/short circuit of related switches, sensors, solenoid valves, etc. will
cause the MIL to light up.
 Be sure to connect and lock the connectors secure ly after work. A loose (unlocked) connector will
cause the MIL to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)
 Certain systems and components, especially those related to OBD, may use a new style slide-lock-
ing type harness connector. For descripti on and how to disconnect, refer to PG-68
.
 Be sure to route and secure the harnesses properly after work. The interference of the harness with
a bracket, etc. may cause the MIL to li ght up due to the short circuit.
 Be sure to connect rubber tubes properly afte r work. A misconnected or disconnected rubber tube
may cause the MIL to light up due to the malfuncti on of the EVAP system or fuel injection system,
etc.
 Be sure to erase the unnecessary ma lfunction information (repairs completed) from the ECM and
TCM (Transmission control module) before returning the vehicle to the customer.
PIIB3706J
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

PRECAUTIONSEC-605
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O

Before replacing ECM, perform ECM Terminals and Reference
Value inspection and make sure ECM functions properly.
Refer to EC-687
.
 Handle mass air flow sensor carefully to avoid damage.
 Do not disassemble mass air flow sensor.
 Do not clean mass air flow senso r with any type of detergent.
 Do not disassemble electric th rottle control actuator.
 Even a slight leak in the air intake system can cause serious
incidents.
 Do not shock or jar the camsh aft position sensor (PHASE),
crankshaft position sensor (POS).
 After performing each TROUBL E DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displ ayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.
 When measuring ECM signals with a circuit tester, never allow
the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.
 Do not use ECM ground termina ls when measuring input/out-
put voltage. Doing so may result in damage to the ECM's tran-
sistor. Use a ground other than ECM terminals, such as the
ground.
MEF040D
SEF217U
SEF348N
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
