DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT
DTC P1710 A/T FLUID TEMPER ATURE SENSOR CIRCUIT
DescriptionINFOID:0000000001327233
The A/T fluid temperature sensor detects the A/ T fluid temperature and sends a signal to the TCM.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001327234
On Board Diagnosis LogicINFOID:0000000001327235
Diagnostic trouble code “P1710 (A/T), P0710 (ENGINE) ATF TEMP SEN/CIRC” with CONSULT-III or 10th
judgement flicker without CONSULT-III is detected w hen TCM receives an excessively low or high voltage
from the sensor.
Possible CauseINFOID:0000000001327236
 Harness or connectors (Sensor circuit is open or shorted.)
 A/T fluid temperature sensors 1 and/or 2
DTC Confirmation ProcedureINFOID:0000000001327237
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following proc edure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “VHCL/S SE-A/T”, “ACCELE POSI” and “SLCT LVR POSI”.
3. Touch “START”.
4. Start engine and maintain the following conditions for at least 10 minutes (Total). (It is not necessary to maintain continuously.)
VHCL/S SE-A/T: 10 km/h (6 MPH) or more
ACCELE POSI: More than 1.0/8
SLCT LVR POSI: “D” position
5. If DTC is detected, go to AT-133, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Item name Condition °C ( °F) Display value (Approx.)
ATF TEMP SE 1 0 (32) - 20 (68) - 80 (176) 3.3 - 2.7 - 0.9 V
ATF TEMP SE 2 3.3 - 2.5 - 0.7 V
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DTC P1731 A/T 1ST ENGINE BRAKING
AT-141
< SERVICE INFORMATION >
D E
F
G H
I
J
K L
M A
B
AT
N
O P
DTC P1731 A/T 1ST ENGINE BRAKING
DescriptionINFOID:0000000001327253
Fail-safe function to prevent sudden decrease in speed by engine brake other than at M1 position.
CONSULT-III Reference Value in Data Monitor ModeINFOID:0000000001327254
On Board Diagnosis LogicINFOID:0000000001327255
Diagnostic trouble code “P1731 A/T 1ST E/BRAKING” with CONSULT-III or 13th judgement flicker without
CONSULT-III is detected under the following conditions.
 When TCM does not receive the proper voltage signal from the sensor.
 When TCM monitors each ATF pressure switch and sol enoid monitor value, and detects as irregular when
engine brake of 1st gear acts other than at M1 position.
Possible CauseINFOID:0000000001327256
 Harness or connectors
(Sensor circuit is open or shorted.)
 Low coast brake solenoid valve
 ATF pressure switch 2
DTC Confirmation ProcedureINFOID:0000000001327257
CAUTION:
 Always drive vehicle at a safe speed.
 Be careful not to rev engine into red zone on the tachometer.
NOTE:
If “DTC Confirmation Procedure” has been previously preformed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “ENGINE SPEED”, “MANU MODE SW” and “GEAR”.
3. Touch “START”.
4. Start engine.
5. Drive vehicle and maintain the following conditions for at least 2 consecutive seconds. ENGINE SPEED: 1,200 rpm
MANU MODE SW: ON
GEAR: “1” position
6. If DTC is detected, go to AT-141, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001327258
1.CHECK INPUT SIGNALS
With CONSULT-III
1. Start the engine.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III.
3. Drive vehicle in the “M” position (1st gear), and conf irm the ON/OFF actuation of “ATF PRES SW 2” and
“ON OFF SOL”.
Item name Condition Display value
ON OFF SOL Low coast brake engaged. Refer to
AT- 1 8
.ON
Low coast brake disengaged. Refer to AT- 1 8
.OFF
ATF PRES SW 2 Low coast brake engaged. Refer to
AT- 1 8
.ON
Low coast brake disengaged. Refer to AT- 1 8
.OFF
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

DTC P1752 INPUT CLUTCH SOLENOID VALVEAT-143
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
DTC P1752 INPUT CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000001327259
Input clutch solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehicle
speed sensor and accelerator pedal positi on sensor (throttle position sensor). Gears will then be shifted to the
optimum position.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000001327260
On Board Diagnosis LogicINFOID:0000000001327261
Diagnostic trouble code “P1752 I/C SOLENOID/CIRC” wit h CONSULT-III or 5th judgement flicker without
CONSULT-III is detected under the following conditions.
 When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
 When TCM detects as irregular by comparing target value with monitor value.
Possible CauseINFOID:0000000001327262
 Harness or connectors
(Solenoid circuit is open or shorted.)
 Input clutch solenoid valve
DTC Confirmation ProcedureINFOID:0000000001327263
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “ACCELE POSI”, “SLCT LVR POSI” and “GEAR”.
3. Touch “START”.
4. Start engine.
5. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds. ACCELE POSI: 1.5/8 - 2.0/8
SLCT LVR POSI: “D” position
GEAR: “3” ⇒ “4” (I/C ON/OFF)
Driving location: Driving the vehic le uphill (increased engine load) will help maintain the driving
conditions required for this test.
6. If DTC is detected go to AT-143, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001327264
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Start the engine.
Item name Condition Display value (Approx.)
I/C SOLENOID Input clutch disengaged. Refer to
AT- 1 8
. 0.6 - 0.8 A
Input clutch engaged. Refer to AT- 1 8
.0 - 0.05 A
:

DTC P1757 FRONT BRAKE SOLENOID VALVEAT-145
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
DTC P1757 FRONT BRAKE SOLENOID VALVE
DescriptionINFOID:0000000001327271
Front brake solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehicle
speed sensor and accelerator pedal positi on sensor (throttle position sensor). Gears will then be shifted to the
optimum position.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000001327272
On Board Diagnosis LogicINFOID:0000000001327273
Diagnostic trouble code “P1757 FR/B SO LENOID/CIRC” with CONSULT-III or 6th judgement flicker without
CONSULT-III is detected under the following conditions.
 When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
 When TCM detects as irregular by comparing target value with monitor value.
Possible CauseINFOID:0000000001327274
 Harness or connectors
(Solenoid circuit is open or shorted.)
 Front brake solenoid valve
DTC Confirmation ProcedureINFOID:0000000001327275
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “ACCELE POSI”, “SLCT LVR POSI” and “GEAR”.
3. Touch “START”.
4. Start engine.
5. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds. ACCELE POSI: 1.5/8 - 2.0/8
SLCT LVR POSI: “D” position
GEAR: “3” ⇒ “4” (FR/B ON/OFF)
Driving location: Driving the vehic le uphill (increased engine load) will help maintain the driving
conditions required for this test.
6. If DTC is detected go to AT-145, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001327276
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Start engine.
Item name Condition Display value (Approx.)
FR/B SOLENOID Front brake engaged. Refer to
AT- 1 8
. 0.6 - 0.8 A
Front brake disengaged. Refer to AT- 1 8
.0 - 0.05 A
:

DTC P1762 DIRECT CLUTCH SOLENOID VALVE
AT-147
< SERVICE INFORMATION >
D E
F
G H
I
J
K L
M A
B
AT
N
O P
DTC P1762 DIRECT CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000001327283
Direct clutch solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehicle
speed sensor and accelerator pedal positi on sensor (throttle position sensor). Gears will then be shifted to the
optimum position.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000001327284
On Board Diagnosis LogicINFOID:0000000001327285
Diagnostic trouble code “P1762 D/C SOLENOID/CIRC” with CONSULT-III or 2nd judgement flicker without
CONSULT-III is detected under the following conditions.
 When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
 When TCM detects as irregular by comparing target value with monitor value.
Possible CauseINFOID:0000000001327286
 Harness or connectors
(Solenoid circuit is open or shorted.)
 Direct clutch solenoid valve
DTC Confirmation ProcedureINFOID:0000000001327287
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “ACCELE POSI”, “SLCT LVR POSI” and “GEAR”.
3. Touch “START”.
4. Start engine.
5. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds. ACCELE POSI: 1.5/8 - 2.0/8
SLCT LVR POSI: “D” position
GEAR: “1” ⇒ “2” (D/C ON/OFF)
Driving location: Driving the vehic le uphill (increased engine load) will help maintain the driving
conditions required for this test.
6. If DTC is detected, go to AT-147, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001327288
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Start the engine.
Item name Condition Display value (Approx.)
D/C SOLENOID Direct clutch disengaged. Refer to
AT- 1 8
. 0.6 - 0.8 A
Direct clutch engaged. Refer to AT- 1 8
.0 - 0.05 A
:

DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE
AT-149
< SERVICE INFORMATION >
D E
F
G H
I
J
K L
M A
B
AT
N
O P
DTC P1767 HIGH AND LOW REVER SE CLUTCH SOLENOID VALVE
DescriptionINFOID:0000000001327295
High and low reverse clutch solenoid valve is controlled by the TCM in response to signals sent from the PNP
switch, vehicle speed sensor and accelerator pedal positi on sensor (throttle position sensor). Gears will then
be shifted to the optimum position.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000001327296
On Board Diagnosis LogicINFOID:0000000001327297
Diagnostic trouble code “P1767 HLR/C SOL/CIRC” with CO NSULT-III or 8th judgement flicker without CON-
SULT-III is detected under the following conditions.
 When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
 When TCM detects as irregular by comparing target value with monitor value.
Possible CauseINFOID:0000000001327298
 Harness or connectors
(Solenoid circuit is open or shorted.)
 High and low reverse clutch solenoid valve
DTC Confirmation ProcedureINFOID:0000000001327299
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “ACCELE POSI”, “SLCT LVR POSI” and “GEAR”.
3. Touch “START”.
4. Start engine.
5. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds. ACCELE POSI: 1.5/8 - 2.0/8
SLCT LVR POSI: “D” position
GEAR: “2” ⇒ “3” (HLR/C ON/OFF)
Driving location: Driving the vehic le uphill (increased engine load) will help maintain the driving
conditions required for this test.
6. If DTC is detected, go to AT-149, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001327300
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON.
2. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Start the engine.
Item name Condition Display value (Approx.)
HLR/C SOL High and low reverse clutch disengaged. Refer to
AT- 1 8
. 0.6 - 0.8 A
High and low reverse clutch engaged. Refer to AT- 1 8
.0 - 0.05 A
:

DTC P1772 LOW COAST BRAKE SOLENOID VALVE
AT-151
< SERVICE INFORMATION >
D E
F
G H
I
J
K L
M A
B
AT
N
O P
DTC P1772 LOW COAST BRAKE SOLENOID VALVE
DescriptionINFOID:0000000001327307
Low coast brake solenoid valve is turned ON or OFF by the TCM in response to signals sent from the PNP
switch, vehicle speed sensor and accelerator pedal positi on sensor (throttle position sensor). Gears will then
be shifted to the optimum position.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000001327308
On Board Diagnosis LogicINFOID:0000000001327309
Diagnostic trouble code “P1772 LC/B SOLENOID/CIRC” with CONSULT-III or 7th judgement flicker without
CONSULT-III is detected when TCM detects an improper voltage drop when it tries to operate the solenoid
valve.
Possible CauseINFOID:0000000001327310
 Harness or connectors
(Solenoid circuit is open or shorted.)
 Low coast brake solenoid valve
DTC Confirmation ProcedureINFOID:0000000001327311
NOTE:
If “DTC Confirmation Procedure” has been previously performed, alw ays turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III
and check monitor “MANU MODE SW” and “GEAR”.
3. Touch “START”.
4. Start engine.
5. Drive vehicle and maintain the following conditions for at least 5 consecutive seconds.
MANU MODE SW: ON
GEAR: “1” or “2” (LC/B ON/OFF)
6. If DTC is detected, go to AT-151, "
Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III”.
Diagnosis ProcedureINFOID:0000000001327312
1.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON.
2. Select “SELECTION FROM MENU” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III.
3. Start engine.
4. Read out the value of “ON OFF SOL” while driving.
Item name Condition Display value
ON OFF SOL Low coast brake engaged. Refer to
AT- 1 8
.ON
Low coast brake disengaged. Refer to AT- 1 8
.OFF
Item name Condition Display value
ON OFF SOLLow coast brake engaged. Refer to
AT- 1 8
.ON
Low coast brake disengaged. Refer to AT- 1 8
.OFF
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISBRC-31
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
 When active test is performed while depressing, t he pedal depression amount will change. This is normal.
 “TEST IS STOPPED” is displayed 10 seconds after operation start.
 After “TEST IS STOPPED” is displayed, touch “BACK” and perform test again.
TEST ITEM
Solenoid Valve
NOTE:
The example shown is for the front right wheel. The procedure for the other wheels is the same as given
below.
 When performing an active test of the ABS function, se lect the main item for each test item. In addition,
when performing an active test of the VDC/TCS function, select the item menu for each test item.
 For the ABS solenoid valve, touch “UP” “KEEP” “DOWN”, and for the ABS solenoid valve (ACT), touch “UP”
“ACTUATOR UP” “ACTUATOR KEEP”, and check to make su re that all solenoid valve (in, out) are operating
as given in the table below.
*: ON for 1 to 2 seconds after the touch, and then OFF
ABS Motor
Touch “ON” and “OFF” on the screen. Make sure AB S motor relay operates as shown in table below.
For Fast and Accurate DiagnosisINFOID:0000000001327675
PRECAUTIONS FOR DIAGNOSIS
 Before performing diagnosis, always read precautions. Refer to BRC-13, "How to Proceed with Diagnosis".
 If ABS actuator and electric unit (control unit), steer ing angle sensor, steering system parts or suspension
system parts have been replaced, or if alignment has been adjusted, be sure to adjust neutral position of
steering angle sensor before driving. Refer to BRC-8, "
Adjustment of Steering Angle Sensor Neutral Posi-
tion".
 After diagnosis is finished, be sure to erase memory. Refer to BRC-26, "
Self-Diagnosis".
 When checking continuity and voltage between units, be sure to check for disconnection, looseness, bend,
or collapse of connector terminals. If any malfuncti on is found, repair or replace connector terminals.
 For intermittent symptoms, possible cause is malfunc tion in harness, harness connector, or terminals. Move
harness, harness connector, and terminals to check for poor connections.
 If a circuit tester is used for the check, be ca reful not to forcibly extend any connector terminal.
 To use CONSULT-III to perform self-diagnosis of ABS act uator and electric unit (control unit), active tests, or
work support, first stop work, then connect CONSULT-III and select “ABS”.
 While self-diagnostic results of CONSULT-III shows malf unction, if CONSULT-III active test is performed, an
engine system error may be indicated. In this case, start engine to resume the normal screen.
 VDC/TCS/ABS system electronica lly controls brake operation and engine output. The following symptoms
may be caused by normal operations:
Operation ABS solenoid valve ABS so
lenoid valve (ACT)
UP KEEP DOWN UP ACTUATOR
UP ACTUATOR
KEEP
FR RH IN SOL OFF ON ON OFF OFF OFF
FR RH OUT SOL OFF OFF ON* OFF OFF OFF
CV 1 OFF OFF OFF OFF ON ON
SV 1 OFF OFF OFF OFF ON* OFF
Operation ON OFF
MOTOR RELAY ON OFF
ACTUATOR RLY ON ON
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
