2008 HONDA CIVIC COUPE TPMS

Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.
The ABS and VSA system (if
equipped) work by comparing the
speed of each wheel. When replacing
tires, use the same size originally
supplied with the vehicle. Tire size
and construction can affect wheel
speed and may cause the system to
activate.It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
If you ever replace a wheel, make
sure that the wheel’s specif ications
match those of the original wheels.
Also be sure you use only TPMS
specif ic wheels. If you do not, the
tire pressure monitoring system will
not work.
Replacement wheels are available at
your dealer.
On vehicles with TPMS
Tires
Replacing T ires and Wheels
Maint enance
261
Installing improper tires on your
vehicle can affect handling and
stability. This can cause a crash
in which you can be seriously
hurt or killed.
Always use the size and type of
tires recommended in this
owner’s manual.
——

y
y
(+yy

µµ µ µ µ µµµ
Î
Î
Î Î
Î
Î
No. Amps. No. Amps. Circuits Protected No. Circuits Protected
Amps.
Circuits Protected
12345678 7.5 A
15 A
10 A
7.5 A
(15 A)
(20 A) 7.5 A 9
10111213141516 7.5 A
7.5 A
10 A
10 A
10 A
7.5 A
7.5 A 10 A ODS (Occupant Detection
System)
Meter
SRS
Right Headlight High Beam
Left Headlight High Beam
Small Lights (Interior)
Small Lights (Exterior)
Right Headlight Low Beam 1718192021222324252627282930 31 32333435363738
If equipped Left Headlight Low Beam
Headlight High Beam Main
Small Lights Main
Not Used
Headlight Low Beam Main
Not Used
Not Used
Moonroof
Door Lock
Driver’s Power Window
HAC Option
Rear Accessory Socket
Accessory
Front Passenger’s Power
Window
Not Used
Not Used
Not Used
Not Used
Accessory, Radio
IG2 HAC
Daytime Running Lights
Front Wiper
10 A
20 A
15 A
20 A
(20 A) 20 A
20 A
(20 A)
(15 A) 15 A
20 A
7.5 A 10 A
7.5 A 30 A
Power Window
Fuel Pump
IG1 ACG
ABS/VSA
Heated Seats
Front Fog Lights
TPMS
Not Used
:
Fuse Locations
T aking Care of t he Unexpect ed
289
INTERIOR FUSE BOX
——
y
y
(+yy

µ
Always check the TPMS malf unction
telltale af ter replacing one or more
tires or wheels on your vehicle to
ensure that the replacement or
alternate tires and wheels allow the
TPMS to continue to f unction
properly.
Your vehicle has also been equipped
with a TPMS malf unction indicator
to indicate when the system is not
operating properly. The TPMS
malf unction indicator is provided by
a separate telltale, which displays the
symbol ‘‘TPMS’’ when illuminated.
When the malf unction indicator is
illuminated,
the system may not be able to detect
or signal low tire pressure as
intended.
TPMS malf unctions may occur f or a
variety of reasons, including the
installation of replacement or
alternate tires or wheels on the
vehicle that prevent the TPMS f rom
f unctioning properly.
Tire Pressure Monitoring System (TPMS) Required Federal Explanat
ion
304
——

y

y
(+yy

µ
Accordingly, when the low tire
pressure telltale illuminates, you
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure.Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Please note that the TPMS is not a
substitute for proper tire
maintenance, and it is the driver’s
responsibility to maintain correct tire
pressure, even if under-inf lation has
not reached the level to trigger
illumination of the TPMS low tire
pressure telltale.
As an added safety feature, your
vehicle has been equipped with a tire
pressure monitoring system (TPMS)
that illuminates a low tire pressure
telltale
when one or more of your tires is
signif icantly under-inf lated.
(If your vehicle has tires of a
dif f erent size than the size indicated
on the vehicle placard or tire
inf lation pressure label, you should
determine the proper tire inf lation
pressure f or those tires.)
Each tire, including the spare (if
provided), should be checked
monthly when cold and inf lated to
the inf lation pressure recommended
by the vehicle manuf acturer on the
vehicle placard or tire inf lation
pressure label.
CONT INUED
U.S. models only
Tire Pressure Monitoring System (TPMS) Required Federal Explanat
ion
T echnical Inf ormation
303
—
—y


y
(+yy

CONT INUED
.................
Jacking up the Vehicle . 272
.......................................
Jack, Tire . 271
................................
Jump Starting . 277
..................................................
Keys . 76
.......................
Label, Certif ication . 294
.................
Lane Change, Signaling . 72
..................
Lap/Shoulder Belts . 14, 19
...............................
LATCH System . 41 Lights
....................
Bulb Replacement . 246
...............................
Indicators . 55, 57
.........................................
Parking . 72
..................................
Turn Signal . 72
....................................
Load Limits . 198
......
LOCK (Ignition Key Position) . 78
Locks
.......
Anti-thef t Steering Column . 78
............................
Fuel Fill Door . 187
.................................
Power Door . 80
...........................................
Trunk . 90
........................
Low Coolant Level . 191
.........................
Low Fuel Indicator . 64
...
Low Oil Pressure Indicator . 57, 281
................................
Lower Anchors . 41
...
Lower Gear, Downshif ting to a . 205
...
Lubricant Specif ications Chart . 297
...........
Luggage, Storing (Cargo) . 197
Indicators
...............................................
EPS . 60
...................................
High Beam . 63
........
Key (Immobilizer System) . 59
....................................
Lights ON . 63
......................................
Low Fuel . 64
................
Low Oil Pressure . 57, 281
..............
Low Tire Pressure . 61, 218
..........
Maintenance Minder . 60, 225
....................
Malf unction Lamp . 282
....................................
REV Limit . 61
..........................
Security System . 64
...........................
Side Airbag Of f . 58
...............................................
SRS . 58
...................................
TPMS . 61, 219
.................................
Trunk Open . 63
Turn Signal and Hazard
...................................
Warning . 59
..............................
Washer Level . 63
Indicators, Instrument .......................................
Panel . 55, 57
...............................
Inf ant Restraint . 37
Inf ant Seats
......................................
Installing . 40
................
Tether Anchor Points . 45
...................
Inf lation, Proper Tire . 255 ........................
Inf ormation Display . 65
.................................
Inside Mirror . 104
.............................
Inspection, Tire . 258
....................
Installing a Child Seat . 40
........................
Instrument Panel . 3, 54
........
Instrument Panel Brightness . 73
................
Instrument and Controls . 53
...............................
Interior Lights . 111
........................................
Introduction . i
Index
INDEX
J K L
V
——

y
y
(+yy

Î
Î
Unexpected, Taking Care ..........................................
of the . 269 ..
Unif orm Tire Quality Grading . 299
........................
Unleaded Gasoline . 186
.......
Used Oil, How to Dispose of . 238
......................
Using a Booster Seat . 47
..........................
Time, Setting the . 180
....................................
Tire Chains . 263
.........
Tire, How to Change a Flat . 271
Tire Pressure Monitoring
........................
System (TPMS) . 218
...............................................
Tires . 255
......................
Air Pressure . 255, 257
........................................
Chains . 263
.........................
Checking Wear . 258
..........................
Compact Spare . 270
......
DOT Tire Quality Grading . 299
......................................
Inf lation . 255
..................................
Inspection . 258
.....................................
Labeling . 301
Low Tire Pressure
...........................
Indicator . 61, 218
..............................
Maintenance . 259
...................................
Replacing . 261
......................................
Rotating . 260
................................
Service Lif e . 258
...........................................
Snow . 263
............................
Specif ications . 298
...................
Summer Tires . 257, 262
.........................................
TPMS . 218
...........................................
Wear . 260
.......................................
Wheels . 264 ...................
Tools, Tire Changing . 271
Towing
.....................................
A Trailer . 221
................
Emergency Wrecker . 290
Transmission Checking Fluid Level, ..............................
Automatic . 242
Checking Fluid Level,
...................................
Manual . 243
..................
Fluid Selection . 242, 243
..............
Identif ication Number . 295
.............
Shif ting the Automatic . 208
..................
Shif ting the Manual . 205
...................................
Treadwear . 299
...................
Treadwear Indicators . 258
.......................................
Trip Meter . 66
................................................
Trunk . 90
....................
Emergency Opener . 91
........................................
Opening . 90
............................
Open Indicator . 63
....................................
Turn Signals . 72 ................................
Vanity Mirror . 109
.................
Vehicle Capacity Load . 198
......................
Vehicle Dimensions . 296
....
Vehicle Identif ication Number . 294
.............................
Vehicle Storage . 267
.....................................
Ventilation . 116
.................................................
VIN . 294
..................................
Viscosity, Oil . 235
.............
WARNING, Explanation of . ii
................
Warning Button, Hazard . 74
.........
Warning Labels, Location of . 51
....................
Warranty Coverages . 313
