GETTING TO KNOW YOUR CAR
10
1.Side vents
2.Left-hand stalk: headlight control
3.Horn
4.Instrument panel: odometer display and warning lights
5.Right-hand stalk, windscreen washer, rear window
washer and trip computer
6.Gear lever
7.Central vents
8.Revolution counter
9.Speedometer
10.Fuel gauge with low fuel warning light and engine
coolant temperature gauge with warning light showing
when the temperature is too high
11.Sound system/Infotelematic Connect system display
(where fitted)
12.Sound system/Infotelematic Connect system (where
fitted)
13.Passenger air bag14.Glove compartment
15.Climate system automatic controls
16.Hazard lights
17.Cigar lighter
18.Glove compartment/Infotelematic Connect system re-
mote controls (where fitted)
19.Console
20.Ashtray and glove compartment
21.Ignition switch
22.Sound system controls on steering wheel
23.Document compartment
24.Driver air bag
25.Cruise control control lever
26.Headlight beam adjuster (Xeno light versions excluded)
27.ASR system on/off.

GETTING TO KNOW YOUR CAR
50
INSTRUMENTSA -Odometer display: speedometer,
kilometre counter, maintenance indi-
cator, engine oil level gauge (where fit-
ted) and, for versions with automatic
gear, engaged gear indicator and sym-
bol for presence of ice on the road, if
any.
B -Warning lights
C -Trip kilometre counter reset
button
D -Button for instrument panel
brightness adjustment
fig. 74F0B0412b
fig. 75F0B0413b

GETTING TO KNOW YOUR CAR
54
ODOMETER DISPLAY
This instrument displays the follow-
ing values:
on the upper line:partial kilome-
tres and engine oil level gauge (where
fitted)
on the lower line:total kilometres
and programmed maintenance indica-
tor; versions with automatic gear are
also fitted with engaged gear indicator
(for further details see the chapter
“Automatic gear”).
Trip kilometre counter fig. 80
Press button Ato display the trip
kilometres. Keep it pressed to reset.Engine oil level gauge
(where fitted)
After turning the ignition key to M,
this indicator first displays the kilo-
metres to be reached before carrying
out the next maintenance operation
and then displays the engine oil level
in the engine sump for a limited time.
Fig. 81shows the correct oil level
condition. Flashing of the wording
“OIL”, together with the sound of the
buzzer and the dedicated message in-
dicate low engine oil level. Flashing of
wording “OIL –“ indicates an engine
oil level sensor failure.
fig. 80
F0B0244b
fig. 81
F0B0415b
fig. 82
F0B0246b
Scheduled maintenance
indicator fig. 82
The maintenance indicator uses
warning lamp Aand kilometre
counter Bto indicate when oil and oil
filter are to be replaced in accordance
with the service schedule. To keep the
warranty valid, go to a Fiat Dealer-
ship(see also the “Car maintenance”
chapter).

GETTING TO KNOW YOUR CAR
89
Memorisation of a speed: (only in
4thor 5thgear and at speeds above
40 km/h): Move lever Ato ON, the
current speed of the vehicle is main-
tained and memorised and wording
“ON” under the speedometer symbol
will turn on, on the odometer display.
If necessary, the speed set may be in-
creased by pressing the accelerator
pedal (e.g. when overtaking); when the
pedal is released the system will return
the speed of the vehicle to that mem-
orised previously.
Acceleration or deceleration
(using lever only): when the vehicle
is travelling at an automatic regulated
speed, move the lever Bto deceler-
ate or Cto accelerate.
Disengagement of the device:
press button Don the lever edge.
The device will switch itself off au-
tomatically when the brake or clutch
pedal is pressed.Restoring the memorised speed:
after pressing the brake or clutch ped-
al or after the device has been disen-
gaged, press button Dto restore the
last speed memorised.
Memory deletion:turn button
from ON to OFF to clear all the mem-
ories.
IMPORTANTUse the speed con-
trol system only when the traffic or
road conditions make it possible to
maintain a constant speed.MANUAL GEARBOX
To engage the gears, press down the
clutch and put the gear lever into one
of the positions shown in the diagram
on the gear lever knob.
IMPORTANTTo put the vehicle
in reverse, the vehicle must be sta-
tionary. Then with the engine running,
shift into reverse and wait at least
2 seconds with the clutch pedal
pressed fully to avoid scraping and
damaging the gears and back.
fig. 109
F0B0073b

RIGHT-HAND DRIVE VERSIONS
235
1.Side vents
2.Passenger air bag
3.Sound system/Infotelematic Connect system (where
fitted)
4.Sound system/Infotelematic Connect system display
(where fitted)
5.Revolution counter
6.Speedometer
7.Fuel gauge with low fuel warning light and engine
coolant temperature gauge with warning light showing
when the temperature is too high
8.Central vents
9.Gear lever
10.Left-hand stalk: headlight control
11.Horn
12.Instrument panel: odometer display and warning lights
13.Right-hand stalk, windscreen washer, rear window
washer and trip computer14.ASR system on/off.
15.Headlight beam adjuster (Xeno light versions excluded)
16.Sound system controls on steering wheel
17.Ignition switch
18.Driver air bag
19.Document compartment
20.Cruise control control lever
21.Ashtray and glove compartment
22.Console
23.Glove compartment/Infotelematic Connect system re-
mote controls (where fitted)
24.Cigar lighter
25.Hazard lights
26.Climate system automatic controls
27.Glove compartment

RIGHT-HAND DRIVE VERSIONS
236
INSTRUMENTS
A -Odometer display: speedometer,
miles counter, maintenance indicator,
engine oil level gauge (where fitted)
and, for versions with automatic gear,
engaged gear indicator
B -Warning lights
C -Trip miles counter reset button
D -Button for instrument panel
brightness adjustment
fig. 2F0B0412b
fig. 3F0B0413b
