ENGINE OIL CHANGE
1.4-1.3 Multijet
Tank capacity45
Reserve6÷7
Refuel petrol engines with unleaded petrol with octane rating (RON) no lower than 95 only (EN 228 Specifications)
Refuel diesel engines with diesel fuel for motor vehicles only (EN 590 Specifications)
FUEL CAPACITIES (litres)
Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia) - Print n. 603.81.555 - 12/2008 - 1stediition
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
When running over 160 km/h, inflate tyres at full load inflation values.
1.4 1.3 Multijetlitres kg litres kg
Fuel tank 2.7 2.4 3.0 2.6
Engine sump and filter 3.0 2.6 3.2 2.8
COLD TYRE INFLATION PRESSURES (bar)
185/65 R15 88 T 2.3 2.1 2.3 2.1 2.3 2.3
195/55 R16 87 H 2.3 2.1 2.3 2.1 2.4 2.4 Tyre size TYRES SUPPLIED
Loadless Medium load Full load
Front Rear Front Rear Front Rear
