2008 FIAT GRANDE PUNTO run flat

126
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
IINDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
Always keep your hands on
the steering wheel rim when
driving, so that if the air bag is trig-
gered, it can inflate without meeting
any obstacles which could cause seri-
ous harm to you. Do not drive with
the body bent forwards, keep the seat
back rest in the erect position and
lean your back well against it.
WARNING
Remember that with the key
engaged and at MAR, even if
the engine is not running, the air bags
may be triggered on a stationary car
if it is bumped by another moving car.
Therefore, never seat children on the
front seat even when the car is sta-
tionary. On the other hand remember
that if the key is at STOP, no safety
system (air bags or pretensioners) is
triggered in the event of an impact; in
this case, failure to come into action
cannot be considered as a sign that
the system is not working properly.
WARNING
Do not wash the seat back
rest with pressurised water
or steam (by hand or at automatic
seat washing stations).
WARNING
The front air bag is triggered
for shocks greater in magni-
tude that the pretensioners. For im-
pacts between these two thresholds,
it is therefore normal that only the
pretensioners are triggered.
WARNING
Do not hook rigid objects to
the coat hooks and to the
support handles.
WARNING
The air bag does not substi-
tute the seat belts, but only
increases their effectiveness. More-
over, since the front air bags do not
come into operation in the event of
front impact at low speed, side colli-
sions, bumps from behind or over-
turning, in these circumstances the
occupants would only be protected
by the seat belts which must therefore
always be fastened.
WARNING
When the ignition key is
turned to MAR, the warning
light
“(with passenger’s front air bag
active) turns on and flashes for few
seconds to remind that passenger’s air
bag will be deployed in a crash, af-
ter which it should go off.
WARNING
If the car has been stolen or
an attempt to steal it has
been made, if it has been subjected to
vandals or floods, have the air bag
system checked by Fiat Dealership.
WARNING
109-126 Punto GDX GB 31-07-2008 17:26 Pagina 126

132
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
USING THE MANUAL
GEARBOX
To engage the gears, press the clutch ped-
al fully and shift the gear lever into one of
the required positions (the diagram is
shown on the knob fig. 2-3).
To engage the 6
thgear, move the gearshift
lever pressing slightly rightwards to pre-
vent engaging the 4
thgear accidentally. Do
the same for shifting from 6thto 5thgear.
IMPORTANT The car can only be put in-
to reverse gear when it has stopped mov-
ing completely. With the engine running,
before engaging the reverse, wait at least
2 seconds with the clutch pedal fully down
to prevent damage and grating of the
gears.
To engage reverse R (6-speed gearbox)
from neutral, proceed as follows: raise ring
Aunder the knob and at the same time
move the gearshift lever leftwards and
then forward fig. 2.
For 1.4
16vversion, to engage reverse R
from neutral, lift the sliding ring Aunder
the knob and shift the lever to the right
and back fig. 3.
fig. 2F0M0142m
To change gears properly
you must push the clutch
pedal fully down. It is therefore es-
sential that there is nothing under the
pedals: make sure the mats are lying
flat and do not get in the way of the
pedals.
WARNING
Do not drive with your hand
resting on the gear lever as
the force exerted, even if
slight, could lead over time to
premature wear on the gearbox inter-
nal components.
fig. 3 - 1.4 16vversion F0M0285m
To engage reverse R (5-speed gearbox)
from neutral, proceed as follows: raise ring
Aunder the knob and at the same time
move the gearshift lever rightwards and
then forward fig. 2.
IMPORTANT The clutch pedal must be
used for gear shift only. Never drive with
the foot resting, even if slightly, on the
clutch pedal. For versions / markets where
applicable, the clutch pedal control elec-
tronics can intervene interpreting the
wrong drive style as a fault
127-138 Punto GDX GB 31-07-2008 17:27 Pagina 132

162
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
IINDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
IT SHOULD BE NOTICED THAT:
The sealing fluid of the quick tyre repair
kit is effective with external temperatures
between –20 °C and +50 °C.
The sealing fluid has limited life.
The compressor shall not be
operated for more than 20
minutes. Risk of overheating!. Tyres
repaired with the quick tyre repair kit
shall be used temporarily only.
WARNING
In the event of a puncture
caused by foreign bodies, it is
possible to repair tyres show-
ing damages on the track or
shoulder up to max 4 mm diameter.
Holes and damages on the
tyre side walls cannot be re-
paired. Do not use the quick tyre re-
pair kit if damaging is due to running
with flat tyre.
WARNING
Repairs are not possible in
case of damages on the
wheel rim (bad groove distortion
causing air loss). Do not remove for-
eign bodies (screws or nails) from the
tyre.
WARNING
153-186 Punto GDX GB 31-07-2008 17:28 Pagina 162

163
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
INFLATING PROCEDURE
The cylinder contains ethyl-
ene glycol. The cylinder con-
tains latex: it can cause allergic reac-
tions. It is harmful if ingested or in-
haled and irritant for the eyes and in
case of contact. In case of contact
rinse immediately with water and take
off contaminated clothes. If swal-
lowed, do not induce vomit, rinse out
the mouth, drink a lot of water and
call the doctor immediately. Keep
away from children. This product must
not be used by asthmatics. Do not in-
hale vapours. Call the doctor imme-
diately in case of allergic reactions.
Keep the cylinder in the space provid-
ed for the purpose and far from heat.
The sealing fluid has limited life.
WARNINGReplace the cylinder if sealer
has run out. Do not throw
away the cylinder and the
sealing fluid. Have the sealing
fluid and the cylinder disposed of in
compliance with national and local
regulations.
Put on the protection gloves
provided together with quick
tyre repair kit.
WARNING
❒Pull up the handbrake. Loosen tyre
inflation valve cap, take out the filler
hose A-fig. 9and screw the ring nut
Bon the tyre valve;
fig. 9F0M0363m
153-186 Punto GDX GB 31-07-2008 17:28 Pagina 163

220
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
2.2 2.1
2.2 2.2
2.2 2.0
2.2 2.2
––
––
2.2 2.0
2.2 2.2
––
––2.2 2.1
2.2 2.2
2.2 2.0
2.2 2.2
––
––
2.2 2.0
2.2 2.2
––
––2.4 2.1
2.5 2.2
2.3 2.1
2.3 2.3
––
––
2.3 2.1
2.4 2.4
2.4 2.2
2.5 2.4––
––
2.3 2.1
2.3 2.3
––
––
2.3 2.1
2.4 2.4
2.4 2.2
2.5 2.4––
––
––
––
2.4 2.2
2.4 2.2
2.4 2.2
2.6 2.4
2.6 2.3
2.8 2.5 ––
––
2.3 2.0
2.2 2.2
––
––
2.2 2.0
2.2 2.2
2.4 2.2
2.4 2.4––
––
––
––
2.2 2.0
2.2 2.2
2.2 2.0
2.2 2.2
2.4 2.2
2.4 2.4
COLD TYRE INFLATION PRESSURE (bar)
Versions 1.2 1.4 1.4
16V1.4 T-JET 1.3 Multijet 1.3 Multijet 1.6 Multijet
75 HP 90 HP
Front Rear Front Rear Front Rear Front Rear Front Rear Front Rear Front Rear
175/65 R15 84T
Medium load
Full load
185/65 R15 88T
Medium load
Full load
185/65 R15 88H
Medium load
Full load
195/55 R16 87H
Medium load
Full load
205/45 R17 88V
Medium load
Full load
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
When running at speed higher than 160 km/h, inflate tyres at full load inflation values.
With T.P.M.S. system, pressure value shall be + 0.1 bar than prescribed value.
T.P.M.S. system not available for tyre 175/65 R15 84T
209-229 Punto GDX GB 6-08-2008 10:11 Pagina 220

Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering - Largo Senatore G. Agnelli. 5 - 10040 Volvera - Torino (Italia) - Print N. 603.81.467 - 07/2008 - 1st edition
1.2 - 1.4 - 1.4 16V- 1.4 T-JET - 1.3 Multijet 75 HP - 1.3 Multijet 90 HP - 1.6 Multijet
Tank capacity45
Riserve5 ÷ 7
Only refuel cars with petrol engines with unleaded petrol with octane rating (RON) not less than 95.
Only refuel cars with diesel engines with diesel fuel for motor vehicles conforming to the EN590 European Specification
FUEL CAPACITY (litres) ENGINE OIL REPLACEMENT
1.2 1.4 1.4 161.4 T-JET1.3 Multijet 75 HP 1.3 Multijet 90 HP1.6 Multijet
liter kg liter kg liter kg liter kg liter kg liter kg liter kg
Sump and filter 2.6 2.25 2.6 2.25 2.9 2.55 3.3 2.9 3.2 2.75 3.2 2.75 4.18 3.49
2.2 2.1
2.2 2.2
2.2 2.0
2.2 2.2
––
––
2.2 2.0
2.2 2.2
––
––2.2 2.1
2.2 2.2
2.2 2.0
2.2 2.2
––
––
2.2 2.0
2.2 2.2
––
––2.4 2.1
2.5 2.2
2.3 2.1
2.3 2.3
––
––
2.3 2.1
2.4 2.4
2.4 2.2
2.5 2.4––
––
2.3 2.1
2.3 2.3
––
––
2.3 2.1
2.4 2.4
2.4 2.2
2.5 2.4––
––
––
––
2.4 2.2
2.4 2.2
2.4 2.2
2.6 2.4
2.6 2.3
2.8 2.5 ––
––
2.2 2.0
2.2 2.2
––
––
2.2 2.0
2.2 2.2
2.4 2.2
2.4 2.4––
––
––
––
2.2 2.0
2.2 2.2
2.2 2.0
2.2 2.2
2.4 2.2
2.4 2.4
COLD TYRE INFLATION PRESSURE (bar)
Versions
1.2 1.4 1.4 16V 1.4 T-JET1.3 Multijet 75 HP 1.3 Multijet 90 HP1.6 MultijetFront Rear Front Rear Front Rear Front Rear Front Rear Front Rear Front Rear
175/65 R15 84T
Medium load
Full load
185/65 R15 88T
Medium load
Full load
185/65 R15 88H
Medium load
Full load
195/55 R16 87H
Medium load
Full load
205/45 R17 88V
Medium load
Full load
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
When running at speed higher than 160 km/h, inflate tyres at full load inflation values.
With T.P.M.S. system, pressure value shall be + 0.1 bar than prescribed value.
T.P.M.S. system not available for tyre 175/65 R15 84T
