The center console outlet is powered directly from the
battery (power available at all times). Items plugged into
this outlet may discharge the battery and/or prevent
engine starting.Electrical Outlet Use With Engine Off
CAUTION!
²Many accessories that can be plugged in draw power from
the vehicle's battery, even when not in use (i.e. cellular
phones, etc.). Eventually, if plugged in long enough, the
vehicle's battery will discharge sufficiently to degrade
battery life and/or prevent engine starting.
²Accessories that draw higher power (i.e. coolers, vacuum
cleaners, lights, etc.); will degrade the battery even more
quickly. Only use these intermittently and with greater
caution.
²After the use of high power draw accessories, or long
periods of the vehicle not being started (with accessories
still plugged in), the vehicle must be driven a sufficient
length of time to allow the alternator to recharge the
vehicle's battery.
²Power outlets are designed for accessory plugs only. Do
not hang any type of accessory or accessory bracket from
the plug. Improper use of the power outlet can cause
damage.
Center Console Power Outlet
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
FUSES (POWER DISTRIBUTION CENTERS)
Fuses (Front Power Distribution Center)
A power distribution center is located in the engine
compartment. This center contains fuses and relays.
Cavity Car-
tridge
FuseMini
FuseDescription
1 Ð 15 Amp
BlueWasher Motor
2 Ð 25 Amp
NeutralPowertrain Control
Module (PCM)
3 Ð 25 Amp
NeutralIgnition Run/Start
4 Ð 25 Amp
NeutralAlternator/EGR Sole-
noid
5ÐÐÐ
6 Ð 25 Amp
NeutralIgnition Coils/Injectors/
Short Runner Valve
7ÐÐÐ
8 Ð 25 Amp
NeutralStarter
9ÐÐÐ
Front Power Distribution Center
