2008 DODGE AVENGER Owners Manual

Fog Lights
1. Access to the lights through the lower fascia cutout is
limited.
2. We recommend you access the lights by turning the
steering wheel to allow access and remove the inner
fender shield. 3. Rotate bulb and connector 1
¤ 4
turn counterclockwise.
4. Pull bulb off of connector and replace with a new one.
CAUTION!Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Fog Light and Connector MAINTAINING YOUR VEHICLE 415
7

Taillights, Rear Turn Signals And Backup Lights
Ð Replacement
The turn signal, brake and taillights and backup lights
are located in the rear corner body panel housing. Changing the Rear Corner Taillight Bulbs
1. Open the trunk and gently pull back the trunk liner
behind the taillight.
Rear Tail Light Pull Back Trunk Liner416 MAINTAINING YOUR VEHICLE

2. Remove the two plastic wing nuts from the taillight
housing.
3. Grasp the taillight and pull firmly outward pushing
gently on the studs from inside to disengage the light
housing. 4. Twist and remove socket from light.
5. Remove bulb from socket and replace.
Location Plastic Wing Nuts
Changing Tail Light Bulb MAINTAINING YOUR VEHICLE 417
7

License Plate Light Ð Rear
1. Remove two retaining screws holding the light lens in
place.
2. Gently pry the light assembly loose. 3. Pull bulb from socket, replace and reattach the light
assembly with the two retaining screws.
Center High-Mounted Stop Light
1. Open the trunk lid to find the centrally located high-
mounted stop light.
Location and Removal of Rear License Light Assembly
High-mounted Stop Light Bulb Replacement418 MAINTAINING YOUR VEHICLE

2. Twist and remove socket from the back of the light
housing. 3. Replace the bulb and reinstall the socket into the
housing by locking it in place with a twist.
Changing High Mount Stop Light Bulb MAINTAINING YOUR VEHICLE 419
7

FLUIDS AND CAPACITIES
FLUIDS AND CAPACITIES
Engine U.S. Metric
Fuel (approximate)
All FWD Engines Ð (Except 2.4L PZEV) 16.9 Gals 64 L
3.5L Engine with AWD (All Wheel Drive) 17.3 Gals 65.5 L
2.4L PZEV (Partial Zero Emissions Vehicle) 18.4 Gals 69.7 L
Engine Oil with Filter
2.4 Liter Engine (SAE 5W-20, API Certified) 4.5 Qts 4.26 L
2.7 Liter Engine (SAE 5W-20, API Certified) 5.5 Qts 5.2 L
3.5 Liter Engine (SAE 10W-30, API Certified) 5.5 Qts 5.2 L420 MAINTAINING YOUR VEHICLE

FLUIDS AND CAPACITIES
Engine U.S. Metric
Cooling System *
2.4 Liter Engine (Mopar t Antifreeze/Coolant 5 Year/
100,000 Mile Formula) or equivalent. 7.7 Qts 7.3 L
2.7 Liter Engine (Mopar t Antifreeze/Coolant 5 Year/
100,000 Mile Formula) or equivalent. 9.8 Qts 9.3 L
3.5 Liter Engine (Mopar t Antifreeze/Coolant 5 Year/
100,000 Mile Formula) or equivalent. 11.6 Qts 11.0 L
* Includes heater and coolant recovery bottle filled to MAX level. MAINTAINING YOUR VEHICLE 421
7

FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
Component Fluids, Lubricants, and Genuine Parts
Engine Coolant Mopar t Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic
Additive Technology) or equivalent
Engine Oil (2.4L, 2.7L) Use API Certified engine oil. SAE 5W-20 is recommended. Refer to the engine oil
fill cap for the correct SAE grade meeting DaimlerChrysler Material Standard MS-
6395.
Engine Oil (3.5L) Use API Certified engine oil. SAE 10W-30 is recommended. Refer to the engine oil
viscosity chart for the correct SAE grade meeting DaimlerChrysler Material Stan-
dard MS-6395.
Oil Filter (2.4L) Mopar t 04884900AB or equivalent.
Oil Filter (2.7L, 3.5L) Mopar t 04884899AB or equivalent.
Spark Plugs (2.4L - EXCEPT
PZEV*) ZFR5F-11 (Gap.043 in [1.11 mm])
Spark Plugs (2.4LÐ with
PZEV ZFR5AP (Gap.031 in [0.8 mm])422 MAINTAINING YOUR VEHICLE
