2008 DODGE AVENGER check engine

Fluid Level Check Ð Vehicles with 2.4L and 2.7L
Engines
Use the following procedure to check the automatic
transaxle fluid level properly:
1. Park the vehicle on level ground.
2. Run the engine at curb idle speed for a minimum of 60
seconds.
3. Apply the parking brake fully.
4. Place the gear selector momentarily in each gear
position ending with the lever in PARK.
5. Wipe the area around the dipstick clean to eliminate
the possibility of dirt entering the transaxle.
6. Remove the dipstick and determine if the fluid is hot
or cold. Hot fluid is approximately 180 F (82 C), which is
the normal operating temperature after the vehicle is driven at least 15 mi (24 km). Hot fluid cannot be held
comfortably between the fingertips. Cold fluid is at a
temperature below 80 F (27 C).
7. Wipe the dipstick clean and reinsert until seated. Then,
remove dipstick and note the reading.
a. If the fluid is hot, the reading should be in the
crosshatched area marked ªHOTº (between the upper
two holes in the dipstick).
b. If the fluid is cold, the fluid level should be between
the lower two holes in the area marked ªCOLD.º
If the fluid level is low, add sufficient fluid through the
filler (dipstick) tube to bring it to the proper level. Do not
overfill.398 MAINTAINING YOUR VEHICLE

CAUTION!² Using a transmission fluid other than the manu-
facturer's recommended fluid may cause deterio-
ration in transmission shift quality and/or torque
converter shudder. Using a transmission fluid
other than that recommended by the manufacturer
will result in more frequent fluid and filter
changes. Refer to ªFluids, Lubricants, and Genu-
ine Partsº for the correct fluid type.
² Dirt and water in the transaxle can cause serious
damage. To prevent dirt and water from entering
the transaxle after checking or replenishing fluid,
make certain that the dipstick cap is re-seated
properly. Transmission Fluid and Filter Changes
Change the automatic transaxle fluid and filter at the
intervals shown in the ªMaintenance Scheduleº in this
manual.
In addition, change the fluid and filter if the transaxle is
disassembled for any reason.
Special Additives
Automatic Transmission Fluid (ATF) is an engineered
product and its performance may be impaired by supple-
mental additives. Therefore, do not add any fluid addi-
tives to the transaxle. The only exception to this policy is
the use of special dyes to aid in detecting fluid leaks. In
addition, avoid using transmission sealers as they may
adversely affect seals. MAINTAINING YOUR VEHICLE 399
7

oil if it has been six months since your last oil change
even if the oil change indicator message is NOT
illuminated.
² Change your engine oil more often if you drive your
vehicle off-road for an extended period of time.
² Under no circumstances should oil change intervals
exceed 6,000 mi (10 000 km) or six months, whichever
comes first.
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If a
scheduled oil change is performed by someone other
than your authorized dealer, the message can be reset by
referring to the steps described under ªOil Change
Requiredº under ªElectronic Vehicle Information Center
(EVIC)º in Section 4 or under ªOdometer/Trip Odom-
eterº under ªInstrument Cluster Descriptionsº in Section
4. At Each Stop for Fuel
² Check the engine oil level about five minutes after a
fully warmed engine is shut off. Checking the oil level
while the vehicle is on level ground will improve the
accuracy of the oil level reading. Add oil only when
the level is at or below the SAFE or MIN mark.
² Check the windshield washer solvent and add if
required.
Once a Month
² Check tire pressure and look for unusual wear or
damage.
² Inspect the battery and clean and tighten the terminals
as required.
² Check the fluid levels of coolant reservoir, brake
master cylinder, power steering, and automatic trans-
axle, and add fluid as needed. MAINTENANCE SCHEDULES 427
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

NOTE: Six-speed AutoStick t Transaxle, if equipped, is
sealed therefore, checking the fluid level can only be
done by a certified dealership service center.
² Check all lights and other electrical items for correct
operation. At Each Oil Change
² Change the engine oil filter.
² Inspect the brake hoses and lines.
CAUTION!Failure to perform the required maintenance items
may result in damage to the vehicle.428 MAINTENANCE SCHEDULES
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Bulbs, Light ............................ 411
Calibration, Compass ..................... 186
Capacities, Antifreeze (Engine Coolant) ......... 20
Capacities, Fluid ........................ 420
Caps, Filler
Fuel ................................ 328
Oil (Engine) .................. 368,369,370,377
Radiator (Coolant Pressure) ............... 391
Car Washes ............................ 401
Carbon Monoxide Warning ................. 323
Cargo Area Features ...................... 160
Cargo Compartment ...................... 160
Cargo Load Floor ........................ 160
Cargo (Vehicle Loading) ................... 160
Catalytic Converter ...................... 379
Caution, Exhaust Gas ...................... 78
CD (Compact Disc) Player ............... 220,223
CD (Compact Disc) Player Maintenance ........ 241 Cellular Phone .................. 89,223,224,241
Center High Mounted Stop Light ............ 418
Chains, Tire ............................ 309
Changing A Flat Tire ..................... 350
Chart, Tire Sizing ........................ 292
Check Engine Light
(Malfunction Indicator Light) ............... 372
Child Restraint .................... 67,69,73,76
Child Restraint Tether Anchors ............. 71,73
Child Safety Locks ........................ 34
Cigar Lighter ........................... 155
Clean Air Gasoline ....................... 320
Cleaning
Wheels ............................. 402
Windshield Wiper Blades ................. 386
Climate Control ......................... 242
Clock ........................ 194,206,221,225
Coin Holder ........................... 156
Compact Disc (CD) Maintenance ............. 241446 INDEX

Digital Video Disc (DVD) Player .......... 220,223
Dimmer Switch, Headlight ................. 134
Dipsticks
Automatic Transaxle ................. 397,398
Oil (Engine) .......................... 374
Disabled Vehicle Towing ................... 362
Disposal
Antifreeze (Engine Coolant) ............... 392
Engine Oil ........................... 378
Door Locks ............................. 30
Door Locks, Automatic .................... 32
Door Opener, Garage ..................... 143
Drive Belts ............................ 378
Driving
On Slippery Surfaces .................... 288
Through Flowing, Rising, or Shallow Standing
Water .............................. 289
DVD Player (Video Entertainment System) ...... 239 E-85 Fuel ............................. 324
Electric Rear Window Defrost ............... 256
Electric Remote Mirrors .................... 86
Electrical Power Outlets ................... 153
Electronic Speed Control (Cruise Control) ...... 140
Electronic Stability Program (ESP) ............ 283
Electronic Vehicle Information Center (EVIC) .... 181
Emergency, In Case of
Jacking ............................. 350
Jump Starting ......................... 358
Towing ............................. 362
Emergency Trunk Release ................. 39,40
Emission Control System Maintenance ...... 372,426
Engine ........................ 78,368,369,370
Air Cleaner .......................... 379
Block Heater ......................... 266
Break-In Recommendations ................ 78
Checking Oil Level ..................... 374
Coolant (Antifreeze) ................. 389,422448 INDEX

Engine Oil ........................... 326
Fuel Requirements .................. 324,326
Maintenance ....................... 324,327
Replacement Parts ..................... 327
Starting ............................. 327
Flooded Engine Starting ................... 263
Floor Console .......................... 156
Fluid Capacities ......................... 420
Fluid Leaks ............................. 80
Fluid Level Checks
Automatic Transaxle ................. 397,398
Brake ............................ 396,424
Cooling System ....................... 389
Engine Oil ........................... 374
Power Steering ..................... 385,424
Fluids ................................ 422
Fluids, Lubricants and Genuine Parts .......... 422
Fog Lights ....................... 132,176,415
Folding Rear Seat ..................... 126,127 Freeing A Stuck Vehicle ................... 361
Front Wheel Bearings ..................... 400
Fuel ................................. 319
Adding ............................. 328
Additives ............................ 322
Clean Air ............................ 320
Ethanol ............................. 321
Filler Cap (Gas Cap) ................. 170,328
Filler Door (Gas Cap) ................... 170
Gasoline ............................ 319
Gauge .............................. 170
Hoses .............................. 394
Light ............................... 171
Materials Added ....................... 322
Methanol ............................ 321
Octane Rating ...................... 319,422
Requirements ...................... 319,420
Tank Capacity ........................ 420
Fuel, Flexible ............. See Flexible Fuel Vehicles450 INDEX

Keyless Entry System (Sedan) ................ 21
Keys ................................. 12
Knee Bolster .......................... 51,53
Lane Change and Turn Signals ........... 176,416
Lap/Shoulder Belts ....................... 42
LATCH (Lower Anchors and Tether for CHildren) .. 73
Latches
Hood ............................... 127
Lead Free Gasoline ...................... 319
Life of Tires ............................ 306
Light Bulbs ............................ 411
Lights .............................. 80,129
Airbag ........................ 52,65,79,171
Back-Up ............................. 416
Brake Warning ........................ 179
Bulb Replacement ...................... 412
Center Mounted Stop ................... 418
Daytime Running ...................... 132 Dimmer Switch, Headlight ............... 130
Electronic Stability Program (ESP) Indicator . . . 284
Engine Temperature Warning .............. 172
Fog .......................... 132,176,415
Headlight Switch ...................... 130
Headlights ........................... 130
Headlights On With Wipers ............... 137
High Beam Indicator .................... 179
Illuminated Entry ....................... 20
Instrument Cluster ..................... 130
Interior ............................. 129
License ............................. 418
Lights On Reminder .................... 132
Low Fuel ............................ 171
Malfunction Indicator (Check Engine) ........ 178
Map Reading ......................... 129
Oil Pressure .......................... 171
Passing ............................. 131
Seat Belt Reminder ..................... 171 INDEX 453
10
