106
Changing a bulb
FRONT/REAR COURTESY LIGHTS

Type C , 12V 10W - 10W
- Release the courtesy light using a screwdriver.
- Remove the cover to gain access to the bulb.
- Change the bulb moving aside the two contacts.
- Ensure that the new bulbs are secured correctly between the two contacts.
- Close the protective flap.
- Fix the courtesy light in its housing and ensure that it is secured correctly.
DIRECTION INDICATOR SIDE REPEATER

Type A , WY5W - 5W amber
- Push the repeater rearwards and release it.
- Support the connector and turn the bulb holder a quarter of a turn to the left.
- Turn the bulb a quarter of a turn to the left.
- Pull the bulb then change it.
- When refitting, engage the repeater rearwards then move it forwards.

106
Changing a bulb
FRONT/REAR COURTESY LIGHTS

Type C , 12V 10W - 10W
- Release the courtesy light using a screwdriver.
- Remove the cover to gain access to the bulb.
- Change the bulb moving aside the two contacts.
- Ensure that the new bulbs are secured correctly between the two contacts.
- Close the protective flap.
- Fix the courtesy light in its housing and ensure that it is secured correctly.
DIRECTION INDICATOR SIDE REPEATER

Type A , WY5W - 5W amber
- Push the repeater rearwards and release it.
- Support the connector and turn the bulb holder a quarter of a turn to the left.
- Turn the bulb a quarter of a turn to the left.
- Pull the bulb then change it.
- When refitting, engage the repeater rearwards then move it forwards.

107
7
TROUBLESHOOTING
Changing a bulb
REAR LIGHTS
For further information concerning the bulbs,
refer to the table “Types of bulb”.

1. Brake lights

Type B , P21W - 21W

2. Direction indicators

Type B, PY21W - 21W - amber

3. Reversing lights

Type B, P21W - 21W

4. Side lights / Fog lamps

Type B, P4/21W - 4W/21W - Identify the faulty bulb then open the rear
doors.
- Unscrew the two screws using the screwdriver supplied in the tool kit
(behind the driver ’s seat) and extract the
bulb holder.
- Release the light unit.
- Disconnect the electrical connector.
- Remove the support by moving aside the tabs.
- Change the bulb.
NUMBER PLATE LIGHTS

Type A, C5W - 5W
- Unclip the transparent cover using the screwdriver supplied in the tool kit
(behind the driver ’s seat) and extract the
bulb holder. - Change the bulb by moving aside
the two contacts.
- Ensure that the new bulbs are secured correctly between the two contacts.
- Replace the plastic lens and press on it.
THIRD BRAKE LIGHT

Type B , W5W - 5W (4 bulbs)
- Unclip the transparent cover using the screwdriver located in the tool kit (behind
the driver).
- Disconnect the electrical connector.
- Remove the bulb holder by squeezing the two tabs.
- Remove the faulty bulb.
- Change the bulb.
If you encounter any difficulty, consult a
CITROËN dealer.
