2008 Citroen C6 Owner's Manual

116
IV
1
4
6
2
3
5
S7
ADHECJIK
UQOFNMLRPVW
BG
R D S A U D I O C O M P A C T D I S C S Y S T E M

117
IV
B U T T O N C O N T R O L S
AOn/Off.Volume adjust.
BCD eject.
CCD aperture.
DSOURCESelection of sound source (Radio, CD, CD changer).
ETELOne press: Display of information concerning the Bluetooth®system if your vehicle is so equipped.
FCall-up of audio adjustments.
GLIST
Radio source:Short press: Display of the list of radio stations available (30 maximum).Long press: Update of list of stations.CD source: Display of list of tracks of the CD.

118
IV
Colour screen C
Technical specifi cations
Your Bluetooth® compatible radio possesses:®
3 wavebands (MW/LW/FM).
Dual tuner with RDS EON PTY, display of the PS name, RDS programme search, TA traffi c information, 24 pre-selections (18 FM - 6 MW/LW), automatic memorisation of the AST strongest stations.
An MP3- compatible CD reader.
Audio power of 4X35 W.

119
IV
G E N E R A L F U N C T I O N S -
A U D I O A D J U S T M E N T S
ON/OFF
With the key in Drive position M, press on control A to switch the radio on or off.Note:If the radio was on the last time you switched off the ignition, it will resume automatically when you switch on the ignition again. You will not have to press on control A.
After switching off the ignition, you can still operate the audio system even without the ignition key being present. Simply press on button A. The system will turn itself off after approx.30minutes.
ANTI-THEFT SYSTEM
This radio is coded in such a way as to function only on your particu-lar vehicle. It would be unusable if installed on any other vehicle.Note: The anti-theft system is automatic and requires no action on your part.

120
IV
R A D I O S O U R C E
NOTES ON RADIO RECEPTION
Your radio will be subject to certain phenomena that are not encoun-tered by domestic systems.
The reception of AM and FM signals may suffer from interference, which is caused by the nature and propa-gation of the signals and does not refl ect on the quality of your radio installation.
In AM, the reception may be affected when passing under power lines or bridges, or when travelling through tunnels.
In FM mode, the reception may be affected by the distance from the station transmitter, the refl ecting of signals off obstacles (mountains, hills, tower blocks) and radio blacks-pots (no coverage from the station transmitter).
SELECTION OF RADIO SOURCE
Press button D to select the source.
You can also do this by means of control 5 at the steering wheel.
SELECTION OF FREQUENCIES AND MEMORY BANKS
Press button R successively to go through the memory banks FM1, FM2 and FM3, for the FM wave-band, and the memory banks MW/LW, for the AM waveband.
MANUAL SEARCH
Manual search is via buttons Jor M.
By keeping button J or M pressed, you will be able to scroll through the waveband. Scrolling will stop as soon as you release the button. The radio will remain tuned to the frequency that is displayed.
TUNING SENSITIVITY
Automatic searches can be carried out according to two levels of sen-sitivity:To capture the most powerful transmitters, choose the local search mode "LO" (default option).
To capture the weakest or most distant transmitters, choose the sensitive search mode "DX".

121
IV
R A D I O S O U R C E
DISPLAY AND SELECTION OF A STATION AVAILABLE IN THE AREA IN WHICH YOU ARE TRAVELLING
Briefl y press on button G to bring up a list of stations, this is updated every 10 minutes.
You can also update this list at any time by giving a long press on button G.
To listen to one of these stations, select by pressing buttons J or Mand validate using button L.
MANUAL PRE-SETTING
Select the waveband and memory bank required using button R.
Select a station using either auto-matic or manual search.
Keep pressing for more than two seconds on one of the pre-selection buttons 1 to 6 on the keypad P.
The sound momentarily cuts off, then returns to its previous level to confi rm that it has memorised the station.
AUTOMATIC MEMORISATION OF TRANSMITTERS (AUTOSTORE FUNCTION)
In FM, if you hold down button Rfor more than two seconds, your radio will automatically memorise the 6 strongest stations on the FM3 memory bank.
The display shows "FM AST".
The radio memorises the 6 strongest transmitters, deleting the 6 previously memorised.
After the memorisation, the radio goes directly to memory 1 of mem-ory bank FM3.Note:If the traffi c information function has been activated (see RDS SYSTEM), the stations offering this facility will be memorised as priority.
If it is unable to memorise any new stations, the system will retain the previously memorised stations.If the system is unable to fi nd 6 stations, the unfi lled memory slots will remain free.

122
IV
R D S S Y S T E M
USING THE RDS (RADIO DATA SYSTEM) FUNCTION ON FM
The majority of FM radio stations use the RDS system. The radio in your vehicle has this system.
The RDS system enables these stations to transmit non-audible data in addition to the broadcasting of their programmes. The data pro-vides access to various functions described in this chapter, such as: display of the station name, inter-mittent traffi c information fl ashes or automatic scanning of stations. This enables you to continue lis-tening to your chosen radio station, regardless of the different frequen-cies it uses in the regions through which you are travelling.
SCANNING OF RDS STATIONS
Your radio keeps the best possible reception by continuously looks for any other frequencies on which the selected radio station is broadcast, automatically choosing the fre-quency offering the best reception (if the station broadcasts on more than one transmitter or frequency.
ACTIVATION/DEACTIVATION OF THE RDS FUNCTIONS
The RDS functions can be accessed via the following two menus:Main menu (press button O).
AUDIO menu (press button L).
To activate/deactivate the functions RDS1. Press button O.2. Select the AUDIO icon using buttons J or M.3. Confi rm your choice with a press on button L.4. Select the sub-menu for the FM waveband, via buttons J or M. Confi rm your choice with a press on button L.5. Select scanning for RDS stations, via buttons J or M.6. Validate your choice with a press on button L.7. Using control L, select/deselect to activate/deactivate the function.8. Validate your choice by selec-ting "OK" on the display.

123
IV
R D S S Y S T E M
REGIONAL SEARCH MODE
Some stations, when they are organised in networks, broadcast regional programmes at certain times of day, and national pro-grammes at other times.
It is possible to search.Either for a regional station only.
Or across the whole network in order to fi nd a different programme.
To activate/deactivate this function, proceed as for Scanning of RDS stations.Note: When this mode is activated, the system will remain tuned to one specifi c regional station.
TA TRAFFIC INFORMATION (TRAFFIC ANNOUNCEMENTS)
Some stations allow broadcasting, only in FM, of these messages thanks to the "TA" function.
You can activate the "TA" func-tion by pressing on button I. This allows you, even though you are listening to another audio source or to a radio programme not itself providing traffi c messages, to receive traffi c information fl ashes from an FM station which broad-casts them.
