77DRIVING-
If this warning light comes on,
accompanied by an audible
signal, contact a CITROËN
dealer to have the system
checked. The air bags may
no longer be triggered in the event of
a serious impact.
F r o n t a i r b a g m a l f u n c t i o n
D i s a r m i n g t h e p a s s e n g e r a i r
bag
T o e n s u r e t h e s a f e t y o f y o u r c h i l d ,
i t i s e s s e n t i a l t o d i s a r m t h e p a s -
s e n g e r a i r b a g w h e n y o u i n s t a l l a
r e a r - f a c i n g c h i l d s e a t o n t h e f r o n t
p a s s e n g e r s e a t . O t h e r w i s e , t h e
c h i l d w o u l d r i s k b e i n g k i l l e d o r s e -
r i o u s l y i n j u r e d i f t h e a i r b a g w e r e
t o i n fl a t e .
W i t h t h e i g n i t i o n s w i t c h e d o f f ,
insert the key into the passenger
air bag disarming switch 1 , turn
it to the "OFF" position, then
remove the key keeping the slot
in this position. The air bag warning light on
the instrument panel is lit
throughout the period of dis-
arming.
In the "OFF" position, the passen-
ger air bag will not be triggered in the
event of an impact.
As soon as the child seat is removed,
turn the air bag slot to the "ON" po-
sition to re-activate the air bag and
thus ensure the safety of your pas-
senger in the event of an impact.
T h i s i s c o n fi r m e d b y a n i n d i -
cator light, accompanied by
a message on the display.
With the ignition on (2nd
notch), illumination of this warning
light indicates that the passenger air
bag is disarmed (switch in the "OFF"
position).
If the two air bag warning
lights are lit continuously, do
not install a rear-facing child
seat. Consult a CITROËN
dealer.
D i s a r m i n g c h e c k
Page 80 of 114
77DRIVING-
If this warning light comes on,
accompanied by an audible
signal, contact a CITROËN
dealer to have the system
checked. The air bags may
no longer be triggered in the event of
a serious impact.
F r o n t a i r b a g m a l f u n c t i o n
D i s a r m i n g t h e p a s s e n g e r a i r
bag
T o e n s u r e t h e s a f e t y o f y o u r c h i l d ,
i t i s e s s e n t i a l t o d i s a r m t h e p a s -
s e n g e r a i r b a g w h e n y o u i n s t a l l a
r e a r - f a c i n g c h i l d s e a t o n t h e f r o n t
p a s s e n g e r s e a t . O t h e r w i s e , t h e
c h i l d w o u l d r i s k b e i n g k i l l e d o r s e -
r i o u s l y i n j u r e d i f t h e a i r b a g w e r e
t o i n fl a t e .
W i t h t h e i g n i t i o n s w i t c h e d o f f ,
insert the key into the passenger
air bag disarming switch 1 , turn
it to the "OFF" position, then
remove the key keeping the slot
in this position. The air bag warning light on
the instrument panel is lit
throughout the period of dis-
arming.
In the "OFF" position, the passen-
ger air bag will not be triggered in the
event of an impact.
As soon as the child seat is removed,
turn the air bag slot to the "ON" po-
sition to re-activate the air bag and
thus ensure the safety of your pas-
senger in the event of an impact.
T h i s i s c o n fi r m e d b y a n i n d i -
cator light, accompanied by
a message on the display.
With the ignition on (2nd
notch), illumination of this warning
light indicates that the passenger air
bag is disarmed (switch in the "OFF"
position).
If the two air bag warning
lights are lit continuously, do
not install a rear-facing child
seat. Consult a CITROËN
dealer.
D i s a r m i n g c h e c k
Page 85 of 114
PRACTICAL INFORMATION84 -
CHECKING THE LEVELS
Dipstick
Oil change
According to the information given in
the servicing booklet.
Note: a v o i d u s e d o i l c o m i n g i n t o
prolonged contact with the skin.
E m p t y t h e u s e d o i l i n t o t h e c o n t a i n -
e r s i n t e n d e d f o r t h i s p u r p o s e i n t h e
CITROËN network. Viscosity selection
I n a l l c a s e s , t h e o i l s e l e c t e d m u s t m e e t
t h e m a n u f a c t u r e r ' s r e q u i r e m e n t s .
Note: the coolant does not need to
be changed.
For vehicles equipped with a parti-
c l e fi l t e r , t h e e n g i n e f a n m a y o p e r a t e
after the ignition has been switched
o f f , e v e n w h e n t h e e n g i n e i s c o l d .
There are two marks
on the dipstick:
A = m a x i m u m
N e v e r fi l l p a s t t h i s
mark.
B = m i n i m u m
To maintain the reliability
of engines and emission
c o n t r o l s y s t e m s , t h e u s e
of addi-tives in engine oil
is prohibited. Brake fluid level:
T h e b r a k e fl u i d m u s t b e c h a n g e d
a c c o r d i n g t o t h e m a n u f a c t u r e r ' s s e r -
v i c i n g s c h e d u l e .
U s e fl u i d s r e c o m m e n d e d b y t h e
m a n u f a c t u r e r , w h i c h f u l fi l D O T 4
standards.
Note: b r a k e fl u i d i s h a r m f u l t o h e a l t h
and very corrosive. Avoid all contact
with the skin.
C o o l i n g s y s t e m
U s e t h e fl u i d r e c o m m e n d e d b y t h e
m a n u f a c t u r e r .
When the engine is warm, the tem-
p e r a t u r e o f t h e c o o l a n t i s c o n t r o l l e d
by the engine fan. As this fan can op-
erate with the ignition key removed
a n d b e c a u s e t h e c o o l i n g s y s t e m i s
p r e s s u r i s e d , w a i t f o r a t l e a s t o n e h o u r
after the engine has stopped before
c a r r y i n g o u t a n y w o r k .
S l a c k e n t h e c a p b y t w o t u r n s t o r e -
l e a s e t h e p r e s s u r e t o p r e v e n t a n y
r i s k o f s c a l d i n g . W h e n t h e p r e s s u r e
has dropped, remove the cap and
t o p u p t h e l e v e l . Used oil
D o n o t d i s p o s e o f u s e d o i l , b r a k e fl u i d o r
c o o l a n t i n t o d r a i n s o r o n t o t h e g r o u n d .
Power steering reservoir
Open the reservoir, with the
e n g i n e a t a m b i e n t t e m p e r a t u r e .
T h e l e v e l s h o u l d a l w a y s b e a b o v e
the MIN. mark and close to the
MAX. mark.
W i n d s c r e e n a n d h e a d l a m p
wash level
F o r b e s t q u a l i t y c l e a n i n g a n d f o r
y o u r s a f e t y , w e w o u l d a d v i s e t h a t
y o u u s e p r o d u c t s r e c o m m e n d e d b y
CITROËN .
F o r o p t i m u m c l e a n i n g a n d t o p r e v e n t
f r e e z i n g , t h i s fl u i d m u s t n o t b e t o p p e d
u p o r r e p l a c e d w i t h w a t e r .
Oil level
C h e c k t h e l e v e l r e g u l a r l y a n d
t o p u p b e t w e e n c h a n g e s . T h e
m a x i m u m c o n s u m p t i o n i s 0 . 5 l
per 600 miles (1 000 km).
Check the level with the vehicle level,
e n g i n e c o l d , u s i n g t h e o i l l e v e l g a u g e
o n t h e i n s t r u m e n t p a n e l o r t h e d i p s t i c k .
Page 98 of 114
9 5PRACTICAL INFORMATION-
ECONOMY MODE FUNCTION
After the engine has stopped, with
the key in the "accessories" position,
c e r t a i n f u n c t i o n s ( w i n d s c r e e n w i p e r ,
e l e c t r i c w i n d o w s , c o u r t e s y l i g h t s ,
a u d i o e q u i p m e n t , e t c . ) c a n o n l y b e
u s e d f o r a c o m b i n e d d u r a t i o n o f a p -
p r o x i m a t e l y t h i r t y m i n u t e s , t o p r e v e n t
discharging the battery.
O n c e t h e t h i r t y m i n u t e s a r e o v e r , a
switching to economy mode message a p p e a r s o n t h e m u l t i - f u n c t i o n d i s p l a y
a n d t h e a c t i v e f u n c t i o n s a r e p u t o n
standby.
T h e s e f u n c t i o n s a r e r e a c t i v a t e d
a u t o - m a t i c a l l y n e x t t i m e t h e v e h i c l e
is driven.
I n o r d e r t o r e s u m e t h e u s e o f t h e s e
f u n c t i o n s i m m e d i a t e l y , t h e e n g i n e
m u s t b e s t a r t e d a n d l e f t t o r u n f o r a
f e w m i n u t e s .
T h e t i m e a v a i l a b l e t o y o u w i l l t h e n
b e d o u b l e t h e d u r a t i o n f o r w h i c h t h e
e n g i n e i s l e f t r u n n i n g . H o w e v e r , t h i s
p e r i o d w i l l a l w a y s b e b e t w e e n fi v e
a n d t h i r t y m i n u t e s .
BATTERY
It is advisable to disconnect the
battery if the vehicle is not to be
u s e d f o r a p e r i o d o f m o r e t h a n
o n e m o n t h .
Before disconnecting the
b a t t e r y , y o u m u s t w a i t 2 m i n -
u t e s a f t e r s w i t c h i n g o f f t h e
ignition.
Never disconnect a terminal when
t h e e n g i n e i s r u n n i n g .
N e v e r c h a r g e a b a t t e r y w i t h o u t fi r s t
disconnecting the terminals.
Close the windows and the roof before
disconnecting the battery.
After every reconnection of the bat-
tery, switch on the ignition and wait
1 m i n u t e b e f o r e s t a r t i n g t o a l l o w t h e
electronic systems to be initialised. If
s l i g h t d i f fi c u l t i e s a r e e x p e r i e n c e d a f t e r
this, please contact a CITROËN
dealer. A fl a t b a t t e r y p r e v e n t s t h e
engine from starting.
T o s t a r t t h e v e h i c l e f r o m
another battery:
- Connect the red cable to the
positive (+) terminals of the two
batteries,
- Connect one end of the green or black cable to the negative (-)
terminal of the slave battery,
- Connect the other end of the green or black cable to an earth
point on the broken down vehicle
as far as possible from the battery
(for example, right-hand engine
m o u n t i n g ) .
O p e r a t e t h e s t a r t e r , l e t t h e e n g i n e r u n .
W a i t f o r t h e e n g i n e t o r e t u r n t o i d l e ,
then disconnect the cables.
To charge the battery using a
battery charger:
- Disconnect the battery,
- F o l l o w t h e i n s t r u c t i o n s f o r u s e
given by the battery charger
m a n u f a c t u r e r ,
- Reconnect starting with the negative (-) terminal,
- Check that the terminals and connectors are clean. If they are
c o v e r e d w i t h s u l p h a t e ( w h i t e o r
greenish deposit), disconnect
them and clean them.
