2008 CHRYSLER SEBRING CONVERTIBLE hood open

NPhone Call Features...................108
NUConnecttSystem Features..............110
NAdvanced Phone Connectivity............115
NThings You Should Know About Your
UConnecttSystem....................117
NGeneral Information...................125
mVoice Recognition System (VR) ± If Equipped . . . 125
NVoice Recognition System (VR) Operation....125
NCommands..........................126
NVoice Training........................129
mSeats................................130
NManual Front Seat Adjustments...........130
NEasy Entry System....................133NPower Seats Ð If Equipped..............134
NHead Restraints......................135
NHeated Seats Ð If Equipped.............135
mTo Open And Close The Hood.............137
mLights...............................138
NExterior & Interior Lighting Control........138
NHeadlights & Parking Lights.............139
NAutomatic Headlights Ð If Equipped.......139
NHeadlights With Wipers (Available With
Auto Headlights Only).................139
NHeadlight Time Delay Ð If Equipped.......140
NDaytime Running Lights (DRL) Ð
If Equipped.........................140
NLights-On Reminder...................141
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

TO OPEN AND CLOSE THE HOOD
Two latches must be released to open the hood. First, pull
the hood release lever located under the left side of the
instrument panel.Next, move to the outside of the vehicle and lift the
secondary latch underneath the center front edge of the
hood. Then, raise the hood.
Hood Release Lever
Hood Safety Catch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137
3

Use the hood prop rod to secure the hood in the open
position. Place the upper end of the prop rod in the hole
on the underside of the hood.
Before closing the hood, make sure to stow the prop rod
in its proper location. To prevent possible damage, do notslam the hood to close it. Use a firm downward push at
the center of the hood to ensure that both latches engage.
WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
LIGHTS
Exterior & Interior Lighting Control
The Multi-Function Control Lever on the left side
of the steering column controls the operation of
the headlights, parking lights, turn signal lights,
instrument panel lights, instrument panel light dimming,
interior lights, and fog lights (if equipped).
Hood Prop Rod Hole Location
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Exhaust gases can injure or kill. They contain carbon
monoxide (CO) which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing CO, refer
to Exhaust Gas in the Safety Tips section of this
manual.
Cooling System
WARNING!
²When working near the radiator cooling fan, dis-
connect the fan motor lead or turn the ignition
switch to the LOCK position. The fan is tempera-
ture controlled and can start at any time the
ignition switch is in the ON position.
²You or others can be badly burned by hot coolant
or steam from your radiator. If you see or hear
steam coming from under the hood, don't open the
hood until the radiator has had time to cool. Never
try to open a cooling system pressure cap when the
radiator is hot.
MAINTAINING YOUR VEHICLE 375
7

BULB REPLACEMENT
Low Beam Headlight, High Beam Headlight
1. Open the hood.
NOTE:It may be necessary to remove the air cleaner
filter housing and position the totally integrated power
module aside prior to replacing the low beam headlight
on the driver's side of the vehicle.
2. Rotate the applicable bulb and connector assembly
1¤4
turn counterclockwise and remove the assembly from the
headlight housing.
3. Disconnect the bulb from the harness connector and
then connect the replacement bulb.
1 Ð High Beam Headlight
2 Ð Low Beam HeadlightMAINTAINING YOUR VEHICLE 4017

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean the
bulb with rubbing alcohol.
4. Install the bulb and connector assembly into the
headlight housing and rotate it
1¤4turn clockwise to lock
it in place.
Front Turn Signal/Park Light
1. Open the hood.
2. Rotate the bulb's electrical connector
1¤4turn counter-
clockwise and remove it from the headlight housing.
Front Turn Signal/Park Light
402 MAINTAINING YOUR VEHICLE

Time Delay.......................... 140
Heated Mirrors.......................... 99
Heated Seats........................... 135
Heater............................... 232
Heater, Beverage Holder (Cup Holder)........ 164
Heater, Engine Block..................... 255
High Beam/Low Beam Select (Dimmer) Switch . . 142
Hitches
Trailer Towing........................ 324
Holder, Cup........................... 164
Holder Heated/Cooled (Cup Holder)......... 164
HomeLinkt(Garage Door Opener) Transmitter . . . 155
Hood Prop............................ 138
Hood Release.......................... 137
Hoses................................ 381
Ignition............................... 12
Key ................................. 12
Lock................................ 12Ignition Key Removal..................... 12
Illuminated Entry........................ 20
Immobilizer (Sentry Key)................... 15
Indicator, Traction Control................. 274
Infant Restraint........................62,63
Information Center, Vehicle................. 187
Instrument Cluster.................174,175,176
Instrument Panel and Controls.............. 173
Instrument Panel Cover................... 389
Instrument Panel Lens Cleaning............. 391
Integrated Power Module (Fuses)............ 395
Interior Appearance Care.................. 389
Interior Lighting......................138,144
Interior Lights.......................... 144
Intermittent Wipers (Delay Wipers)........... 147
Introduction............................. 4
Jack Location........................... 339
Jack Operation.......................338,340
INDEX 441
10

To Open Hood.......................... 137
Tongue Weight/Trailer Weight.............. 326
Tonneau Cover.......................... 81
Towing............................... 322
Behind a Motor Home.................. 333
Disabled Vehicle....................... 349
Guide.............................. 325
Recreational.......................... 333
Weight.............................. 325
Towing Vehicle Behind a Motor Home......... 333
Traction.............................. 271
Traction Control......................... 274
Traction Control Light.................... 274
Traction Control Switch................... 274
Trailer Towing.......................... 322
Cooling System Tips.................... 332
Hitches............................. 324
Minimum Requirements................. 327
Tips ................................ 331Trailer and Tongue Weight................ 326
Wiring.............................. 330
Trailer Towing Guide..................... 325
Trailer Weight.......................... 325
Transaxle
Additives............................ 386
Automatic......................251,255,384
Autostick............................ 262
Filter............................... 386
Maintenance.......................... 384
Operation........................... 255
Overdrive........................... 260
Selection of Lubricant................... 412
Transmission
Range Indicator....................... 178
Transmission.....................See Transaxle
Transmitter Battery Service
(Remote Keyless Entry).................... 26
INDEX 451
10
