2008 CADILLAC SRX relay

Relays Usage
FAN 2Right Side Engine Cooling
Fan Motors
FAN S/P Series/Parallel Engine Cooling Fan
FRT WASH Front Washer PumpRelays Usage
FAN 1Left Side Engine Cooling
Fan Motors
FOG LAMP Front Fog Lamps
SPARE Spare
5-102

Relays Usage
IGN Ignition Switch (ON)
STRTR Starter Solenoid
PWR/TRN Powertrain/Engine Control Module
HI BEAM High-Beam Headlamps
SPARE Spare
WPR Windshield Wiper System - On/Off
WPR HIWindshield Wiper
System - Low/High
HDLP WASH Headlamp Washer Pump (Option)
LO BEAM -
W/O HID/HIDLow-Beam Headlamps
REAR WASH Rear Washer Pump
HORN Horn
A/C CMPRSR
CLTCHAir Conditioning Compressor Clutch
FUEL PUMP Fuel Pump
ACCYAccessory Power (Rear Wipers,
Inside Rearview Mirror)
J Case Fuses Usage
FAN 2 Right Cooling Fan Motor
SPARE Spare
FAN 1 Left Cooling Fan Motor
J Case Fuses Usage
BLWR Front Blower Motor Assembly
STRTR Starter Solenoid
LPDB 2LRPDB (Left Side Rear Power
Distribution Box)
ABS MOTOR Antilock Brake System Module
LPDB 1LRPDB (Left Side Rear Power
Distribution Box)
RPDB 1RRPDB (Right Side Rear Power
Distribution Box)
SPARE Spare
SPARE Spare
RPDB 2RRPDB (Right Side Rear Power
Distribution Box)
Mini Fuses Usage
FRT WASH Front Washer Pump
SPARE Spare
SPARE Spare
AIRBAGSensing Diagnostic Module (SDM),
Occupant Sensor Display,
Instrument Cluster
ABS IGNAntilock Braking System Ignition,
Variable Effort Steering
IGN SW Ignition Switch, Immobilizer Module
5-103

Mini Fuses Usage
ECM/TCM IGNEngine Control Module/Transmission
Control Module Ignition Power,
Mass Airow Sensor (V6)
MISC IGN Air Quality Sensor
EMIS 1Pre 02 Sensors, Cam Phasor (V6),
Canister Purge (V6), Intake Manifold
Tuning Valve (V6)
SPARE Spare
DISPLYInstrument Panel Cluster, Climate
Control Module, Diagnostic Link
Connector
BCM 2LED Instrument Panel Dimming,
Overhead Lamps, Vanity Lamps
EVEN COILSEven Ignition Coils, Even Fuel
Injectors
BCM 6Right Side Rear Stoplamp, Turn
Lamps, Key Capture Solenoid
RDO Radio
ODD COILSOdd Ignition Coils, Odd Fuel
Injectors
BCM 1 Body Control Module (BCM) Power
LT HI BEAM Left Side High-Beam HeadlampMini Fuses Usage
BCM 7/CLOCK Switch Dimming, Analog Clock
SPARE Spare
EMIS 2Cooling Fan Relays, Air Conditioning
Clutch Relay, Post O2 Sensors,
Mass Airow Sensor (V8),
Canister Purge (V8)
ECM BATT Engine Control Module (ECM)
RT HI BEAM Right Side High-Beam Headlamp
RVC SNSRBattery Regulated Voltage
Control Sense
FOG LAMP Front Fog Lamps
ECM 1 Engine Control Module (ECM)
BCM 5Left Side Front Turn Lamps,
Rear Stoplamps, Turn Lamps
WPR Windshield Wiper Motor
SPARE Spare
BCM 4Center High-Mounted Stoplamp
(CHMSL), Back-up Lamps
CIGInstrument Panel Accessory Power
Outlet (Cigarette Lighter)
RT LO BEAM Right Side Low-Beam Headlamp
5-104

Relays Usage
STOP Not Used
ELCElectronic Level Control (ELC)
Compressor Motor
PRK LAMP Not Used
REAR/FOG Not UsedRelays Usage
SPARE Spare
RT POS Not Used
LH/POS/
PRK LAMPFront & Rear Park Lamps
SPARE Spare
5-106

Mini Fuses Usage
STR/WHL/
CNTRLSteering Wheel Controls
RSA/RSERear Seat Entertainment,
Rear Seat Audio
ONSTAR
TV/XMOnStar
®Module, XM™ Radio
3RD ROW
SW/RFAFlip Fold Seat Switches, Remote
Keyless Entry System Module
AMP Audio Amplier
REAR SEAT
MDLRear Seat Module, Flip/Fold Motors
DRIVER
DR MDLDriver Door Module (Locks,
Outside Rearview Mirror,
Window Switches)
STOP LAMPS Not Used
MRK LAMP License Lamps
LH/PRK POS
LAMPSLeft Side Taillamp, Left Side Front
Park Lamps, Sidemarker Lamps
Mini Fuses Usage
RH/PRK
LAMPSRight Side Taillamp,
Right Side Front Park Lamps,
Sidemarker Lamps
TRLR PRK
LAMPSTrailer Park Lamps
SPARE Spare
SPARE Spare
SPARE Spare
MSM/RPAMemory Seat Module, Ultrasonic
Rear Parking Assist (URPA) Module
AUX PWR
OUTLETRear Auxiliary Power Outlet
PRK LAMP
LH/POS RLYParking Lamp Relay
REAR/
FOG LAMPNot Used
RH/POS LAMP Not Used
5-107

Relays Usage
REAR DEFOG Rear Window Defogger
SPARE Spare
SPARE SpareRelays Usage
UNLCK Rear Door Locks
SPARE Spare
LCK Rear Door Locks
5-109

Relays Usage
RUN RLYRear Air Conditioning Blower Motor,
Climate Control Ignition,
Heated Steering Wheel
SPARE Spare
Mini Fuses Usage
WPR ISRVM
VICSRear Wiper Switch,
Inside Rearview Mirror
THEFT UGDO Garage Door Opener
SPARE Spare
CNSTR/VENT Canister Vent Solenoid
PWER L/GATE Power Liftgate Module
REAR DEFOG Rear Window Defogger
SPARE Spare
BCM 3Hush Panel Lamps, Overhead
Courtesy Lamp Assembly,
Right Side Front Turn Lamp
REAR A/C Rear Air Conditioning System
RUN Climate Control Module
HDD/STR/WHL Heated Steering Wheel
SPARE Spare
SPARE Spare
SPARE Spare
Mini Fuses Usage
DR/LCK Rear Door Locks
PDMPassenger Door Module (Locks,
Outside Mirror, Window Switches)
AIRBAGSensing Diagnostic Module (SDM),
Occupant Sensor, Roll-over Sensor
SPARE Spare
MRTD Suspension Module
ELCElectronic Leveling Compressor
(ELC) Exhaust Solenoid, ELC Relay
J Case Fuses Usage
S/ROOF/MDL Power Sunroof Module
PWR LIFT
GATEPower Liftgate Motors
Circuit
BreakersUsage
PWR/SEATS Power Seat Motors
Misc. Usage
FUSE PLR Fuse Puller
J/C Joint Connector
5-110
