2008 AUDI S5 display

Downloaded from www.Manualslib.com manuals search engine Care of vehicle and cleaning213
Controls
Safety
Driving tips
General maintenance
Self-help
Technical data After washing, the wheels should only be cleaned with an "acid-
free" cleaning agent for alloy wheels. This is available from Audi
dealers and specialist retailers. Never leave the cleaning agent on
the rims for any longer than specified in the instructions before
rinsing it off. If the wheel cleaner fluid contains acid it can attack the
surfaces of the wheel bolts.
Car polish or other abrasive agents should not be used. If the
protective paint coating is damaged by stone chips etc., the
damaged area should be touched up immediately.
WARNING
Please note when cleaning the wheels that water, ice and road salt
can impair the effectiveness of the brakes – this can cause an
accident.Care of interiorMMI display screen and control consoleThe MMI display screen can be cleaned with a soft cloth and a
special “LCD cleaner” (available from retailers of electrical goods).
Moisten the cloth with a small amount of the cleaning fluid.
Clean the MMI control console with a fine brush first to prevent any
dirt from getting in between the control buttons and the housing.
We then recommend wiping the MMI control console using a cloth
moistened with washing-up liquid and water.
Caution
To avoid scratching the screen, do not wipe the MMI display with a
dry cloth.•
To avoid any possibility of damage, do not let any liquid get
inside the control console.
Plastic parts and leatherettePlastic parts and leatherette can be cleaned with a damp cloth. If
this is not sufficient, plastic parts and leatherette should only be
treated with a special solvent-free plastic cleaner.Textile covers and trim partsTextile covers and trim parts (e.g. seats, door trim) should be
cleaned regularly with a vacuum cleaner. This will remove surface
dirt which could otherwise be rubbed into the textile material
during use. Do not use steam cleaners, as the steam could carry the
dirt deeper into the textile material.
Normal cleaning
We recommend that you use a soft sponge or lint-free, micro-fibre
cloth for normal cleaning. Only use brushes on floor coverings and
mats, as other textile surfaces could become damaged.
In the case of normal surface dirt you can use a foam cleaner. Use a
sponge to spread the foam on the textile surface and to work it into
the material lightly. However, make sure that the textile material
does not become soaking wet. Then dab off the foam with a dry and
absorbent cloth (e.g. a micro-fibre cloth) and vacuum off any
residue once the surface is completely dry.
Removal of stains
To treat stains caused by spilled drinks (coffee, fruit juice or similar)
make up a solution with a mild detergent for sensitive fabrics and
apply it with a sponge. If the stains are difficult to remove, a
washing paste can be applied directly onto the stain and worked
into the fabric. The surface will then have to be wiped with clear
water to remove any residue left by the paste. To do so, use a damp
cloth or sponge and then dab the stain with an absorbent cloth.
Treat chocolate or make-up stains with a washing paste and then
rinse off with water (using a damp sponge).
document_0900452a81793dcc.book Seite 213 Mittwoch, 21. März 2007 5:42 17

Downloaded from www.Manualslib.com manuals search engine Checking and topping up fluids 222
WARNING
•
For safety reasons the bonnet must always be completely
closed when the vehicle is moving. After closing it always check
that it is properly secured. The bonnet must be flush with the adja-
cent body panels.
•
Should you notice that the bonnet is not safely secured when
the vehicle is moving, stop the vehicle immediately and close the
bonnet properly, otherwise it could cause an accident.
Engine compartment layoutEngine compartment layout
Main components for checking and refillingFig. 212 Locations of fluid containers, engine oil dipstick and engine oil filler
cap
Jump-start terminal (+) under a cover . . . . . . . . . . . . .
Brake fluid reservoir (
) . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil filler cap (

) . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil dipstick (orange) . . . . . . . . . . . . . . . . . . . . . .
Radiator expansion tank () . . . . . . . . . . . . . . . . . . . . .
Windscreen washer container (
) . . . . . . . . . . . . . . . .
Jump-start terminal (-) with hexagon head . . . . . . . . .
Hydraulic fluid reservoir for power steering . . . . . . . .
Engine oilGeneral notesWe recommend that you have the oil change carried out by an Audi
dealership/qualified workshop according to the intervals stated in
the Service Schedule or according to the service interval display in
the instrument cluster.
Whether your vehicle is serviced at flexible service intervals or fixed
service intervals is shown in the Service Schedule.
The correct oil specifications for your engine are listed in the Tech-
nical data section ⇒page 281, “Performance, weights and dimen-
sions”.
Check that the specifications quoted (VW standards) appear on the
container either singly or in combination with other specifications.
Flexible service intervals (Audi LongLife Service*)
Special engine oils ⇒page 281, “Performance, weights and dimen-
sions” have been developed as part of the Audi LongLife Service
(⇒“Service Schedule”).
This type of oil must be used if you intend to take advantage of the
extended maintenance intervals allowed by Audi's LongLife Service.A1
230, 256
A2
227
A3
224
A4
223
A5
225
A6
231
A7
230, 256
A8
190
document_0900452a81793dcc.book Seite 222 Mittwoch, 21. März 2007 5:42 17

Downloaded from www.Manualslib.com manuals search engine General notes279
Controls
Safety
Driving tips
General maintenance
Self-help
Technical data This applies especially when the vehicle is fully laden.
CapacitiesFuel tank
Windscreen washerVehicle identification data
Vehicle identification number on the sound
system or MMI
– Select: Function selector button > Vehicle ID
number ⇒fig. 263.Vehicle identification number in the engine
compartment
The vehicle identification number is located on the right-hand side
of the engine compartment.
Type plate
The type plate is located on the right-hand side of the engine
compartment. Vehicles for certain export countries have no type
plate.
Fuel tank
ltr.
approx. 65
Windscreen and
headlight washer system*
ltr.
approx. 4.5
Fig. 263 MMI display:
Vehicle identification
number
Fig. 264 Vehicle data
sticker
CAR
document_0900452a81793dcc.book Seite 279 Mittwoch, 21. März 2007 5:42 17

Downloaded from www.Manualslib.com manuals search engine Index285
Controls
Safety
Driving tips
General maintenance
Self-help
Technical data Blower
Deluxe automatic air conditioner . . . . 94
Deluxe automatic air conditioner plus . .
102
Bonnet
Closing . . . . . . . . . . . . . . . . . . . . . . . . . 221
Opening . . . . . . . . . . . . . . . . . . . . . . . . 220
Releasing . . . . . . . . . . . . . . . . . . . . . . . 220
Boot
SeeLoading luggage compartment . 158
SeeLuggage compartment . . . . . . . . . 75
Boot lid
Central locking system . . . . . . . . . . . . . 48
Manual release . . . . . . . . . . . . . . . . . . . . 49
Brake system
Brake assist system . . . . . . . . . . . . . . . 187
Brake fluid . . . . . . . . . . . . . . . . . . . . . . 227
Brake light defective . . . . . . . . . . . . . . . 36
Brake pads worn . . . . . . . . . . . . . . . . . . 36
Brake servo . . . . . . . . . . . . . . . . . . . . . . 189
Electro-mechanical parking brake . . . 119
General notes . . . . . . . . . . . . . . . . . . . . 189
Malfunction . . . . . . . . . . . . . . . . . . . . . . 31
Warning lamp . . . . . . . . . . . . . . . . . . . . 19
Bulb holder
Bayonet fastener . . . . . . . . . . . . . . . . . 266
Bulb monitor . . . . . . . . . . . . . . . . . . . . . . . . 36
Bulbs
Bayonet fastener . . . . . . . . . . . . . . . . . 266
Changing (general notes) . . . . . . . . . . 265
Bulbs, changing . . . . . . . . . . . . . . . . . . . . 265
Brake lights . . . . . . . . . . . . . . . . . . . . . 269
Bulb holder with bayonet fastener . . 266Front fog lights . . . . . . . . . . . . . . . . . . 268
Number plate light . . . . . . . . . . . . . . . 274
Rear fog light . . . . . . . . . . . . . . . . . . . . 272
Rear lights . . . . . . . . . . . . . . . . . . . . . . 269
Reversing light . . . . . . . . . . . . . . . . . . . 272
Turn signals (rear) . . . . . . . . . . . . . . . . 269
Business equipment . . . . . . . . . . . . . . . . . 240
CCapacities . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Car keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Care of vehicle . . . . . . . . . . . . . . . . . . . . . . 210
Catalytic converter . . . . . . . . . . . . . . . . . . 195
Central locking system . . . . . . . . . . . . . . . . 42
Boot lid . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Deadlock mechanism . . . . . . . . . . . . . . 45
Fuel tank flap . . . . . . . . . . . . . . . . . . . . 217
Locking . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Locking and unlocking the vehicle from
inside . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Manual locking . . . . . . . . . . . . . . . . . . . . 47
Opening and closing windows . . . . . . . 50
Switches on driver's door . . . . . . . . . . . 46
Unlocking . . . . . . . . . . . . . . . . . . . . . . . . 45
Changing a wheel . . . . . . . . . . . . . . . . . . . 250
Changing bulbs
SeeBulbs . . . . . . . . . . . . . . . . . . . . . . . 265
Chassis number . . . . . . . . . . . . . . . . . . . . . 279
Child safety . . . . . . . . . . . . . . . . . . . . . . . . 175
Child safety seat . . . . . . . . . . . . . . . . . . . . 176
Child seat categories . . . . . . . . . . . . . . 176
Fitting . . . . . . . . . . . . . . . . . . . . . . . . . . 179ISOFIX system . . . . . . . . . . . . . . . . . . . . 181
On front passenger's seat . . . . . . . . . . 176
Safety notes . . . . . . . . . . . . . . . . . . . . . 175
Cigarette lighter . . . . . . . . . . . . . . . . . . . . . . 85
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
Cleaning Alcantara . . . . . . . . . . . . . . . . . . 216
Cleaning seat covers
Alcantara . . . . . . . . . . . . . . . . . . . . . . . . 216
Natural leather . . . . . . . . . . . . . . . . . . . 215
Textile covers . . . . . . . . . . . . . . . . . . . . 213
Cleaning textile covers and trim parts . . 213
Clock, setting . . . . . . . . . . . . . . . . . . . . . . . . 13
Closing
Bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Coat hooks . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Colour code . . . . . . . . . . . . . . . . . . . . . . . . 279
Compact temporary spare wheel
SeeSpare wheel . . . . . . . . . . . . . . . . . . 246
Compartment for (sun)glasses . . . . . . . . . 89
Compass in mirror . . . . . . . . . . . . . . . . . . . . 68
Controls and displays
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Convenience close function . . . . . . . . . . . . 50
Convenience open function . . . . . . . . . . . . 50
Cooling system
Anti-freeze additive . . . . . . . . . . . . . . . 224
Checking coolant level . . . . . . . . . . . . 225
Coolant . . . . . . . . . . . . . . . . . . . . . . . . . 224
Coolant temperature gauge . . . . . . . . . 11
Malfunction . . . . . . . . . . . . . . . . . . . . . . 32
Radiator fan . . . . . . . . . . . . . . . . . . . . . 226
Topping up coolant . . . . . . . . . . . . . . . 226
document_0900452a81793dcc.book Seite 285 Mittwoch, 21. März 2007 5:42 17

Downloaded from www.Manualslib.com manuals search engine Index 286Cruise control system
Adjusting speed . . . . . . . . . . . . . . . . . 125
Control lever on steering wheel . . . . 123
Cruise mode . . . . . . . . . . . . . . . . . . . . 124
Indicator lamp . . . . . . . . . . . . . . . . . . . . 17
Introduction . . . . . . . . . . . . . . . . . . . . . 123
Pre-selecting a speed . . . . . . . . . . . . . 126
Resuming cruise control . . . . . . . . . . 126
Safety notes . . . . . . . . . . . . . . . . . . . . . 123
Switching off . . . . . . . . . . . . . . . . . . . . 127
Switching off temporarily . . . . . . . . . 126
Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . 83
Current fuel consumption . . . . . . . . . . . . . 25DDate display . . . . . . . . . . . . . . . . . . . . . . . . 13
Daytime running lights . . . . . . . . . . . . . . . 56
Deactivating front passenger's airbag . . 173
Deadlock mechanism . . . . . . . . . . . . . . 42, 45
Defrosting windows . . . . . . . . . . . . . . 96, 104
Deluxe automatic air conditioner . . . . . . . 91
Air distribution . . . . . . . . . . . . . . . . . . . 95
Air outlets . . . . . . . . . . . . . . . . . . . . . . . 97
Air outlets for rear passengers . . . . . . 97
Air recirculation mode . . . . . . . . . . . . . 95
Automatic mode . . . . . . . . . . . . . . . . . . 93
Basic settings . . . . . . . . . . . . . . . . . . . . 98
Blower . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Controls . . . . . . . . . . . . . . . . . . . . . . . . . 92
Defrosting . . . . . . . . . . . . . . . . . . . . . . . 96
Description . . . . . . . . . . . . . . . . . . . . . . 91
Economical operation . . . . . . . . . . . . . 98Heated rear window . . . . . . . . . . . . . . . 96
Seat heating, front . . . . . . . . . . . . . . . 112
Switching on and off . . . . . . . . . . . . . . 93
Temperature . . . . . . . . . . . . . . . . . . . . . 94
Deluxe automatic air conditioner plus . . . 99
AC mode . . . . . . . . . . . . . . . . . . . . . . . . 105
Air distribution . . . . . . . . . . . . . . . . . . 104
Air outlets . . . . . . . . . . . . . . . . . . . . . . . 105
Air outlets for rear passengers . . . . . 106
Air recirculation mode . . . . . . . . . . . . 103
Automatic mode . . . . . . . . . . . . . . . . . 101
Automatic recirculation . . . . . . . . . . . 107
Auxiliary heating . . . . . . . . . . . . . . . . . 108
Auxiliary heating - remote control . . 111
Auxiliary heating - running time . . . . 111
Basic settings . . . . . . . . . . . . . . . . . . . 107
Blower . . . . . . . . . . . . . . . . . . . . . . . . . 102
Controls . . . . . . . . . . . . . . . . . . . . . . . . 100
Defrosting . . . . . . . . . . . . . . . . . . . . . . 104
Description . . . . . . . . . . . . . . . . . . . . . . . 99
Economical operation . . . . . . . . . . . . . 106
Heated rear window . . . . . . . . . . . . . . 104
Switching on and off . . . . . . . . . . . . . 101
Synchronisation . . . . . . . . . . . . . . . . . 108
Temperature . . . . . . . . . . . . . . . . . . . . 102
Digital clock . . . . . . . . . . . . . . . . . . . . . . . . . 13
Digital compass . . . . . . . . . . . . . . . . . . . . . 68
Digital speedometer . . . . . . . . . . . . . . . . . . 22
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 278
Dipped headlights . . . . . . . . . . . . . . . . . . . 54
Defective . . . . . . . . . . . . . . . . . . . . . . . . 36
DIS
SeeDriver information system . . . . . . 20Door catches/boot lid warning . . . . . . . . . 23
Doors
Manual locking . . . . . . . . . . . . . . . . . . . 47
Driver
SeeSitting position . . . . . . . . . . . . . . . 154
Driver information system . . . . . . . . . . . . . 20
Auto-check control . . . . . . . . . . . . . . . . 29
Bulb monitor . . . . . . . . . . . . . . . . . . . . . 36
CD and radio display . . . . . . . . . . . . . . . 21
Digital speedometer . . . . . . . . . . . . . . . 22
Door catches/boot lid warning . . . . . . 23
Driver messages . . . . . . . . . . . . . . . . . . 30
On-board computer . . . . . . . . . . . . . . . . 25
Outside temperature display . . . . . . . . 21
Red symbols . . . . . . . . . . . . . . . . . . . . . 30
Service interval display . . . . . . . . . . . . . 23
Speed warning . . . . . . . . . . . . . . . . . . . . 28
Yellow symbols . . . . . . . . . . . . . . . . . . . 34
Driver messages . . . . . . . . . . . . . . . . . . . . . 30
Driving abroad . . . . . . . . . . . . . . . . . . . . . 195
Headlights . . . . . . . . . . . . . . . . . . . . . . 195
Unleaded fuel . . . . . . . . . . . . . . . . . . . 195
Driving away from a standstill . . . . . . . . 120
Driving away when towing a trailer . . . . 121
Driving safety . . . . . . . . . . . . . . . . . . . . . . 153
Driving time . . . . . . . . . . . . . . . . . . . . . . . . . 25
Dust filter
Deluxe automatic air conditioner . . . . 91
Deluxe automatic air conditioner plus 99
DVD player . . . . . . . . . . . . . . . . . . . . . . . . . . 77
document_0900452a81793dcc.book Seite 286 Mittwoch, 21. März 2007 5:42 17

Downloaded from www.Manualslib.com manuals search engine Index289
Controls
Safety
Driving tips
General maintenance
Self-help
Technical data Light sensor . . . . . . . . . . . . . . . . . . . . . . . . . 54
Light sensor defective . . . . . . . . . . . . . . . . 35
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Coming home . . . . . . . . . . . . . . . . . . . . . 56
Daytime running lights . . . . . . . . . . . . . 56
Exterior lighting . . . . . . . . . . . . . . . . . . . 56
Front fog lights . . . . . . . . . . . . . . . . . . . 55
Headlight control . . . . . . . . . . . . . . . . . . 54
Leaving home . . . . . . . . . . . . . . . . . . . . . 56
Rear fog lights . . . . . . . . . . . . . . . . . . . . 55
Switching on and off . . . . . . . . . . . . . . . 54
Loading luggage compartment . . . . . . . . 158
Load-through hatch . . . . . . . . . . . . . . . . . . 81
Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Central locking system . . . . . . . . . . . . . 45
Locking and unlocking the vehicle from in-
side
Central locking system . . . . . . . . . . . . . 46
Locking doors manually . . . . . . . . . . . . . . . 47
LongLife Service . . . . . . . . . . . . . . . . . . . . 222
Luggage compartment . . . . . . . . . . . . . . . . 75
Extending . . . . . . . . . . . . . . . . . . 78, 79, 80
Fastening rings . . . . . . . . . . . . . . . . . . . 76
Loading . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Load-through hatch . . . . . . . . . . . . . . . . 81
Side storage compartment . . . . . . . . . . 77
Stretch net . . . . . . . . . . . . . . . . . . . . . . . 77
See alsoLoading luggage compartment
158
Luggage rack
SeeRoof carrier . . . . . . . . . . . . . . . . . . . 82
MMain beam headlights . . . . . . . . . . . . . . . . 58
Indicator lamp . . . . . . . . . . . . . . . . . . . . 17
Make-up mirrors . . . . . . . . . . . . . . . . . . . . . 60
Manual operation
Boot lid . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Fuel tank flap . . . . . . . . . . . . . . . . . . . . 219
Tilting panorama roof . . . . . . . . . . . . . . 52
Maximum speed
SeePerformance, weights and
dimensions . . . . . . . . . . . . . . . . . . . . 281
Memory for driver's seat . . . . . . . . . . . . . . 72
Activating remote control key . . . . . . . 73
Recalling settings . . . . . . . . . . . . . . . . . 72
Storing settings . . . . . . . . . . . . . . . . . . . 72
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Mileage recorder . . . . . . . . . . . . . . . . . . . . . 14
Minimising pollution . . . . . . . . . . . . . . . . . 196
Mirrors
Anti-dazzle setting . . . . . . . . . . . . . . . . . 65
Automatic anti-dazzle exterior mirrors 67
Automatic anti-dazzle interior mirror . 65
Exterior mirrors . . . . . . . . . . . . . . . . . . . 66
Interior mirror . . . . . . . . . . . . . . . . . . . . 65
Make-up mirrors . . . . . . . . . . . . . . . . . . 60
MMI control console, cleaning . . . . . . . . 213
MMI display, cleaning . . . . . . . . . . . . . . . . 213
Mobile phones . . . . . . . . . . . . . . . . . . . . . . 240
Modifications . . . . . . . . . . . . . . . . . . . . . . . 239
NNatural leather . . . . . . . . . . . . . . . . . . . . . . 214
Number plate light
Changing bulb . . . . . . . . . . . . . . . . . . . 274OOctane rating . . . . . . . . . . . . . . . . . . . . . . . 217
Oil
SeeEngine oil . . . . . . . . . . . . . . . . . . . . 223
Oil consumption . . . . . . . . . . . . . . . . . . . . 223
Oil dipstick . . . . . . . . . . . . . . . . . . . . . . . . . 223
Oil level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
On-board computer . . . . . . . . . . . . . . . . . . . 25
Opening
Bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Outside temperature display . . . . . . . . . . . 21
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9PPaint damage . . . . . . . . . . . . . . . . . . . . . . . 212
Paint No. . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Parking aid
Seeparking system . . . . . . . . . . . . . . . 128
Parking brake . . . . . . . . . . . . . . . . . . . . . . . 119
Parking lights . . . . . . . . . . . . . . . . . . . . . . . . 58
parking system
Adjusting warning beeps . . . . . . . . . . 139
Detection range of reversing camera 135
Front and rear, with display . . . . . . . . 129
document_0900452a81793dcc.book Seite 289 Mittwoch, 21. März 2007 5:42 17

Downloaded from www.Manualslib.com manuals search engine Index 290
Front and rear, with display and reversing
camera . . . . . . . . . . . . . . . . . . . . . . . . 131
General notes . . . . . . . . . . . . . . . . . . . 128
Note on distances . . . . . . . . . . . . . . . . 142
Notes on acoustic parking aid . . . . . . 143
Notes on reversing camera . . . . . . . . 143
Parking next to an obstacle . . . . . . . . 141
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Reversing camera (Rear View) . . . . . . 134
Reversing camera, parking mode 1 . 136
Reversing camera, parking mode 2 . 137
Special parking situations . . . . . . . . . 141
Switching graphic display on and off 140
Switching reversing camera on and off . .
140
Towing bracket . . . . . . . . . . . . . . . . . . 138
Passengers
SeeSitting position . . . . . . . . . . . . . . . 155
Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Performance figures
SeePerformance, weights and
dimensions . . . . . . . . . . . . . . . . . . . . 281
Performance, weights and dimensions . 281
General notes . . . . . . . . . . . . . . . . . . . 278
Petrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Polishing . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Pollen filter
Deluxe automatic air conditioner . . . . 91
Deluxe automatic air conditioner plus 99
Pollution filter
Deluxe automatic air conditioner . . . . 91
Deluxe automatic air conditioner plus 99Power management . . . . . . . . . . . . . . . . . 192
Battery power . . . . . . . . . . . . . . . . . . . 193
Driver message . . . . . . . . . . . . . . . . . . 193
Power steering . . . . . . . . . . . . . . . . . . . . . 190
QQuartz clock . . . . . . . . . . . . . . . . . . . . . . . . . 13
quattro
SeeFour-wheel drive . . . . . . . . . . . . . . 191RRadio transmitters . . . . . . . . . . . . . . . . . . 240
Fixed installation . . . . . . . . . . . . . . . . . 240
Mobile equipment . . . . . . . . . . . . . . . . 240
Radio-controlled clock . . . . . . . . . . . . . . . . 13
Rain sensor . . . . . . . . . . . . . . . . . . . . . . . . . 62
Rain sensor defective . . . . . . . . . . . . . . . . . 35
Reading lights
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Rear centre console
Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Rear fog lights . . . . . . . . . . . . . . . . . . . . . . . 55
Rear lights
Defective . . . . . . . . . . . . . . . . . . . . . . . . 36
Rear View camera
SeeReversing camera . . . . . . . . . . . . 131
Rear view mirrors
SeeMirrors . . . . . . . . . . . . . . . . . . . . . . . 65
Rear window, sun blind . . . . . . . . . . . . . . . 61Remote control keys . . . . . . . . . . . . . . . . . . 38
Indicator lamp . . . . . . . . . . . . . . . . . . . . 39
Replacing the battery . . . . . . . . . . . . . . 39
Unlocking and locking . . . . . . . . . . . . . 43
Replacement keys . . . . . . . . . . . . . . . . . . . . 38
Replacement parts . . . . . . . . . . . . . . . . . . 239
Reset button . . . . . . . . . . . . . . . . . . . . . . . . 14
Retaining net . . . . . . . . . . . . . . . . . . . . . . . . 77
Rev counter . . . . . . . . . . . . . . . . . . . . . . . . . 12
Reversing camera . . . . . . . . . . . . . . . 131, 134
Parking mode 1 . . . . . . . . . . . . . . . . . . 136
Parking mode 2 . . . . . . . . . . . . . . . . . . 137
Roof carrier . . . . . . . . . . . . . . . . . . . . . . . . . 82
Attachment points . . . . . . . . . . . . . . . . 82
Roof load . . . . . . . . . . . . . . . . . . . . . . . . 83
Running in . . . . . . . . . . . . . . . . . . . . . . . . . 195
New engine . . . . . . . . . . . . . . . . . . . . . 195
SSAFE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Safe driving . . . . . . . . . . . . . . . . . . . . . . . . 152
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Safety features . . . . . . . . . . . . . . . . . . . . . 152
Seat adjustment
Easy-entry function . . . . . . . . . . . . . . . . 71
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . 70
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Adjusting seat belts . . . . . . . . . . . . . . 163
Belt tensioners . . . . . . . . . . . . . . . . . . . 165
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . 216
During pregnancy . . . . . . . . . . . . . . . . 164
Putting on . . . . . . . . . . . . . . . . . . . . . . . 163
document_0900452a81793dcc.book Seite 290 Mittwoch, 21. März 2007 5:42 17

Downloaded from www.Manualslib.com manuals search engine Index291
Controls
Safety
Driving tips
General maintenance
Self-help
Technical data Safety notes . . . . . . . . . . . . . . . . . . . . . 161
Taking off . . . . . . . . . . . . . . . . . . . . . . . 164
Warning lamp . . . . . . . . . . . . . . . . . . . . 17
Seat heating
Front (deluxe automatic air conditioner)
112
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Seat memory . . . . . . . . . . . . . . . . . . . . . . . . 72
Service interval display . . . . . . . . . . . . . . . 23
Service position for windscreen wipers . . 64
servotronic . . . . . . . . . . . . . . . . . . . . . . . . . 190
Side lights . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Single journey memory . . . . . . . . . . . . . . . 26
Sitting position
Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Front passenger . . . . . . . . . . . . . . . . . . 155
Incorrect sitting position . . . . . . . . . . 157
Rear passengers . . . . . . . . . . . . . . . . . 155
Snow chains . . . . . . . . . . . . . . . . . . . . . . . 237
Sockets
230 Volt . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Spare key . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Starting the engine . . . . . . . . . . . . . . . . 41
Spare parts . . . . . . . . . . . . . . . . . . . . . . . . 239
Spare wheel . . . . . . . . . . . . . . . . . . . . . . . . 246
Speed warning . . . . . . . . . . . . . . . . . . . . . . 28
Speedometer . . . . . . . . . . . . . . . . . . . . . 14, 22
Starting the engine
Jump-starting . . . . . . . . . . . . . . . . . . . . 255
Spare key . . . . . . . . . . . . . . . . . . . . . . . . 41
Tow-starting . . . . . . . . . . . . . . . . . . . . . 257
Starting with jump leads . . . . . . . . . . . . . 255Steering
Locking the steering . . . . . . . . . . . . . . 114
Malfunction . . . . . . . . . . . . . . . . . . . . . . 33
Steering wheel height adjustment
(manual) . . . . . . . . . . . . . . . . . . . . . . . 114
Storage compartments . . . . . . . . . . . . . . . . 89
Front seats . . . . . . . . . . . . . . . . . . . . . . . 90
Stretch net . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Sun blind . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Sun roof (tilting panorama roof) . . . . . . . . 51
Manual operation . . . . . . . . . . . . . . . . . 52
Tilting open and closed . . . . . . . . . . . . 51
Sun visors . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Sunroof (tilting panorama roof)
Convenience open/close function . . . . 50
Switches on driver's door
Central locking system . . . . . . . . . . . . . 46
Switching off the engine . . . . . . . . . 116, 118
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
TTailgate
SeeBoot lid . . . . . . . . . . . . . . . . . . . . . . . 48
Tank capacity . . . . . . . . . . . . . . . . . . . . . . . 279
Technical data . . . . . . . . . . . . . . . . . . . . . . 278
Text messages . . . . . . . . . . . . . . . . . . . . . . . 30
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Total journey memory . . . . . . . . . . . . . . . . 26
Tow-away protection . . . . . . . . . . . . . . . . . 47
Towing
Automatic braking . . . . . . . . . . . . . . . . 199
Trailer stabilisation . . . . . . . . . . . . . . . 199Towing away . . . . . . . . . . . . . . . . . . . . . . . 257
Towing bracket
Parking system . . . . . . . . . . . . . . . . . . . 138
Towing bracket, removable . . . . . . . . . . . 201
Towing bracket, retrofitting . . . . . . . . . . . 206
Towline anchorage
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Tow-starting . . . . . . . . . . . . . . . . . . . . . . . . 259
Traction control system
How the system works . . . . . . . . . . . . 188
Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Accessories . . . . . . . . . . . . . . . . . . . . . . 201
Notes on towing . . . . . . . . . . . . . . . . . . 200
Points to check before towing . . . . . . 198
Technical requirements . . . . . . . . . . . 198
Trailer stabilisation . . . . . . . . . . . . . . . . . . 199
Trailer turn signals
Indicator lamp . . . . . . . . . . . . . . . . . . . . 17
Trailer weights
SeePerformance, weights and
dimensions . . . . . . . . . . . . . . . . . . . . 281
Transport bag
SeeLoad-through hatch . . . . . . . . . . . . 81
Tread depth . . . . . . . . . . . . . . . . . . . . . . . . 234
Trip recorder . . . . . . . . . . . . . . . . . . . . . . . . 14
Trips, checklist . . . . . . . . . . . . . . . . . . . . . . 152
Turn signals . . . . . . . . . . . . . . . . . . . . . . . . . 58
Indicator lamp . . . . . . . . . . . . . . . . . . . . 16
Type plate . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Tyre Mobility System . . . . . . . . . . . . . . . . 247
Tyre pressure . . . . . . . . . . . . . . . . . . . . . . . 232
document_0900452a81793dcc.book Seite 291 Mittwoch, 21. März 2007 5:42 17
