Using the telephone147
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control Your mailbox number is assigned to one-touch dial button . If you
haven't already stored a mailbox number
page 157, you will have
the opportunity do this when you select one-touch dial button .
The second telephone number stored in the SIM card phone book
(position number “2”) is assigned to one-touch dial button .
The next seven telephone numbers in the SIM card phone book are
assigned to buttons to respectively.
Note
•If a position is already assigned, it must be deleted before you
can store a new entry at that position.
•How many position numbers are stored depends on the SIM card
being used.
Applies to vehicles: with handset for the car telephone kit
Answering and ignoring telephone
calls
Answering telephone calls
– Press the control button for Answer, or
– Press the “Call” button
page 140, fig. 124.Ignoring telephone calls
– Press the control button for Reject, or
– Press the “End call” button
page 140, fig. 124.
Depending on whether the caller is stored in the phone book and
whether the number is transmitted with the call, the name, the tele-
phone number or Unknown will appear on the MMI display.
If you activate the Answer on eject function, an incoming call will be
answered immediately when you take the handset out of the carrier

page 156.
Applies to vehicles: with handset for the car telephone kit
Emergency calls
Without SIM card
– Switch on the ignition, the MMI and (if not already acti-
vated) the handset
page 140. A Bluetooth connection
must exist between the handset and the car telephone
kit. Please insert the SIM card should be shown in the
handset display.
– Press the control button for SOS
fig. 132.
1
1
2abc
3def9wxyz
Fig. 131 Incoming call
A5
A3
Fig. 132 Control
button SOS










Using the telephone 148
– When the message Do you really wish to connect to the
emergency number? appears in the handset display,
confirm with Ye s. The emergency number will be dialled.
With SIM card and PIN entered
– Switch on the ignition, the MMI and (if not already acti-
vated) the handset
page 140. A Bluetooth connection
must exist between the handset and the car telephone
kit, and a SIM card must be in the handset.
– If necessary, press the “End call” button to display the
main screen
page 142, fig. 126.
– Enter the emergency number (e.g. 112).
– Press the “Call” button
page 140, fig. 124 to start
dialling.
WARNING
Since your telephone operates via radio waves, a connection
cannot be guaranteed under all circumstances. Do not rely solely
on your telephone when a vital communication (e.g. medical emer-
gency) is involved.
Note
•You can also dial an emergency number on the MMI
page 89.
•Always follow the directions of the emergency operators when
making an emergency call. Do not end the call before you are
requested to do so. Otherwise, this could result in life-saving infor-
mation not being passed on.
•Emergency numbers are not the same for all countries. Please
familiarise yourself with the correct emergency numbers in advance
when travelling in foreign countries or regions where the numbers
may be different.
Applies to vehicles: with handset for the car telephone kit
Ending calls
– To end an active call or stop dialling a number, press the
control button for End call
fig. 133, or
– Press the “End call” button
page 140, fig. 124.
If you placed a call on hold earlier on, that call will remain on hold.
Use the Resume function to continue the call.
If a menu is open in the handset display, the menu will be closed the
first time you press the “End call” button. The active call is discon-
nected when you press the “End call” button again.
A7
Fig. 133 Active call
A3










Using the telephone 150
Private mode/Handsfree mode
•Private mode - to talk over the handset. The other vehicle occu-
pants cannot hear the call. Private mode is automatically activated
if you remove the handset from the carrier during an active call.
•Handsfree mode - to talk over the vehicle's handsfree system. If
you are talking over the handset (private mode), you can use the
Handsfree mode option on the handset to switch to handsfree
mode. Handsfree mode is automatically activated if you insert the
handset in the carrier during an active call.
Note
The options available during a call may vary depending on the
mobile network service provider. For more information, contact your
service provider.
Applies to vehicles: with handset for the car telephone kit
Answering and replacing further
calls
Answering further telephone calls
If you are already talking on the phone when someone else calls, the
options Answer and Reject will appear on the display.
If you select Answer, the active call will be placed on hold and you
will receive the incoming call. If you select Reject, the incoming call
will be declined.
Replacing a call
If you already have a call on hold and are talking to a second caller
when a third call is received, the options Replace and Reject will
appear on the display.
If you select Replace, the active call will be replaced by the incoming
call. If you select Reject, the incoming call will be declined.
Note
The option Call waiting must be activated on your mobile phone for
you to be made aware of incoming calls during a conversation

page 156. This option depends on your mobile network service
provider.










Menus151
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
Menus
Applies to vehicles: with handset for the car telephone kit
Introduction
Use the navigation button to select the main menus.
– Press the control button for Menu
page 142,
fig. 126. The tab of the main menu shown in the
display is highlighted in white.
– To select a main menu, e.g. Settings
fig. 135, use the
navigation button to scroll left or right across the display.
The submenu of the main function you have selected will
appear in the centre of the display.– Press the bottom part of the navigation button to jump to
the submenu.
– Press the top or bottom part of the navigation button to
scroll up or down to the desired submenu item, for
example Call options. An arrow to the right of the
submenu item in the centre part of the display

fig. 136 indicates that further submenus are available.
– Press the right part of the navigation button to open the
next submenu level.
– To activate or deactivate a selection button
fig. 136,
press the control button for Ok.
– To jump one level up the menu tree, press the control
button for Back
fig. 136.
– To close the menus, press the “End call” button.
When the arrows on either side of the main menu name are
displayed, you can browse through the main menus by pressing the
right or left side of the navigation button.
If you have called up a submenu in the centre of the display and
several submenu levels are available, you can browse through the
submenus by pressing the right or left side of the navigation button.
Select Options to call up further options for a function displayed on
the handset screen.
Use the handset keypad to enter a name, text message or other
characters
page 143.
Fig. 135 Settings
Fig. 136 Settings
menu - Call options
A8
AA
A1
A2
AB










Menus 152
Applies to vehicles: with handset for the car telephone kit
“Last calls” menu
You can find, dial, store or delete telephone numbers in
the call lists.
– Press the control button for Menu
page 142,
fig. 126.
Numbers dialled
The Numbers dialled list contains the last twenty24) names or
numbers you have dialled.Missed calls
The Missed calls list contains the names or numbers of the last
twenty
24) missed calls.
Symbol
page 142, fig. 126 appears on the display.
Received calls
The Received calls list contains the names or numbers of the last
twenty
24) answered calls.
Delete
•Numbers dialled - to delete the complete call list.
•Missed calls - to delete the complete call list.
•Received calls - to delete the complete call list.
•All calls - to delete all of the call lists.
Options
The following options are available in the Numbers dialled, Missed
calls or Received calls menu:
•Details - to display the telephone number, date and time.
•Edit number - to change a selected telephone number.
•Store number - to edit and store a name, telephone number and
memory position.
•Delete number - to delete one selected telephone number.
•Call number - to call the selected telephone number.
Note
•If you press the “Call” button
page 140, fig. 124 in the main
screen, the list of dialled numbers will be displayed.
•The call lists contain telephone numbers which were stored after
the mobile phone was connected.
•If the SIM card is changed, the complete contents of the call lists
will be deleted.
24)The total number of phone numbers that can be stored in the call lists may
vary depending on your service provider.
Fig. 137 Last calls
menu
Fig. 138 Submenu
options
A8
A6
A5











Menus153
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
•If you switch the call information on the MMI off and on again

page 97, the complete contents of the call lists will be deleted.
Applies to vehicles: with handset for the car telephone kit
“Phone book” menu
– Press the control button for Menu
page 142,
fig. 126.
– Select Phone book using the navigation button.
New entry
•Name - to enter a first name and surname.
•Number - to enter the telephone number for the entry.
•Pos it ion - used for speed dialling and one-touch dialling

page 146. A free position is automatically suggested.
•Store - to store the phone book entry on the SIM card.
Finding an entry
When you enter the initial letter of an entry you want to find, the
cursor jumps through the list to the entries starting with that letter.
When an entry is selected, you can call up the following functions
by pressing the control button for Options:
•Details - to display the name, telephone number and position of
the entry.
•Edit - to edit the name, telephone number and position of the
entry.
•Delete - to delete the selected entry.
•Call - to call the selected entry.
Memory in use
•SIM - SIM card entries are loaded and displayed.
•Telephone - Phone book entries on the mobile phone are loaded
and displayed. To use this function, a mobile phone with SIM Access
Profile must be connected to the car telephone kit and the SIM card
must be in the phone
page 24.
•SIM+Tel. - SIM card entries and phone book entries on the mobile
phone are loaded and displayed. To use this function, a mobile
phone with SIM Access Profile must be connected to the car tele-
phone kit and the SIM card must be in the phone
page 24. If the
SIM card is in the handset, only the SIM card entries will be
displayed.
The memory in use can be set separately on the MMI
page 100.
Displaying the phone book entries
The phone book entries are displayed in alphabetical order together
with a category symbol
fig. 140, e.g. SIM card, private, business,
mobile phone or telephone symbol.
Fig. 139 Phone book
menu
Fig. 140 Phone book
entries
A8










Menus 154
Applies to vehicles: with handset for the car telephone kit
“Text messages” menu
Text messages can be sent using the handset.
– Press the control button for Menu
page 142,
fig. 126.
– Select Te x t m e s s a g e s using the navigation button.
New text msg
Enter the text on the handset keypad
page 143.
Long texts will be sent in two or more separate messages. The total
message length is shown in the top right-hand corner of the display
and is counted down from 765
page 143, fig. 128.When you open a new text message, you can call up the following
functions by pressing the control button for Options:
•Send - to send the text message you have written.
•Store - to store the text message you have written.
•Insert symbol - to insert special characters such as €.
•Add word - to write a word and add it to the dictionary
•Insert template - to insert a template, e.g. I will be late ...
•Input language - to select German, English, French, Italian,
Spanish or Portuguese for a text message.
•Input mode - to select T9 mode, ABC mode or 123 mode.
Inbox
When you open a new text message in the inbox, you can select the
following functions by pressing the control button for Options:
•Delete - to delete the open text message.
•Call - to dial the number of the person who sent the text
message.
•Reply - to answer a text message you have received.
•Extract number - to copy a telephone number from a text
message into the display for editing.
•Edit - to edit a text message open in the inbox.
•Forward - to forward a text message you have received to
another telephone number.
Outbox
The outbox lists the entries you have stored and sent.
When you open a text message in the outbox, you can select the
following functions by pressing the control button for Options:
•Delete - to delete the open text message.
•Call - to dial the number of the person who sent the text
message.
Fig. 141 Text
messages menu
Fig. 142 Text message
settings
A8
A4










Menus155
MMI componentsMMI control consoleMulti-function steering wheelTelephone handsetVoice control
•Extract number - to copy a telephone number from a text
message into the display for editing.
•Edit - to edit a text message open in the inbox.
•Forward - to forward a text message you have received to
another telephone number.
Templates
The Templates menu is used to insert a text template (e.g. I will be
late ...) into a text message.
Text message settings
•Status report - to receive a delivery status report from the
message centre after you send a text message.
•Va li dity - to specify how long text messages are held at the
message centre.
•Service centre - to retrieve or change the number of the message
centre.
•Memory capacity - to display the total capacity of the text
message memory and the amount of memory used.
•Store text msg - to store text messages in the outbox when they
are sent. The memory can fill up quickly if you activate this function.
If the memory is full, the crossed-out envelope symbol will appear
in the display and no more text messages can be received.
Delete txt msgs
•Read - to delete read text messages from the inbox.
•Unread - to delete unread text messages from the inbox.
•Sent - to delete text messages you have written and sent.
•Unsent - to delete text messages you have written but not sent.
•Delete all - to delete all text messages on the SIM card.
Note
The handset display shows only text messages which are stored on
the SIM card.
Applies to vehicles: with handset for the car telephone kit
“Settings” menu (handset)
– Press the control button for Menu
page 142,
fig. 126.
– Select Settings using the navigation button.
Switch off tel.
The car telephone kit logs off the GSM network and shuts down but
the handset remains connected. If mobile phones are connected,
these connections are closed.
The car telephone kit can be switched on again from the handset
and will automatically log onto the GSM network.
Fig. 143 Settings
Fig. 144 Ring tone
volume
A8
