2008 Acura TSX display

While the multi-information display
shows ‘‘POSITION SETUP,’’ press
the SEL/RESET button on the
steering wheel. The display changes
to ‘‘MEMORY POSITION LINK’’ as
shown above.Press the SEL/RESET button. The
display changes as shown above.
Select ‘‘ON’’ or ‘‘OFF ’’ by pressing
the INFO button, and enter your
selection by pressing the SEL/
RESET button.
If ‘‘MEMORY POSITION LINK’’ is
‘‘ON,’’ the driver’s seat moves to the
positionstoredinthememorywhen
you open the driver’s door, using the
remote transmitter.
Refer to page for setting the seat
position memory. Also ref er to page
forremotetransmitteruse.
132 143
Position Setup
Memory Posit ion L ink
Multi-Inf ormation Display
104
\f—\f—
y
\f\fy
(\fy\f
\fy
2008 TSX

If you f ail to enter your selection,
you will see the above display f or
several seconds, and the display goes
back to ‘‘CUSTOMIZE MENU.’’
Repeat the setup.
When your selection is entered, you
will see the above display for several
seconds, then the display goes back
to ‘‘CUSTOMIZE MENU.’’
To exit ‘‘MEMORY POSITION
LINK,’’ press the INFO button until
you see ‘‘EXIT,’’ then press the SEL/
RESET button. The display goes
back to ‘‘CUSTOMIZE MENU.’’
Multi-Inf ormation Display
Inst rument s and Cont rols
105
\f—\f—
y
\f\fy
(\fy\f

\fy
2008 TSX

There are two custom settings in the
Lighting Setup:Press the SEL/RESET button. The
display changes as shown above.
Each time you press the INFO
button, the highlighted number
changes f rom ‘‘15 sec,’’ to ‘‘30 sec,’’
andthento‘‘60sec.’’Tomakeyour
selection, press the SEL/RESET
button.
INTERIOR LIGHT
DIMMING TIME
HEADLIGHT AUTO OFF TIMER
While the ‘‘LIGHTING SETUP’’ is
displayed, press the SEL/RESET
button on the steering wheel. Each
time you press the INFO button, the
display changes between
‘‘INTERIOR LIGHT DIMMING
TIME’’ and ‘‘HEADLIGHT AUTO
OFF TIMER.’’ To make your
selection, press the SEL/RESET
button. The interior lights f ade out when you
close all doors. You can change the
time that the interior lights fade out.
While the multi-information display
shows ‘‘LIGHTING SETUP,’’ press
the SEL/RESET button on the
steering wheel. The display changes
to ‘‘INTERIOR LIGHT DIMMING
TIME’’ as shown above.
Lighting Setup
Int erior L ight Dimming T ime
Multi-Inf ormation Display
106
\f—\f—
y
\f\fy
(\fy\f


y
2008 TSX

If you f ail to enter your selection,
you will see the above display f or
several seconds, and the display goes
back to ‘‘CUSTOMIZE MENU.’’
Repeat the setup.
When your selection is entered, you
will see the above display for several
seconds, and then the display goes
back to ‘‘CUSTOMIZE MENU.’’
To exit ‘‘INTERIOR LIGHT
DIMMING TIME,’’ press the INFO
button until you see ‘‘EXIT,’’ then
press the SEL/RESET button. The
display goes back to ‘‘CUSTOMIZE
MENU.’’
CONT INUED
Multi-Inf ormation Display
Inst rument s and Cont rols
107
\f—\f—
y
\f\fy
(\fy\f

y
2008 TSX

While the multi-information display
shows ‘‘LIGHTING SETUP,’’ press
the SEL/RESET button on the
steering wheel. Then press the
INFO button to display
‘‘HEADLIGHT AUTO OFF TIMER’’
as shown above.Press the SEL/RESET button. The
display changes as shown above.
Each time you press the INFO
button, the highlighted number
changes f rom ‘‘0 sec,’’ to ‘‘15 sec,’’ to
‘‘30 sec,’’ and then to ‘‘60 sec.’’Press the INFO button repeatedly
until the desired time appears, then
press the SEL/RESET button to
enter your selection.
When your selection is entered, you
will see the above display for several
seconds, and then the display goes
back to ‘‘CUSTOMIZE MENU.’’
Headlight A uto Of f T imer
Multi-Inf ormation Display
108
\f—\f—
y
\f
\fy
(\fy\f

y
2008 TSX

The headlights, parking lights,
taillights, and license plate lights
turn of f af ter the selected time when
you remove the key f rom the ignition
switch and close the driver’s door.If you f ail to enter your selection,
you will see the above display f or
several seconds, then the display
goes back to ‘‘CUSTOMIZE MENU.’’
Repeat the setup.To exit ‘‘HEADLIGHT AUTO OFF
TIMER,’’ press the INFO button
until you see ‘‘EXIT,’’ then press the
SEL/RESET button. The display
goes back to ‘‘CUSTOMIZE MENU.’’
Multi-Inf ormation Display
Inst rument s and Cont rols
109
\f—\f—
y
\f
\fy
(\fy\f

y
2008 TSX

There are three custom settings in
the Door · Window Setup:DOOR LOCK MODE
KEYLESS LOCK
ACKNOWLEDGEMENT
SECURITY RELOCK TIMER
While the multi-information display
shows ‘‘DOOR · WINDOW SETUP,’’
press the SEL/RESET button on the
steering wheel. Each time you press
the INFO button, the display
changesasshowninthenext
column.
To customize a setting, press the
INFO button repeatedly until you see
the setting you want to customize,
and press the SEL/RESET button.
Then f ollow the procedures
described on the f ollowing pages. Door · Window Setup
Multi-Inf ormation Display
110
: Press the INFO Button.
——
y


y
(y

y
2008 TSX

While the multi-information display
is showing ‘‘DOOR · WINDOW
SETUP,’’ press the SEL/RESET
buttononthesteeringwheel.The
display changes to ‘‘DOOR LOCK
MODE’’ as shown above.Press the SEL/RESET button. The
display changes as shown above.
In def ault setting, if you push the
UNLOCK button once on the remote
transmitter or turn the key clockwise
in the driver’s door lock, only the
driver’s door unlocks.
You can select whether only the
driver’s door unlocks or all the doors
unlock in ‘‘DOOR LOCK MODE.’’
Select ‘‘DRIVER DOOR’’ or ‘‘ALL
DOORS’’ by pressing the INFO
button, and enter your selection by
pressing the SEL/RESET button.
CONT INUED
Door L ock Mode
Multi-Inf ormation Display
Inst rument s and Cont rols
111
\f—\f—
y
\f
y
(\fy\f

y
2008 TSX
