2008 Acura RL display

ÛÝÛ
Ý
While the multi-information display
is in the METER SETUP of the
CUSTOMIZE GROUP, press the
SEL/RESET button. The screen
changes to CUSTOMIZE MENU.
Press the INFO ( / ) button until
you see the above display. Press the SEL/RESET button. The
screen changes as shown above. The
highlighted number is the current
setting above or below the outside
temperature. Press the INFO ( /
) button repeatedly until the
number you want appears, then
press the SEL/RESET button to
enter your selection.
If you sometimes f ind that the
temperature reading is a f ew
degrees above or below the actual
temperature, you can adjust it by
f ollowing these instructions:
CONT INUED
A djust Outside T emp. Display
Multi-Inf ormation Display
Inst rument s and Cont rols
97
\f—\f—
y\f
y
(\fy\f
\fy
2008 RL

ÛÝ
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY. To exit ADJUST OUTSIDE TEMP.
DISPLAY without changing the
current setting, select EXIT by
pressing the INFO ( / ) button,
then press the SEL/RESET button.
The screen goes back to
CUSTOMIZE MENU.
If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the
adjust outside air temperature
display setup.
Multi-Inf ormation Display
98
\f—\f—
y\fy
(\fy\f
\fy
2008 RL

ÛÝÛÝ
While METER SETUP is shown in
the CUSTOMIZE GROUP of the
multi-inf ormation display, press the
SEL/RESET button. The screen
changes to CUSTOMIZE MENU.
Press the INFO ( / ) button until
you see the above display.
To cause trip A and average fuel
economy A to reset every time you
ref uel your vehicle, f ollow these
instructions:
Press the SEL/RESET button. The
screen changes as shown above.
Select ON or OFF by pressing the
INFO ( / ) button, then press the
SEL/RESET button to enter your
selection.
CONT INUED
T rip A & A vg. Fuel Reset wit h Ref uel
Multi-Inf ormation Display
Inst rument s and Cont rols
99
\f—\f—
y\fy
(\fy\f
\fy
2008 RL

ÛÝ
To exit TRIP A & AVG. FUEL
RESET with REFUEL without
changing the current setting, select
EXIT by pressing the INFO ( / )
button, then press the SEL/RESET
button. The screen goes back to
CUSTOMIZE MENU.
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY.
If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the trip
A and average f uel reset with ref uel
setup.
Multi-Inf ormation Display
100
\f—\f—
y\fy
(\fy\f
\fy
2008 RL

ÛÝ
µ
µ
µ
ÛÝ
While METER SETUP is shown in
the CUSTOMIZE GROUP of the
multi-inf ormation display, press the
SEL/RESET button. The screen
changes to CUSTOMIZE MENU.
Press the INFO ( / ) button until
you see the above display.
IGN OFF The elapsed time is
reset when you turn the ignition
switch to the LOCK (0) position.
TRIP A The elapsed time is reset
when the Trip A is reset.
TRIP B The elapsed time is reset
when the Trip B is reset.
Press the SEL/RESET button. The
screen changes as shown above.
Select the desired setting by
pressing the INFO ( / ) button,
then press the SEL/RESET button
to enter your selection.
There are three elapsed time reset
choices you can make:
CONT INUED
Elapsed T ime Reset
Multi-Inf ormation Display
Inst rument s and Cont rols
101
\f—\f—
y\f\fy
(\fy\f
\fy
2008 RL

ÛÝ
When your choice is set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE ENTRY. To exit ELAPSED TIME RESET
without changing the current setting,
select EXIT by pressing the INFO
( / ) button, then press the SEL/
RESET button. The screen goes
back to CUSTOMIZE MENU.
If your choice is not set, you will see
the above display f or several seconds,
then the screen goes back to
CUSTOMIZE SETUP. If this
happens, you need to repeat the
elapsed time reset setup.
Multi-Inf ormation Display
102
\f—\f—
y\f
y
(\fy\f
\fy
2008 RL

ÛÝÛ
Ý
ÛÝ
ÛÝ
There are two position setups you
can make:MEMORY POSITION LINK
AUTO TILT & TELESCOPIC
While the multi-information display
is in the CUSTOMIZE GROUP
screen, select POSITION SETUP by
pressing the INFO ( / ) button,
and then press the SEL/RESET
button.
Each time you press the INFO ( / ) button, the screen changes as
shown in the illustration. Press the
INFO ( / ) button until you see
the setting you want to customize,
then press the SEL/RESET button
to enter your selection.
CONT INUED
Position Setup
Multi-Inf ormation Display
Inst rument s and Cont rols
103
Press the or button.
Press the SEL/RESET button. seepage104
seepage106
\f—\f—
y\fy
(\fy\f
\fy
2008 RL

ÛÝ
When Memory Position Link is set
to ON, the driver’s seat, the steering
wheel, and the outside mirror
positions move to the positions
stored in memory. To cause the
memory to activate, open the driver’s
door with the remote, or grab the
door handle while carrying the
remote.
To set the seat memory position, see
page . For inf ormation on using
the remote, see page . While the multi-information display
is in the POSITION SETUP screen
of the CUSTOMIZE GROUP, press
the SEL/RESET button. The screen
changes to the above display.Press the SEL/RESET button. The
screen changes as shown above.
Select ON or OFF by pressing the
INFO ( / ) button, then press the
SEL/RESET button to enter your
selection.
160
170
Memory Posit ion L ink
Multi-Inf ormation Display
104
\f—\f—
y\f\fy
(\fy\f
\fy
2008 RL
