This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise to
about the middle of the gauge. In
severe driving conditions, the pointer
may rise to the upper zone. If it
reaches the red (hot) mark, pull
safely to the side of the road. Forinstructions and precautions on
checking the engine’s cooling
system, see page .This shows how much f uel you
have. It may show slightly more
or less than the actual amount.
434
Gauges
Temperature Gauge Fuel Gauge
72
U.S. model is shown.SPEEDOMETER
FUEL GAUGE
TEMPERATURE
GAUGE TACHOMETER
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
\f—\f—\fy\f
\fy
()-
\fy\f\fy
2008 MDX

Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
inf ormation display along with a
‘‘CHECK TIRE PRESSURE’’
message.If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure/
TPMS indicator and message on the
multi-inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible.
425
CONT INUED
Tire Pressure Monitoring System (TPMS)
Low Tire Pressure/
TPMS Indicator
Driving
351
\f—\f—\fy
\f\fy
()-
\fy\fy
2008 MDX

Constant application of the brakes
when going down a long hill builds
up heat and reduces their ef f ective-
ness. Use the engine to assist the
brakes by taking your f oot of f the
accelerator and downshif ting to a
lower gear.
Check the brakes after driving
through deep water. Apply the
brakes moderately to see if they f eel
normal. If not, apply them gently and
f requently until they do. Be extra
cautious in your driving.
Your vehicle is equipped with disc
brakes at all f our wheels. A power
assist helps reduce the ef f ort needed
on the brake pedal. The emergency
brake assist system increases the
stopping f orce when you depress the
brake pedal hard in an emergency
situation. The anti-lock brake system
(ABS) helps you retain steering
control when braking very hard.
Resting your f oot on the pedal keeps
the brakes applied lightly, builds up
heat, and reduces their ef f ectiveness
and reduces brake pad life. In
addition, f uel economy can be
reduced. It also keeps your brake
lights on all the time, conf using
drivers behind you.As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Tire Pressure Monitoring System (TPMS), Braking System
Braking System
356
\f—\f—\fy
\f
\fy
()-
\fy\f
y
2008 MDX

Under these conditions, trailer
stability assist begins to stabilize the
vehicle/trailer combination by
reducing the vehicle speed. The
control unit sends signals to
selectively apply the brakes and
regulate the engine output. The
brake lights of your vehicle will be
turned on automatically by the
system even if you do not keep the
pressure on the brake pedal.
Your vehicle is equipped with trailer
stability assist f unction. This
f unction works on the same sensors
as the vehicle stability assist (VSA)
system. This f unction helps to
stabilize the vehicle/trailer
combination when the trailer
severely sways or oscillates. For
more inf ormation of the VSA system,
see page .
When the brakes are applied, the
trailer’s brake lights come on along
with the vehicle brake lights.
When the trailer stability assist
activates, you will see the VSA
activation indicator blink. There may
also be some noise f rom the VSA
hydraulic system.Trailer stability assist cannot prevent
a loss of control. Always reduce the
vehicle speed and steer f irmly. Do
not brake suddenly or make quick
steering motion. It could cause the
trailertojackknifeorturnoverand
the system becomes inef f ective.
Trailer stability assist cannot prevent
swaying that can occur in crosswinds
and in normal and emergency
driving maneuvers. It helps only to
stabilize the vehicle/trailer
combination in these conditions,
af ter the oscillation becomes severe.
If the function detects the vehicle/
trailer instability, it checks if the
swaying is caused by the trailer, and
if the trailer swaying or oscillation is
increasing.
The vehicle/trailer combination is
more af f ected by crosswinds,
buf f eting, and improper tongue load.
These conditions can make the
trailer unstable, and cause it to sway. Always obey the recommended
speed limits f or towing a trailer, see
page .
Trailer stability assist will also be
inef f ective while driving at high
speed or towing a trailer with a high
center of gravity.
359
373
T railer Stability A ssist
Driving
375
\f—\f—\fy
\f

y
()-
\fy\f\fy
2008 MDX

If youturnoff theVSA,thetrailer
stability assist f unction also shuts of f .
Press and hold the VSA of f switch
until you hear a beep (see page ).
The VSA activation indicator comes
on as a reminder. Press and hold the
switch again to turn the system on.
The function turns on every time you
start the engine along with the VSA,
even if you turned it of f the last time
you drove the vehicle.
The control unit monitors the VSA
circuitry and the braking system. If
there is a problem with the brake
lighting system, the trailer stability
assist f unction shuts down and the
‘‘CHECK TRAILER STABILITY
ASSIST’’ message appears on the
multi-inf ormation display.
If you see this message, have your
vehicle checked at your dealer as
soon as possible. In this case, your vehicle still has the
VSA traction and stability
enhancement, but it will not have the
trailer stability assist f unction.
If there is a problem with the VSA
system, the system and Trailer
Stability Assist shuts of f . The VSA
system and VSA activation indicators
also come on (see page ).
The ABS indicator and the brake
system indicator may also come on
along with the VSA system indicator.
If you see these warning indicators,
have your vehicle checked at your
dealer as soon as possible.
359
360
T railer Stability A ssist
Trailer Stability Assist Failure
376
\f—\f—\fy
\f
y
()-
\fy\f
y
2008 MDX

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.
This section also includes
instructions on how to read the
maintenance minder messages on
the multi-information display, and
instructions f or simple maintenance
tasks you may want to take care of
yourself .......................
Maintenance Saf ety .382
....................
Maintenance Minder .383
..............................
Fluid Locations .391
.......
Engine Compartment Cover .392
........................
Adding Engine Oil .393
Changing the Engine Oil and
...........................................
Filter .394
..............................
Engine Coolant .396
....................
Windshield Washers .398
....
Automatic Transmission Fluid .399
....................................
Brake Fluid .401
....................
Power Steering Fluid .402
....................................
Timing Belt .402
.............................................
Lights .403
..................
Dust and Pollen Filter .409
................
Cleaning the Seat Belts .409
.....................................
Floor Mats .410
.................................
Wiper Blades .411
...............................................
Tires .415
...................
Checking the Battery .421
.............................
Vehicle Storage .422
469
Maintenance
Maint enance
381
\f—\f—\fy
\f
\fy
()-
\fy\fy
2008 MDX

µµµ
µ
µ µ
Ì Youshouldcheckthefollowing
items at the specif ied intervals. If
you are unsure of how to perf orm
any check, turn to the appropriate
page listed.
Engine oil level Check every
time you fill the fuel tank. See
page .
Engine coolant level Check the
radiator reserve tank every time
you f ill the f uel tank. See page .
Automatic transmission Check
the f luid level monthly. See page .
Brakes Check the f luid level
monthly. See page .
Tires Check the tire pressure
monthly. Examine the tread f or
wear and foreign objects. See page . Lights Check the operation of
the headlights, parking lights,
taillights, high-mount brake light,
and license plate lights monthly.
See page .
U.S. Vehicles:
According to state and federal
regulations, f ailure to perf orm
maintenance on the items marked
with will not void your emissions
warranties. However, Acura
recommends that all maintenance
services be perf ormed in accordance
with the intervals indicated by the
Multi-Inf ormation Display. 326
326
399 401
416 403
Owner’s Maintenance Checks
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’to EPA
standards.
Maintenance Minder
Maint enance
389
\f—\f—\fy
\f
\fy
()-
\fy\fy
2008 MDX

Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position:You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run.
When you turn the ignition switch to
the START (III) position, you do not
hear the normal noise of the engine
trying to start. You may hear a
clicking sound, a series of clicks, or
nothing at all. If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page ). You can
then try jump starting the vehicle
f rom a booster battery (see page
).
In this case, the starter motor’s
speed sounds normal, or even f aster
than normal, when you turn the
ignition switch to the START (III)
position, but the engine does not run. Are you using a properly coded
key? An improperly coded key will
cause the immobilizer system
indicator in the instrument panel
to blink rapidly (see page ).
Check these things:
Check the transmission interlock.
The transmission must be in Park
or neutral or the starter will not
operate.
Turn the ignition switch to the ON
(II) position. Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See
on page .
Turn the ignition switch to the
START (III) position. If the
headlights do not dim, check the
condition of the f uses. If the f uses
areOK,thereisprobably
something wrong with the
electrical circuit for the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem. See on page . 421
432
432
446 70
CONT INUED
Nothing Happens or the Starter
Motor Operates Very Slowly T he Starter Operates Normally
Jump Starting
Emergency T owing
If theEngineWon’tStart
T aking Care of t he Unexpect ed
431
\f—\f—\fy
\f\fy
()-
\fy\fy
2008 MDX
