CHANGING A FUSE
Operating procedure for replacing a
faulty fuse with a new fuse to rectify a
failure of the corresponding function.
There are two fuseboxes under the
dashboard, one fusebox in the en-
gine compartment and another on
the battery.
Changing a fuse
Before replacing a fuse, it is essen-
tial to fi nd the cause of the incident
and to have it rectifi ed. The fuse
identifi cation numbers are indicated
inside the fusebox.
Replace a blown fuse with one of the
same rating (the same colour). Use the special tool
A that is pro-
vided in the fuse housing fl ap, which
also contains spare fuses.

Correct Incorrect

Tool A

Access to the fi rst
dashboard fusebox
Fuses under the dashboard
Your vehicle's electrical
system is designed to oper-
ate with either standard or
optional equipment.
Before installing electrical equip-
ment or accessories on your vehi-
cle, consult a CITROËN dealer.
CITROËN declines all responsibil-
ity for the consequences and costs
that are caused by faults or repairs
on your vehicle resulting from the in-
stallation of accessories that are not
supplied and/or not recommended by
CITROËN and not installed according
to its instructions, particularly when
the energy consumption of all of the
additional accessories connected ex-
ceeds 10 milliamperes (Ma).

181
XI
P R A C T I C A L I N F O R M A T I O N
Fuses under the dashboard
Access to the fuses

 Undo the screw by a quarter turn
and pivot the housing. Table of fuses

Fuse N° Rating Functions

F1 15 A Rear screen wipe

F2 30 A Locking and unlocking earth

F3 5 A Airbags and pretensioners

F4 10 A Multimedia, photochromic rear view mirror, particle
fi lter, diagnostic socket, air conditioning, manual
headlamp height adjustment

F5 30 A Front windows, front door electronics control pad,
panoramic glass roof

F6 30 A Rear windows

F7 5 A Interior lamps, refrigerated glovebox, radio

F8 20 A Multifunction screen, radio, steering wheel controls,
multimedia, defl ation detection, alarm, trailer

F9 30 A Multimedia, front 12 V sockets, torch, radio

F10 15 A Height corrector (suspension)

F11 15 A Brake switch, ignition switch

F12 15 A Parking assistance, automatic screen wipe and
lighting, passenger’s electric seat, lane departure
warning system, Hi-Fi amplifi er, trailer

F13 5 A Engine relay unit (BSM), driver’s electric seat

F14 15 A
Air conditioning, Bluetooth ® hands-free kit, automatic
gearbox lever, airbags, instrument panel

F15 30 A Locking and unlocking

F16 - SHUNT

F17 40 A Heated rear screen

182
XI
P R A C T I C A L I N F O R M A T I O N

Access to the second dashboard
fusebox

After any operation on the fuses
in the fusebox, check that the
fusebox cover is put back cor-
rectly for their protection. Table of fuses

Fuse N° Rating Functions

F29 20 A Heated seats

F30 - Not used

F31 40 A Trailer relay unit

F32 15 A Rear 12 V socket

F33 5 A Parking assistance, automatic screen wipe and
lighting, passenger’s electric seat, lane departure
warning system, Hi-Fi amplifi er

F34 5 A Trailer

F35 - Not used

F36 20 A Hi-Fi amplifi er

F37 10 A Air conditioning, light pack

F38 30 A Driver’s electric seat

F39 5 A Fuel fl ap

F40 30 A Passenger’s electric seat, panoramic glass roof

183
XI
P R A C T I C A L I N F O R M A T I O N
Fuses in the engine
compartment
Access to the fuses

 Detach and remove the cover.

After any operation, carefully re-
close the cover. If the cover is not
correctly positioned or not proper-
ly closed, this could cause serious
problems on your vehicle. For the
same reason, take care not to spill
any liquid in the fusebox.
All work on the maxi-fuses,
which are located in these
fuseboxes and which give
extra protection, must be carried
out by CITROËN technicians.

184
XI
P R A C T I C A L I N F O R M A T I O N
Table of fuses
Fuse N° Rating
Functions

F1 20 A Engine management

F2 15 A Horn

F3 10 A Screen wash pump

F4 20 A Headlamp wash pump

F5 15 A Engine components

F6 10 A Xenon dual-function directional headlamps, automatic headla
mp height adjustment, clutch
switch, protection switch box (BCP)

F7 10 A Automatic gearbox, engine coolant level switch, power steering

F8 25 A Starter motor

F9 10 A Stoplamp switch

F10 30 A Engine components

F11 40 A Rear blower

F12 30 A Screen wipe

F13 40 A Built-in Systems Interface (BSI)

F14 30 A Air pump, heat exchange saver

F15 10 A Right-hand main beam

F16 10 A Left-hand main beam

F17 15 A Left-hand dipped beam

F18 15 A Right-hand dipped beam

F19 15 A Engine components

F20 10 A Engine components

F21 5 A Cooling fan relay

185
XI
P R A C T I C A L I N F O R M A T I O N
Fuses on the battery
After any operation, carefully re-
close the cover. If the cover is not
correctly positioned or not proper-
ly closed, this could cause serious
problems on your vehicle. For the
same reason, take care not to spill
any liquid in the fusebox.
Table of fuses
Fuse N° Rating
Functions

F1 5 A Automatic gearbox actuator

F2 5 A Stop switch

F3 5 A Battery charge estimation ECU

F4 20 A ESP supply

F5 5 A ESP supply

F6 20 A ECU for 6-speed electronic gearbox/automatic gearbox
Access to the fuses

 Detach and remove the cover.
Fuses F1 to F6 are located on the
small board, clipped vertically on the
battery fusebox. Fuses
F7 to F12 are midi-
fuses. All work on these
fuses must be carried out
by CITROËN technicians.

186
XI
P R A C T I C A L I N F O R M A T I O N
BATTERY
Procedure for charging your battery
when it is fl at or for starting the en-
gine using another battery.
Access to the battery
The battery is located under the
bonnet.
To gain access to it:

 open the bonnet using the inte-
rior lever, then the exterior lever,

 secure the bonnet strut,

 remove the plastic cover to gain
access to the two terminals,

 unclip the fuse box to remove
the battery, if necessary.
Do not force the plate as locking
will not be possible of the clip is po-
sitioned incorrectly.
Start the procedure again. Starting using another battery

 Connect the red cable to the posi-
tive terminal (+) of the fl at battery

A , then to the positive terminal (+)
of the slave battery B .

 Connect one end of the green or
black cable to the negative ter-
minal (-) of the slave battery B .

 Connect the other end of the
green or black cable to an earth
point C on the broken down ve-
hicle.

 Operate the starter, let the en-
gine run.

 Wait until the engine returns to
idle and disconnect the cables.
Charging the battery using a
battery charger

 Disconnect the battery from the
vehicle.

 Follow the instructions for use
provided by the manufacturer of
the charger.

 Reconnect starting with the neg-
ative terminal (-).

 Check that the terminals and
connectors are clean. If they are
covered with sulphate (whitish or
greenish deposit), remove them
and clean them.
Disconnecting/Reconnecting
the cables

 Raise the locking plate 1 fully.

 Position the open clip of the ca-
ble on the positive (+) terminal of
the battery.

 Press vertically on the clip 2 to
position it correctly against the
battery.

 Lock the clip by lowering the
plate 1 .

187
XI
P R A C T I C A L I N F O R M A T I O N
The batteries contain harm-
ful substances such as sul-
phuric acid and lead. They
must be disposed of in accordance
with regulations and must not, in
any circumstances, be discarded
with household waste.
Take used remote control batteries
and vehicle batteries to a special
collection point.
It is advisable to disconnect the
battery if the vehicle is to be left un-
used for more than one month.
Do not disconnect the ter-
minals while the engine is
running.
Do not charge the batteries without
disconnecting the terminals fi rst.
Do not push the vehicle to start the
engine if it is fi tted with a 6-speed
electronic gearbox system. Following reconnection of the
battery
Following reconnection of the bat-
tery, switch on the ignition and wait
1 minute before starting to permit
initialisation of the electronic sys-
tems. However, if slight diffi culties
are encountered following this oper-
ation, contact a CITROËN dealer.
Referring to the corresponding sec-
tion, you must yourself reinitialise:
- the remote control key,
- the one-touch electric windows,
- the glass panoramic roof shutter,
- the parameters of the multi-
function display,
-
the audio equipment radio stations,
- the GPS satellite navigation system.
Before disconnecting the battery
Wait 2 minutes after switching off
the ignition before disconnecting
the battery.
Close the windows and the doors
before disconnecting the battery.
ENERGY ECONOMY MODE
System which manages the duration
of use of certain functions to con-
serve a suffi cient level of charge in
the battery.
After the engine has stopped, you can
still use functions such as the audio
and telematics system, windscreen
wipers, dipped headlamps, courtesy
lights, etc. for a maximum combined
duration of thirty minutes. Switching to economy mode
Once the thirty minutes are over, a
message appears on the multi-function
display indicating that the vehicle has
switched to economy mode and the
active functions are put on standby.
If the telephone is being used at this
time:
- it will be maintained for 10 min-
utes with your Audio system
hands-free kit,
- it will be maintained for 10 min- utes with the NaviDrive, then it
will transfer to your telephone
depending on its model.
Exiting economy mode
These functions are reactivated au-
tomatically next time the vehicle is
driven.
In order to resume the use of these
functions immediately, start the en-
gine and let it run for at least 5 min-
utes.
A fl at battery prevents the
engine from starting (refer
to the corresponding para-
graph).
