CHANGING A BULB
P r o c e d u r e f o r r e p l a c i n g a f a u l t y b u l b
w i t h a n e w b u l b w i t h o u t t h e u s e o f
a n y t o o l s . Headlamps
Model with halogen headlamps
1. Dipped beams (H7 - 55 W)
2. Main beams (H1 - 55 W)
3. Sidelamps (H6 W - 6 W)
4. Direction indicators
(H21 - 21 W) A s l i g h t m i s t i n g m a y a p p e a r o n t h e
internal surface of the headlamp
glass in some climatic conditions
( e . g . l o w t e m p e r a t u r e o r h u m i d i t y ) ;
this disappears after the lamps have
b e e n o n f o r a f e w m i n u t e s .
D o n o t t o u c h t h e b u l b d i r e c t l y
w i t h y o u r fi n g e r s , u s e l i n t - f r e e
c l o t h s .
T h e h e a d l a m p s a r e fi t t e d w i t h p o l y -
c a r b o n a t e g l a s s w i t h a p r o t e c t i v e
coating:
do not clean them using a dry
or abrasive cloth, nor with a
detergent or solvent product,
w h e n u s i n g a h i g h p r e s s u r e
w a s h e r o n p e r s i s t e n t m a r k s , d o
not direct at the lamps or their
outlines for too long, so as not to
damage their coating and their
s e a l s .
Changing a halogen bulb
s h o u l d o n l y b e d o n e a f t e r
the headlamp has been
s w i t c h e d o f f f o r a f e w m i n u t e s ( r i s k
o f s e r i o u s b u r n s ) .
I t i s i m p e r a t i v e t o u s e o n l y a n t i -
u l t r a v i o l e t ( U V ) t y p e b u l b s i n o r d e r
n o t t o d a m a g e t h e h e a d l a m p .
Page 160 of 282
138
XI
P R A C T I C A L I N F O R M A T I O N
Dipped beam headlamps
R e m o v e t h e r u b b e r c o v e r .
Rotate the bulb-holder a quarter
t u r n a n t i - c l o c k w i s e a n d r e m o v e i t
f r o m i t s h o u s i n g .
R e p l a c e t h e f a u l t y b u l b .
R e p o s i t i o n t h e b u l b - h o l d e r b y
p u s h i n g i t i n , t i g h t e n i n g i t b y a
q u a r t e r t u r n c l o c k w i s e .
R e fi t t h e r u b b e r c o v e r . Main beam headlamps
R e m o v e t h e r u b b e r c o v e r .
D e t a c h t h e c l i p s b y l o w e r i n g
t h e m o n e a c h s i d e o f t h e b u l b .
P u l l o n t h e b u l b - h o l d e r t o r e m o v e i t .
R e p l a c e t h e f a u l t y b u l b .
Push the bulb-holder back into
i t s h o u s i n g .
R e a t t a c h t h e c l i p s .
R e fi t t h e r u b b e r c o v e r . Sidelamps
Rotate the bulb-holder a quarter
t u r n a n t i - c l o c k w i s e .
R e m o v e i t f r o m i t s h o u s i n g .
R e p l a c e t h e f a u l t y b u l b .
R e p o s i t i o n t h e b u l b - h o l d e r .
R o t a t e i t a q u a r t e r t u r n c l o c k w i s e
t o r e p o s i t i o n i n i t s h o u s i n g .
Page 161 of 282
139
XI
P R A C T I C A L I N F O R M A T I O N
Direction indicators Integrated direction indicator side repeaters
The direction indicator bulb is locat-
e d u n d e r n e a t h t h e m a i n b e a m b u l b .
R e m o v e t h e r u b b e r c o v e r .
P u l l o n t h e b u l b - h o l d e r t o r e m o v e i t .
R e p l a c e t h e f a u l t y b u l b .
Reposition the bulb-holder in the
b r a c k e t a n d p u s h i t i n .
R e fi t t h e r u b b e r c o v e r . T o c h a n g e t h e r e p e a t e r , p r e s s d o w n -
w a r d s fi r m l y o n t h e z o n e i n d i c a t e d
b y t h e a r r o w , t h e n p u l l t h e r e p e a t e r .
Repeaters can be obtained from a
C I T R O Ë N d e a l e r . Model with Xenon headlamps
and directional headlamps
1. Dual-function Xenon headlamps
(dipped/main beam)
2. Additional main beams
(H7 - 55 W)
3. Sidelamps (H6 W - 6 W)
( s e e p r e v i o u s p a g e )
4. Direction indicators
(H21 - 21 W)
( s e e p r e v i o u s p a g e )
Page 162 of 282
140
XI
P R A C T I C A L I N F O R M A T I O N
If the headlamp bears this
s y m b o l , a n y o p e r a t i o n t o
change the Xenon dual-
function directional head-
l a m p ( D 1 S - 3 5 W ) m u s t b e c a r r i e d
o u t b y p r o f e s s i o n a l s ( r i s k o f e l e c -
t r o c u t i o n ) .
C o n s u l t a C I T R O Ë N d e a l e r .
It is recommended to change both
bulbs at the same time if one of
t h e m i s f a u l t y .
Dual-function Xenon headlamps
(dipped/main beam)
Additional main beams
R e m o v e t h e r u b b e r c o v e r .
Rotate the bulb-holder a quarter
t u r n a n t i - c l o c k w i s e a n d r e m o v e i t
f r o m i t s h o u s i n g .
R e p l a c e t h e f a u l t y b u l b .
R e p o s i t i o n t h e b u l b - h o l d e r b y
p u s h i n g i t i n , t i g h t e n i n g i t b y a
q u a r t e r t u r n c l o c k w i s e .
R e fi t t h e r u b b e r c o v e r . When using a high-pres-
s u r e w a s h e r o n p e r s i s t e n t
marks, do not direct at the
lamps or their outlines for too long,
so as not to damage their coating
a n d t h e i r s e a l s .
