2008.5 Citroen C4 DAG remote control

5
F A M I L I A R I S A T I O N
O P E N I N G
Remote control

A. Unfolding/folding the key.

B. Unlocking the vehicle.

C. Locking the vehicle.

 56, 57
A long press on button
C locks the
vehicle and closes the windows.
Two successive presses on button C
deadlocks the vehicle. Press once to lock the vehicle.
Press again to unlock the vehicle.

 65
Manual central locking

D.
Activating/deactivating guide-me-home
lighting.

6
F A M I L I A R I S A T I O N
O P E N I N G

 Unlock the vehicle with the remote
control or the key.

 Press up on the lever and lift the
tailgate.
Tailgate Spare wheel and tools
Access to the spare wheel

 Lift the carpet, then remove the tool
holder to gain access to the wheel.

 134
Locking filler cap

 Turn the key a quarter turn to lock
and unlock the fi ller cap.
When refuelling, place the cap on the
carrier on the inside face of the fi ller
fl ap.

 68 If your spare wheel is of different
dimensions to the wheels on the
vehicle, it is essential to use it only
on a temporary basis, and to not
drive above 80 km/h (50 mph).

 67 Access to the tools
The tools are located in a protective
holder in the spare wheel.

B. Removing the fi ller cap.
Fuel tank capacity: 10 litres approxi-
mately.

A. Opening the fuel fi ller fl ap.
To open the fuel fi ller fl ap, pull at its
notched edge. There is a fuel label on
the inside of the fl ap.
Fuel tank

54
III
C O M F O R T
MIRRORS
Exterior mirrors
Each mirror is adjustable to provide
the rear view needed for overtaking
or parking. They can also be folded
for parking in confi ned spaces.
Adjustment
With the ignition on:

 move control 1 to the right or to
the left to select the correspond-
ing mirror,

 move control 2 in one of four di-
rections to adjust,

 return control 1 to the central po-
sition. The objects observed are, in real-
ity, closer than they appear.
Take this into account in order to
correctly judge the distance of ve-
hicles approaching from behind.
Folding

 from outside: lock the vehicle
using the remote control or the
key.

 from inside: with the ignition on,
pull control 1 rearwards.
If the mirrors are folded using con-
trol 1 , they will not unfold when the
vehicle is unlocked. Pull again on
control 1 .
Unfolding

 from outside: unlock the vehicle
using the remote control or the
key.

 from inside: with the ignition on,
pull control 1 rearwards.
The folding and unfolding of the exte-
rior mirrors using the remote control
can be deactivated by a CITROËN
dealer. Automatic tilting in reverse gear
System which provides a view of the
ground during parking manoeuvres
in reverse gear.
Programming

 With the engine running, engage
reverse gear.

 Select and adjust the left-hand
and right-hand mirrors in suc-
cession.
The adjustment is stored immediately.
Stopping

 Exit reverse gear and wait twenty
seconds.
or

 Return control 1 to the central
position.
The mirror glass returns to its initial
position.
The mirror glass also returns to its
initial position if:
-
the speed exceeds 6 mph (10 km/h),
- the engine is switched off.
Using

 With the engine running, engage
reverse gear.

 Move control 1 to the right or to
the left to select the correspond-
ing mirror.
The glass of the mirror selected tilts
downwards, in accordance with its
programming.
The de-icing/demisting of the exte-
rior mirrors is linked to that of the
rear screen.

56
IV
A C C E S S
REMOTE CONTROL KEY
System which permits central un-
locking or locking of the vehicle us-
ing the lock or remotely. It is also
used to locate the vehicle, activate
the guide-me-home lighting and
start the engine, as well as providing
protection against theft.
Unlocking the vehicle
Complete unlocking using the
remote control
Unfolding the key

 First press button A to unfold the
key.

 Press the open padlock
to unlock the vehicle. Complete unlocking using the
key

 Turn the key to the left in the
driver's door lock to unlock the
vehicle.
Unlocking is confi rmed by rapid
fl ashing of the direction indicators
for approximately two seconds.
According to version, the exterior
mirrors unfold at the same time.
This also triggers the timed switch-
ing on of the welcome lighting, cour-
tesy lights and exterior sidelamps
for approximately thirty seconds. Locking is confi rmed by fi xed lighting
of the direction indicators for approxi-
mately two seconds.
According to version, the exterior
mirrors fold at the same time.
Locking the vehicle
Normal locking using the remote
control
 Press the closed pad-
lock to lock the vehicle
completely.

 Press the closed padlock for more
than two seconds to close the
windows automatically in addition
to locking. If one of the doors, the rear screen
or the boot is still open, the central
locking does not take place.
When the vehicle is locked, if it is
unlocked inadvertently, it will relock
automatically after thirty seconds
unless a door is opened.
The folding and unfolding of the
exterior mirrors using the remote
control can be deactivated by a
CITROËN dealer.
Normal locking using the key

 Turn the key to the right in the
driver’s door lock to lock the ve-
hicle completely.

57
IV
A C C E S S
Deadlocking using the key

 Turn the key to the right in the
driver’s door lock to lock the ve-
hicle completely and hold it in
this position for more than two
seconds to close the windows
automatically in addition to locking.

 Turn the key to the right again
within fi ve seconds to deadlock
the vehicle.
Deadlocking is confi rmed by fi xed
lighting of the direction indicators for
approximately two seconds.
According to version, the exterior
mirrors fold at the same time. Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

 First press button A to fold the
key.
Locating your vehicle

 Press the closed padlock to locate
your locked vehicle in a car park.
This is indicated by lighting of the
courtesy lights and fl ashing of the di-
rection indicators for a few seconds. Guide-me-home lighting
A press on button
B operates the
guide-me-home lighting (lighting of
the sidelamps and dipped beams for
approximately one minute).
A second press before the end of the
timing cancels the guide-me-home
lighting.
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code
must be recognised in order for
starting to be possible.
This electronic engine immobiliser
locks the engine management sys-
tem a few minutes after the ignition
is switched off and prevents starting
of the engine by anyone who does
not have the key.
In the event of a mal-
function, you are in-
formed by lighting of
this warning lamp, an
audible signal and a message on
the multifunction screen.
In this case, your vehicle does not
start; contact a CITROËN dealer as
soon as possible.
Folding the key
Deadlocking using the
remote control

 Press the closed pad-
lock to lock the vehicle
completely or press the
closed padlock for more
than two seconds to
close the windows au-
tomatically in addition to
locking.

 Press the closed padlock again
within fi ve seconds to deadlock
the vehicle.

59
IV
A C C E S S
Remote control problem
Following disconnection of the ve-
hicle battery, replacement of the re-
mote control battery or in the event
of a remote control malfunction, you
can no longer unlock, lock or locate
your vehicle.

 First of all, use the key in the lock
to unlock or lock your vehicle.

 Then, reinitialise the remote
control.
If the problem persists, contact a
CITROËN dealer as soon as possible.
Reinitialisation

 Switch off the ignition.

 Turn the key to position 2
(Ignition
on
) .

 Press the closed padlock imme-
diately for a few seconds.

 Switch off the ignition and re-
move the key from the ignition
switch.
The remote control is fully opera-
tional again. Battery ref.: CR0523/3 volts.
This replacement battery is avail-
able from CITROËN dealers.
If the remote control
battery is fl at, you are
informed by lighting
of this warning lamp,
an audible signal and a message on
the multifunction screen.

 Unclip the casing using a coin at
the notch.

 Slide the fl at battery out of its
location.

 Slide the new battery into its
location observing the original
direction.

 Clip the casing together.

 Reinitialise the remote control.
Changing the battery

60
IV
A C C E S S
Lost keys
Visit a CITROËN dealer with the
vehicle's V5 registration document
and your personal identifi cation
documents.
The CITROËN dealer will be able to
retrieve the key code and the trans-
ponder code required to order a re-
placement key.
Remote control
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
cle, without you being aware of it.
Do not repeatedly press the buttons
of your remote control out of range
and out of sight of your vehicle.
You run the risk of stopping it from
working and the remote control
would have to be reprogrammed.
The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
off, except for reprogramming.
Locking the vehicle
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more diffi cult in an emergency.
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
even for a short time. Anti-theft protection
Do not make any modifi cations to the
electronic engine immobiliser sys-
tem; this could cause malfunctions.
When purchasing a second-
hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the
keys in your possession are the only
ones which can start the vehicle.
Do not throw the remote
control batteries away, they
contain metals which are
harmful to the environment.
Take them to an approved collection
point.

57
IV
A C C E S S
Deadlocking using the key

 Turn the key to the right in the
driver’s door lock to lock the ve-
hicle completely and hold it in
this position for more than two
seconds to close the windows
automatically in addition to locking.

 Turn the key to the right again
within fi ve seconds to deadlock
the vehicle.
Deadlocking is confi rmed by fi xed
lighting of the direction indicators for
approximately two seconds.
According to version, the exterior
mirrors fold at the same time. Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

 First press button A to fold the
key.
Locating your vehicle

 Press the closed padlock to locate
your locked vehicle in a car park.
This is indicated by lighting of the
courtesy lights and fl ashing of the di-
rection indicators for a few seconds. Guide-me-home lighting
A press on button
B operates the
guide-me-home lighting (lighting of
the sidelamps and dipped beams for
approximately one minute).
A second press before the end of the
timing cancels the guide-me-home
lighting.
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code
must be recognised in order for
starting to be possible.
This electronic engine immobiliser
locks the engine management sys-
tem a few minutes after the ignition
is switched off and prevents starting
of the engine by anyone who does
not have the key.
In the event of a mal-
function, you are in-
formed by lighting of
this warning lamp, an
audible signal and a message on
the multifunction screen.
In this case, your vehicle does not
start; contact a CITROËN dealer as
soon as possible.
Folding the key
Deadlocking using the
remote control

 Press the closed pad-
lock to lock the vehicle
completely or press the
closed padlock for more
than two seconds to
close the windows au-
tomatically in addition to
locking.

 Press the closed padlock again
within fi ve seconds to deadlock
the vehicle.
