2008.5 Citroen C4 DAG ECO mode

24
I
I N S T R U M E N T S a n d C O N T R O L S
Indicator and warning lamps
When the ignition is switched on
The warning lamps come on for a
few seconds when the vehicle's igni-
tion is switched on.
When the engine is started, these
warning lamps should switch off.
If they remain on, before moving off,
consult information on the warning
lamp concerned. Associated warnings
The switching on of certain warning
lamps may be accompanied by an
audible signal and a message on
the multifunction screen.
The warning lamps may come on
continuously or fl ash.
Certain warning lamps may come
on in two different modes. Only by
relating the type of lighting to the
operation of the vehicle can it be
ascertained whether the situation
is normal or whether a fault has oc-
curred. Operation indicator lamps
If one of the following indicator
lamps comes on, this confi rms that
the corresponding system has come
into operation.
Front fog lamps.
Left-hand direction
indicator.
Sidelamps.
Main beam headlamps.
Dipped headlamps.
Right-hand direction
indicator.
Rear fog lamp.
Visual indicators informing the driver
that a system is in operation (opera-
tion or deactivation indicator lamps) or
of the occurrence of a fault (warning
lamp).

24
I
I N S T R U M E N T S a n d C O N T R O L S
Indicator and warning lamps
When the ignition is switched on
The warning lamps come on for a
few seconds when the vehicle's igni-
tion is switched on.
When the engine is started, these
warning lamps should switch off.
If they remain on, before moving off,
consult information on the warning
lamp concerned. Associated warnings
The switching on of certain warning
lamps may be accompanied by an
audible signal and a message on
the multifunction screen.
The warning lamps may come on
continuously or fl ash.
Certain warning lamps may come
on in two different modes. Only by
relating the type of lighting to the
operation of the vehicle can it be
ascertained whether the situation
is normal or whether a fault has oc-
curred. Operation indicator lamps
If one of the following indicator
lamps comes on, this confi rms that
the corresponding system has come
into operation.
Front fog lamps.
Left-hand direction
indicator.
Sidelamps.
Main beam headlamps.
Dipped headlamps.
Right-hand direction
indicator.
Rear fog lamp.
Visual indicators informing the driver
that a system is in operation (opera-
tion or deactivation indicator lamps) or
of the occurrence of a fault (warning
lamp).

45
III
C O M F O R T
AUTOMATIC AIR CONDITIONING 1 - Automatic operation
This system automatically regulates
temperature, air fl ow and air distribu-
tion in the passenger compartment
according to the temperature select-
ed (for each side, right and left).
It provides an optimum level of
comfort regardless of the climatic
conditions, by permanent use of
the automatic air conditioning mode
(press the AUTO button ) and with

all the vents open.
Having no airfl ow prevents the air
conditioning and the system in gen-
eral from working.

To prevent misting of the interior
of the vehicle in cold and damp
conditions, the use of AUTO
mode is recommended. 2 - Adjustment of
temperature on left
hand side
To set and display the de-
sired temperature, rotate
control 2 or 3 :
The display HI (high) corre-
sponds to a demand for max-
imum heating (above 27).
The display LO (low) cor-
responds to a demand for
maximum air conditioning
(below 15).
3 - Adjustment of
temperature on right
hand side
- To the left to lower the temperature
-
To the right to raise the temperature
The difference between the tem-
peratures on the right and on the left
cannot be greater than 3 degrees.
A setting around 21 will provide a
temperature that is comfortable.
Depending on your requirements,
an adjustment between 18 and 24 is
normal.
A press on this control,
confi rmed by the display of
"A/C"
and "AUTO" , auto-
matically manages all the
5 following functions according to
the temperature chosen:
- Flow of air.
- Cabin temperature.
- Distribution of air.
- Air conditioning.
- Recycling of air.
To enable the system to operate, all
the air vents should be kept open. This is the normal operating
mode.

63
IV
A C C E S S
ELECTRIC WINDOWS
System intended to open or close a
window manually or automatically.
Fitted with a safety auto-reverse
system and a system for deactiva-
tion in the event of misuse of the
rear controls.

1. Driver's electric window
control.

2. Passenger's electric window
control.

3. Rear right electric window
control.

4. Rear left electric window
control.

5. Deactivation of the rear
electric window and door
controls. One-touch electric windows
There are two options:
-
manual mode

 Press or pull the control gently.
The window stops when the
control is released.
- automatic mode

 Press or pull the control fi rmly.
The window opens or closes
fully when the control is re-
leased.

 Pressing the control again
stops the movement of the
window.
The electric window controls re-
main operational for approximate-
ly 45 seconds after the ignition is
switched off or until the vehicle is
locked after a door is opened.
If one of the passenger windows can-
not be operated from the driver's door
control pad, carry out the operation
from the control pad of the passenger
door concerned, and vice versa. Safety anti-pinch
When the window rises and meets
an obstacle, it stops and partially
lowers again.
If the window cannot be closed (for
example, in the presence of ice),
immediately after the movement is
reversed:

 press and hold the control until
the window opens fully,


then pull the control immediately
and hold it until the window closes,

 continue to hold the control for
approximately one second after
the window has closed.

The safety
anti
-
pinch
function
is not operational during these
operations.

77
V I S I B I L I T Y
V
Special position of the
windscreen wipers
In the minute following switching off
of the ignition, any action on the stalk
positions the wipers in the centre of
the windscreen.
This action enables you to position
the wiper blades for winter parking,
cleaning or replacement.
To park the wipers after this has
been done, switch on the ignition
and operate the stalk. For optimum and lasting wiping of
the "fl at-blade" wiper blades, it is
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- change them approximately every 6 months,
- avoid using them to retain card- board on the windscreen. COURTESY LAMPS
Selection and control of the various
passenger compartment lamps.

1. Front courtesy
lamp

2. Map reading
lamps
Front courtesy lamp In this position, the courtesy
lamp comes on gradually: Permanently off.
Permanent lighting.
In permanent lighting mode, differ-
ent lighting times are available:
- with the ignition off, approxi- mately ten minutes,
- in energy economy mode, ap- proximately thirty seconds,
- with the engine running, unlim- ited.
- when the vehicle is unlocked,
- when a door or the boot is opened,
- when the key is removed from the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle. It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is
closed.
Map reading lamps

 With the ignition on, press the
corresponding switch.

77
V I S I B I L I T Y
V
Special position of the
windscreen wipers
In the minute following switching off
of the ignition, any action on the stalk
positions the wipers in the centre of
the windscreen.
This action enables you to position
the wiper blades for winter parking,
cleaning or replacement.
To park the wipers after this has
been done, switch on the ignition
and operate the stalk. For optimum and lasting wiping of
the "fl at-blade" wiper blades, it is
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- change them approximately every 6 months,
- avoid using them to retain card- board on the windscreen. COURTESY LAMPS
Selection and control of the various
passenger compartment lamps.

1. Front courtesy
lamp

2. Map reading
lamps
Front courtesy lamp In this position, the courtesy
lamp comes on gradually: Permanently off.
Permanent lighting.
In permanent lighting mode, differ-
ent lighting times are available:
- with the ignition off, approxi- mately ten minutes,
- in energy economy mode, ap- proximately thirty seconds,
- with the engine running, unlim- ited.
- when the vehicle is unlocked,
- when a door or the boot is opened,
- when the key is removed from the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle. It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is
closed.
Map reading lamps

 With the ignition on, press the
corresponding switch.

78
V I S I B I L I T Y
V
This comes on automatically when
the boot is opened and switches
off automatically when the boot is
closed.
Different lighting times are available:
- when the ignition is off, approxi-mately ten minutes,
- in energy economy mode, ap- proximately thirty seconds,
- when the engine is running, no limit.
The sill lighting is at the bottom of
each door panel.
The lamps come on automatically
when a door is opened and switch
off automatically when all of the
doors are closed.
BOOT LIGHTING Sill illumination

119
IX
D R I V I N G
CRUISE CONTROL
System which automatically main-
tains the vehicle speed programmed
by the driver, without any action on
the accelerator pedal.
The cruise control is switched on
manually: the vehicle speed must be
at least 25 mph (approx. 40 km/h)
and you must engage:
- fourth gear on a manual gearbox,
- second gear, in sequential mode, on an electronic gearbox or
automatic gearbox,
- position A on an electronic
gearbox or D on an automatic
gearbox.
The cruise control cannot, in any
circumstances, take the place of the
observance of speed limits or of the
vigilance and responsibility of the
driver. Steering wheel controls
The cruise control switches are
located on the left-hand side of the
steering wheel.
Displays on the instrument panel
The programmed information is
grouped together in zone
A of the
instrument panel display. Programming
Rotate the control
1 to the "REG"
position.
Activation
On selection of the function via con-
trol 1, no cruise speed has yet
been memorised.
Once the desired speed has been
reached using the accelerator, press
button 2 or button 4 . The cruise
speed is then memorised. It is dis-
played in zone A of the instrument
panel.
You can then release the accelera-
tor pedal. The vehicle will automati-
cally keep to the speed chosen.
The speed of your vehicle may vary
slightly in relation to that memo-
rised.
You can adjust the memorised speed
on the instrument panel display by
pressing on:

 button 4 to increase the speed,

 button 2 to decrease the speed.
Successive presses modify the
cruise speed in steps of 1 mph and a
sustained press in steps of 3 mph.
