2007 VOLVO XC90 window

2007 Volvo XC90
Wipers operate at "high" speed.
Tailgate wiper/washer
1. Intermittent wiping
2. Normal wiping
Move the lever forward to start the tailgate washer.
Tailgate wiper and reverse gear
If the front wipers are on and the transmission is put into reverse gear\
, the tailgate wiper will go into
intermittent wiping function
1.
If the tailgate wiper is already in normal wiping function, the normal w\
iping function will continue.
1. Consult your Volvo retailer if you would like to have this function d\
eactivated.
pg. 61 Instruments and controls
Hazard warning flashers, rear window/sideview mirror defroster
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (21 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Hazard warning flashers
The four-way flasher should be used to indicate that the vehicle has bec\
ome a traffic hazard. To activate
the flashers, press the triangular button in the center dash. Press the \
button again to turn off the flashers.
NOTE: Regulations regarding the use of the hazard warning flasher may vary, d\
epending on where you
live.

Rear window and sideview mirror defroster
Press the switch to start heating the rear window and sideview mirrors t\
o remove ice or condensation. A
light in the switch will light up.
A timer automatically switches off the heating after approximately 12 mi\
nutes. The LED will go out
correspondingly.
pg. 62 Instruments and controls
Trip computer (option)
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (22 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Trip computer
The trip computer stores information gathered from several systems in yo\
ur vehicle and has four menus
that can be displayed in the text window.
l Driving distance on current fuel reserve
l Average fuel consumption
l Current fuel consumption
l Average speed
l Current speed in mph (Canadian models only)
l DSTC (see page 130 for detailed information)
NOTE: Warning messages from the vehicle's monitoring systems will override th\
e trip computer
function. If a warning message is displayed in the text window while you\
are using the trip computer,
you must acknowledge the message by pressing button A. Press button A ag\
ain to return to the trip
computer function.
Trip computer controls and functions
The four
1 trip computer functions can be accessed by twisting control B one step \
at a time in either
direction. Twisting a fifth
2 time returns you to the original function. The trip computer can be res\
et
(current data will be erased from system memory) by pressing RESET (b\
utton C).
1. Driving distance on current fuel reserve
This function shows the approximate distance that can be driven on the f\
uel remaining in the tank. This
calculation is based on average fuel consumption during the last 20 mile\
s (30 km) of driving and the
amount of fuel remaining in the tank when the reading was taken.
When the driving distance on current fuel reserve is less than 12 miles \
(20 km), "----" will be displayed
in the text window.
2. Average fuel consumption
This value indicates fuel consumption since the last time the trip compu\
ter was reset (by pressing
RESET, button C). When the engine is switched off, information on fuel \
consumption is stored and
remains in system memory until the RESET (button C) is pressed again.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (23 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
NOTE: This does not set the vehicle's speed.
Setting speed
Press + or - to set the current speed. CRUISE-ON will be displayed in th\
e information window in the
instrument panel.
Increasing or decreasing speed
Use + or - in the following ways to increase or decrease the vehicle's s\
peed:
l Press and hold down + or - until the vehicle reaches the desired speed. \
l Press + or - for approximately a half second and release the button to i\
ncrease or decrease vehicle
speed by approximately 1 mph (1.6 km/h).
NOTE: Cruise control will not function at speeds below approximately 20 mph (\
30 km/h).
Braking
l Cruise control is automatically disengaged when the brake pedal is depre\
ssed. The currently set speed
is stored in memory.
l Pressing resume will return the vehicle to the previously set speed.
Acceleration
Momentary acceleration, such as when passing another vehicle, does not a\
ffect cruise control operation.
The vehicle will automatically return to the previously set speed when y\
ou release the accelerator pedal.
Disengaging cruise control
To disengage cruise control, press the CRUISE button. CRUISE or CRUISE-O\
N will no longer be
displayed in the information window in the instrument panel.
NOTE: Cruise control is automatically disengaged if:
l the engine is switched off
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (25 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
l the gear selector is placed in (N)eutral
l the wheels start to spin or lock
l if an increase in speed is maintained for more than one minute
l if the vehicle's speed falls below approximately 20 mph (30 km/h).
pg. 64 Instruments and controls
Cruise control
Temporarily disengaging cruise control
l Press 0 to temporarily disengage cruise control. CRUISE will be displaye\
d in the information window
in the instrument panel.
l Press the brake pedal.
Press "resume"
to return to the previously set speed.
WARNING!
Cruise control should not be used in heavy traffic or when driving on we\
t or slippery roads, or when
driving on unpaved or uneven road surfaces. Cruise control may not maint\
ain set speed on steep
downgrades.
pg. 65 Instruments and controls
Auxiliary 12-volt sockets
12 volt sockets
These 12 volt sockets can be used to plug in certain accessories such as\
cellular telephones, etc.
The ignition key must be in at least position I for the sockets in the f\
ront seat and the optional socket at
the rear of the center console to function.
12-volt socket in the cargo compartment
Fold down the lid to use the socket. This socket can be used even if the\
ignition is switched off.
NOTE:
l If the 12-volt sockets are used while the engine is not running, there i\
s a risk that the vehicle's battery
will be discharged.
l If the ignition is switched off and a device drawing more than 0.1A is c\
onnected to a socket, a battery
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (26 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
warning will be displayed in the text window.
l The covers should be kept on when the auxiliary sockets are not in use. \
l Maximum current from the sockets is 15A.
Ashtrays/cigarette lighter
The auxiliary sockets can also be used for cigarette lighters.
Ashtrays and lighters are available as accessories. Please contact your \
Volvo retailer.
pg. 66 Instruments and controls
Parking brake
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (27 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Opening the tailgate
To open the upper section of the tailgate, pull the handle (A) downwar\
d.
To fold down the lower section of the tailgate, pull handle (B) upward\
.
pg. 68 Instruments and controls
Power windows
The power windows are controlled by buttons in the arm rests. The igniti\
on switch must be ON1
(ignition key in position I, II or the engine running) for the electri\
cally operated windows to function.
To lower: Press down the front edge of the button to the first detent (\
"stop").
To raise: Lightly pull up the front edge of the button to the first dete\
nt ("stop").
Auto up/down function (front doors only):
Either front door window can be opened or closed automatically.
Auto down: Press the front part of the button as far down as possible and release \
it immediately. To
stop the window at any time, pull the button up.
Auto up: Pull the front part of the button up as far as possible and release it \
immediately. To stop the
window at any time, press the button down.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (30 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
NOTE: If a window is obstructed during auto-up, it will automatically reverse\
direction and return to its
starting position. If a window is repeatedly obstructed during auto-up o\
peration, an overload protection
circuit breaker will temporarily halt window function. The window will r\
eturn to normal function after a
brief cool-down period.
WARNING!
Always remove the ignition key when the vehicle is unattended.
Make sure that the windows are completely unobstructed before they are o\
perated.
Never leave children unattended in the vehicle.
1. The power windows will also function after the ignition has been swit\
ched off as long as neither of the front
doors has been opened.
pg. 69 Instruments and controls
Power windows
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (31 of 40)12/30/200\
6 5:53:37 PM
