2007 VOLVO XC90 turn signal

2007 Volvo XC90
Replacing high/low beams/turn signal/parking light bulbs
The entire lamp housing must be lifted out when replacing these bulbs.
To lift out the lamp housing:
- Switch off the ignition.
- Open the hood.
- Pull up the retaining pins (see the illustration above).
- Lift out the lamp housing.
WARNING!
Active Bi-Xenon headlights (option) - due to the high voltage used by \
these headlights, these bulbs
should only be replaced by an authorized Volvo service technician.
pg. 195 Maintenance
Replacing bulbs
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (20 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Location of the bulbs in the headlight housing
- Low beam headlight/Active Bi-Xenon headlight (option)
- High beam headlight
- Turn signal
- Parking light
- Side marker light
Replacing the low beam bulb
(Halogen headlights)
- Remove the plastic cover over the bulb (1) by turning it countercloc\
kwise.
- Pull the connector from the lamp housing (2).
- Loosen the bulb's retaining spring by first moving it to the right and\
then moving it out of the way.
- Pull out the bulb from the holder.
- Insert the new bulb (without touching the glass) in the holder.
- Move the retaining spring up and push it slightly to the left until it\
seats properly.
- Press the bulb holder into place on the headlight housing.
- Reinstall the plastic cap. The letters "HAUT" on the cap must be upwar\
d.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (21 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Replacing the turn signal bulb
- Turn the lamp holder approximately 1/4 turn counterclockwise and pull \
it out of the headlight housing.
- Press in the bulb slightly and pull it out of the holder.
- Align the guide lugs on the side of the base of the new bulb in the gr\
ooves in the holder. Press it in and
turn it slightly clockwise.
- Press the lamp holder into the place in the headlight housing and turn\
it approximately 1/4 turn
clockwise.
Front fog lights
Avoid touching the glass on the bulb
with your fingers.
- Switch off the ignition.
- Turn the bulb holder slightly counterclockwise to release it.
- Replace the bulb. The shape of the foot of the bulb corresponds to the\
shape of the bulb holder.
- Reinstall the bulb holder by turning it slightly clockwise. The side o\
f the holder marked "TOP" should
face upward.
pg. 198 Maintenance
Replacing bulbs
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (24 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Location of tail light bulbs
1. Parking light
2. Turn signal
3. Back-up light
4. Parking light
5. Brake light
NOTE: If the message indicating a burned out bulb remains in the information \
display after a bulb has
been replaced, consult an authorized Volvo retailer or workshop.
Replacing bulbs in the tail light cluster
- Switch off all lights and turn ignition key to position 0.
- Fold down the lower section of the tailgate, and fold up the rear sect\
ion of the cargo area floor.
- If the vehicle is equipped with the optional grocery bag holder, detac\
h the holder's bands.
- Remove the corner panel (A in the illustration above).
- Open the cover (B) in the side panel by pulling the tab (C) upward\
/outward.
- Loosen the bolts (D).
- Pull the entire tail light housing straight out.
- Disconnect the wiring.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (25 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
- Place the tail light housing on a soft cloth to avoid scratching the l\
ens.
- Turn the lamp holder(s) counterclockwise and pull out.
- Turn signal, back-up light, brake light bulbs: Turn the bulb countercl\
ockwise and remove it.
- Parking light bulbs: Pull the bulb straight out.
- Insert a new bulb.
- Place the lamp holder in the groove and turn clockwise.
- Press wiring back into place.
- Align the tail light housing with the holes for the retaining bolts an\
d press it into place.
- Tighten the retaining bolts.
- Reinsert the side and corner panels.
pg. 199 Maintenance
Replacing bulbs
Rear fog light
- Switch off the ignition.
- Carefully insert a small screwdriver (see illustration above).
- Pry out the lamp housing.
- Turn the bulb holder counterclockwise and remove it.
- Turn the bulb counterclockwise and remove it.
- Insert a new bulb and press the lamp housing back into place.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (26 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
16. -
17. Accessory audio 5
18. -
19. Rear window wiper 15
20. Trailer wiring (15-feed) 20
21. -
22. -
23. All Wheel Drive 7.5
24. -
25. -
26. Park assist 5
27. Main fuse: trailer wiring, park assist, All Wheel Drive 30
28. Central locking system 15
29. Driver's side trailer lighting: parking lights, turn signal 25
30. Passenger's side trailer lighting: brake light, fog light, turn sign\
al 25
pg. 206 Maintenance
Fuses
No.Amperage
31. Main fuse: fuses 37 and 38 40
32. -
33. -
34. -
35. -
36. -
37. Heated rear window 20
38. Heated rear window 20


file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (36 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
Dimensions
Length188.9 in (479.8 cm)
Width 74.7 in (189.8 cm)
Height 70.2 in (178.4 cm)
Wheelbase 112.6 in (285.7 cm)
Front track 64.3 in (163.4 cm)
Rear track 63.9 (162.4 cm)
Turning
circle 39-40 ft. (11.9-12.3
m)
Cargo capacity
With optional 3rd row of seats folded down:
5-seat: 41.6 cu. ft (1178 liters)
7-seat: 43.3 cu. ft (1225 liters)
Behind 1st row of seats, with 2nd (and optional 3rd) row of seats fold\
ed down:
5-seat: 84.9 cu. ft (2403 liters)
7-seat: 85.1 cu. ft (2410 liters)
Behind 1st row of seats, with front passenger seat, 2nd row (and option\
al 3rd row) of seats folded down:
5-seat: 92.0 cu. ft (2606 liters)
7-seat: 93.2 cu. ft (2640 liters)
pg. 211 Specifications
Bulbs
High beam H7 65W-
Low beam H11
55W -
Active Bi-Xenon low beam (option) D1S 35W
Active Bi-Xenon high beam (option) H9 65W
Front fog lights H1 55W
Front/rear parking lights, front/rear side marker lights license plate l\
ight, rear
footwell lighting W5W
W2,1x9,5d
Front turn signals H21W BAY9s
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (5 of 10)12/30/2006\
5:53:52 PM

2007 Volvo XC90
Rear fog lightP21/4W BAY9s
Brake lights, backup lights P21W BA15s
Rear turn signals PY21W BA15s
10. Vanity mirror lighting 1.2W SV5.5
11. Front footwell lighting, cargo area lighting C5W SV8.5
WARNING!
Active Bi-Xenon headlights (option) - due to the high voltage used by \
these headlights, these bulbs
should only be replaced by an authorized Volvo service technician.
pg. 212 Specifications
Engine oil
Specifications
Engine oil must meet the minimum ILSAC specification GF-3, API SL, and A\
CEA A1/ B1. Lower
quality oils may not offer the same fuel economy, engine performance, or\
engine protection.
Volvo recommends
.
Volume
Engine designation Volume between
MIN-MAX on dipstick Volume
1
3.2 6-cyl. B6324S
0.85 US qts (0.8 liters) 7.7 US qts (7.3 liters)
V8 AWD B8444S 1.3 US qts (1.2 liters) 7.1 US qts. (6.7
liters)
1. Including filter replacement
pg. 213 Specifications
Fluid specifications and capacities
file:///K|/ownersdocs/2007/2007_XC90/07xc90_10.htm (6 of 10)12/30/2006\
5:53:52 PM
