2007 VOLVO C70 CONVERTIBLE stop start

2007 Volvo C70
1. Remove the ignition key.
2. Reinsert the key in the ignition switch. The vehicle will then attemp\
t to reset CRASH MODE to normal
mode.
3. Try to start the vehicle.
Moving the vehicle
If the electrical system is able to reset system status to normal (CRAS\
H MODE SEE MANUAL will no
longer be displayed), the vehicle may be moved carefully from its prese\
nt position, if for example, it is
blocking traffic. It should, however, not be moved farther than is absol\
utely necessary.
WARNING
Even if the vehicle appears to be drivable after CRASH MODE has been set\
, it should not be driven or
towed (pulled by another vehicle). There may be concealed damage that \
could make it difficult or
impossible to control. The vehicle should be transported on a flatbed to\
w truck to a trained and qualified
Volvo service technician for inspection/ repairs.
30 01 Safety
Child safety
Children should be seated safely
Volvo recommends the proper use of restraint systems for all occupants i\
ncluding children. Remember
that, regardless of age and size, a child should always be properly rest\
rained in a car.
Your car is also equipped with ISOFIX/ LATCH attachments, which make it \
more convenient to install
child seats.
Some restraint systems for children are designed to be secured in the ve\
hicle by lap belts or the lap
portion of a lap-shoulder belt. Such child restraint systems can help pr\
otect children in cars in the event of
an accident only if they are used properly. However, children could be e\
ndangered in a crash if the child
restraints are not properly secured in the vehicle. Failure to follow th\
e installation instructions for your
child restraint can result in your child striking the vehicle's interior\
in a sudden stop.
Holding a child in your arms is NOT a suitable substitute for a child re\
straint system. In an accident, a
child held in a person's arms can be crushed between the vehicle's inter\
ior and an unrestrained person. The
child could also be injured by striking the interior, or by being ejecte\
d from the vehicle during a sudden
maneuver or impact. The same can also happen if the infant or child ride\
s unrestrained on the seat. Other
occupants should also be properly restrained to help reduce the chance o\
f injuring or increasing the injury
of a child.
file:///K|/delme/2007_C70/07c70_01.htm (27 of 41)12/22/2006 9:15:37 PM\

2007 Volvo C70
4. Oil pressure warning light1

If the light comes on while driving, stop the car, stop the engine immed\
iately, and check the engine oil level. If the oil
level is normal and the light stays on after restart, have the car towed\
to the nearest trained and qualified Volvo
service technician. After hard driving, the light may come on occasional\
ly when the engine is idling. This is normal,
provided it goes off when the engine speed is increased.
5. Seat belt reminder
See page 16 for detailed information.
6. Generator warning light

If the light comes on while the engine is running, have the charging sys\
tem checked by a trained and qualified Volvo
service technician.
7. Brake failure warning light

If this light comes on while driving or braking, stop the car as quickly\
as possible in a safe place, open the hood, and
check
1 On certain engines, this symbol is not used to indicate low oil pressur\
e. Instead, a text warning is provided in the information
display, see also
page 192.
52 02 Instruments and controls
Symbols - instrument panel
the brake fluid level in the reservoir. See page 190 for the location of the reservoir.
file:///K|/delme/2007_C70/07c70_02.htm (11 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
NOTE
Canadian models are equipped with the second
symbol.
WARNING
If the fluid level is below the MIN mark in the reservoir or if a "Brake failure - Service urgent" message \
is
displayed in the information display: DO NOT DRIVE. Have the car towed to a trained and qualified Volvo service
technician and have the brake system inspected.
If the fluid level is below the MIN mark in the reservoir or if a "BRAKE FAILURE - SERVICE URGENT" message
is displayed in the information display: DO NOT DRIVE. Have the car towed to a trained and qualified Volvo service
technician and have the brake system inspected.

If the BRAKE and ABS warning lights come on at the same time, this could\
indicate a fault in the brake
system. In this case:
1. Stop the car in a suitable place and switch off the engine.
2. Restart the engine.
3. If both warning lights go off, no further action is required and the \
car can be driven.
4. If both lights remain on after the engine has been restarted, switch \
off the engine again and check the brake fluid
level. See
page 190 for the location of the reservoir.
Door open warning
The driver will be alerted if either door, the hood, or the trunk lid ar\
e open or ajar.
At low speeds

If the car is moving at a speed of less than approximately 4 m.p.h. (7 \
km/h), the Information symbol in the instrument
panel will light up and a message will be shown in the information displ\
ay indicating which door(s), etc is not
completely closed.
file:///K|/delme/2007_C70/07c70_02.htm (12 of 43)12/22/2006 9:15:42 PM\

2007 Volvo C70
122 06 Starting and driving
General information
Economical driving conserves natural resources
Better driving economy may be obtained by thinking ahead, avoiding rapid\
starts and stops and adjusting
the speed of your vehicle to immediate traffic conditions.
Observe the following rules:
l Bring the engine to normal operating temperature as soon as possible by \
driving with a light foot on the
accelerator pedal for the first few minutes of operation. A cold engine \
uses more fuel and is subject to
increased wear.
l Whenever possible, avoid using the vehicle for driving short distances. \
This does not allow the engine
to reach normal operating temperature.
l Drive carefully and avoid rapid acceleration and hard braking.
l Use the transmission's Drive (D) position as often as possible and avo\
id using kickdown.
l Do not exceed posted speed limits.
l Avoid carrying unnecessary items (extra load) in the vehicle.
l Maintain correct tire pressure. Check tire pressure regularly (when tir\
es are cold).
l Remove snow tires when threat of snow or ice has ended.
l At highway driving speeds, fuel consumption will be lower with the air c\
onditioning on and the
windows closed than with the air conditioning off and the windows open. \
l Using the onboard trip computer's fuel consumption modes can help you le\
arn how to drive more
economically.
Other factors that decrease gas mileage are:
l Dirty air cleaner
l Dirty engine oil and clogged oil filter
l Dragging brakes
l Incorrect front end alignment
Some of the above mentioned items and others are checked at the standard\
maintenance intervals.
Avoid overheating the engine
Do not drive at engine speeds above 4,500 rpm if you tow a trailer in hi\
lly areas. This could cause the
engine oil to overheat.
file:///K|/delme/2007_C70/07c70_06.htm (2 of 18)12/22/2006 9:15:48 PM

2007 Volvo C70
WARNING
Driving with the trunk open: Driving with the trunk open could lead to poisonous exhaust gases
entering the passenger compartment. If the trunk must be kept open for a\
ny reason, proceed as follows:
l Close the windows
l Set the ventilation system control to air flow to floor, windshield and \
side windows and the blower
control to its highest setting.
Weight distribution affects handling
At the specified curb weight your vehicle has a tendency to understeer, \
which means that the steering
wheel has to be turned more than might seem appropriate for the curvatur\
e of a bend. This ensures good
stability and reduces the risk of rear wheel skid. Remember that these p\
roperties can alter with the vehicle
load. The heavier the load in the cargo area, the less the tendency to u\
ndersteer.
Handling, roadholding
Vehicle load, tire design and inflation pressure all affect vehicle hand\
ling. Therefore,
123 06 Starting and driving
General information
check that the tires are inflated to the recommended pressure according \
to the vehicle load. See the "Tire
pressure" section. Loads should be distributed so that capacity weight o\
r maximum permissible axle loads
are not exceeded.
Driving through water
The vehicle can be driven through water up to a depth of approximately 9\
in. (25 cm), at a maximum
speed of 6 mph (10 km/h).
l Take particular care when driving through flowing water.
l Clean the electrical connections for trailer wiring after driving in mud\
or water
l When driving through water, maintain low speed and do not stop in the wa\
ter.
WARNING
After driving through water, press lightly on the brake pedal to ensure \
that the brakes are functioning
normally. Water or mud can make the brake linings slippery, resulting in\
delayed braking effect.
file:///K|/delme/2007_C70/07c70_06.htm (3 of 18)12/22/2006 9:15:48 PM

2007 Volvo C70
CAUTION
l Engine damage will occur if water is drawn into the air cleaner.
l If the vehicle is driven through water deeper than 9 in (25 cm), water\
may enter the differential and
the transmission. This reduces the oil's lubricating capacity and may sh\
orten the service life of these
components.
l Do not allow the vehicle to stand in water up to the door sills longer t\
han absolutely necessary. This
could result in electrical malfunctions.
l If the engine has been stopped while the car is in water, do not attempt\
to restart the engine. Have the
car towed out of the water.
Cold weather precautions
If you wish to check your vehicle before the approach of cold weather, t\
he following advice is worth
noting:
l Make sure that the engine coolant contains 50 percent antifreeze. Any ot\
her mixture will reduce freeze
protection. This gives protection against freezing down to - 31°F (-\
35°C). See section "Coolant". The use
of "recycled" antifreeze is not approved by Volvo. Different types of an\
tifreeze must not be mixed.
l Volvo recommends using only genuine Volvo antifreeze in your vehicle's r\
adiator. Your Volvo retailer
stocks plenty of Volvo engine coolant to help protect your vehicle durin\
g cold weather.
l Try to keep the fuel tank well filled - this prevents the formation of c\
ondensation in the tank. In
addition, in extremely cold weather conditions it is worthwhile to add f\
uel line de-icer before refueling.
l The viscosity of the engine oil is important. Oil with low viscosity (t\
hinner oil) improves cold-weather
starting as well as decreasing fuel consumption while the engine is warm\
ing up. For winter use, 5W-30
oil, particularly the synthetic type
1, is recommended. Be sure to use good quality oil but do not use cold-
weather oil for hard driving or in warm weather. See
page 239 for more information.
l The load placed on the battery is greater during the winter since the wi\
ndshield wipers, lighting, etc. are
used more often. Moreover, the capacity of the battery decreases as the \
temperature drops. In very cold
weather, a poorly charged battery can freeze and be damaged. It is there\
fore advisable to check the state
of
1Synthetic oil is not used when the oil is changed at the normal maintena\
nce intervals except at owner request and
at additional charge. Please consult your Volvo retailer.
124 06 Starting and driving
General information
charge more frequently and spray an antirust oil on the battery posts.
l Volvo recommends the use of snow tires on all four wheels for winter dri\
ving - see the chapter "Wheels
and tires."
file:///K|/delme/2007_C70/07c70_06.htm (4 of 18)12/22/2006 9:15:48 PM

2007 Volvo C70
or when the vehicle is being towed.
NOTE
A ticking sound may be audible if the key is turned to a position betwee\
n 0 and I. To stop this sound,
turn the key to position II and back to position 0.
I - Intermediate position
1
Certain accessories, radio, etc. on, daytime running lights off.
1Please be aware that leaving the key in this positions I or II will incr\
ease battery drain.
II - Drive position
The key's position when driving. The vehicle's entire electrical system\
is activated.
III - Start position
Turn the key to this position and release it immediately. The key retur\
ns automatically to
the Drive position.
A chime will sound if the key is left in the ignition and the driver's d\
oor is opened.
Steering wheel lock
When the key is removed from the ignition, the steering wheel locks so t\
hat it cannot be turned.
Releasing the steering wheel lock
If the front wheels are hard up against a curb, the steering wheel lock \
may be under too much tension to
file:///K|/delme/2007_C70/07c70_06.htm (11 of 18)12/22/2006 9:15:48 PM\

2007 Volvo C70
Remove your foot from the clutch pedal while driving. The shift pattern \
should be followed.
Overdrive (5th and 6th gears) should be used as often as possible to h\
elp improve fuel economy.
1 Clutch interlock
The clutch must be fully depressed before you can start your car. If the\
clutch is not depressed, it will not be
possible to start the engine.
Engaging reverse gear, 6-speed transmission
Reverse gear should only be engaged from a complete stop.
NOTE
Reverse gear is electronically blocked and cannot be selected if the veh\
icle is moving at a speed of
approximately 13 mph (20 km/h).
CAUTION
Never shift into reverse while moving
forward.
WARNING
An extra mat on the driver's floor can cause the accelerator, brake, and\
/or clutch pedal to catch. Check
that the movement of these pedals is not impeded. Not more than one prot\
ective floor covering may be
used at one time.
file:///K|/delme/2007_C70/07c70_06.htm (15 of 18)12/22/2006 9:15:48 PM\
