2 Contents

00 Introduction
General information
6
Volvo and the environment
7
Important warnings
9

01 Safety
Occupant safety
12
Seat belts
14
Supplemental Restraint System
17
Front airbags
18
Occupant Weight Sensor
21
Side impact protection airbags
24
Door mounted inflatable curtains
25
Whiplash Protection System
26
Roll-over Protection System
28
Crash mode
29
Child safety
30
Child restraint systems
33
Infant seats
35
Convertible seats
37
Booster cushions
39
ISOFIX lower anchors
40

02 Instrument and controls
Instrument overview
44
Instrument panel
57
Symbols - instrument panel
50
Information display
53
Lighting panel
55
Left-side steering wheel lever
57
Trip computer
58
Right-side steering wheel lever
60
Cruise control
62
Right-side steering wheel keypad
64
Steering wheel adjustment,
Hazard warning flashers
65
Parking brake
66
12-volt sockets
67
Power windows
68
Mirrors
69
Personal settings
72
HomeLink® Universal
Transceiver (option)
74
file:///K|/delme/2007_C70/07c70_00.htm (2 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70
3 Contents

03 Climate
General information
80
Air vents
81
Electronic Climate Control (ECC)
82
Air distribution
85

04 Interior
Front seats
88
Power retractable hard top
92
Interior lighting
98
Storage compartments
100

05 Locks and alarm
Remote control and key blade
108
Locking and unlocking
114
Glove compartment and trunk
115
Opening the trunk from the inside
116
Alarm
117
4 Contents

06 Starting and driving
General information
122
Fuel requirements
125
Ignition switch, Steering wheel
lock
128
Starting the vehicle
129
Manual transmission
131
Automatic transmission
132
Shiftlock override
135
Brake system
136
Stability system
138
Front/rear park assist
140
Towing
142
Jump starting
145
Towing a trailer
146
Detachable trailer hitch
148
Transporting loads
149

07 Wheel and tires
General information
152
Tire inflation
154
Tire designations
158
Glossary of tire terminology
160
Vehicle loading
161
Uniform tire quality gradings
163
Snow chains, snow tires, studded tires
164
Wheel nuts
165
Tire rotation
166
Temporary spare
167
Changing a wheel
168
Tire sealing system
170

08 Car care
Washing and cleaning the vehicle
178
Paint touch up
182
5 Contents
file:///K|/delme/2007_C70/07c70_00.htm (3 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70

09 Maintenance and servicing
Volvo maintenance
186
Maintaining your vehicle
187
Hood
189
Engine compartment
190
Engine oil
191
Fluids
193
Wiper blades
195
Battery
196
Bulbs
198
Replacing bulbs
199
Fuses
208

10 Audio
Audio functions
218
Radio functions
221
CD player/CD changer (option)
227
Audio menu
231

11 Specifications
Label information
234
Dimensions and weights
236
Fluids
238
Engine oil
239
Engine specifications
241
Electrical system
242
Volvo programs
244
6 Introduction
General information
Shiftlock (automatic transmission)
When your car is parked, the gear selector is locked in the Park (P) position. To release the selector from this position, turn the igniti\
on
key to position II (or start the engine), depress the brake pedal, pre\
ss the button on the front side of the gear selector and move the selector
from Park (P).
Keylock (automatic transmission)
When the ignition is switched off, the gear selector must be in the Park\
(P) position before the key can be removed from the ignition
switch.
Anti-lock Brake System (ABS)
The ABS system in your car performs a self-diagnostic test when the vehi\
cle first reaches the speed of approximately 12 mph (20 km/ h).
The brake pedal will pulsate several times and a sound may be audible fr\
om the ABS control module. This is normal.
Fuel filler door
Press the button on the light switch panel when the car is at a standsti\
ll to open the fuel filler door.
Fuel filler cap
After refueling, close the fuel filler cap by turning it clockwise until\
it clicks into place. If this cap is not closed tightly or if the engine is
running when the car is refueled, the Malfunction Indicator Lamp ("Chec\
k Engine" light) may indicate a fault.
Points to keep in mind
l Before you operate your vehicle for the first time, please familiarize y\
ourself with the new-engine oil consumption information on page
191. You should also be familiar with the information found in the chapters\
"Instruments and controls," and "Starting and driving."
l Information contained in the balance of the manual is extremely useful a\
nd should be read after operating the vehicle for the first time.
l The manual is structured so that it can be used for reference. For this \
reason, it should be kept in the vehicle for ready access.
l Do not export your Volvo to another country before investigating that co\
untry's applicable safety and emission control requirements. In
some cases it may be difficult or impossible to comply with these requir\
ements. Modifications to the emission control system(s) may
render your Volvo not certifiable for legal operation in the U.S., Canad\
a and other countries.
l All information, illustrations and specifications contained in this manu\
al are based on the latest product information available at the
file:///K|/delme/2007_C70/07c70_00.htm (4 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70
Check seat belt mechanism function as follows: attach the seat belt and \
pull rapidly on the strap.
17 01 Safety
Supplemental Restraint System
Supplemental Restraint System (SRS)
As an enhancement to the three-point seat belts, your Volvo is equipped \
with a Supplemental Restraint
System (SRS). Volvo's SRS consists of seat belt tensioners, front airb\
ags, side impact airbags, the
occupant weight sensor, and inflatable curtains. All of these systems ar\
e monitored by the SRS control
module. An SRS warning light in the instrument panel (see the illustrat\
ion above) illuminates when the
ignition key is turned to position I, II, or III, and will normally go o\
ut after approximately 7 seconds if no
faults are detected in the system.
Where applicable, a text message will also be displayed when the SRS war\
ning light illuminates. If this
warning symbol is not functioning properly, the general warning symbol
illuminates and either SRS
AIRBAG SERVICE URGENT or SRS AIRBAG SERVICE REQUIRED will be displayed.
WARNING
l If the SRS warning light stays on after the engine has started or if it \
illuminates while you are driving,
have the vehicle inspected by a trained and qualified Volvo service tech\
nician as soon as possible.
l Never try to repair any component or part of the SRS yourself. Any inter\
ference in the system could
cause malfunction and serious injury. All work on these systems should b\
e performed by a trained and
qualified Volvo service technician.
file:///K|/delme/2007_C70/07c70_01.htm (9 of 41)12/22/2006 9:15:37 PM

2007 Volvo C70
WARNING
If your vehicle has been subjected to flood conditions (e.g. soaked car\
peting/standing water on the floor
of the vehicle) or if your vehicle has become flood-damaged in any way,\
do not attempt to start the
vehicle or put the key in the ignition before disconnecting the battery \
(see below). This may cause
airbag deployment which could result in personal injury. Have the vehicl\
e towed to a trained and
qualified Volvo service technician for repairs.
l Automatic transmission:
l Before attempting to tow the vehicle, use the following procedure to ove\
rride the shiftlock system to
move the gear selector to the neutral position:
- Switch off the ignition for at least 10 minutes and disconnect the bat\
tery
- Wait at least one minute.
- Insert the key in the ignition and turn it to position II.
- Press firmly on the brake pedal.
- Move the gear selector from Park (P) to the Neutral (N) position. See
page 135 for information on
manually overriding the shiftlock system.
18 01 Safety
Front airbags
The front airbag system
The front airbags supplement the three-point seat belts. For these airba\
gs to provide the protection
intended, seat belts must be worn at all times.
The front airbag system includes gas generators and the airbags. A decel\
eration sensor activates the gas
file:///K|/delme/2007_C70/07c70_01.htm (10 of 41)12/22/2006 9:15:37 PM\

2007 Volvo C70
1. Remove the ignition key.
2. Reinsert the key in the ignition switch. The vehicle will then attemp\
t to reset CRASH MODE to normal
mode.
3. Try to start the vehicle.
Moving the vehicle
If the electrical system is able to reset system status to normal (CRAS\
H MODE SEE MANUAL will no
longer be displayed), the vehicle may be moved carefully from its prese\
nt position, if for example, it is
blocking traffic. It should, however, not be moved farther than is absol\
utely necessary.
WARNING
Even if the vehicle appears to be drivable after CRASH MODE has been set\
, it should not be driven or
towed (pulled by another vehicle). There may be concealed damage that \
could make it difficult or
impossible to control. The vehicle should be transported on a flatbed to\
w truck to a trained and qualified
Volvo service technician for inspection/ repairs.
30 01 Safety
Child safety
Children should be seated safely
Volvo recommends the proper use of restraint systems for all occupants i\
ncluding children. Remember
that, regardless of age and size, a child should always be properly rest\
rained in a car.
Your car is also equipped with ISOFIX/ LATCH attachments, which make it \
more convenient to install
child seats.
Some restraint systems for children are designed to be secured in the ve\
hicle by lap belts or the lap
portion of a lap-shoulder belt. Such child restraint systems can help pr\
otect children in cars in the event of
an accident only if they are used properly. However, children could be e\
ndangered in a crash if the child
restraints are not properly secured in the vehicle. Failure to follow th\
e installation instructions for your
child restraint can result in your child striking the vehicle's interior\
in a sudden stop.
Holding a child in your arms is NOT a suitable substitute for a child re\
straint system. In an accident, a
child held in a person's arms can be crushed between the vehicle's inter\
ior and an unrestrained person. The
child could also be injured by striking the interior, or by being ejecte\
d from the vehicle during a sudden
maneuver or impact. The same can also happen if the infant or child ride\
s unrestrained on the seat. Other
occupants should also be properly restrained to help reduce the chance o\
f injuring or increasing the injury
of a child.
file:///K|/delme/2007_C70/07c70_01.htm (27 of 41)12/22/2006 9:15:37 PM\

2007 Volvo C70
All states and provinces have legislation governing how and where childr\
en should be carried in a car.
Find out the regulations existing in your state or province. Recent acci\
dent statistics have shown that
children are safer in rear seating positions than front seating position\
s when properly restrained. A child
restraint system can help protect a child in a vehicle. Here's what to l\
ook for when selecting a child
restraint system:
l It should have a label certifying that it meets applicable Federal Motor\
Vehicle Safety Standards
(FMVSS 213) - or in Canada, CMVSS 213.
l Make sure the child restraint system is approved for the child's height,\
weight and development - the
label required by the standard or regulation, or instructions for infant\
restraints, typically provide this
information.
l In using any child restraint system, we urge you to carefully look over \
the instructions that are provided
with the restraint. Be sure you understand them and can use the device p\
roperly and safely in this vehicle.
A misused child restraint system can result in increased injuries for bo\
th the infant or child and other
occupants in the vehicle.
When a child has outgrown the child safety seat, you should use the rear\
seat with the standard seat belt
fastened. The best way to help protect the child here is to place the ch\
ild on a cushion so that the seat belt
is properly located on the hips (see the illustration on
page 39). Legislation in your state or province may
mandate the use of a child seat or cushion in combination with the seat \
belt, depending on the child's age
and/or size. Please check local regulations.
A specially designed and tested booster cushion (not available in Canad\
a) can be obtained from your
Volvo retailer for children weighing 33 - 80 lb. (15 - 36 kg) and 38-5\
4 inches (97 - 137 cm) in height.
31 01 Safety
Child safety
WARNING
l Do not use child safety seats or child booster cushions/backrests in the\
front passenger's seat. We also
recommend that children under 4 feet 7 inches (140 cm) in height who h\
ave outgrown these devices sit
in the rear seat with the seat belt fastened.
l Keep vehicle doors and trunk locked and keep keys out of a child's reach\
. Unsupervised children
could lock themselves in an open trunk and risk injury. Children should \
be taught not to play in
vehicles.
l On hot days, the temperature in the trunk or vehicle interior can rise v\
ery quickly. Exposure to these
high temperatures for even a short period of time can cause heat-related\
injury or death. Small children
are particularly at risk.
file:///K|/delme/2007_C70/07c70_01.htm (28 of 41)12/22/2006 9:15:37 PM\

2007 Volvo C70
2 0 0 7
VOLVO C70
42 02 Instruments and controls
Instrument overview
44
Instrument panel
47
Symbols - instrument panel
50
Information display
53
Lighting panel
55
Left-side steering wheel lever
57
Trip computer
58
Right-side steering wheel lever
60
Cruise control
62
Right-side steering wheel keypad
64
Steering wheel adjustment, Hazard warning flashers
65
Parking brake
66
12-volt sockets
67
Power windows
68
Mirrors
69
Personal settings
72
HomeLink® Universal Transceiver (option)
74
43 02 Instruments and controls
44 02 Instruments and controls
file:///K|/delme/2007_C70/07c70_02.htm (1 of 43)12/22/2006 9:15:41 PM
