2007 TOYOTA SEQUOIA Owners Manual

11 92007 SEQUOIA from Aug. ’07 Prod. (OM34462U)
u13091
CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
u13092
To remove the convertible seat:
Press the buckle release button and allow
the belt to retract completely. The belt will
move freely again and be ready to work
for an adult or older child passenger.
u13093
(C) BOOSTER SEAT INSTALLATION
A booster seat must be used in for-
wardfacing position only.

1202007 SEQUOIA from Aug. ’07 Prod. (OM34462U)
u13094
Move seat fully back
CAUTION
A forwardfacing child restraint sys-
tem should be allowed to be
installed on the front passenger
seat only when it is unavoidable.
Always move the seat as far back
as possible even if the front pas-
senger occupant classification indi-
cator light indicates “OFF”, because
the front passenger airbag could in-
flate with considerable speed and
force. Otherwise, the child may be
killed or seriously injured.
Do not allow the child to lean his/
her head or any part of his/her
body against the door or the area
of the seat, front or rear pillar or
roof side rail from which the side
airbags or curtain shield airbags
deploy even if the child is seated in
the child restraint system. It is dan-
gerous if the side airbag and cur-
tain shield airbag inflate, and the
impact could cause death or seri-
ous injury to the child.
u13194
Same angle
Same position
When installing a child restraint
system in the third seat center
position, adjust both seat cushions
to the same position and align both
seatbacks at the same angle. Other-
wise, the child restraint system can-
not be securely restrained and this
may cause death or serious injuries
in a collision.

1212007 SEQUOIA from Aug. ’07 Prod. (OM34462U)
u13096
To install the booster seat:
Sit the child on a booster seat. Run the
lap and shoulder belt through or around
the booster seat and across the child fol-
lowing the instructions provided by its
manufacturer and insert the tab into the
buckle taking care not to twist the belt.
Make sure the shoulder belt is correctly
across the child’s shoulder and that the
lap belt is positioned as low as possible
on the child’s hips. See “Seat belts” on
page 73 in this Section for details.
CAUTION
Always make sure the shoulder belt
is positioned across the center of
child’s shoulder. The belt should be
kept away from child’s neck, but
not falling off child’s shoulder.
Otherwise, the child may be killed
or seriously injured in case of sud-
den braking or a collision.
Both highpositioned lap belts and
loosefitting belts could cause
death or serious injuries due to
sliding under the lap belt during a
collision or other unintended event.
Keep the lap belt positioned as low
on a child’s hips as possible.
For child’s safety, do not place the
shoulder belt under child’s arm.
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent your
child from properly latching the tab
and buckle.
If the seat belt does not function
normally, it cannot protect your
child from death or serious injury.
Contact your Toyota dealer immedi-
ately. Do not install the child
restraint system on the seat until
the seat belt is fixed.

1222007 SEQUOIA from Aug. ’07 Prod. (OM34462U)
u13092
To remove the booster seat:
Press the buckle release button and allow
the belt to retract.
u13146
Follow the procedure below for a child
restraint system that requires the use
of a top strap.
u13147
Anchor brackets
Use one anchor bracket on the rear of
second seats and two anchor brackets on
the floor as shown above to attach the top
strap.
Anchor bracket is installed for each sec-
ond seating position.
— U sin g a to p st rap
(for bench type second seats)

1232007 SEQUOIA from Aug. ’07 Prod. (OM34462U)
u13102
TO USE THE ANCHOR BRACKETS:1. Remove the head restraint.
u13148
Outside position
u13142
Center position
2. Fix the child restraint system with the seat belt.
Latch the hook onto the anchor
bracket and tighten the top strap.
For instructions to install the child re-
straint system, see “Child restraint” on
page 108 in this Section.
CAUTION
Make sure the top strap is securely
latched, and check that the child re-
straint system is secure by pushing
and pulling it in different directions.
Follow all the installation instructions
provided by its manufacturer.

1242007 SEQUOIA from Aug. ’07 Prod. (OM34462U)
u13104
3. Replace the head restraint.
u13208
Follow the procedure below for a child
restraint system that requires the use
of a top strap.
u13209
Anchor brackets
Use the anchor brackets on the floor as
shown above to attach the top strap.
Anchor bracket is installed for each sec-
ond seat.
— U sin g a to p st rap
(for separate type second
seats)

1252007 SEQUOIA from Aug. ’07 Prod. (OM34462U)
u13210
TO USE THE ANCHOR BRACKETS:1. Remove the head restraint.
u13211
2. Fix the child restraint system with the seat belt.
Latch the hook onto the anchor
bracket and tighten the top strap.
For instructions to install the child re-
straint system, see “Child restraint” on
page 108 in this Section.
CAUTION
Make sure the top strap is securely
latched, and check that the child re-
straint system is secure by pushing
and pulling it in different directions.
Follow all the installation instructions
provided by its manufacturer.
u13212
3. Replace the head restraint.

1262007 SEQUOIA from Aug. ’07 Prod. (OM34462U)
u13195
Follow the procedure below for a child
restraint system that requires the use
of a top strap.
u13213
Anchor brackets
Symbol mark
Use the anchor brackets on the back of
the third seats to attach the top strap.
Anchor bracket is installed for right side
and center seating positions.
This symbol indicates the locations of
user ready anchor brackets.
u13196
TO USE THE ANCHOR BRACKET (right
side):
1. Remove the head restraint.
— U sin g a to p st rap
(for third seats)
