2007 TOYOTA SEQUOIA phone

ix
7“Map” switch
You can select a destination simply by
touching the location on the displayed map.
38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8“Intersection” switch
You can enter the names of two intersecting
streets. This is helpful if you do not know the
specific street address of your destination
but know the general vicinity. 39. . . . . . . . .
9“Freeway Ent./Exit” switch
You can enter the name of a freeway (inter-
state) entrance or exit. 40. . . . . . . . . . . . . . .
10“Phone #” switch
You can enter a destination by the telephone
number. 41. . . . . . . . . . . . . . . . . . . . . . . . . . .
11“Coordinates” switch
You can set a destination using latitude and
longitude as coordinates. 41. . . . . . . . . . . .
12Quick access switch
You can select one of 5 preset destinations
directly. To use this function, it is necessary
to set the “Attribute” for each memory point.
(To register a “Quick Access”, see page 74.)
26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Home switch
You can select your own home without en-
tering the address each time. To use this
function, it is necessary to set the “Attribute”
for the memory point. (To register “Home”,
see page 74.) 26. . . . . . . . . . . . . . . . . . . . . .
14“Change” switch
To change the search area, touch this
switch. 24. . . . . . . . . . . . . . . . . . . . . . . . . . . .

xi
— Registering home
RS01001
1. Push the “MENU” button.
RS01002
2. Touch “My Places”.
RS01003
3. Touch “Register”.
3U018b
4. There are 13 different methods to
search your home.
When you finish memory point registration,
the memory point data screen will appear.
RS01004
5. Touch “Attribute”.
The icon, quick access, name, location and
phone number can be changed. (See “(b)
Editing memory points” on page 72.)
RS01005
6. Touch “Home” switch.
Registration of home is complete.

7
1U014a
The registered point is shown by on the
map.
To change the icon or name, etc., see page
72.
You can register up to 106 memory points. If
you attempt to register more than 106, a mes-
sage appears for confirmation.
1U015a
To see information about the icon
where the cursor is set
1U016a
To display information about an icon, set the
cursor on it.
POI INFORMATION
When the cursor is set on a POI icon, the
name and
“Info.” switch are displayed on
the top of the screen.
1U021a
Touch the “Info.” switch.
1U017a
Information such as the name, address, and
phone number are displayed.
If you touch the
“Enter ” switch, the posi-
tion of cursor is set as a destination.
If there is already a preset destination, the
“Add to ” switch and the “Replace
” switch are displayed.
When there is already a preset destination,
using the
“Add to ” switch to set an addi-
tional destination, will set the new one as the
first point of arrival.
To register this POI as a memory point, touch
the
“Mark” switch. (For details, see page
70.)

8
INFORMATION
The desired Point of Interest can be dis-
played on the map screen. (For details,
see page 53.)
MEMORY POINT INFORMATION
When the cursor is set on a memory point
icon, the name and
“Info.” switch are dis-
played on the top of screen.
1U022a
Touch the “Info.” switch.
1U018a
Information such as the name, location, and
phone number are displayed.
If you touch the
“Enter ” switch, the posi-
tion of cursor is set as a destination.If there is already a set destination, the
“Add
to
” switch and the “Replace ”switch are displayed.
When there is already a preset destination,
using the
“Add to ” switch to set an addi-
tional destination, will set the new one as the
first point of arrival.
To edit a memory point, touch the
“Edit”switch. (For details, see page 72.)

17
TERMS AND CONDITIONS
Personal Use Only. You agree to use this
Data for the solely personal, non com-
mercial purposes for which you were li-
censed, and not for service bureau,
time−sharing or other similar purposes.
Accordingly, but subject to the restric-
tions set forth in the following para-
graphs, you may copy this Data only as
necessary for your personal use to (i)
view it, and (ii) save it, provided that you
do not remove any copyright notices that
appear and do not modify the Data in any
way. You agree not to otherwise repro-
duce, copy, modify, decompile, disas-
semble or reverse engineer any portion
of this Data, and may not transfer or dis-
tribute it in any form, for any purpose, ex-
cept to the extent permitted by mandato-
ry laws. You may transfer the Data and
all accompanying materials on a perma-
nent basis if you retain no copies and the
recipient agrees to these End−User
Terms. Multi−disc sets may not be trans-
ferred on a divided basis.
Restrictions. Except where you have
been specifically licensed to do so by [LI-
CENSEE] and without limiting the pre-
ceding paragraph, you may not (a) use
this Data with any products, systems, or
applications installed or otherwise con-
nected to or in communication with ve-
hicles, capable of vehicle navigation,
positioning, dispatch, real time route
guidance, fleet management or similar
applications; or (b) with or in communica-
tion with any positioning devices or any
mobile or wireless−connected electronic
or computer devices, including without
limitation cellular phones, palmtop and
handheld computers, pagers, and per-
sonal digital assistants or PDAs.No Warranty. This Data is provided to
you “as is,” and you agree to use it at your
own risk. [LICENSEE] and its licensors
(and their licensors and suppliers) make
no guarantees, representations or war-
ranties of any kind, express or implied,
arising by law or otherwise, including but
not limited to, content, quality, accuracy,
completeness, effectiveness, reliability,
fitness for a particular purpose, useful-
ness, use or results to be obtained from
this Data, or that the Data or server will be
uninterrupted or error−free.
Disclaimer of Warranty:
[LICENSEE]
AND ITS LICENSORS (INCLUDING
THEIR LICENSORS AND SUPPLIERS)
DISCLAIM ANY WARRANTIES, EX-
PRESS OR IMPLIED, OF QUALITY,
PERFORMANCE, MERCHANTABIL-
ITY, FITNESS FOR A PARTICULAR
PURPOSE OR NON−INFRINGEMENT.
Some States, Territories and Countries
do not allow certain warranty exclusions,
so to that extent the above exclusion may
not apply to you.

23
DESTINATION INPUT AND ROUTE GUIDANCE
Basic functions in frequent use
Destination input24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting the search area24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by Home26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by Quick access26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Address”26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “POI Name”30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “POI Category”33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Emergency” 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Memory”37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Previous”38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Map”38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Intersection”39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Freeway Ent./Exit”40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Coordinates”41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input by “Phone #”41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting route guidance42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Entering destination42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Route guidance screen44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typical voice guidance prompts44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting and deleting destination46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting and deleting route48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Show POI icons53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Route overview55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Route preview56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen configuration57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Distance and time to destination61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foot print map62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION II

24
Destination input —
Push the “DEST” button and the
“Destination” screen appears.
2U001b
You can use one of 13 different methods to
enter your destination. (See pages 26
through 41.)
INFORMATION
When inputting the destination, the
response to the switch may be slow.
The route for returning may not be the
same as that for going.
The route guidance to the destination
may not be the shortest route nor a
route without traffic congestion.
Route guidance may not be available
if there is no road data for the speci-
fied location.
When setting the destination on a
map with a scale larger than 0.5 mile
(800 m), the map scale changes to 0.5
mile (800 m) automatically. Set the
destination again.
To select an
“Address”, “POI
Name”
, “Freeway Ent./Exit”,
“Intersection” or “Phone #” in a
different area, it is necessary to
change the search area.
If you enter a destination, the road
nearest to the point you selected is
set as the destination.
CAUTION
While you are driving, be sure to obey
traffic regulations and keep the road
conditions in mind. If a traffic sign on
the road has been changed, the route
guidance may provide wrong informa-
tion.
— Selecting the search area
The “Destination” screen allows you to select
the area to search for your destination.
Touch the
“Change” switch on the
“Destination” screen to display a map of
the United States and Canada divided into
11 areas. See page 12 for map database in-
formation and updates.
2U002a
Touch one of the “US1” through “CAN”switches to select a search area. Touch
the “OK” switch and the “Destination”
screen returns.

41
— Destination input by
“Coordinates”
Touch the “Coordinates” switch on the
“Destination” screen.
2U045a
Input the latitude and the longitude.
When the input is finished, touch the
“OK”switch.
When you touch the switch of the desired
point, the screen changes and displays
the map location of the selected destina-
tion and the route preference. (See “ —
Entering destination” on page 42.)
— Destination input by
“Phone #”
Touch the “Phone #” switch on the
“Destination” screen.
2U046a
Input a telephone number.
After inputting a telephone number, touch
the
“OK” switch, and the screen changes
and displays the map location of the se-
lected destination and the road prefer-
ence. (See “ — Entering destination” on
page 42.)
If there is more than one site having the same
number, the following screen appears.
2U047b
INFORMATION
If there is no match for the telephone
number inputted, a list of identical
numbers but with different area
codes will be displayed.
To set a memory point as a destina-
tion using the phone number, the
number must be registered previous-
ly. (See page 76.)
