2007 TOYOTA RAV4 Quick Reference Guide

13
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
12
FEATURES/OPERATIONS
(2) Lower
(3) Pull down
Seats-Folding down second row seats
Right side
remote seat release Left side
remote seat release
Vehicles with third row seats
Vehicles without third row seats
Windshield wiper & washer
Rear
Front
Pull to wash and wipe Adjust interval
Interval wipe
Slow
Fast
Wa s h and wipe
Wipe
Interval wipe
Wa s h and wipe
Seats-Stowing third row seats (if equipped)
(2) Lower
(1) Push
(5) Pull up
(7) Push
down
(8) Push to lock in
(4) Fold down
(3) Pull
(9) Push to lock in
(1) Push
(6) Lift up
Single wipe

14
FEATURES/OPERATIONS
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Tilt and telescopic steering wheel
Hold wheel, push lever down, set angle and length,
then return lever.
NOTE: Do not attempt to adjust while the vehicle
is in motion.
Lock
release
lever
Length
Angle
Lights & turn signals
Tu r n signals
Headlights
High beam flasher
Low beams
Front fog lights (if equipped)
Headlights
-Daytime Running Light system (if equipped)
Automatically turns on the headlights at a reduced
intensity.
-Automatic light cut off system Will automatically
turn lights off after a delay of 30 seconds,or the
lock switch on remote may be pushed.
Front fog lights come on only when the headlights
are on low beam.
Parking lights
Right turn
Tu r n
Lane change
Lane change
Left turn
Windows
Driver side
Automatic operation (Driver side only) Push the
switch completely down or pull it completely up and
release to fully open or close. To stop window
midway, lightly push the switch in the opposite
direction.
Window lock switch Deactivates all passenger
windows. Driver’s window remains operable.
Up
DownWindows
lock buttonUpDown
NOTE: If the battery is disconnected, the window
needs to be reinitialized. Refer to the Owner’s
Manualfor more details.
15
Parking brake
Pull
(2) Push(1) Pull slightly
(3) Lower Set Release
High beams

17 16
FEATURES/OPERATIONS
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Air Conditioning/Heating
Manual Air Conditioning
Air flow vent selector
Fan speed
Temperature
Air Conditioning ON/OFF
Use for quick cooling. MAX A/C changes air
intake to recirculate. It is not possible to
change intake to fresh, or to turn A/C OFF in
this mode.
Rear defogger
Fresh or recirculated cabin air
Temperature (Driver side)
Temperature (Front passenger side)
Fresh or recirculate cabin air
Air flow vent
Air Conditioning ON/OFF
“DUAL” button
Indicator ON:Separate temperature settings
for driver and passenger.
Indicator OFF:Synchronize temperature
settings for driver and passenger.
Micro dust and pollen filter ON/OFF
Rear defogger
Fan speed
Climate control OFF
Automatic climate control ON
Adjust the temperature
setting, and airflow
vents and fan will adjust automatically.
Automatic Air ConditioningIn “ ” or “ ” mode, use fresh air (“ ”
indicator “OFF”)to reduce window fogging.
Seat heaters(if equipped)
Left front seat
Right front seat
In “ ” or “ ” mode, use fresh air (“ ”
indicator “OFF”)to reduce window fogging.
Bottle holders
Front doorsRear doors
Clock
Manual
Air Conditioning system
H-Hour set
M-Minute set
:00-Round off minutes Automatic
Air Conditioning system

19
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
18
FEATURES/OPERATIONS
“”
Vo l u m e control
“MODE”
Push to turn audio ON and select an audio mode.
Push and hold to turn the audio OFF.
“”
-In radio modePush to select a preset station.
Push and hold to seek the next strong station.
-In CD modePush to skip up or down to next/
previous
track.
By inserting a mini plug into the AUX audio jack, you
can listen to music from a portable audio device
through the vehicle’s speaker system.
>>
Steering wheel controls (if equipped)
CD PLAYER
To scan tracks on a disc Push “SCAN.” Push again to
hold selection.
CDChanger (Ty p e 2)
-To load one disc Push “LOAD” and insert one disc.
-To load multiple discs Push and hold “LOAD” until
you hear a beep. Insert one disc. Wait until the
green indicator illuminates and shutter
opens to
insert next disc.
To select a file (MP3/WMA only) Tu r n “TUNE.
FILE.”
To select a folder (MP3/WMA only) Push either side
of “FOLDER.”
AUX audio jack
Audio
View CD text Eject CD Push to turn
ON/OFF
Push to
adjust
tone &
balance
Push to
skip
up/down
folder Seek
station/
CD track
select
Station/CD
track scanMode
Load CD(s) Preset buttons - functions in other
modes indicated above number.
RADIO
To preset stations Tune in the desired station and
hold down a preset button (1-6) until you hear a
beep. Push desired preset button (1-6) to select.
To scan stations Push “SCAN.” Push and hold to scan
preset stations. Push again to hold selection.
-+
Ty p e 1
Ty p e 2 additional functions
Ty p e 2 (with JBL speakers)

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
20
FEATURES/OPERATIONS
Door locks
UnlockLock
Moonroof (if equipped)
Tilting operation
Sliding operation
NOTE:If battery is disconnected, the moonroof
needs to be reinitialized. Refer to the Owner’s
Manualfor more details.
21
Open
Close
Close Tilt
Recommended
driving position
to minimize
wind noise.
Rear seat entertainment system (if equipped)
Front audio system
DVD player
DVD screen
Remote control
A/V input adapter
115V AC Power outlet
115V AC Power outlet ON/OFF switch
Auto LSD (Limited Slip Differential)
(2WD models)
Push the “AUTO LSD” switch when the vehicle is
stopped. To deactivate, push the switch again.
NOTE: It will ONLY work for 2-wheel drive models. It
should ONLY be used when wheel spinning occurs on
slippery or unpaved surfaces.
Refer to the Owner‘s Manualfor more details on
this system before attempting to
use it.
Bluetooth®technology allows dialing or receipt of
calls without taking your hands from the steering
wheel or using a cable to connect the telephone and
the system.
Refer to the Owner’s Manualfor more details.
Telephone controls (Bluetooth®)*
(if equipped)

23
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
22
FEATURES/OPERATIONS
Cup holders
FrontRear
Second row
Third row side trim
(if equipped)
115V AC (if equipped)
ON/OFF switch
Rear console Push
NOTE:Key must be in the “ON” position to be used.
Light control-Instrument panel
Brightness
control+
-
Power outlets
12V DC
Luggage Compartment
Instrument panelInside center console
NOTE:Designed for car accessories. Key must be in
the “ACC” or “ON” position to be used.
With the dial turned fully up, instrument panel
lights will not dim when the headlights are turned
ON.
Cruise control
Turning system ON/OFF
Functions
System ON/OFF
Resume
2/Increase speed
Set/Decrease speed Cancel1
1The set speed may also be cancelled by depressing
the brake pedal.
2The set speed may be resumed once vehicle speed
exceeds 25 mph.
Refer to the Owner’s Manualfor more details.

24
SAFETY AND
EMERGENCY FEATURES
Moving the lever to “LOCK” will allow the door to
be opened only from the outside.
Doors-Child safety locks
If belt is fully extended, then retracted even
slightly, it cannot be re-extended beyond that point,
unless fully retracted again. This feature is used to
help hold child restraint systems securely.
To f i n d more information about seat belts, and how
to install a child restraint system, refer to the
Owner’s Manual.
Keep as low on
hips as possible
Take up
slack
To o high
Seat belts
Tire Pressure Warning System
The system is designed to provide a warning when
tire pressure of any one of the tires (including the
spare) is critically low
.
Refer to the Owner’s Manualfor more details.
Seat belts-Shoulder belt anchor
Push up or
squeeze lock
release to lower
Rear door

To remove the spare tire, turn the wheel nuts
counterclockwise with the wheel nut wrench and
remove.
Spare tire & tools
Tool location
Removing the spare tire
25
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
To remove the spare tire cover,* open the back
door. Unhook the latch on the bottom of the
cover. After closing the back door, remove the
cover.
!A word about safe vehicle operations This Pocket Reference Guideis a summary of
basic vehicle operations. It contains brief
descriptions of fundamental operations so you
can locate and use the vehicle’s main
equipment quickly and easily.
The Pocket Reference Guideis not intended
as a substitute for theOwner’s Manual
located in the vehicle’s glove box. We
strongly encourage you to review theOwner’s
Manual and supplementary manuals so you
will have a better understanding of the
vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota
Motor Sales, U.S.A., Inc. wish you many years
of satisfied driving in your new RAV4.
This Pocket Reference Guideis not a full
description of RAV4 operations. Every
RAV4 owner should review the Owner’s
Manualthat accompanies this vehicle.
Pay special attention to the boxed
“ ” information highlighted in
this reference guide and throughout the
Owner’s Manual. Each box contains safe
operating instructions to help you avoid
injury or equipment malfunction.
All information in this Pocket Reference
Guideis current at the time of printing.
Toyota reserves the right to make changes
at any time without notice.
This utility vehicle has a significantly higher
rollover rate than other types of vehicles. Refer to
the Owner’s Manualfor important rollover
information.
2007
RAV4
Luggage compartment
Inside left side box
Refer to the Owner’s Manualfor tire changing and
jack positioning procedures.
NOTE:To prevent theft, the latch can only be
released when the back door is opened.
Luggage compartment
Inside right side box
JackTool bag
* If equipped
