2007 TOYOTA PRIUS Ev mode

7
or
Hybrid vehicle immobilizer / Theft deterrent
system indicator light Tail light indicator light
Shift position indicator light
*4
Driving ready light
Automatic air conditioner indicator light
Recirculate mode indicator light
Smart entry and start system warning light
*5
Windshield air flow indicator light
Slip indicator light
Headlight high beam indicator light
Headlight indicator light Turn signal indicator lights
Cruise control indicator light*3
Hybrid system warning light*2
Automatic head light leveling system
warning light*2
Electric power steering system warning light*2
“AIRBAG ON” and “AIRBAG OFF”
indicator lights
Rear window and outside rear view mirror
defoggers indicator light
Hybrid battery warning light*2

26
21p157
ANTENNA LOCATIONS1. Antennas inside cabin
2. Antennas outside cabin
ALARMS AND WARNING LIGHT
Your vehicle is equipped with alarms
inside and outside, as well as warning
light in the instrument cluster, that re-
mind you if there is a problem involv-
ing the smart entry and start system.
This warning light will come on when the
“IG −ON” mode is enabled and will go off
after a few seconds.
If an alarm sounds or the warning light
comes on, be sure to check your ve-
hicle and smart key.

27
(a) The hybrid system was not turnedoff and the transaxle was in a posi-
tion other than “P”.
When the driver ’s door is opened with the
hybrid system in “ACC” or “IG −ON” and
with the transaxle in a position other than
“P”.
Inside alarm: Beeps continuously
Multiinformation display: Warning mes-
sage
Alarms will be turned off by any of the
following operations:
Closing the driver ’s door
Pressing the “P” position switch
Turning off the hybrid system (b) The smart key was brought outside
the vehicle with the transaxle in a
position other than “P”.
When the driver ’s door is opened or
closed with the hybrid system not to be
turned off and with the transaxle in a
position other than “P”, it is determined
that the smart key is not in the vehicle.
Inside alarm: Beeps continuously
Outside alarm: Beeps continuously
Warning light: On
Alarms will be turned off by any of the
following operations:
Pressing the “P” position switch
Bringing the smart key inside the ve-
hicle
Turning off the hybrid system
(c) The hybrid system was not turned off with the transaxle in “P”.
When the driver ’s door is opened with the
hybrid system in “ACC” and with the
transaxle in “P”.
Inside alarm: 3 beeps
In the “IG −ON” mode, an alarm will not
sound. (d) The smart key was brought outside
the vehicle.
When the driver ’s door is opened or
closed with the hybrid system not to be
turned off (and with the transaxle in “P”),
it is determined that the smart key is not
in the vehicle.
Inside alarm: One beep
Outside alarm: 3 beeps
Warning light: On
(e) Locking with smart function was at- tempted with the hybrid system not
to be turned off.
When you attempt to lock all the doors
using smart locking function with the hy-
brid system not to be turned off and with
the transaxle in a position other than “P”.
Outside alarm: One beep (sounds for 2
seconds)
Warning light: On
At this time, the doors cannot be
locked.

31
21p136
UNLOCKING THE DOOR(S) WITH
SMART FUNCTION
The smart entry and start system can
be used to unlock the door(s) without
being inserted into the door keyhole.
When you get close to your vehicle (about
1 m (3 ft.) from each outside front door
handle), and are carrying the smart key,
the electronic code emitted from the key
is automatically checked to determine if it
corresponds to the registered ID code for
the vehicle. When you take hold of the
side back of the outside door handle sur-
face, it will unlock. At this time, two
beeps sound and the turn signal lights
flash twice.When you push and hold down the back
door opener switch, carrying the smart
key, the ID code is checked in the same
way as in the front door case. And all the
doors will unlock. At this time, two beeps
sound and the turn signal lights flash
twice.
When you get close to your vehicle (about
1 m or 3 ft. from either front door), carry-
ing the smart key or unlock the back door
using smart key function, the interior light
comes on for 15 seconds if the interior
light switch is in the “DOOR” position.
However, the interior lights go out when
you push the power door lock switch in
the lock position or press the “POWER”
switch once or twice from the off setting
to select the “ACC” or “IG
−ON” mode
without depressing the brake pedal. For
further information, see “Interior lights” on
page 115.
You have 30 seconds to open a door after
operating the smart unlocking function. If
a door is not opened by then, all the
doors will be automatically locked again.
INFORMATION
The rear doors are not equipped
with smart function.
When unlocking the door(s), be sure
to take hold of the back side of the
outside door handle firmly as
shown in the illustration. Taking
hold of the handle with a gloved
hand might cause a delay in unlock-
ing.

32
When you take hold of the handle
or push the back door opener to
unlock the door(s), be sure to con-
firm that the door(s) have been un-
locked. If the two beeps and the
turn signal lights flash twice, the
doors are unlocked. At this time,
you can pull the outside door han-
dle or push the back door opener to
open the door. If you quickly move
closer to the vehicle or pull the out-
side door handle or push the back
door opener quickly, the doors
might not unlock. If you cannot
open the door by pulling the out-
side door handle or pushing the
back door at this time, push back
the outside door handle to the origi-
nal position or release your hand
from the back door and then try
again.
If you bring the smart key very
close to the outside door handle or
the back door opener, the doors
might not lock.
If another person who is not carry-
ing a smart key takes hold of an
outside door handle or push the
back door opener when you are
within the effective range of the
smart function, the door(s) may not
unlock.
If a large amount of water is ap-
plied to the outside door handle or
the back door during heavy rain or
a car wash, and someone carrying a
smart key is near the vehicle, the
door(s) might be unlocked. However,
if the outside front door handle is
not pulled out or back door opener
not pushed, the doors will lock au-
tomatically after about 30 seconds.
To ensure the unlocking door(s),
perform unlocking operation within
3 seconds after getting close to the
vehicle (about 1 m or 3 ft. from the
front doors or back door). If it
takes longer than that, unlocking
function may not be enabled.
CHANGING THE DOORS TO BE UN-
LOCKED
Each time you push the lock button
together with the panic button on the
smart key for about 5 seconds with the
hybrid system off, the setting for door
unlocking will change as follows:
1. Driver ’s door unlocking mode: If you
perform smart unlocking operation on
the driver’s door, it will unlock. Per-
forming unlocking operation on the
front passenger ’s door or back door
will unlock all the doors. When the
system switches to this m ode, one
beep sounds inside the vehicle and two
beeps sound three times.
2. All doors unlocking mode: Performing
smart unlocking operation on either
front door or back door will unlock all
the doors. When the system switches
to this mode, one beep sounds inside
the vehicle and two beeps sound twice.
3. Single door unlocking mode: The
driver ’s door or back door on which
you perform smart unlocking operation
will unlock. However, performing un-
locking operation on the front passen-
ger’s door will unlock all the doors.
When the system switches to this
mode, one beep sounds inside the ve-
hicle and two beeps sound once.

33
INFORMATION
When changing the mode, be sure
to push both lock and panic but-
tons firmly, or panic alarm may be
activated.
 This operation will not change the
wireless remote control unlocking
function.
 In the single or driver’s door un-
locking mode, if you get into the
vehicle from the driver’s door carry-
ing the smart key, all the smart un-
locking controls activated by the
smart key will be stopped for secu-
rity. If you get out of the vehicle
from the driver’s door carrying the
smart key and get out of the effec-
tive range of the smart function,
unlocking control by the smart key
will be possible. However, unlocking
control may not be carried out for
5 seconds after you get out from
the vehicle. In this case, operate
unlock control again after 5 sec-
onds.
BATTERY POWER SAVING
When doors are locked, the smart entry
and start system transmits electromagnetic
waves to the outside of the vehicle at
regular intervals. For this reason, the ve-
hicle battery will be discharged if the ve-
hicle is left for a long time. If the key is
left within the effective range of the smart
function outside of the vehicle, the key
and the vehicle transmit electromagnetic
waves periodically. If these conditions con-
tinue for a long time, the battery in the
key and vehicle will be discharged.
To prevent the batteries from being dis-
charged, the smart function is automatical-
ly deactivated in the following conditions:
If there is no response from the key
for more than 14 days
If the key is left within the effective
range of the smart function outside of
the vehicle for more than 10 minutes To reactivate the smart function, perform
any of the following:
(a) Press the lock button on the outside front door handle or back door while
carrying the smart key.
(b) Perform a wireless remote control op- eration.
(c) Insert and turn the mechanical key in the keyhole of the driver’s door.

37
To lock and unlock all the doors, push
the switches slowly and securely.
To lock: Push the lock switch. All the side
doors and back door are locked simulta-
neously. At this time, the turn signal lights
will flash once.
Check to see that the doors are securely
locked.
If any of the doors is not securely closed
or if the key is in the key slot, locking
cannot be performed by the lock switch.
At this time, a beep will sound for 10
seconds on the vehicle with smart entry
and smart system. However, if the key is
in the key slot, a beep will not sound. To
stop the beep, close all the side doors
and back door securely or push the un-
lock switch.
The buzzer can be disabled. For details,
contact your Toyota dealer.
To unlock: Push the unlock switch once to
unlock the driver ’s door alone. Pushing
the switch twice within 3 seconds unlocks
all the doors simultaneously. Each time
the unlock switch is pushed, the turn sig-
nal lights will flash twice.This double switch operation to unlock all
the side doors and back door can be
changed to a single switch operation. For
details, contact your Toyota dealer.
When the unlock switch is pressed the
interior light comes on. The light remains
on for about 15 seconds unless any of the
doors is opened and then closed. (For
further information, see “Interior lights” on
page 115.)
You have 30 seconds to open a door after
using the wireless remote unlock feature.
If a door is not opened by then, all the
doors will be automatically locked again.
The timing for the automatic door lock
function can be changed. For details, con-
tact your Toyota dealer.
If the lock or unlock switch is kept
pressed in, the locking or unlocking opera-
tion is not repeated. Release the switch
and then push it again.
The following adjustments can be made in
this system. For details, contact your
Toyota dealer:
Canceling the wireless door locking or
unlocking function
Canceling the flash of the turn signal
lights
21p015a
Pushing the panic switch for 1 second
blows the horn intermittently and
flashes the headlights, tail lights and
emergency flashers and turns on the
interior light.
The panic switch is used to deter vehicle
theft when you witness anyone attempting
to break into or damage your vehicle.
The alarm will last for one minute. To stop
the alarm midway, do the follows:
Push any switch on the key.
Put the hybrid system in the “IG
−ON”
mode.
—Activating panic mode

38
The panic mode does not work in “IG−ON”
mode.
The alarm function can be activated or
deactivated. For details, contact your
Toyota dealer.
For vehicles sold in U.S.A.
FCC ID: MOZB21TG
MADE IN JAPAN
FCC ID: MOZB21RG
MADE IN JAPAN
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, includ-
ing interference that may cause unde-
sired operation.
CAUTION
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
For vehicles sold in Canada
This device complies with RSS −210 of
industry Canada. Operation is subject to
the following two conditions:
(1) This device may not cause interfer-
ence, and (2) this device must accept
any interference, including interference
that may cause undesired operation of
the device.
For replacement, use a CR2032 lithium
battery or equivalent and a special screw-
driver.
CAUTION
Special care should be taken that
small children do not swallow the re-
moved battery or components.
NOTICE
 When replacing the battery, be care-
ful not to lose the components.
 Replace only with the same or
equivalent type recommended by a
Toyota dealer.
 Dispose of used batteries according
to the local laws.
Replace the battery by following proce-
dures.
—Replacing battery
