2007 TOYOTA CAMRY remote start

’07Camry_U (L/O 0608)
14
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Ty p e A
Ty p e B
Your vehicle is supplied with two kinds
of keys.
1. Master keys (black)—
These keys work in every lock. Your
Toyota dealer will need one of them to
make a new key with a built−in trans-
ponder chip.
Since the doors and trunk lid can be
locked without a key, you should al-
ways carry a spare master key in case
you accidentally lock your keys inside
the vehicle.
Type B only—This key is fitted with the
wireless remote control transmitter. For
information on use of the wireless re-
mote control transmitter, see “Wireless
remote control” on page 20 in this Sec-
tion.
2. Sub key (gray)—
This key will not work in the glove box,
trunk and the door located behind the
rear seat armrest (on some models).
To protect items locked in the trunk or
glove box when using valet parking,
leave the sub key with the attendant.A transponder chip for engine immobilizer
system has been placed in the head of
the master and sub keys. These chips are
needed to enable the system to function
correctly, so be careful not to lose these
keys. If you make your own duplicate key,
you will not be able to cancel the system
or start the engine.
Keys (with key cylindertype
ignition switch)

’07Camry_U (L/O 0608)
30
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
NOTICE
Make sure the positive side and
negative side of the battery are
faced correctly.
Do not replace the battery with wet
hands. Water may cause unexpected
rust.
Do not touch or move any compo-
nents inside the transmitter, or it
may interfere with proper operation.
Be careful not to bend the electrode
when inserting the transmitter bat-
tery and that dust or oils do not
adhere to the case.
Close the transmitter case securely.
After replacing the battery, check that the
transmitter operates properly. If the trans-
mitter still does not operate properly, con-
tact your Toyota dealer.The smart key system consists mainly
of the following functions.
Engine immobilizer function (For de-
tails, see “Engine immobilizer system”
on page 18 in this Section.)
Wireless remote control function (For
details, see “Wireless remote control”
on page 20 in this Section.)
Push button start function (For details,
see “How to start the engine” on page
316 in Section 3.)
Entry function and start function (See
“ENTRY FUNCTION AND START
FUNCTION” described below.)
Steering lock function (See “STEERING
LOCK FUNCTION” described below.)
CAUTION
People with implanted pacemakers
or cardiac defibrillators should keep
away from the smart key system
antennas, because the radio waves
may affect the operation of such
devices. For the antenna locations
see “ANTENNA LOCATION” on page
32 in this Section.
Users of any electrical medical de-
vice other than implanted pacemak-
ers and implanted cardiac defibrilla-
tors should consult the manufactur-
er of the device for information
about its operation under the influ-
ence of radio waves. Radio waves
could have unexpected effects on
the operation of such medical de-
vices.
If necessary, the entry function can
be disabled. See “DISABLING THE
SMART KEY SYSTEM” on page 36
in this Section.
Smart key system

’07Camry_U (L/O 0608)
33
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
2. Start function actuation area—Inside
of the cabin
The start function may not be acti-
vated, if the key is in the auxiliary box
of the driver ’s side instrument panel
and glove box, on the instrument pan-
el, on the package tray, on the floor,
etc.
In the following cases, the smart key
system may not operate properly.
When facilities issuing strong electro-
magnetic waves such as TV towers,
electric power stations, broad casting
stations are nearby.
In places where automated payment fa-
cilities are installed (such as gas sta-
tions).
When you are carrying a electronic key
together with a mobile communications
system such as a two−way radio or
cellular phone.
When the electronic key is in contact
with or covered by a metallic object.
When another person is operating a
wireless remote control function on
another vehicle near your vehicle.
When the battery is discharged. To re-
place the battery, see “—Replacing bat-
tery” on page 28 in this Section.
When the electronic key is near a
high−voltage or noise−emitting device.
When you are carrying an electronic
key together with a key for another
smart key system equipped vehicle or
another instrument emitting radio
waves.
Depending on the position of the key
or vehicle body shape, the key may
not work well even within the actuation
area.
When the key surface is covered by a
sticker, etc. that may cut off electro-
magnetic wave.
Even if the smart key system does not
operate properly, you can still enter and
start the engine. For further information,
see “Side doors” on page 36 and “Trunk
lid” on page 46 in this Section, and see
“How to start the engine” on page 316 in
Section 3.
STARTING THE ENGINE WHEN THE
ELECTRONIC KEY BATTERY IS
DISCHARGED
If the key indicator does not flash and
the engine cannot be started by using
the start function, the battery may be
discharged. Replace the key battery as
soon as possible. (See “Wireless re-
mote control” on page 20 in this Sec-
tion.)
However the engine can be started in the
following procedures.
1. While the brake pedal is depressed,
touch the Toyota logo side of the
electronic key to the “ENGINE START
STOP” switch.

’07Camry_U (L/O 0608)
34
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
2. Start the engine within 5 seconds after
the green indicator light on the
“ENGINE START STOP” switch comes
on and a buzzer sounds.
BATTERY POWER SAVING
Both the vehicle and key transmitters are
always sending signals to each other. To
prevent battery drain, the smart key sys-
tem is automatically deactivated in the fol-
lowing conditions:
If the electronic key is left outside of
the vehicle and within the effective
range of the entry function actuation
area for more than 10 minutes.
If the door lock or unlock operation is
not performed more than 2 weeks.
The key and the vehicle are communicat-
ing even while the vehicle is not being
driven. Do not leave the key near the
vehicle (within 2 m [7 ft.]).
The vehicle battery may drain if the
vehicle is not used for a long period of
time. To prevent battery drain, disconnect
the battery negative (−) terminal or disable
the smart key system. (For details about
disable the smart key system, see
“DISABLING THE SMART KEY SYSTEM”
on page 36 in this Section.)To reactivate the smart key system, per-
form any of the following:
(a) Press the lock button on the front out-
side door handle or trunk open button
while carrying the electronic key.
(b) Perform a wireless remote control op-
eration.
(c) Insert and turn the mechanical key in
the keyhole of the driver’s door.If the electronic key receives strong elec-
tromagnetic waves over a period of time,
the battery can be drastically run down.
You should always keep the following
electrical appliances at least 1 m (3 ft.)
away from the electronic key.
TV
Personal computer
Cellular phone or cordless phone re-
charger unit
Electric light stand
Fluorescent desk light

’07Camry_U (L/O 0608)
50
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
SETTING THE SYSTEM
1. Vehicles with key cylinder−type ignition
switch—The key is removed from the
ignition switch.
Vehicles with smart key system—The
ignition switch is turned off.
The engine immobilizer system is set and
the indicator light will start flashing. (For
details, see “Engine immobilizer system”
on page 18 in this Section.)
2. Have all passengers get out of the
vehicle.
3. Close and lock all the doors, trunk and
hood.The indicator light will remain on when all
the doors, trunk and hood are closed and
locked.
The theft deterrent system will automati-
cally be set after 30 seconds. When the
system is set, the indicator light will start
flashing again.
4. After making sure the indicator light
starts flashing, you may leave the ve-
hicle.
Never leave anyone in the vehicle when
you set the system, because unlocking
from the inside will activate the system.
WHEN THE SYSTEM IS SET
Activating the system
The system will sound the alarm under
the following conditions:
If any of the doors is unlocked or if
the trunk or hood is forcibly opened
without the key, wireless remote control
or entry function of the smart key sys-
tem.
If the battery terminal is disconnected
and then reconnected.
If the ignition is hotwired.
The indicator light will come on when the
system is activated.All the doors will be automatically locked
again when the following two conditions
are met:
If any of the doors is unlocked without
the key, wireless remote control or
entry function of the smart key system.
If the key is not in the ignition switch
(vehicles with key cylinder−type ignition
switch) or the ignition switch is set to
off (vehicles with smart key system).
After one minute, the alarm will automati-
cally stop and the indicator light will start
flashing again.
Reactivating the alarm
Once set, the system automatically resets
the alarm after the alarm stops.
The alarm will activate again under the
same circumstances described in
“Activating the system”.
Stopping the alarm
The alarm will be stopped by the following
three ways:
Set the ignition switch to ON.
Unlock any of the doors with the key
or wireless remote control.
Open the trunk with the key, wireless
remote control or entry function of the
smart key system.

’07Camry_U (L/O 0608)
51
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
CANCELLING THE SYSTEM
The system will be cancelled by the
above mentioned 3 ways.
If the tail lights come on for 2 seconds,
the theft deterrent system has been
alarmed. Check to see if there is any
abnormality with your vehicle.
TESTING THE SYSTEM
1. Open all the windows.
2. Set the system as described above.
The doors should be locked with the
key, wireless remote control or entry
function of the smart key system. Be
sure to wait until the indicator light
starts flashing.
3. Unlock any door from the inside. The
system should activate the alarm.
4. Stop the alarm as described above.
5. Repeat this operation for the other
doors, trunk and hood. When testing
the hood, also check that the system
is activated when the battery terminal
is disconnected and then reconnected.
If the system does not work properly,
have it checked by your Toyota dealer.
This indicates that the fuel filler door
is on the left side of your vehicle.1. To open the fuel filler door, pull the
lever up.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or al-
low open flames when refueling.
The fumes are flammable.
When opening the cap, do not re-
move the cap quickly. In hot weath-
er, fuel under pressure could cause
injury by spraying out of the filler
neck if the cap is suddenly re-
moved.
Fuel tank cap

’07Camry_U (L/O 0608)
356
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
You can purchase a new key at your
Toyota dealer if you can give them the
key number and master key.
Vehicles with key cylinder−type ignition
switch—Even if you lose only one key,
contact your Toyota dealer to make a new
key. If you lose all your master keys, you
cannot make new keys; the whole engine
immobilizer system must be replaced.
Vehicles with smart key system—If you
lose any of your keys, contact your
Toyota dealer to have new keys made.
Lost keys increase the danger of vehicle
theft. Bring all of the remaining vehicle
keys when you visit your Toyota dealer.
See the suggestion given in “Keys” on
page 14 or 16 in Section 1−2.
You can use the wireless remote control
system and smart entry and start system
by new key, if the systems are equipped
with your vehicle. Contact your Toyota
dealer for detailed information.If your keys are locked in the vehicle and
you cannot get a duplicate, many Toyota
dealers can still open the door for you,
using their special tools. If you must
break a window to get in, we suggest
breaking the smallest side window be-
cause it is the least expensive to replace.
Be extremely cautious to avoid cuts from
the glass.
If you lose your keys

’07Camry_U (L/O 0608)
412
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
ENGINE COMPARTMENT
1. RR FOG 10 A: No circuit
2. FR DEF 15 A (2.4 L 4cylinder [2AZ
FE] engine): No circuit
3. AM2 7.5 A: Starting system
4. ALTS 7.5 A: Charging system
5. MAYDAY/TEL 7.5 A: No circuit
6. EACM 10 A (3.5 L V6 [2GRFE] en-
gine): No circuit
7. ETCS 10 A: Electronic throttle control
system
8. HAZ 15 A: Turn signal lights
9. IG2 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, starting system, “GAUGE
NO.2” and “IGN” fuses
10. STR LOCK 20 A: Steering lock system
11. DOME 10 A: Gages and meters, vanity
lights, trunk light, ignition switch light,
door courtesy lights, interior light, per-
sonal lights, clock, smart key system
12. ECUB NO.1 10 A: Wireless remote
control system, front passenger occu-
pant classification system, main body
ECU, vehicle stability control system
13. RADIO NO.1 15 A: Audio system, nav-
igation system14. DOOR NO.1 25 A: Main body ECU
15. AMP 25 A: Audio system
16. EFI MAIN 30 A: Multiport fuel injection
system/sequential multiport fuel injec-
tion system, electronic throttle control
system, “EFI NO.2” and “EFI NO.3”
fuses
17. EFI NO.3 10 A: Multiport fuel injection
system/sequential multiport fuel injec-
tion system
18. EFI NO.2 15 A: Multiport fuel injection
system/sequential multiport fuel injec-
tion system
19. SHORN 7.5 A: Horn
20. A/F 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
21. MPXB 10 A: Gages and meters
22. EFI NO.1 10 A: Theft deterrent sys-
tem, smart key system, multiport fuel
injection system/sequential multiport
fuel injection system, electronic throttle
control system
23. HORN 10 A: Horns
24. HLP(RL) 15 A: Right−hand headlight
(low beam)
25. HLP(LL) 15 A: Left−hand headlight
(low beam)
Fuses
