2007 TOYOTA CAMRY stop start

’07Camry_U (L/O 0608)
332
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
CAUTION
Do not exceed 72 km/h (45 mph) or
the posted towing speed limit,
whichever is lower. Because insta-
bility (swaying) of a towing vehicle
trailer combination usually in-
creases as the speed increases, ex-
ceeding 72 km/h (45 mph) may
cause loss of control.
Slow down and downshift before
descending steep or long downhill
grades. Do not make sudden down-
shifts.
Avoid holding the brake pedal down
too long or too frequently. This
could cause the brakes to overheat
and result in reduced braking effi-
ciency.
Improving fuel economy is easy—just take
it easy. It will help make your vehicle last
longer, too. Here are some specific tips
on how to save money on both fuel and
repairs:
Keep your tires inflated at the cor-
rect pressure. Underinflation causes
tire wear and wastes fuel. See page
385 in Section 7−2 for instructions.
Do not carry unneeded weight in
your vehicle. Excess weight puts a
heavier load on the engine, causing
greater fuel consumption.
Avoid lengthy warmup idling. Once
the engine is running smoothly, begin
driving—but gently. Remember, howev-
er, that on cold winter days this may
take a little longer.
Keep the automatic transmission se-
lector lever in the “D” position when
engine braking is not required. Driv-
ing with the selector lever in a position
other than “D” will reduce the fuel
economy. (For details, see “Automatic
transmission” on page 161 in Section
1−7.)
Accelerate slowly and smoothly.
Avoid jackrabbit starts. Get into high
gear as quickly as possible.
Avoid long engine idling. If you have
a long wait and you are not in traffic,
it is better to turn off the engine and
start again later.
Avoid engine lugging or overrev-
ving. Use a gear position suitable for
the road on which you are travelling.
Avoid continuous speeding up and
slowing down. Stop−and−go driving
wastes fuel.
Avoid unnecessary stopping and
braking. Maintain a steady pace. Try
to time the traffic signals so you only
need to stop as little as possible or
take advantage of through streets to
avoid traffic lights. Keep a proper dis-
tance from other vehicles to avoid sud-
den braking. This will also reduce wear
on your brakes.
Avoid heavy traffic or traffic jams
whenever possible.
Do not rest your foot on the clutch
or brake pedal. This causes premature
wear, overheating and poor fuel econo-
my.
Maintain a moderate speed on high-
ways. The faster you drive, the greater
the fuel consumption. By reducing your
speed, you will cut down on fuel con-
sumption.
How to save fuel and make
your vehicle last longer

’07Camry_U (L/O 0608)
337
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
When the engine does not start, the fol-
lowing procedure can be used to start the
engine if the vehicle’s starting system and
“ENGINE START STOP” switch function
normally.
1. Put the transmission in “P”.
2. Set the ignition switch to ACC by push-
ing the “ENGINE START STOP” switch
once.
3. Push and hold the “ENGINE START
STOP” switch for about 15 seconds
while depressing the brake pedal firmly.
Even if the engine can be started using
the above procedure, the system may be
malfunctioning. Have the vehicle checked
by your Toyota dealer.
If the engine cannot be started using the
above procedure, immediately contact your
Toyota dealer.CAUTION
Do not place any objects close to the
“ENGINE START STOP” switch. If the
object pushes on the switch, an unex-
pected engine start may result.
If the engine will not start, your engine
may be flooded because of repeated
cranking.
With key cylinder−type ignition switch—If
this happens, turn the key to “START”
with the accelerator pedal fully depressed.
Keep the key and accelerator pedal in
these positions for 15 seconds and re-
lease them. Then try starting the engine
with your foot off the accelerator pedal.
With smart key system—If this happens,
press the “ENGINE START STOP” switch
(engine switch) with the brake pedal and
the accelerator pedal fully depressed, and
hold the “ENGINE START STOP” switch
for about 30 seconds. Then the cranking
hold function stops cranking automatically,
and you can try starting the engine with
your foot off the accelerator pedal.
If the engine does not start, wait a few
minutes and try again.
If the engine still will not start, it needs
adjustment or repair. Call a Toyota dealer
or qualified repair shop for assistance.
(b) Emergency start (vehicles
with smart key system)(c) Starting a flooded engine

’07Camry_U (L/O 0608)
341
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
In the event that the battery is dis-
charged, the engine may not restart
even after the battery is recharged or
replaced. For safety reasons, the engine
may be disabled when battery voltage
is extremely low. If the engine is dis-
abled, the start system must be normal-
ized.
To normalize the start system:
1. Shift the transmission to the “P” posi-
tion and set the ignition switch off.
2. Open and close any of the doors.
3. Start the engine.If your engine stalls while driving...
1. Reduce your speed gradually, keeping
a straight line. Move cautiously off the
road to a safe place.
2. Turn on your emergency flashers.
3. Set the ignition switch to ACC or off,
and try starting the engine again.
If the engine will not start, see “If your
vehicle will not start” on page 336 in this
Section.
CAUTION
If the engine is not running, the
power assist for the brakes and
steering will not work so steering
and braking will be much harder
than usual.
Vehicles with smart key system—
If the engine stalls while driving, do
not open the driver’s door until the
vehicle comes to a complete stop.
Opening the driver’s door locks the
steering wheel, resulting in loss of
steering control.
If engine speed does not increase when
the accelerator pedal is depressed, there
may be a problem somewhere in the elec-
tronic throttle control system.
At this time, vibration may occur. Howev-
er, if you depress the accelerator pedal
more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle
checked by your Toyota dealer as soon as
possible.
Even if the abnormality of the electronic
throttle control system is corrected during
low speed driving, the system may not be
recovered until the engine is stopped and
the ignition switch is set to ACC or off.
CAUTION
Be especially careful to prevent erro-
neous pedal operation.
(e) Starting the engine after a
battery discharge
(vehicles with smart key system)
If your engine stalls while
drivingIf you cannot increase engine
speed

’07Camry_U (L/O 0608)
343
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
1. Reduce your speed gradually,
keeping a straight line. Move cau-
tiously off the road to a safe place
well away from the traffic. Avoid
stopping on the center divider of
a highway. Park on a level spot
with firm ground.
2. Stop the engine and turn on your
emergency flashers.
3. Firmly set the parking brake and
put the transmission in “P” (auto-
matic) or reverse (manual).
4. Have everyone get out of the ve-
hicle on the side away from traffic.
5. Read the following instructions
thoroughly.CAUTION
When jacking, be sure to observe
the following to reduce the possi-
bility of death or serious injury:
Follow jacking instructions.
Do not put any part of your
body under the vehicle sup-
ported by the jack. Otherwise,
personal injury may occur.
Do not start or run the engine
while your vehicle is supported
by the jack.
Stop the vehicle on a level firm
ground, firmly set the parking
brake and put the transmission
in “P” (automatic) or reverse
(manual). Block the wheel diag-
onally opposite to the one be-
ing changed if necessary.
Make sure to set the jack prop-
erly in the jack point. Raising
the vehicle with jack improper-
ly positioned will damage the
vehicle or may allow the ve-
hicle to fall off the jack and
cause personal injury.
Never get under the vehicle
when the vehicle is supported
by the jack alone.
Use the jack only for lifting
your vehicle during wheel
changing.
Do not raise the vehicle with
someone in the vehicle.
When raising the vehicle, do
not place any objects on top
of or underneath the jack.
Raise the vehicle only high
enough to remove and change
the tire.
If you have a flat tire—

’07Camry_U (L/O 0608)
377
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
Rear (3.5 L V6 [2GRFE] engine)
When jacking up your vehicle with the
jack, position the jack correctly as
shown in the illustrations.
CAUTION
When jacking, be sure to observe the
following to reduce the possibility of
death or serious injury:
Follow jacking instructions.
Do not put any part of your body
under the vehicle supported by the
jack. Personal injury may occur.
Do not start or run the engine while
your vehicle is supported by the
jack.
Stop the vehicle on a level firm
ground, firmly set the parking brake
and put the transmission in “P”
(automatic) or reverse (manual).
Block the wheels on the opposite
side of the jack up point if neces-
sary.
Make sure to set the jack properly
in the jack point. Raising the ve-
hicle with jack improperly posi-
tioned will damage the vehicle or
may allow the vehicle to fall off the
jack and cause personal injury.
Never get under the vehicle when
the vehicle is supported by the jack
alone; use vehicle support stands.
Do not raise the vehicle with some-
one in the vehicle.
When raising the vehicle, do not
place any objects on top of or un-
derneath the jack.
NOTICE
Make sure to place the jack correctly,
or your vehicle may be damaged.

’07Camry_U (L/O 0608)
414
2007MY CAMRY from Oct. ’06 Prod. (OM33748U)
7. STOP 10 A: Stop lights, high mounted
stoplight, shift lock control system,
multiport fuel injection system/sequen-
tial multiport fuel injection system, main
body ECU, anti−lock brake system, ve-
hicle stability control system, traction
control system, brake assist system,
electronic throttle control system
8. TI&TE 30 A: No circuit
9. AM1 7.5 A: Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system
10. A/C 7.5 A: Air conditioning system
11. PWR 25 A: Power windows
12. DOOR NO.2 25 A: Main body ECU
13. S/ROOF 30 A: Electric moon roof
14. TAIL 15 A: Front side marker lights,
tail lights, rear side marker lights, li-
cense plate lights, front turn signal/
parking lights
15. PANEL 7.5 A: Navigation system, seat
heaters, emergency flashers, air condi-
tioning system, audio system, clock,
glove box light, instrument panel lights,
steering switches
16. ECU IG NO.1 10 A: Main body ECU,
electric moon roof, tire pressure warn-
ing system, electric cooling fans, auto
anti−glare inside rear view mirror17. ECU IG NO.2 7.5 A: Anti−lock brake
system, vehicle stability control system,
traction control system, brake assist
system, shift lock control system, auto-
matic transmission, cruise control sys-
tem
18. A/C NO.2 10 A: Air conditioning sys-
tem, rear window defogger
19. WASH 10 A: Windshield wipers and
washer
20. SHTR 20 A: Seat heaters
21. GAUGE NO.1 10 A: Emergency flash-
ers, back−up lights, charging system
22. WIP 25 A: Windshield wipers and
washer
23. HLP LVL 7.5 A: No circuit
24. INJ 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, starting system
25. IGN 10 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, theft deterrent system, SRS
airbag system, steering lock system,
front passenger occupant classification
system, smart key system, electronic
throttle control system
26. GAUGE NO.2 7.5 A: Gages and me-
ters, multi−information display, clock27. ECUACC 7.5 A: Clock, main body
ECU, shift lock control system, outside
rear view mirror, smart key system
28. CIG 20 A: Power outlet
29. PWR OUTLET 20 A: Power outlet
30. RADIO NO.2 7.5 A: Audio system,
navigation system
31. MIR HTR 10 A: Outside rear view mir-
ror defoggers
32. POWER 30 A: Power windows
33. P/SEAT 30 A: Power seats
