3
BEFORE DRIVING
BEFORE DRIVING
Fuel Recommendation....................................................................................... 3-1
Immobilizer System............................................................................................ 3-2
Door Locks.......................................................................................................... 3-4
Windows............................................................................................................... 3-6
Mirrors................................................................................................................... 3-8
Front Seat Adjustment...................................................................................... 3-9
Adjusting Seat Position.................................................................................... 3-9
Adjusting Seatbacks........................................................................................3-10
Seat Belts..........................................................................................................3-11
Lap Belt (if equipped).....................................................................................3-15

Downloaded from www.Manualslib.com manuals search engine 1576G-74EYour vehicle comes with a pair of identical
keys. Keep the spare key in a safe place.
One key can open all of the locks on the
vehicle.
The key identification number is stamped on
a metal tag provided with the keys. Keep
the tag in a safe place. If you lose your
keys, you will need this number to have
new keys made. Write the number down
and keep it in a safe accessible place away
from the vehicle.
BEFORE DRIVING
3-2
w ww w
w WARNING
• Do not use locally made key.
Should you require a duplicate key,
place your order with a MARUTI
SUZUKI dealer only.Note:
Keep the spare key very carefully. When it
is lost, consult your dealer by quoting key
number.
Immobilizer System
This system is designed to help prevent
vehicle theft by electronically disabling the
engine starting system.
The engine can be started only with your
vehicle’s original immobilizer ignition key
which has an electronic identification code
programmed into it. The key communicates
the identification code to the vehicle when
the key is turned to the “ON” position. If
you need to make spare keys, contact your
MARUTI SUZUKI dealer. The vehicle must
be programmed with the correct identifica-
tion code for the spare keys. A key made
by an ordinary locksmith will not work. Key Number :
IMMOBILIZER KEYS
76G-03-002

Downloaded from www.Manualslib.com manuals search engine 1776G-74E
BEFORE DRIVING
3-4
Central door locking system (if equipped)
You can lock and unlock all doors simultan-
eously by using the key in the driver’s door
lock.
To lock all doors simultaneously, insert the
key in the driver’s door lock and turn the
top of the key toward the rear of the
vehicle.
To unlock all doors simultaneously, insert
the key in a driver’s door lock and turn the
top of the key toward the front of the
vehicle.
You can also lock or unlock all the side
doors by pushing down or pulling up the
driver's door lock knob.
76G-03-007
Side Door Locks
To lock the driver's door from outside the vehicle:
a) Insert the key fully and turn the top of
the key toward the rear of the vehicle,
or
b) Push in the lock knob down and hold the
door handle up as you close the door.
To unlock the driver's door from outside the
vehicle, insert the key fully and turn the top
of the key toward the front of the vehicle.
To lock a front passenger’s door from
outside the vehicle, turn the lock knob
forward, then pull and hold the door handle
as you close the door.
To lock a rear door from outside the
vehicle, push in the lock knob down and
close the door.To lock a door from inside the vehicle, push
the lock knob down. Pull the lock knob up
to unlock the door.
w ww w
w WARNING
DOOR LOCKS
76G-03-005 76G-03-006
Always lock all doors when driving.
Locking the door prevents occupants
from being thrown from the vehicle
in the event of an accident. It also
helps prevent unintentional opening
of the doors.

Downloaded from www.Manualslib.com manuals search engine 18
76G-74E
NOTE:
Moving the lock knob on passenger's
door locks or unlocks the passenger's
door only.
Be sure to hold the door handle up
when you close a locked front door, or
the door will not remain locked.
w ww w
w WARNING
Child-Proof Locks (if equipped)
As illustrated, a child-proof lock is provided
for both rear doors. When the lock lever is
down, position 1, the child proof lock is
activated, and when up, in position 2 the
child-proof lock is deactivated, when the
child-proof lock is activated, the rear door
cannot be opened from the inside even if
the inside door lock is unlocked but can be
opened from the outside.
Be sure to place the child-proof lock
in the locked position whenever
children are seated in the rear.
Rearend Door Lock
To unlock the door, insert the key into the
lock knob and turn it clockwise.
76G-03-008 76G-03-009
TYPE-1 (ALTO) EXAMPLE
3-5BEFORE DRIVING

Downloaded from www.Manualslib.com manuals search engine 20
76G-74E
The driver’s window has an “auto-down”
feature for added convenience (at toll
booths or drive-through restaurants, for
example). This means you can open the
window without holding the window switch
in the “Down” position. Press the driver’s
window switch completely down and release
it. To stop the window before it reaches the
bottom, lift up the switch briefly.
To open or to close a window with the
passenger's door switch, push the top part
of the switch or lift up the top part of the
switch respectively.
76G-03-013
3-7BEFORE DRIVING
The driver’s door also has a lock switch for
the passenger’s window. When you push in
the lock switch, the passenger’s window
can not be raised or lowered by operating
either of the switches 2 or 3. To restore
normal operation, push the switch again.
76G-03-014
w ww w
w WARNING
You should always push in the lock
switch when there are children in the
vehicle. Children can be seriously
injured if they get part of their body
caught by the window during
operation.
Since the electric windows consumes
a large amount of electricity, the same
should not be used excessively with
engine in “OFF” condition.
CAUTION

Downloaded from www.Manualslib.com manuals search engine 2376G-74E
BEFORE DRIVING
3-10
The adjustment lever for each front seat is
located under the front of the seat. To
adjust the seat position, pull up on the
adjustment lever and slide the seat forward
or rearward. After adjustment, try to move
the seat forward and rearward to ensure
that it is securely latched.
w ww w
w WARNING
To avoid excessive seat belt slack,
which reduces the effectiveness of the
seat belts as a safety device, make
sure that the seats are adjusted
before the seat belts are fastened.
Seatbacks should always be in an
upright position when driving, or seat
belt effectiveness may be reduced.
Seat belts are designed to offer
maximum protection when seatbacks
are in the fully upright position.
Front Seats
The seatbacks can be adjusted to different
angles. To adjust the seatback angle, pull
up the lever on the outboard side of the
seat, move the seatback to the desired
position, and release the lever to lock the
seatback in place.
w ww w
w WARNING
76G-03-022
76G-03-023
TYPE-1 (ALTO)
TYPE-2 (ALTO K10)ADJUSTING SEATBACKS

Downloaded from www.Manualslib.com manuals search engine 2776G-74E
BEFORE DRIVING
3-14
w ww w
w WARNING
To Adjust the Belt
Pull the shoulder portion of the belt
upwards through the tongue plate.
The length of the diagonal shoulder strap
adjusts itself to allow freedom of movement.
The seat belt has an emergency locking
retractor (ELR), which is designed to lock
the seat belt only during a sudden stop or
impact.
No modifications or additions of any
sort should be made to the seat belt
or its operating mechanism.
76G-03-035
Seat Belt Inspection
Periodically inspect the seat belts to make
sure they work properly and are not
damaged. Check the webbing, buckles, latch
plates, retractors, anchorages and guide
loops. Replace any seat belts which do not
work properly or are damaged.
76G-03-036
To unfasten the belt, press the release
button on the buckle catch.
76G-03-034

Downloaded from www.Manualslib.com manuals search engine 30
76G-74E
IGNITION SWITCHThe ignition switch has the following four
positions:
Do not use any locally made key.
Should you require duplicate key,
place your order with MARUTI
SUZUKI dealer only.LOCK
This is the normal parking position. It is the
only position in which the key can be
removed.
The “LOCK” position locks the ignition, and
prevents normal use of the steering wheel
after the key is removed.
To release the steering lock, fully insert the
key and turn it clockwise to one of the other
positions. If you have trouble turning the
key to unlock the steering, try turning the
steering wheel slightly to the right or left
while turning the key. To avoid possible injury, do not operate
controls by reaching through the steering
wheel.
STEERING COLUMN CONTROLS
w ww w
w WARNING
w ww w
w WARNING
4-1
76G-04-00176G-04-003 76G-04-002
