2007 SATURN VUE HYBRID maintenance schedule

Service and Appearance Care
.................. 285
Service
................................................. 287
Fuel
...................................................... 289
Checking Things Under the Hood
......... 294
Headlamp Aiming
................................. 328
Bulb Replacement
................................ 331
Windshield Wiper Blade Replacement..... 338
Tires
..................................................... 339
Appearance Care
.................................. 370
Vehicle Identication
............................. 379
Electrical System
.................................. 380
Capacities and Specications
................ 387Maintenance Schedule
.............................. 389
Maintenance Schedule
.......................... 390
Customer Assistance Information
............. 407
Customer Assistance and
Information
........................................ 408
Reporting Safety Defects
...................... 422
Index
.......................................................... 425
2
ProCarManuals.com

Oil Pressure Light
If you have a low
engine oil pressure
problem, this light will
stay on after you
start your engine, or
come on when you
are driving.
This indicates that your engine is not receiving
enough oil.
The engine could be low on oil, or could have
some other oil problem. Have it xed immediately.
The oil light may also come on when the ignition
is on but the engine is not running, the light
will come on as a test to show you it is working,
but the light will go out when you turn the
ignition to START. If it does not come on with the
ignition on, you may have a problem with the
fuse or bulb. Have it xed right away.{CAUTION:
Do not keep driving if the oil pressure is
low. If you do, your engine can become so
hot that it catches re. You or others could
be burned. Check your oil as soon as
possible and have your vehicle serviced.
Notice:Lack of proper engine oil maintenance
may damage the engine. The repairs would
not be covered by your warranty. Always follow
the maintenance schedule in this manual for
changing engine oil.
176
ProCarManuals.com

Change Engine Oil Light
If this light comes on,
it means that service
is required for
your vehicle.
SeeScheduled Maintenance on page 392and
Engine Oil on page 297for more information.
After having the oil changed you will need to reset
the light. SeeEngine Oil Life System on page 300
for more information.
Security Light
Your vehicle has
a Passlock®
theft-deterrent system.
With this system, the security light will ash as
you open the door if your ignition is off.
This light will come on briey when the vehicle is
turned on.
For more information, seePasslock
®on page 110.
177
ProCarManuals.com

3. When the chocks are in place, release the
regular brakes until the chocks absorb
the load.
4. Reapply the regular brakes. Then apply your
parking brake and shift into PARK (P).
5. Release the regular brakes.
When You Are Ready to Leave After
Parking on a Hill
1. Apply your regular brakes and hold the pedal
down while you:
start your engine,
shift into a gear, and
release the parking brake.
2. Let up on the brake pedal.
3. Drive slowly until the trailer is clear of the
chocks.
4. Stop and have someone pick up and store
the chocks.
Maintenance When Trailer Towing
Your vehicle will need service more often when
you’re pulling a trailer. SeeScheduled Maintenance
on page 392for more information. Things that
are especially important in trailer operation are
automatic transaxle uid (don’t overll), engine oil,
drive belt, cooling system and brake system.
Each of these is covered in this manual, and the
Index will help you nd them quickly. If you’re
trailering, it’s a good idea to review this information
before you start your trip.
Check periodically to see that all hitch nuts and
bolts are tight.
283
ProCarManuals.com

Engine Air Cleaner/Filter
SeeEngine Compartment Overview on page 296
for the location of the engine air cleaner/lter.
When to Inspect the Engine Air
Cleaner/Filter
Inspect the air cleaner/lter at the MaintenanceII
intervals and replace it at the rst oil change
after each 50,000 mile (83 000 km) interval.
SeeScheduled Maintenance on page 392for
more information. If you are driving in dusty/dirty
conditions, inspect the lter at each engine
oil change.
How to Inspect the Engine Air
Cleaner/Filter
To inspect the air cleaner/lter remove the lter
from the vehicle and lightly shake the lter to
release loose dust and dirt. If the lter remains
caked with dirt, a new lter is required.
To inspect or replace the engine air cleaner/lter,
do the following:
1. Unscrew the clamp on the air duct hose.
302
ProCarManuals.com

Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected for
wear and cracking. SeeScheduled Maintenance
on page 392for more information.
Replacement blades come in different types and
are removed in different ways. For proper type and
length, seeNormal Maintenance Replacement
Parts on page 402.
To replace the windshield wiper blade assembly
do the following:
1. Lift the wiper arm away from the windshield.2. Push the release lever (B) to disengage the
hook and push the wiper arm (A) out of the
blade (C).
3. Push the new wiper blade securely on the
wiper arm until you hear the release lever
click into place.
To replace the rear wiper blade, follow the steps
listed above.
338
ProCarManuals.com

Tire Inspection and Rotation
Tires should be rotated every 5,000 to 8,000 miles
(8 000 to 13 000 km).
Any time you notice unusual wear, rotate your
tires as soon as possible and check wheel
alignment. Also check for damaged tires or wheels.
SeeWhen It Is Time for New Tires on page 349
andWheel Replacement on page 353for more
information.
The purpose of regular rotation is to achieve more
uniform wear for all tires on the vehicle. The rst
rotation is the most important. See “Scheduled
Maintenance” for additional information.When rotating your tires, always use the correct
rotation pattern shown here.
After the tires have been rotated, adjust the front
and rear ination pressures as shown on the
Tire and Loading Information label. SeeLoading
Your Vehicle on page 264, for an example of
the tire and loading information label and
its location on your vehicle.
348
ProCarManuals.com

Maintenance Schedule................................ 390
Introduction............................................... 390
Maintenance Requirements........................ 390
Your Vehicle and the Environment............ 390
Using the Maintenance Schedule............... 390
Scheduled Maintenance............................. 392
Additional Required Services..................... 395
Maintenance Footnotes.............................. 396
Owner Checks and Services..................... 397At Each Fuel Fill....................................... 398
At Least Once a Month............................. 398
At Least Once a Year............................... 398
Recommended Fluids and Lubricants........ 401
Normal Maintenance
Replacement Parts ................................. 402
Engine Drive Belt Routing......................... 403
Maintenance Record.................................. 404
Section 6 Maintenance Schedule
389
