2007 SATURN OUTLOOK radiator cap

Service........................................................ 377
Accessories and Modications................... 377
California Proposition 65 Warning.............. 378
Doing Your Own Service Work.................. 378
Adding Equipment to the Outside of
Your Vehicle.......................................... 379
Fuel............................................................. 379
Gasoline Octane........................................ 379
Gasoline Specications.............................. 379
California Fuel........................................... 380
Additives................................................... 380
Fuels in Foreign Countries........................ 381
Filling the Tank......................................... 381
Filling a Portable Fuel Container............... 384
Checking Things Under the Hood.............. 384
Hood Release........................................... 385
Engine Compartment Overview.................. 386
Engine Oil................................................. 387
Engine Oil Life System.............................. 390
Engine Air Cleaner/Filter............................ 392
Automatic Transmission Fluid.................... 394
Engine Coolant.......................................... 396
Radiator Pressure Cap.............................. 399
Engine Overheating................................... 400Overheated Engine Protection
Operating Mode..................................... 402
Cooling System......................................... 402
Power Steering Fluid................................. 408
Windshield Washer Fluid........................... 409
Brakes...................................................... 410
Battery...................................................... 413
Jump Starting............................................ 414
All-Wheel Drive........................................... 420
Headlamp Aiming........................................ 421
Bulb Replacement....................................... 422
High Intensity Discharge (HID) Lighting..... 422
Halogen Bulbs........................................... 422
License Plate Lamp................................... 423
Replacement Bulbs................................... 423
Windshield Wiper Blade Replacement....... 424
Tires............................................................ 425
Tire Sidewall Labeling............................... 426
Tire Terminology and Denitions............... 429
Ination - Tire Pressure............................. 432
Tire Pressure Monitor System................... 433
Tire Inspection and Rotation...................... 438
When It Is Time for New Tires.................. 440
Section 5 Service and Appearance Care
375
ProCarManuals.com

A. Radiator Pressure Cap (Out of View). See
Radiator Pressure Cap on page 399.
B. Engine Coolant Recovery Cap. SeeCooling
System on page 402.
C. Underhood Fuse Block. SeeUnderhood Fuse
Block on page 479.
D. Remote Positive (+) Terminal. SeeJump
Starting on page 414.
E. Power Steering Fluid Reservoir. SeePower
Steering Fluid on page 408.
F. Engine Oil Fill Cap. See “When to Add Engine
Oil” underEngine Oil on page 387.
G. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 387.
H. Automatic Transmission Fluid Dipstick. See
“Checking the Fluid Level” underAutomatic
Transmission Fluid on page 394.
I. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 410.
J. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 392.
K. Windshield Washer Fluid Reservoir. See
“Adding Washer Fluid” underWindshield
Washer Fluid on page 409.Engine Oil
Checking Engine Oil
It is a good idea to check the engine oil every time
you get fuel. In order to get an accurate reading,
the oil must be warm and the vehicle must be
on level ground.
The engine oil dipstick handle is a yellow loop.
SeeEngine Compartment Overview on page 386
for the location of the engine oil dipstick.
1. Turn off the engine and give the oil
several minutes to drain back into the oil
pan. If you do not do this, the oil dipstick might
not show the actual level.
2. Pull out the dipstick and clean it with a paper
towel or cloth, then push it back in all the
way. Remove it again, keeping the tip down,
and check the level.
387
ProCarManuals.com

How to Add Automatic Transmission
Fluid
Refer to the Maintenance Schedule to determine
what kind of transmission uid to use. See
Recommended Fluids and Lubricants on page 497.
If the uid level is low, add only enough of the
proper uid to bring the level into the crosshatched
area on the dipstick.
1. Remove the dipstick.
2. Using a long-neck funnel, add enough uid at
the dipstick hole to bring it to the proper level.
It does not take much uid, generally less
than one half of a pint (0.25 L). Do not overll.
Notice:Use of the incorrect automatic
transmission uid may damage your vehicle,
and the damages may not be covered by
your warranty. Always use the automatic
transmission uid listed inRecommended
Fluids and Lubricants on page 497.
3. After adding uid, recheck the uid level as
described under “How to Check Automatic
Transmission Fluid,” earlier in this section.
4. When the correct uid level is obtained, twist
& lock dipstick cap in place.
Engine Coolant
The cooling system in your vehicle is lled with
DEX-COOL®engine coolant. This coolant is
designed to remain in your vehicle for ve years or
150,000 miles (240 000 km), whichever occurs
rst, if you add only DEX-COOL
®extended
life coolant.
The following explains your cooling system and
how to add coolant when it is low. If you have
a problem with engine overheating or if you need
to add coolant to the radiator, seeEngine
Overheating on page 400.
A 50/50 mixture of clean, drinkable water and
DEX-COOL
®coolant will:
Give freezing protection down
to−34°F (−37°C).
Give boiling protection up to 265°F (129°C).
Protect against rust and corrosion.
Help keep the proper engine temperature.
Let the warning lights and gages work as they
should.
396
ProCarManuals.com

Adding Coolant
If more coolant is needed, add the proper
DEX-COOL®coolant mixture at the coolant
recovery tank, but be careful not to spill it.
If the coolant recovery tank is completely empty,
add coolant to the radiator. SeeEngine
Overheating on page 400.
{CAUTION:
Turning the radiator pressure cap when the
engine and radiator are hot can allow
steam and scalding liquids to blow out
and burn you badly. With the coolant
recovery tank, you will almost never
have to add coolant at the radiator. Never
turn the radiator pressure cap — even a
little — when the engine and radiator
are hot.
{CAUTION:
You can be burned if you spill coolant on
hot engine parts. Coolant contains
ethylene glycol, and it will burn if the
engine parts are hot enough. Do not spill
coolant on a hot engine.
Occasionally check the coolant level in the
radiator. For information on how to add coolant to
the radiator, seeCooling System on page 402.
Radiator Pressure Cap
Notice:If the pressure cap is not tightly
installed, coolant loss and possible engine
damage may occur. Be sure the cap is properly
and tightly secured.
SeeEngine Compartment Overview on page 386
for more information on location.
399
ProCarManuals.com

Overheated Engine Protection
Operating Mode
This emergency operating mode lets your vehicle
be driven to a safe place in an emergency
situation. If an overheated engine condition exists,
an overheat protection mode which alternates
ring groups of cylinders helps prevent engine
damage. In this mode, there is a signicant loss in
power and engine performance. The temperature
gage indicates an overheat condition exists.
Driving extended distances and/or towing a trailer
in the overheat protection mode should be
avoided.
Notice:After driving in the overheated engine
protection operating mode, to avoid engine
damage, allow the engine to cool before
attempting any repair. The engine oil will be
severely degraded. Repair the cause of coolant
loss, change the oil and reset the oil life
system. SeeEngine Oil on page 387.
Cooling System
When you decide it is safe to lift the hood, here is
what you will see:
A. Engine Coolant Reservoir
B. Radiator Pressure Cap (covered)
C. Engine Cooling Fans
402
ProCarManuals.com

{CAUTION:
An electric engine cooling fan under the
hood can start up even when the engine
is not running and can injure you. Keep
hands, clothing, and tools away from any
underhood electric fan.
If the coolant inside the coolant recovery tank is
boiling, do not do anything else until it cools down.
The vehicle should be parked on a level surface.
When the engine is cold, the coolant level
should be at least up to the FULL COLD mark. If it
is not, you may have a leak at the pressure cap
or in the radiator hoses, heater hoses, radiator,
water pump or somewhere else in the cooling
system.
{CAUTION:
Heater and radiator hoses, and other
engine parts, can be very hot. Do not
touch them. If you do, you can be burned.
Do not run the engine if there is a leak. If
you run the engine, it could lose all
coolant. That could cause an engine re,
and you could be burned. Get any leak
xed before you drive the vehicle.
403
ProCarManuals.com

If there seems to be no leak, with the engine on,
check to see if the electric engine cooling fans
are running. If the engine is overheating, both fans
should be running. If they are not, your vehicle
needs service.
Notice:Engine damage from running your
engine without coolant is not covered by your
warranty.
Notice:Using coolant other than DEX-COOL
®
may cause premature engine, heater core, or
radiator corrosion. In addition, the engine
coolant could require changing sooner, at
30,000 miles (50 000 km) or 24 months,
whichever occurs rst. Any repairs would not
be covered by your warranty. Always use
DEX-COOL
®(silicate-free) coolant in your
vehicle.
How to Add Coolant to the Coolant
Recovery Tank
Notice:This vehicle has a specic coolant ll
procedure. Failure to follow this procedure
could cause your engine to overheat and
be severely damaged.If you have not found a problem yet, check to see
if coolant is visible in the coolant recovery tank.
If coolant is visible but the coolant level is not at or
above the FULL COLD mark, add a 50/50 mixture
of clean, drinkable water and DEX-COOL
®
coolant at the coolant recovery tank, but be sure
the cooling system, including the coolant recovery
tank pressure cap, is cool before you do it. See
Engine Coolant on page 396for more information.
{CAUTION:
Steam and scalding liquids from a hot
cooling system can blow out and burn
you badly. They are under pressure, and if
you turn the radiator pressure cap — even
a little — they can come out at high
speed. Never turn the cap when the
cooling system, including the radiator
pressure cap, is hot. Wait for the cooling
system and radiator pressure cap to cool
if you ever have to turn the pressure cap.
404
ProCarManuals.com

1. To remove the panel that covers the radiator
cap, detach fasteners and lift off panel.
2. Remove the radiator pressure cap when the
cooling system, including the upper radiator
hose, is no longer hot. Turn the pressure cap
slowly counterclockwise about one full turn.
If you hear a hiss, wait for that to stop. A hiss
means there is still some pressure left.3. Keep turning the
pressure cap slowly,
and remove it.
4. Fill the radiator with the proper DEX-COOL®
coolant mixture, up to the base of the ller
neck. SeeEngine Coolant on page 396
for more information about the proper coolant
mixture.
406
ProCarManuals.com
