2007 SATURN ION display

Oil Pressure Light..................................... 177
Passlock®Warning Light............................ 178
Reduced Engine Power Light.................... 178
Highbeam On Light................................... 179
Fuel Gage................................................. 179
Boost Gage............................................... 180
Message Center.......................................... 182
Low Traction Message.............................. 182
Traction Off Message................................ 182
Cruise Control Message............................ 183
Transaxle Fluid Hot Message.................... 183
Change Engine Oil Message..................... 183
Check Gage Message............................... 184
Power Steering Message........................... 184
Trunk Ajar Warning Message.................... 184Check Gas Cap Message......................... 185
Low Fuel Warning Message...................... 185
Error Message........................................... 185
Audio System(s)......................................... 186
Setting the Time (Without Date Display).... 187
Setting the Time (With Date Display)......... 188
Radio with CD (Base)............................... 190
Radio with CD (MP3)................................ 195
Using an MP3........................................... 205
XM Radio Messages................................. 212
Radio Reception........................................ 214
Care of Your CDs..................................... 215
Care of the CD Player.............................. 215
Fixed Mast Antenna.................................. 215
XM™ Satellite Radio Antenna System....... 215
Section 3 Instrument Panel
138
ProCarManuals.com

J(On/Off):Press this button to turn the cruise
control system on and off.
+RES (Resume):Press this part of the button to
resume a set speed and to accelerate the speed.
−SET (Set):Press this part of the button to set a
speed and to decrease the speed.
To set a speed do the following:
1. Press the on/off button to turn cruise control
on. The indicator light on the button will
come on.
2. Get to the speed you want.
3. Press the−SET part of the control button and
release it. The CRUISE message will display
in the instrument panel cluster to show the
system is engaged.
4. Take your foot off the accelerator pedal.
When the brakes are applied, the cruise control
shuts off.If the vehicle is in cruise control and the Enhanced
Traction System (ETS) begins to limit wheel
spin, the cruise control will automatically
disengage. SeeEnhanced Traction System (ETS)
on page 226. When road conditions allow, the
cruise control can be used again.
Resuming a Set Speed
Suppose you set your cruise control at a desired
speed and then you apply the brake. This, of
course, disengages the cruise control. The
CRUISE message in the instrument panel cluster
will also go out indicating cruise is no longer
engaged. To return to your previously set speed,
you do not need to go through the set process
again. Once you are going about 25 mph (40 km/h)
or more, you can press the +RES part of the
button briey.
This will take you back up to your previously
chosen speed and stay there.
148
ProCarManuals.com

Speedometer and Odometer
Your speedometer lets you see your speed in
both miles per hour (mph) and kilometers per
hour (km/h).
Your odometer is located in your message center,
and shows how far your vehicle has been
driven, in either miles (used in the United States)
or kilometers (used in Canada).
When information messages need to be shown in
the message center, they will be shown in
place of the odometer. To display the odometer
after a message(s) is shown, clear each message
by pressing the trip/reset button located to the
right of the speedometer. SeeMessage Center on
page 182for more information.
Your vehicle has a tamper-resistant odometer.
You may wonder what happens if your vehicle
needs a new odometer installed. If the new one
can be set to the mileage total of the old odometer,
then that will be done. If not, it will be set at
zero and a label must be put on the driver’s door
to show the old mileage reading when the new
odometer was installed. If the mileage is unknown,
the label should then indicate “previous mileage
unknown”.
Trip Odometer
Your trip odometer shows how far your vehicle has
been driven since the trip odometer was last reset.
To reset the trip odometer to zero, press and hold
the trip/reset button for about two seconds.
Tachometer
The tachometer
displays the engine
speed in revolutions
per minute (rpm).
Notice:If you operate the engine with the
tachometer in the shaded warning area, your
vehicle could be damaged, and the damages
would not be covered by your warranty. Do not
operate the engine with the tachometer in
the shaded warning area.
165
ProCarManuals.com

The oil light may also come on when the ignition
is on but the engine is not running, the light
will come on as a test to show you it is working,
but the light will go out when you turn the
ignition to START. If it does not come on with the
ignition on, you may have a problem with the
fuse or bulb. Have it xed right away.
{CAUTION:
Do not keep driving if the oil pressure is
low. If you do, your engine can become so
hot that it catches re. You or others could
be burned. Check your oil as soon as
possible and have your vehicle serviced.
Notice:Lack of proper engine oil maintenance
may damage the engine. The repairs would
not be covered by your warranty. Always follow
the maintenance schedule in this manual for
changing engine oil.
Passlock®Warning Light
Your vehicle has a
Passlock®
theft-deterrent system.
With this system, the
security light will ash as
you open the door if your
ignition is off.
For more information, seePasslock
®on page 103.
Reduced Engine Power Light
This light will come on
briey when you start
the engine.
This light, along with the service engine soon light
will be displayed when a noticeable reduction in
the vehicle’s performance may occur. Stop the
vehicle and turn off the ignition. Wait for
10 seconds and restart your vehicle. This may
correct the condition.
178
ProCarManuals.com

If your vehicle has this gage, it is located on the
steering column.
This gage indicates vacuum during light to
moderate throttle and boost under heavier throttle.
This gage displays the air pressure level in the
intake manifold before it enters the engine’s
combustion chamber.This gage is automatically centered at zero every
time the ignition is turned to RUN. Actual
vacuum or boost is displayed from this zero point.
The boost gage has three pairs of lights that
are located on each side of the gage. These lights
are used to indicate three different engine rpm
levels. The default setting for the lower pair
of lights is 4,400 rpm, the middle pair of lights is
5,600 rpm, and the top pair of lights is 6,200 rpm.
These settings can be adjusted by turning the
stem behind each light. To have the light
pair come on at a higher rpm level, turn the stem
counterclockwise. To have the light pair come
on at a lower rpm level, turn the stem clockwise.
Each detent adjusts the settings by 100 rpm.
To restore the default settings, press and hold any
stem for three seconds. The lights will ash
three times.
To turn the lights off or on, press and release
any stem.
Canada
181
ProCarManuals.com

Message Center
The message center is located in the instrument
panel cluster. It gives you important safety
and maintenance facts.
If there are several messages, each message will
be shown for a few seconds and will continue
to repeat until cleared. To clear a message, press
the trip/reset button while the message you
want to clear is being displayed.
Many messages will also cause a chime to sound,
to alert you to the message.
Changing the Language (Canada Only)
Vehicles rst sold in Canada have instrument panel
clusters that show messages in either English or
French. To change the language, do the following:
1. Turn the ignition on.
2. Press the trip/reset button until the current
language of ENGLISH or FRENCH is
displayed.
3. Press and hold the trip/reset button for
several seconds until the language is
changed.
4. Press the trip/reset button to return to the
odometer display.
Low Traction Message
If your vehicle has an
enhanced traction
system (ETS), this LOW
TRAC message will
be displayed when the
system is limiting
wheel spin.
SeeEnhanced Traction System (ETS) on
page 226for more information.
Traction Off Message
If your vehicle has an
enhanced traction
system (ETS), this
TRAC OFF message
will be displayed briey
when the system
has been turned off.
SeeEnhanced Traction System (ETS) on
page 226for more information.
182
ProCarManuals.com

Cruise Control Message
The CRUISE message
is displayed briey when
your cruise control
system has been
activated, or set to a
desired speed.
SeeCruise Control on page 147for more
information.
Transaxle Fluid Hot Message
If the TRANS HOT
message is displayed,
the automatic transaxle
uid may be
overheating.
SeeEngine Overheating on page 297for more
information.
Change Engine Oil Message
When the CHG OIL
message is displayed, it
means that service is
required for your
vehicle.
SeeScheduled Maintenance on page 391and
Engine Oil on page 283for more information.
183
ProCarManuals.com

Check Gage Message
If the CHK GAGE
message is displayed,
the engine coolant
may be overheated.
A chime will also sound
to alert you to this
message.
If this message is displayed, check your engine
coolant temperature gage. If the needle is in
the red area, your engine may be overheating.
SeeEngine Coolant Temperature Gage on
page 173andEngine Overheating on page 297
for more information.
Notice:Driving with either the CHK GAGE
message or the COOLANT message displayed
in the message center and the Engine
Coolant Temperature Gage on your instrument
panel in the red zone could cause your
vehicle to overheat. SeeEngine Overheating
on page 297. Your vehicle could be damaged
and the damages might not be covered by your
warranty.
Power Steering Message
If the PWR STR
message is displayed,
a problem has been
detected with the
electric power steering.
If you suspect electric power steering problems
and/or the PWR STR message is on, see
your retailer for service and repair.
Trunk Ajar Warning Message
When the TRUNK
message is displayed, it
means the trunk lid is
not fully closed.
184
