2007 SATURN ION engine

The following information will tell you how to use
the jack and change a tire.
Removing the Spare Tire and Tools
The equipment you will need is located in
the trunk.
Models with a 2.2L L4 or 2.4L Engine
1. Open the trunk. SeeTrunk on page 98
for more information.
2. Lift the trunk liner to access the spare tire
and tools.
351
ProCarManuals.com

3. Remove the retainer (B) that holds down the
spare tire. SeeCompact Spare Tire on
page 365
4. Remove the spare tire (C) by gently pulling it
up and out of the trunk.
5. Remove the wing nut (D) that holds the jack
and remove the jack and wheel wrench (E).Models with a 2.0L L4 Supercharged
Engine
1. Open the trunk. SeeTrunk on page 98for
more information.
2. Lift the trunk liner to access the spare tire
and tools.
353
ProCarManuals.com

A. Cover
B. Retainer
C. Jack and Wheel Wrench
D. Stow Bolt Extension
E. Spare Tire
F. Bolt
2.2L L4 and 2.4L Engine
363
ProCarManuals.com

A. Cover
B. Retainer
C. Jack and Wheel Wrench
D. Stow Bolt Extension
E. Spare Tire
F. Foam Support
G. Bolt
To store a at or spare tire and tools, do the
following:
1. Remove the stow bolt extension rod and
sleeve from the jack.
2. Re-attach the wheel wrench to the jack.
3. Place the at tire face down into the spare tire
hub. Avoid scraping the aluminum wheel, if
equipped, on the hold-down bolt.
4. Screw the stow bolt extension rod and
the sleeve into the existing spare tire
hold-down bolt.
5. Place the jack into the center of the at tire,
being careful not to scratch the inside of
the wheel.
2.0L L4 Supercharged Engine
364
ProCarManuals.com

Vehicle Identication
Vehicle Identication Number (VIN)
This is the legal identier for your vehicle. It
appears on a plate in the front corner of the
instrument panel, on the driver side. You can see
it if you look through the windshield from outside
your vehicle. The VIN also appears on the Vehicle
Certication and Service Parts labels and the
certicates of title and registration.
Engine Identication
The eighth character in the VIN is the engine
code. This code helps you identify your vehicle’s
engine, specications, and replacement parts.
Service Parts Identication Label
This label is on your spare tire cover. It is
very helpful if you ever need to order parts.
The label has the following information:
Vehicle Identication Number (VIN)
Model designation
Paint information
Production options and special equipment
Do not remove this label from the vehicle.
374
ProCarManuals.com

Engine Compartment Fuse Block
The engine compartment fuse block is located in
the engine compartment on the driver’s side
of the vehicle. SeeEngine Compartment Overview
on page 280for more information on location.
2.2L L4 Engine
Fuses Usage
1Engine Control Module, Transaxle
Control Module
2 Not Used
Fuses Usage
3 Not Used
4 Passenger’s Side Headlamp
5 Air Conditioning
6 Not Used
7 Not Used
8Anti-lock Brake System, Traction
Control Module
9Engine Control Module, Electronic
Throttle Control
10Canister Purge Solenoid, Mass
Airow Sensor, Low Coolant
Switch, Oxygen Sensors, Air Pump
Relay Coil
11Electric Ignition Control Module,
Charging System, Neutral Stop
Back-Up Switch
12 Not Used
13Transaxle, Engine Control
Module (ECM)
14Transaxle Control Module, Neutral
Stop Back-Up
15 PRNDL, Back-up Switch
16 Fuel Injectors (Cylinder 1, 2, 3, 4)
17 Fog Lamps
18 Driver’s Side Headlamp
19 Windshield Wiper
378
ProCarManuals.com

Fuses Usage
20 Horn
21Entertainment, Premium Radio
Amplier
22Anti-lock Brake System, Traction
Control Module
23 Rear Defogger
38 Starter/Ignition
39 Body Control Module 1
40Anti-lock Brake System, Traction
Control Module
41 Body Control Module 2
42 Not Used
43 Electric Power Steering
44 Air Pump Relay Fuse
45 Cooling Fan
46 Crank
47 Body Control Module 1A
48 Body Control Module (IGN 3)Relays Usage
24 Air Conditioning Clutch
25 Horn
26 Fog Lamps
27 Air Solenoid
28 Run, Crank (IGN1)
29 Powertrain
30 Engine Cooling Fan
31 Engine Control Module
32 Wiper System 1
33 Wiper System 2
34 Rear Window Defogger
Diodes Usage
35
§Air Conditioning Diode
36
§Not Used
37
§Wiper Diode
Miscellaneous Usage
49 Fuse Puller
379
ProCarManuals.com

2.0L L4 Supercharged Engine
Fuses Usage
1 Engine Control Module
2 Not Used
3 Not Used
4 Passenger’s Side Headlamp
Fuses Usage
5 Air Conditioning
6 Not Used
7 Not Used
8 Anti-lock Brake System
9Engine Control Module, Electronic
Throttle Control
10Canister Purge Solenoid, Mass
Airow Sensor, Low Coolant Switch,
Oxygen Sensors
11Electric Ignition Control Module,
Charging System, Neutral Safety
Stop Back-Up Switch
12 Not Used
13 Engine Control Module
14 Boost
15 Back-up Switch
16 Fuel Injectors
17 Fog Lamps
18 Driver’s Side Headlamp
380
