2007 SAAB 9-3 technical data

1
Owner’s Manual
Saab 9-3 M2007
© Saab Automobile AB 2006Service Readiness, Saab Automobile AB, Trollhättan, Sweden
Printed in Sweden
Safety 11
Security 47
9-3 Convertible 61
Instruments and controls 81
Interior equipment 117
Starting and driving 149
Car care 201
Customer Assistance and Information 273
Technical data 279
Index 299
93_U S _M 07.book Page 1 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

6Engine bay, 4-cylColor code______________ 293
Engine number __________ 293
Gearbox number _________ 293
Warning labels __________ 8
Vehicle identification number 293Alternator_______________ 216
Drive belt _______________ 216
Exhaust emission control __ 155
Ignition system __________ 286
Simple troubleshooting (ACC) 268
Spark plugs _____________ 286
Turbo gauge ____________ 88Engine oil: checking level __ 207Automatic transmission _________ 163
Transmission: technical data _____ 287
Manual transmission ___________ 162
Battery ______________________ 213
Battery charge ________________ 213
Jump starting _________________ 198
Engine: description ____________ 202
Engine: technical data __________ 283
Important considerations for driving 154
Oil grade and viscosity__________ 284
Topping-up fluid _________ 218
Wash/wipe stalk switch____ 101
Washer fluid ____________ 218
Washer jets ____________ 218
Power steering ________________ 212
Fluid: checking/topping up _______ 212
Coolant: checking/topping-up ____ 209
Driving in hot climates __________ 187
Radiator _____________________ 283
Temperature gauge ____________ 88
Changing a fuse _________ 234
Fuse table _____________ 239
Fuses _________________ 234
Relays ________________ 239ABS brakes_____________ 170
Brake pads _____________ 211
Brake system ___________ 289
Brake fluid______________ 211
93_U S _M 07.book Page 6 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

7
Engine bay, 2.8 V6Power steering___________ 212
Fluid: checking/topping up__ 212Vehicle identification
number ________________ 293
Colour code _____________ 293
Engine number __________ 293
Warning labels___________ 8
Gearbox number _________ 293Exhaust emission control __ 155
Drive belt _______________ 216
Simple troubleshooting (ACC) 268
Alternator_______________ 216
Turbo gauge ____________ 88
Spark plugs _____________ 286
Ignition system __________ 286Automatic transmission _________ 163
Manual gearbox_______________ 162
Gearbox: technical data_________ 287
Engine: description ____________ 202
Engine oil: topping up __________ 207
Oil grade and viscosity__________ 284
Engine: technical data __________ 283
Important considerations
for driving ___________________ 154Engine oil: checking level________ 207
Battery ______________________ 213
Battery charge ________________ 213
Jump starting _________________ 198
Wash/wipe stalk switch ____ 101
Topping-up fluid _________ 218
Washer jets_____________ 218
Washer fluid ____________ 218Changing a fuse _________ 236
Fuses _________________ 234
Relays ________________ 239
Fuse table ______________ 236ABS brakes_____________ 171
Brake pads _____________ 289
Brake system ___________ 170
Brake fluid______________ 211
Cooling system, coolant capacity__ 283
Coolant: checking/topping-up ____ 209
Driving in hot climates __________ 187
Temperature gauge ____________ 88
93_U S _M 07.book Page 7 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

186 Starting and drivingRemember that tires age: it may therefore
be necessary to change winter tires before
they reach the legal wear limit, as they grad-
ually lose their friction properties with age.
If you get into a front wheel skid and the car
has a manual transmission, the best
response is to freewheel, which means
declutching so that the wheels neither drive
nor brake, and to cautiously steer in the
desired direction.
If the car has automatic transmission, ease
off the accelerator slightly and steer cau-
tiously in the desired direction.
If you get into a rear wheel skid, steer in the
same direction as the movement of the rear
of the car.
Driving with tire chains3Snow chains must only be fitted to the wheel
and tire dimensions that Saab recommends
in "Technical data" on page 279.
We recommend that you contact a Saab
dealer regarding approved tire chains. See
also page 248.
WARNING
Do not drive at speeds above 30 mph
(50 km/h) when tire chains are fitted.
Tire chains can reduce directional
stability.
Do not fit tire chains to the car’s rear
wheels.
NOTICE Check the links frequently for wear.
Check that the chains do not foul the
wheel arch liner at full lock.
Refer to the "Technical data" section
on page 279, for information on wheel
and tire dimensions approved for the
fitting of tire chains.
93_U S _M 07.book Page 186 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

279 Technical data
General data __________ 280
Engine _______________ 283
Engine oil _____________ 284
Fuel__________________ 285
Engines ______________ 286
Electrical system_______ 286
Drive belt _____________ 287
Manual transmission ___ 287
Automatic transmission _ 288
Suspension ___________ 288
Steering ______________ 288
Brake system__________ 289
Wheels and tires _______ 290
Plates and labels _______ 293
Technical data
3Asterisk means: equipment not fitted in all cars
(can depend on model variant, engine variant,
market specification, options or accessories).93_U S _M 07.book Page 279 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

280 Technical dataGeneral dataOverall length, including bumpers: ______
Sport Sedan and Convertible _________ 182.5'' (4635 mm)
SportCombi_______________________ 183.2'' (4654 mm)
Overall width, including door mirrors _____ 80.2'' (2038 mm)
Maximum height ____________________ 60.6'' (1539 mm)
Wheelbase ________________________ 105.3'' (2675 mm)
Tr a c k :
Front ____________________________ 59.8'' (1524 mm)
Rear ____________________________ 59.3'' (1506 mm)
Ground clearance at GVW ____________ approx. 4.7''
(120 mm)
Number of seats (incl. driver):
Sport Sedan and SportCombi ________ 5
Convertible _______________________ 4
Turning circle:
Measured at vehicle extremities _______ 39.0 ft. (11.9 m)
V.I.N. label on vehi-
cles sold in U.S.A.V.I.N. label on vehicles sold in
CanadaPermissible load (in addition to the driver) = GVW minus curb weight. The maximum
permissible axle load, front or rear, must not be exceeded.
The precise curb weight of the vehicle and load capacity are specified in the vehicle
registration documents.Trunk length, Sport Sedan:
Rear seat raised ___________________ 40.8'' (1036 mm)
Rear seat lowered _________________ 69.8'' (1774 mm)
Trunk length, Convertible _____________ 29.1" (740 mm)
Trunk length, SportCombi:
Rear seat raised ___________________ 39.9'' (1013 mm)
Rear seat lowered _________________ 70.0'' (1777 mm)
Trunk volume (VDA):
Sport Sedan ______________________ 15.0 cu.ft. (425 l)
Convertible, soft top raised ___________ 12.4 cu.ft. (352 l)
Convertible, soft top folded ___________ 8.3 cu.ft. (235 l)
SportCombi ______________________ 14.8 cu.ft. (419 l)
SportCombi with rear seat lowered ____ 45.0 cu.ft. (1273 l)
93_U S _M 07.book Page 280 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

281 Technical data
Curb weight
(i.e. with full fuel tank, full washer fluid res-
ervoir, standard tools and spare wheel):
Sport Sedan ______________________ 3210–3570 lbs.
(1455–1620 kg)
Convertible _______________________ 3510–3840 lbs.
(1590–1740 kg)
SportCombi_______________________ 3300–3690 lbs.
(1495–1675 kg)
Gross vehicle weight (GVW):
Sport Sedan ______________________ 4140–4510 lbs.
(1880–2045 kg)
Convertible _______________________ 4350–4620 lbs.
(1975–2095 kg)
SportCombi_______________________ 4230–4630 lbs.
(1920–2100 kg)
Maximum axle load:
Sport Sedan, front _________________ 2480 lbs. (1125 kg)
Sport Sedan, rear __________________ 2230 lbs. (1010 kg)
Convertible, front __________________ 2540 lbs. (1150 kg)
Convertible, rear ___________________ 2310 lbs. (1050 kg)
SportCombi, front __________________ 2480 lbs. (1125 kg)
SportCombi, rear __________________ 2230 lbs. (1010 kg)
Weight distribution:
Curb weight + driver (150 lbs. (68 kg)),
front/rear, Sport Sedan and SportCombi approx. 60/40 %
GVW, front/rear, Sport Sedan and Sport-
Combi ___________________________ approx. 50/50 %Maximum roof load, Sport Sedan and Sport-
Combi ___________________________ 220 lbs. (100 kg)
Maximum load in trunk, Sport Sedan, Con-
vertible and SportCombi _____________ 175 lbs. (80 kg)
The combined weight of occupants and
cargo should never exceed:
Sport Sedan and SportCombi ________ 926 lbs. (420 kg)
Convertible _______________________ 776 lbs. (352 kg)
Maximum combined weight of driver and
passengers ______________________
Sport Sedan and SportCombi (5x150 lbs.) 750 lbs. (340 kg)
Convertible (4x150 lbs.) _____________ 600 lbs. (272 kg)93_U S _M 07.book Page 281 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

282 Technical data
WARNING
The GVW and maximum axle loads must not be exceeded.
Note that if some accessories (e.g. towbar, CD changer) are
fitted, the available load capacity is reduced by the weight of
these.
When carrying a load in the trunk, make sure that it is lashed
down securely, particularly when part or all of the rear seat is
folded down.
Trailer:
Trailer with brakes ___________________ Max. 3500 lbs.
(1588 kg)
Trailer without brakes ________________ Max. 1000 lbs.
(450 kg)
Recommended towball load ___________ 110–165 lbs.
(50–75 kg)
See also page 190.
Maximum theoretical towing speed, trailer
with brakes _______________________ 60 mph (100 km/h)
Maximum theoretical towing speed, trailer
without brakes ____________________National restrictions
apply
When towing a trailer, increase the pressure
of the rear tires by 20 kPa (3 psi).
The above speed and weight restrictions are those specified by
Saab Automobile AB.
Note that national restrictions may apply to trailer speeds and
weights (see page 188).
93_U S _M 07.book Page 282 W ednesday, April 12, 2006 9:30 AM
