2007 SAAB 9-3 engine

285 Technical data
Fuel
Extra engine oil additives.
Don't add anything to your oil. The recommended oils are all
you will need for good engine performance and protection.
When to change engine oil.
Your vehicle has a display (SID) where time for service will be
shown. Based not only on mileage but also on driving condi-
tions the mileage at which a service will be indicated can vary
considerably.
For this service system to work it is of outmost importance that
the right engine oil is used.
When the message for service is displayed you need to have
the required service done as soon as possible.
After the service your service personnel will reset the service in-
dicator. It is important to reset the service indicator in order to
optimize the time to the next service.
Oil capacity, including filter (oil change)
4-cyl engine ______________________ 6.3 qts. (6.0 l)
V6 engine ________________________ 6.3 qts. (6.0 l)Fuel tank capacity ________________ 16.05 U.S. gal. (61 l)
For optimum performance Saab recom-
mends: _______________________Gasoline engines –
AON 90.
Gasoline with a lower octane rating can be used, although not
lower than AON 87. However, engine performance will fall
slightly and heavy loading and laboring should be avoided. For
optimum performance, use the recommended grade of fuel.
For further information on fuel, see page 159.93_U S _M 07.book Page 285 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

286 Technical dataEngines Electrical system2.0T EcopowerRating, EEC at 5300 rpm ____________ 210 hp (155 kW)
Maximum torque, EEC at 2500-4000 rpm 221 ft.lb. (300 Nm)
Compression ratio__________________ 9.5:12.8 V6 (250) EcopowerRating, EEC at 5500 rpm ____________ 250 hp (184 kW)
Maximum torque, EEC at 1800-4500 rpm 257 ft.lb. (350 Nm)
Compression ratio__________________ 10.0:1Voltage ___________________________ 12 V
Battery capacity ____________________ 60 Ah
Starter motor:
4-cyl engine ______________________ 1.8 kW
V6 engine ________________________ 1.4 kW
Alternator rating:
4-cyl engine with manual gearbox _____ 120 A/14 V
4-cyl engine with automatic gearbox ___ 140 A/14 V
V6 engine ________________________ 155 A/14 V
Firing order ________________________
4-cyl engine ______________________ 1-3-4-2
V6 engine ________________________ 1-2-3-4-5-6
Spark plugs:
4-cyl engine
Type ____________________________ NGK PFR6T-10G
Electrode gap _____________________ 0.9–1.0 mm
Tightening torque __________________ 20 ft.lb. (28 Nm)
V6 engine
Type ____________________________ PLFR6C 10G
Electrode gap _____________________ 0.9–1.0 mm
Tightening torque __________________ 20 ft.lb. (28 Nm)
93_U S _M 07.book Page 286 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

287 Technical data
Drive belt Manual transmissionOutside length ______________________
4-cyl engine ______________________ 40.472'' (1028 mm)
V6 engine ________________________ 83.463'' (2120 mm)Drive belt, 4-cyl engine Drive belt, V6 engine
Type _____________________________ Fully synchronized
with final drive gear
and differential
Oil type (for topping up)_______________ Saab MTF 0063
Oil capacity:
5-speed _________________________ 1.9 qts. (1.8 l), to
level plug
6-speed, 2.8 V6 ___________________ 3.15 qts. (3.0 l)
Speed, mph (km/h) at 1000 rpm in highest
gear (5th gear) ____________________ 27–30 (43–48)
Speed, mph (km/h) at 1000 rpm in highest
gear (6th gear) ____________________ 29–35 (46–56)
93_U S _M 07.book Page 287 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

291 Technical data
Recommended tire/engine combinationsRF/XL = Reinforced (or Extra Load) tire.
NOTICESnow chains:
Snow chains must not be fitted to the rear wheels, and may only
be used with the following wheel-tire combinations:
Wheels Tires
6.5 x 16"_______ 215/55 R16 M+S or
215/55 R16
Contact your Saab dealer regarding suitable snow chains.
Max. permissible speed with snow chains fitted is 30 mph
(50 km/h).
Snow chains must not be fitted to wheels larger than 16".NOTICEWheels larger than 17" must not be fitted for reasons stated on
page 245.
Exercise care when driving on uneven roads or against the curb
if the car is heavily laden. This particularly applies to cars with
17" wheels.
Permitted wheel offset is 41 mm.
2.0 Turbo V6 engine
All season tires
215/55 R16 97 H RF/XL x –
235/45 R17 94 V x x
Summer tires
235/45 R17 94 W – x
Winter (snow) tires
215/55 R16 93 Q x x
235/45 R17 94 Q x x
Wheel sizes
6.5 x 16" x –
7.5 x 17" x x
93_U S _M 07.book Page 291 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

293 Technical data
Plates and labelsWhen contacting your Saab dealer it may
sometimes be necessary to quote the car’s
vehicle identification, engine and gearbox
numbers.
1 V.I.N. number and barcode, inside wind-
shield
2 Gearbox number
3 Engine number
4USA: Label for color codes (trim and
body). Tire information label can be found
on the B-pillar. See also page 251.
Canada: Label for tire pressure and color
codes (trim and body)
5 Certification label
6 Chassis number (stamped on body).93_U S _M 07.book Page 293 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

294 Technical data1 Region ________Y = Nor thern Europe
2 Country _______S = Sweden
3 Manufacturer ___3 = Saab Automobile AB
4 Product line ____F = 9-3
5 Model series ___B = 9-3 Linear
D = 9-3 Arc
F = 9-3 Aero6 Body version ___4 = 4-door
7 = Convertible
5 = 5-door
7 Gearbox _______5 = 5-speed manual
6 = 6-speed manual
9 = 5-speed automatic
1 = 6-speed automatic
8 Engine variant __Y = 2.0 Turbo
U = V6 engine
9 Check digit _____0-9 or X
10 Model year ____7 = 2007
11 Factory _______1 = Trollhättan
6 = Graz
12 Serial number __000001-999999
Position: 1234567891011 12
||||||||| | | |
Vehicle identifi-
cation number:Y S 3 F D 4 9 Y X 7 1 016584
| |||||
1 2 3 4 5 6 = identification codes for certain chassis components
93_U S _M 07.book Page 294 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

296 Technical dataWarning and indications that can
be shown on the SIDWhich warnings and indications that can be
shown depends on engine variant and car
specification.
Symbol Text
Antilock brake malfunc.
Contact service.
Brake malfunction.
Make a safe stop.
Brake fluid level low.
Make a safe stop.
Release park brake.
Oil pressure low.
Make a safe stop.
Low engine oil level.
Fill oil now.
Reduced engine power.
Contact service.
Limited performance.
Coolant level low.
Refill.
Hot engine. Make a
safe stop. Idle engine.
Airbag malfunction.
Contact service.
Gearbox malfunction.
Limited performance.
Gearbox too hot. Make a
safe stop. Open hood.
Battery not charging.
Make a safe stop.
Headlight levelling
malfunction.
Tap brakes lightly
before using cruise ctrl.
Traction control failure.
Contact service.
Stability control failure.
Contact service.
Washer fluid level low.
Refill.
Key not accepted.
Contact service.
Remote control battery
low. Replace battery.
Number of keys:
Active key number:
Steering lock malfunc.
Make a safe stop.
Pull out key, turn
steering wheel. Restart.
Theft protection failure.
Contact service.
Alarm tripped during
last arming period.
Rear left seat
backrest unlocked.
Rear right seat
backrest unlocked.
Parking assistance
malfunction. Service.
Parking assistance
sensor interference.
93_U S _M 07.book Page 296 W ednesday, April 12, 2006 9:30 AM
ProCarManuals.com

299 Index
Index
AABS brakes
____________________ 173
ACC
_________________________ 107
Adjustment, steering wheel
________ 120
Air filter
_______________________ 211
Airbag
_________________________ 32
Anchorage eyes, Sport Sedan
_____ 141
Anti-corrosion treatment
__________ 267
Antilock braking system __________ 173
Anti-spin
______________________ 175
Ashtrays ______________________ 136
Autochecking of lights, warning and
indicator lights
__________________ 89
Autodimming
_______________ 125
, 126
Automatic climate control (ACC)
____ 107
Automatic closing of moonroof
_____ 131
Automatic closing of windows,
Sport Sedan and SportCombi _____ 122
Automatic transmission
___________ 165
BBattery
_______________________ 215
Bedding-in of new brake pads
_____ 163
Before towing a trailer
____________ 193
Belt height, Sport Sedan and
SportCombi
____________________ 14
Brake fluid, grade
_______________ 289Brakes
________________________ 172
Braking _______________________ 172
Bulb changing
__________________ 221
Bulb table
_____________________ 235
Buying new tires
________________ 246
CCabin lighting, Convertible
_________ 80
Cabin lighting, Sport Sedan and
SportCombi
___________________ 133
Calibrating front electric windows
with pinch protection
_____________ 80
Calibration of windows, Sport Sedan
and SportCombi
_______________ 123
Car alarm
______________________ 58
Car transport ___________________ 199
Care of air conditioning
___________ 270
Cargo guard
___________________ 150
Cargo guard, SportWagon
________ 150
Cargo net, SportCombi
___________ 147
Change of address notification
_____ 276
Changing a tire
_________________ 259
Changing bulbs _________________ 221
Changing the battery, remote control
_56
Changing wiper blades
___________ 219
Checking the number of remote
controls
_______________________ 55
Checks before towing a trailer
_____ 193
Child safety
_____________________ 24
Child safety locks, rear doors
_______ 54
Child seats
_____________________ 24Cigarette lighter
_________________ 136
Cleaning the engine bay
__________ 263
Cleaning upholstery
______________ 262
Closing the soft top manually,
Convertible
____________________ 70
Closing the soft top, Convertible
_____ 66
Clutch interlock
_________________ 164
Comfort opening of moonroof
______ 131
Comfort opening of windows,
Sport Sedan and SportCombi _____ 121
Compact spare
_________________ 256
Compact spare wheel fitted, driving
with
_________________________ 257
Compass
______________________ 129
Convertible _____________________ 63
Convertible, washing
_____________ 264
Coolant
_______________________ 211
Crash memory, see EDR
_________ 278
Cruise control
__________________ 171
Cup holder
_____________________ 134
DDate codes, tires
________________ 256
Deactivating rear windows,
Sport Sedan and SportCombi
_____ 123
Deactivating the passenger door
window button, Convertible
________ 79
Deactivating the rear window
switches
_____________________ 123
Deep water, driving through
_______ 196
Definitions and terminology, tire ____ 253
