2007 PORSCHE CAYMAN Central Locking System

Unlocking
Presstherocker-switch.Indicatorlightgoesout.
Ifthedoorswerelockedwiththecentrallockingswitch,theycanbeopenedbypullingtheinnerdoorhandle:
1.Pullinnerdoorhandleoncetounlockdoorlock.
2.Pullinnerdoorhandleagaintoopendoor.
Automaticdoorlocking
YourauthorizedPorschedealercanprogramdiversetypesofautomaticdoorlockinginthecontrolunitofthecentrallockingsystem.
Type1
Doorslockautomaticallywhentheignitionisswitchedon.
Type2
Doorslockautomaticallywhenaspeedof3-6mph(5-10km/h)isexceeded.
Type3
Doorslockautomaticallywhentheignitionisswitchedon.Ifdoorsareopenedwiththeenginerunning,theylockagainautomaticallywhenaspeedof3-6mph(5-10km/h)isexceeded.
Type4
Thedoorsdonotlockautomatically.
Note
Automaticallylockeddoorscanbeunlockedwiththecentrallockingbuttonoropenedbypullingontheinsidedoorhandletwice.
OnvehicleswiththeSportChronoPackagePlus,thePCMcanbeusedtoactivateautomaticdoorlocking.
Pleaseobservethechapter“IndividualMemory”intheseparatePCMoperatinginstructions.
Warning!
Inanemergencysituationwhereyouneedtoexitthecarthroughanautomaticallylockeddoor,rememberthefollowingproceduretoopenthedoor.
Unlockthedoorsbypressingthecentrallockingbuttonor
pulltheinsidedoorhandletwicetoopenthedoor.
Faultindication
Adoublehornsignalduringlockingindicatesadefectinthecentrallockingoralarmsystem.HavethedefectremediedatanauthorizedPorschedealer.
Overloadprotection
Ifthecentrallockingsystemisoperatedmorethantentimeswithinaminute,furtheroperationisblockedfor30seconds.
30Controls,Instruments

A-Light-emittingdiodeforalarmsystem
AlarmSystem,Passenger
CompartmentMonitoring
Readinessforoperation
Thisdevicecomplieswith:Part15oftheFCCRulesRSS-210ofIndustryCanada.
Operationissubjecttothefollowingtwocondi-tions:
1.Thisdevicemaynotcauseharmfulinterfer-ence,and
2.thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.
Note
ThemanufacturerisnotresponsibleforanyradioorTVinterferencecausedbyunauthorizedmodificationstothisequipment.Suchmodificationcouldvoidtheuser’sauthoritytooperatetheequipment.
Warning!
AnychangesormodificationsnotexpresslyapprovedbyPorschecouldvoidtheuser’sauthoritytooperatethisequipment.
Thealarmsystemandpassengercompartmentmonitoringsystemareswitchedonwhenthedoorsarelockedwiththekeyorremotecontrol.
Pleaseobservethechapter”CENTRALLOCKINGINCARSWITHALARMSYSTEM”onpage28.
Unlockingthevehiclebyusingthekeyinthedoorlockandopeningthedoormayactivatethealarmsystemwithin10seconds.
Switchingoffthealarmsystemifitis
triggeredaccidentally
Unlockthevehiclewiththeremotecontrol.
Thealarmsystemandpassengercompartmentmonitoringsystemareswitchedoffautomaticallywhenthedoorsareunlocked.
Functionindication
Ifthealarmsystemisactivated,light-emittingdiodeAonthedashboardflashes.
If,afterlocking,thelight-emittingdiodedoesnotflashor,aftertenseconds,itemitsdoubleflashes,thennotallalarmcontactsareclosed.Additionally,abriefhornsignalsounds.
Whenthedoorsareunlocked,thealarmsystemandpassengercompartmentmonitoringsystemareswitchedoffandthelight-emittingdiodegoesoff.
Whenthealarmisarmed,thefollowing
areasaremonitored
–Doors
–Frontandrearlids
–Glovecompartment
–Passengercompartment
Ifoneofthesealarmcontactsisinterrupted,thealarmhornsoundsforapproximately3minutes.Additionally,theemergencyflasherandthepas-sengercompartmentlightflashforapproximatelyfourminutes.Whenthealarmistriggered,thelight-emittingdiodechangesovertodoubleflash-es.
32Controls,Instruments

Inordernottolimittheactionrangeofthepassen-gercompartmentmonitoringsystem:
Donotfoldthebackrestsforward.
Deactivatingthepassengercompartment
monitoringsystemforonelockingprocess
Ifapersonoranimalremainsinthecarwhileitislocked,thepassengercompartmentmonitoringsystemmustbeswitchedoff.
Quicklylockcartwice.Thedoorsarelockedbutcanbeopenedfromtheinside:
1.Pullinnerdoorhandleoncetounlockdoorlock.
2.Pullinnerdoorhandleagaintoopendoor.
Note
Informanypersonremaininginthecarthatthealarmsystemwillbetriggeredifthedoorisopened.
Faultindication
Adoublehornsignalduringlockingindicatesadefectinthecentrallockingoralarmsystem.
HavethedefectremediedatanauthorizedPorschedealer.
Controls,Instruments33

Danger!
Riskofseriouspersonalinjuryordeathtothechild,whenexcessiveforceisactingonthepassenger’sseatduetotheseatbelt.Insuchcases,thepassenger’sairbagcanbeswitchedonunintentionally.
Afterfasteningthechildrestraintsystem,donotadjusttheseat.
Checktheconditionofthepassenger’sairbagsystemshownbytheindicatorlampinthecentralconsole.
Activatingtheautomaticlockingretractor
1.Ifachildrestraintsystemmustbefastenedtothepassenger’sseat,adjustthepassenger’sseatasfarawayfromtheairbagaspossible.
2.Fastenchildseat.
3.Pullthesafetybeltretractorcompletelyout.Atthispointthelockingmechanismisactivated.
4.Insertthesafetybelttongueintothebuckleandmakecertainthatitisproperlylatched.Makenomoreadjustmentstotheseat.
5.Allowthesafetybelttoretractuntilitistightonthechildrestraintsystem.Youmayfurthertightenthebeltbypullingonittoallowmoreofittoretract.Makesurethatexcessiveseatbeltforcesdonotoccurbymovingtheseatwiththechildseatinstalled.
Releasingthesafetybelt
1.Unbucklethesafetybeltlatch.
2.Thenmakecertainthatthebelthasfullyretracted.Atthispointtheautomaticlockingfeaturewillbedisengaged.SeekappropriateadvicefromyourauthorizedPorschedealeraboutthepossibleinstallationofaPorschechildrestraintsystem.
Controls,Instruments61

Operation,Instruments
Overviewofthefunctions
1Lightswitch2Turnsignals/headlightdimmer/asherlever3Ignitionlock/lockingthesteeringcolumn4Hands-freemicrophonefortelephone5Horn6Windshieldwiper/washerlever,Rearwindowwiper
7PorscheCommunicationManagement/Radio8Interiortemperaturesensor,GPSantenna9Emergencyasherswitch10Centrallockingbutton,Readinessdisplayforalarmsystem11Cupholder12Operatingleverforon-boardcomputer13Lockingleverforsteering-wheeladjustment
14Operatingleverforcruisecontrol15Controlpanelforheating,ventilationandairconditioningsystem16Buttonsforrearspoiler,PorscheActiveSuspensionManagementPASM),SportMode,PorscheStabilityManagement(PSM),Sportsexhaustsystem17Seatheating,left/right
82Controls,Instruments

ElectricalSystem
Generalinformation
Inordertoavoiddamageandfaultsinelectricalorelectronicsystems,electricalaccessoriesshouldbeinstalledatyourauthorizedPorschedealer.
OnlyuseaccessoriesauthorizedbyPorsche.
Danger!
Riskofshortcircuitandre,resultinginseriouspersonalinjuryordeath.Replacingfusesorrelayswiththeenginerunningortheignitiononcouldcauseelectricalshock.
Disconnectedthebatteryduringallworkontheelectricalsystem.
Pleaseobservethechapter”BATTERY”onpage262.
Relays
Defectiverelaysshouldbechangedonlybyanauthorizedworkshop.
Alarmsystem,centrallocking
Thestatusofthecentrallockingandalarmsystemisnotchangedbydisconnectingthebattery.Whenthebatteryisdisconnected,thealarmsystemceasestofunction.
Overloadprotection
Ifthecentrallockingsystemisoperatedmorethantentimeswithinaminute,furtheroperationisblockedfor30seconds.
Loadswitch-offafter2hoursor7days
Iftheignitionkeyisremoved,loadswhichareswitchedonorareinstandbymode(suchastheluggagecompartmentlight,interiorlightandradio)areautomaticallyswitchedoffafterapprox.2hours.
Ifthevehicleisnotstartedorunlockedwiththeremotecontrolwithin7days,theremotecontrolstandbyfunctionisswitchedoff(tosavethevehiclebattery).
1.Inthiscase,unlockthedriver’sdoorwiththekeyatthedoorlock.Leavethedoorclosedinordertopreventthealarmsystemfrombeingtriggered.
2.Pressbutton1ontheremotecontrol.
Theremotecontrolisnowactivatedagain.
A-Diagnosticsocket
Replacingfuses
Inordertopreventdamagetotheelectricalsystemduetoshortcircuitsandoverloads,theindividualcircuitsareprotectedbyfuses.Thefuseboxislocatedinthedriver’sfootwell.
PracticalTips,EmergencyService259
