2007 PORSCHE BOXSTER sensor

A-SeatheatingB-DefrostingthewindshieldC-Recirculating-airbuttonD-TemperaturesensorE-ECObutton(air-conditioningcompressoroff/on)F-HeatedrearwindowG-TemperaturebuttonH-ACmaxI-AirdistributiontofootwellJ-AirdistributiontocentralandsideventsK-AirdistributiontowindshieldL-Blowerspeedbutton
Airconditioning
Thedisplaypanelshowsthefollowing
Airquantity,airdistribution,andtemperaturecanbesetonthecontrolpanel.
–Temperature
–Air-conditioningcompressoron/off
–Blowerspeed
–ACmax
–Airdistribution
Settingtemperature
PressbuttonGupwardsordownwardsrespectively.
Theselectedtemperatureisshownonthedisplaybyabardisplay.
Ifabarcannotbeseen,thetemperatureissettomaximumcold.
Ifallbarscanbeseen,thetemperatureissettomaximumwarm.
Note
Formaximumcooling,activateACmaxbuttonH.
Adjustingblowerspeed
PressbuttonLupwardsordownwardsrespectively.
Theblowerspeedisshownonthedisplaybyabardisplay.
Thecompressorisswitchedoffatlowblowerspeeds.
152Controls,Instruments

A-Seatheating,leftB-DefrostingthewindshieldC-Recirculating-airbuttonD-TemperaturesensorE-ECObutton(air-conditioningcompressoroff/on)F-Heatedrearwindow/doormirrorheatingG-Seatheater,rightH-TemperaturebuttonI-AUTObutton(automaticmode)J-AirdistributiontofootwellK-AirdistributiontocentralandsideventsL-AirdistributiontowindshieldM-Blowerspeedbutton
Automaticairconditioningsystem
Automaticmode
Theautomaticair-conditioningsystemcontrolsthepreselectedinteriortemperaturecompletelyautomatically.Ifnecessary,theautomaticsystemcanbemanuallyinfluenced.
PressAUTObuttonI.AUTOwillappearonthedisplaypanel.Airquantityanddistributionareautomaticallycontrolledandvariationsarecompensated.
Allautomaticsettingfunctionscanbeindividuallychanged.Thissettingisretaineduntiltheappropri-atefunctionbuttonispressedagainortheAUTObuttonispressed.
Settingtemperature
PressbuttonHupwardsordownwardsrespectively.
Tosuitpersonalcomfort,theinteriortem-peraturecanbeadjustedbetween61°Fand85°F/16°Cand29.5°C.
Recommendation:72F/22C.
If“LO”or“HI”appearsonthedisplay,thesystemisoperatingatmaximumcoolingorheatingpower.Automaticcontrolisnolongeractive.
Controls,Instruments155

Note
Ifthepreselectedtemperatureischanged,theblowerspeedcanincreaseautomaticallyinautomaticmode.Thedesiredtemperatureisreachedmorequicklythisway.
Sensors
Toavoidaffectingtheperformanceoftheair-condi-tioningsystem:
DonotcoverthesunsensorontheinstrumentpanelorthetemperaturesensorD.
Defrostingthewindshield
PressbuttonB(switchonoroff).Thewind-shieldisdemistedordefrostedasquicklyaspossible.Airflowstothewindshieldonly.Thelight-emittingdiodeinthebuttonlightsup.
ECO-switchingcompressorfor
air-conditioningsystemonandoff
Theairconditioningcompressorswitchesoffautomaticallyattemperaturesbelowapprox.37°F/3°Candcannotbeswitchedon,evenmanually.
Wheneveroutsidetemperaturesexceedapprox.37°F/3°C,theair-conditioningcompressorisalwaysswitchedoninautomaticmode.
Thecompressorcanbeswitchedoffmanuallytosavefuel,butcontrolcomfortisthenlimited:
PressECObuttonE.Thecompressorisswitchedoff.Thelight-emittingdiodeinthebuttonlightsup.
Iftheinteriortemperatureistoohigh,switchcompressorbackonorpressAUTObutton.
Todryincomingairindampweather,donotswitchofftheair-conditioningcompressor.Thispreventsmistingofwindows.
Adjustingblowerspeed
PressbuttonMupwardsordownwardsrespectively.Thepresetblowerspeedisincreasedordecreased.
Thespeedstagesareindicatedbyabardisplay.
Thecompressorisswitchedoffatlowblowerspeeds.
Ifthebuttonispresseddownwardsatthelowestblowerstage,theblowerandautomaticcontrolareswitchedoff.“OFF”willappearonthedisplayfield.
PressingthebuttonupwardsorpressingtheAUTObuttonswitchestheblowerandautomaticcontrolbackonagain.
Recirculating-airsetting
Function
Theoutside-airsupplyisinterruptedandonlytheinsideairiscirculated.
Warning!
Riskofaccidentduetoimpairedvision,resultinginseriouspersonalinjuryordeath.Inrecirculating-airsetting,thewindowsmayfogup.
Onlyselectrecirculating-airsettingforshortperiods.
Ifthewindowsfogup,switchrecirculating-airsettingoffimmediatelybypressingtherecirculating-airbuttonagainandselectthe“Defrostwindshield”function.
Switchingrecirculating-airsettingonoroff
PressbuttonC.Thelight-emittingdiodeinthebuttonlightsup.
Overapprox.37°F/3°C
Iftheair-conditioningcompressorwasoff,itswitchesonautomatically.Thedurationofrecirculating-airsettingisnotlimited.
156Controls,Instruments

HowEmissionControlWorks
Whenanautomobileengineisrunning,itusesenergygeneratedthroughthecombustionofamixtureofairandfuel.Dependingonwhetheracarisdrivenfastorslowlyorwhethertheengineiscoldorhot,someofthefuel(hydrocarbons)maynotbeburnedcompletely,butmaybedischargedintotheenginecrankcaseorexhaustsystem.Additionalhydrocarbonsmayentertheatmospherethroughevaporationoffuelfromthefueltank.Thesehydrocarbons(HC),whenreleasedintotheair,contributetoundesirablepollution.
Inaddition,carbonmonoxide(CO)andoxidesofnitrogen(NOx)contributetoengineemissions.They,too,areformedduringthecombustionprocessanddischargedintotheexhaustsystem.
Toreducethesepollutants,yourPorscheisequippedwithapreciselycalibratedfuelinjectionsystemtoassureafinelybalancedair/fuelmixtureunderalloperatingconditions.
Oxygensensor
Theoxygensensor,installedintheexhaustpipecontinuouslysensestheoxygencontentoftheexhaustandsignalstheinformationtoanelectroniccontrolunit.Thecontrolunitcorrectstheair/fuelratio,sotheenginealwaysreceivesanaccuratelymeteredair/fuelmixture.
Crankcaseventilation
Throughcrankcaseventilation,undesirableemissionsfromtheenginecrankcasearenotpermittedtoreachtheoutsideatmosphere.Theseemissionsarerecirculatedfromthecrankcasetotheairintakesystem.Fromheretheemissionsmixwiththeintakeairandarelaterburnedintheengine.
Catalyticconverters
Thecatalyticconvertersareefficient”clean-up“devicesbuiltintotheexhaustsystemofthevehicle.Thecatalyticconvertersburntheundesirablepollutantsintheexhaustgasbeforeitisreleasedintotheatmosphere.
Theexclusiveuseofunleadedfueliscriticallyimportantforthelifeofthecatalyticconvert-ers.Therefore,onlyunleadedfuelmustbeused.
Thecatalyticconverterswillbedamagedby:
–pushortowstartingthevehicle,
–misfiringoftheengine,
–turningofftheignitionwhilethevehicleismovingor
–drivinguntilthefueltankiscompletelyempty,
–byotherunusualoperatingconditions.
Donotcontinuetooperateyourvehicleundertheseconditions,sincerawfuelmightreachthecatalyticconverters.Thiscouldresultinoverheatingoftheconverters.Federallawprohibitsuseofleadedfuelinthiscar.
226Maintenance,CarCare

damagedbydesignfeatures(e.g.brushes)ofautomaticcarwashes.
Thefollowingpartsareparticularlysuscepti-bletodamage:
–Convertibletop(hotwaxtreatmentcannotbeused,asthewaxattackstheconvertibletopmaterial),
–Windshieldwipers(alwaysswitchthemofftopreventthemwipingunintentionallyinintermittentorsensoroperation)
–Externaltelephoneantenna(alwaysunscrew)
–Fixedrearspoilerorextendedrearspoiler
–Wheels(thewidertherimandthelowerthetireheight,thegreatertheriskofdamage)
–High-glosswheels(topreventthesefromgettingscratched,donotcleanwiththewheel-cleaningbrushesofthecarwash).
Pleaseconsulttheoperatorbeforeusingautomaticcarwashes.
Washanddrybyhandallpointsnotreachedbyacarwash,suchasdoorandlidseamsordoorsills.
Note
Automaticcarwashesspraywateratoddanglesandhighpressures,whicharenotseeninnormaldriving.Therefore,watercansometimesfinditswayintothepassengerscompartmentduringorshortlyafterthecarwash.
Doorlocks
Topreventthedoorlocksfromfreezingduringthecoldseason,thelockcylindersshouldbecoveredduringawash.
Shouldthelocksfreeze,useanordinaryde-icer.Inmanycases,awellwarmedkeycanhelp.Neveruseexcessiveforce.
Paint
Neverrubadustycarwithadryclothsincedustparticlesareabrasiveandcoulddullanddamagethesurfacefinish.
Thepaintworkofyourcarisexposedtoalltypesofmechanicalandchemicalconditions,particularlyclimaticonessuchasbrightsunlight,rain,frostandsnow.Ultravioletlight,rapidchangesintemperature,rain,snow,industrialdustandchemicaldepositsconstantlyattackthepaintwhichisonlyabletowithstandsuchexposureinthelongtermifitisgivenregularcareandattention.
Donotapplysiliconepolishestothewind-shield,windowsorconvertibletop.
Donottreatmatt-paintedcomponentswithpreservativesorpolishesasthiswillspoilthematteeffect.
Preservation
Thepaintsurfacebecomesdullovertimeduetoweathering.Itisthereforenecessarytopreservethepaintregularly.
Thiskeepsthepaintshinyandelastic.Dirtispreventedfromadheringtothepaintsurfaceandindustrialdustispreventedfrompenetratingthepaint.
Provideditiswashedandtreatedwithpreservativeregularly,thebrandnewfinishofyourvehiclewillberetainedforyearstocome.
Maintenance,CarCare235
